CTC Union IGS-803SM-8PH24 User manual

Installation
The switch comes with both wall mount and DIN rail hardware
brackets. When installing the DIN rail bracket, be sure to correctly
align the orientation pin.
Figure 8. DIN Rail Figure 9. Wall Mount
The switch with DIN Rail bracket has a steel spring in the upper
rail of the bracket. This spring is compressed for mounting and
un-mounting by applying downward force.
Figure 10. Mounting Figure 11.Un-mounting
Introduction
IGS-803SM-8PH(E)24 are managed industrial grade Gigabit PoE
(Power over Ethernet) switches that provide stable and reliable
Ethernet transmission. Housed in rugged DIN rail or wall
mountable enclosures, these switches are designed for harsh
environments, such as industrial networking and intelligent
transportation systems (ITS) and are also suitable for many
military and utility market applications where environmental
conditions exceed commercial product specifications. Standard
operating temperature range models (-10°C to 60°C) and wide
operating temperature range models (-40°C to 75°C) fulfill the
special needs of industrial automation applications.
Features
Redundant dual DC inputs 24/48VDC
DCV 'boost' feature; regulated 55VDC PoE output voltage
IP30 rugged metal housing
Wide temperature range -40°C ~75°C (IGS-803SM-8PHE24)
Supports many advanced Ethernet L2 functions
Console, Telnet (ssh), Web and SNMP management
Industrial grade EMS, EMI; UL60950-1, EN50121-4,
EN61000-6-2, EN61000-6-4
Specifications
Ethernet Interface
Standards: IEEE802.3 (10Base-T), 802.3u (100Base-TX),
802.3ab (1000Base-T)
RJ-45 (shielded) Ports: 8 ports
Speed: 10/100/1000M (Auto)
Optical Interface
Standards: IEEE802.3u (100Base-FX), 802.3z (1000Base-X),
802.3ab (1000Base-T)
3 ports, SFP based
Speed: 100/1000M (Manual)
Switch Features
Store & Forward Switch
Supports IEEE802.3x Flow Control
Auto MDI/MDI-X
Duplex: Full/Half (Auto-negotiation per IEEE802.3u)
Switching Fabric: 22Gbps (Non-blocking)
Packet Buffer: 1Mb
MAC Table: 8K
MTU: 64~9600 bytes
Quick Installation Guide
IGS-803SM-8PH24
IGS-803SM-8PHE24
Industrial Grade Managed Gigabit Ethernet PoE Switches
Specifications (cont.)
Power over Ethernet
8 PoE enabled ports, Alternate A Mode
Supports IEEE802.3af 15.4watts PoE per port
Supports IEEE802.3at 30watts PoE+ per port (180W budget)
Positive (VCC+) pins 1,2 (55VDC); Negative (VCC-) pins 3,6
Power
Absolute Input Range: 20VDC~57VDC
Reverse Polarity Protection: Yes
Dual Power Inputs: Yes
Connector: Removable terminal block
Consumption:
Items
Input Voltage
Total Power
Consumption
Device Power
Consumption
PoE Budget
Boost
Efficiency
24VDC
200.2W
9.2W
180W
94%
48VDC
195.1W
9.8W
180W
97%
Mechanical
Water & Dust Proof: IP30 Protection
Dimensions: 116 mm (D) x 64 mm (W) x 152 mm (H)
Mounting: DIN-Rail, Wall Mount (Kits included)
Weight: 970 g
Environmental
Operating Temperature : -10°C~60°C (IGS-803SM-8PH24)
-40°C~75°C (IGS-803SM-8PHE24)
Storage Temperature: -40°C~85°C
Humidity: 5%~95% (Non-condensing)
Certifications
EMC: CE
EMI (Electromagnetic Interference): FCC, FCC Part 15 Subpart
B Class A, CE EN55022 Class A
Railway Traffic: EN50121-4
Immunity for Heavy Industrial Environment: EN61000-6-2
Emission for Heavy Industrial Environment: EN61000-6-4
EMS (Electromagnetic Susceptibility) Protection Level:
EN61000-4-2 (ESD) Level 3, Criteria B
EN61000-4-3 (RS) Level 3, Criteria A
EN61000-4-4 (Burst) Level 3, Criteria A
EN61000-4-5 (Surge) Level 3, Criteria B
EN61000-4-6 (CS) Level 3, Criteria A
EN61000-4-8 (PFMF, Magnetic Field) Field Strength:
300A/m, Criteria A
Safety: UL60950-1 ●Shock: EN60068-2-27
Freefall: EN60068-2-32 ●Vibration: EN60068-2-6
MTBF: 311,276 hours (MIL-HDBK-217)
[email protected]
V1.2
- 1 -
- 2 -
To download this QIG or a more complete user manual, please visit
http://www.ctcu.com/Industrial/
T+886-2-26591021
F+886-2-26590237
[e-mail]
CTC Union Technologies Co., Ltd.
Far Eastern Vienna Technology Center
(Neihu Technology Park)
8F, No. 60 Zhouzi St., Neihu District, Taipei 114
Taiwan
© 2014 CTC Union Technologies Co., Ltd.
All trademarks are the property of their respective owners.
Technical information in this document is subject to change without notice.
- 7 -
www.ctcu.com
