Introduction
IFS‐500/800modelsare5/8‐port10/100Base‐T(X)Ethernet
switchesthatprovidestableandreliableEthernettransmission.
HousedinruggedDINrailorwallmountableenclosures,these
switchesaredesignedforharshenvironments,suchasindustrial
networkingandintelligenttransportationsystems(ITS)andare
alsosuitableformanymilitaryandutilitymarketapplications
whereenvironmentalconditionsexceedcommercialproduct
specifications.Standardoperatingtemperaturerangemodels(0
to60°C)andwideoperatingtemperaturerangemodels(‐40to
75°C)fulfillthespecialneedsofindustrialautomation
applications.

Features
•RedundantdualDCinputs12/24/48VDC
•IP30ruggedmetalhousing
•Widetemperaturerange‐40~75C(500‐E,800‐E)
•IndustrialgradeEMScertification
•DIPswitchenable/disablebroadcaststormfilter
•UL508,CE,FCC,EN50121‐4Railtraffic

Specifications
EthernetInterface
•Connector:RJ‐45(shielded)
•IFS‐500;5‐ports/IFS‐800;8‐ports
•AutoMDI/MDI‐X
•Speed:10/100Base‐TX(Autoper802.3u)
•Duplex:Full/Half(Autoper802.3u)
•SupportsIEEE802.3xFlowControl
•Store&ForwardSwitch
•SwitchingFabric:1Gbps(IFS‐500),1.6Gbps(IFS‐800)
•Packetbuffer:448kb
•Packetsize:64~1536bytes
•Standards:IEEE802.3,802.3u,802.3x
•2KMACtable
•MTU:64~1536bytes
•BroadcastStormprotection







QuickInstallationGuide


IFS‐500
IFS‐500‐E
IFS‐800
IFS‐800‐E
IndustrialGradeFastEthernetSwitches





















TodownloadthisQIGoramorecompleteusermanual,pleasevisit
http://www.ctcu.com/Industrial/




[email protected]




Specifications(cont.)
Power
•Absoluterange:9.6~60VDC
•Reversepolarityprotection:Yes
•Dualpowerinputs:Yes
•Connector:terminalblock
•Consumption:
IFS‐500‐0.06A@48VDC,2.88watts
IFS‐800‐0.08A@48VDC,3.84watts

Mechanical
•Water&DustProof:IP30Protection
•Dimensions:106x39x142mm(DxWxH)
•Mounting:DIN‐Rail,WallMount(kitsincluded)
•Weight:620g(500)/625g(800)

Environmental
•OperatingTemperature:
•0°C~60°C,‐40°C~75°C(widetemp.for*‐E)
•StorageTemperature:‐40°C~85°C
•Humidity:5~95%(non‐condensing)

Certifications
•EMI:FCCPart15subBclassA,EN55022ClassA
•EMS:(ElectomagneticSusceptibility)
•EN61000‐4‐2(ESD)Level3,CriteriaB
•EN61000‐4‐3(RS)Level3,CriteriaA
•EN61000‐4‐4(Burst)Level3,CriteriaA
•EN61000‐4‐5(Surge)Level3,CriteriaB
•EN61000‐4‐6(CS)Level3,CriteriaA
•EN61000‐4‐8(MagneticField)Level3,CriteriaA
•Safety:UL508(pending)
•RailwayTraffic:EN50121‐4
•Shock:EN60068‐2‐27Freefall:EN60068‐2‐32
•Vibration:EN60068‐2‐6
•MTBF:650473hours(IFS‐500)552587hours(IFS‐800)

[email protected]www.ctcu.comV1.0

 
 
ConnectorsInstallation
IFS‐500/800comeswithbothwallmountandDINrailhardware
brackets.WheninstallingtheDINrailbracket,besuretocorrectly
aligntheorientationpin.


 
 
 


IFS‐5005‐portFastEthernetswitch 
 
 
 
 
 
 
DINRailWallMount
 
 
IFS‐8008‐portFastEthernetswitchIFS‐500/800withDINRailbrackethasasteelspringintheupper
railofthebracket.Thisspringiscompressedformountingand
un‐mountingbyapplyingdownwardforce.

IFS‐500andIFS‐800are5and8‐portFastEthernetindustrial
switches.TheLANconnectionsusesshieldedRJ‐45whichsupport
AutoMDI/MDI‐X.



Power&Alarm

 
 
 
 
 
 
 
 
 
Aremovableterminalblockprovidesbothpowerandalarm
connections.Powercanbeprovidedthroughthedualinputsfrom
separatesources.Oneelectricalrelaycanbewiredintoanalarm
circuit.TherelayisconnectedasNormallyClosed(NC).




 
mountingun‐mounting
 
 
 
LEDIndicatorsNotes:
IFS‐500andIFS‐800haveLEDsonthefrontfacethatreportthe
conditionofpower,alarm,LANlinkandspeed.




LINK/
ACT
100

PWR2 Fault
PWR
1



PWR1:ThisgreenLEDwilllightifpowerisconnectedandactive
atthePWR1terminalconnection.

PWR2:ThisgreenLEDwilllightifpowerisconnectedandactive
atthePWR2terminalconnection.

Fault:ThisamberLEDwilllightifeitherpowerinputhasanyfault
conditionandaslongasDIPsw#1isOFF.

100:ThisyellowLEDwilllightwhentheLANconnectedspeedis
100Mandwillremainoffiftheconnectedspeedis10M.

LINK/ACT:ThisgreenLEDwilllightwhentheLANporthasalink
andwillflashwhenthereisEthernettraffic.

OperationModeSwitch
IFS‐500/800usesa2‐poleDIPswitchforconfiguration.





Eachpoleoftheswitchhasthefollowingfunctions:

1.PWRAlarm:When'On'thisswitchwilldisablealarmifthereis
apowerfailureinonesupply.Ifonlyconnectingtoasinglepower
source,placethisswitch'On'todisablethealarm.

2.BSP:When'On'thisswitchwilldisablethebroadcaststorm
protectionfeaturewhichisenabledbydefault.

