CTC Union SB202 Series User manual

SB202 Series Switch BoxSB202 Series Switch Box
4-12 Channel4-12 Channel
Product ManualProduct Manual

2
• Introduction...................................................................3
• Product Description...........................................................3
• Product Dimensions & Diagram................................................4
• Mounting Instructions .........................................................5
• Conduit Entry .................................................................6
• Grounding ....................................................................7
• Installation of Sensor / signal Input Cable ......................................8
• Post Installation Testing ..................................................... 11
• Warranty & Return Information .............................................. 13
T  C

3
I
CTC junction box solutions allow for the monitoring of remotely mounted vibration
sensors, which would be otherwise restricted to human access due to safety
considerations.
SB202 Series Switch Box Overview: 4-12 channel boxes, stainless steel
enclosure.
The SB202 Switch Box is a common cable termination point for bringing sensor
cables into a switch box for routine data collection with portable data collectors.
The SB202 4-12 Channel Stainless Steel switch box is used to convert the two-
conductor input wiring of up to 12 remotely installed sensors, proximity probes
and/or temperature probes to a switched BNC and a switched two-pin MIL spec
connector for data collection. Input wiring from each sensor is connected to
the outputs via quick-connect or screw terminal blocks. Each terminal block
includes input for positive, negative and shield. Additionally, the SB202 Switch
Box can be equipped with a multi-pin connector for interface with online systems
for continuous live readings. This connection requires a JB905-1A/2A plug.
The panel board located within the enclosure has a centrally located switch that
determines that panel’s sensor output to the BNC and two-pin MIL connectors.
Measurement location cards are located on the inside of the enclosure door to
identify each channel.
Rated for NEMA 4X (IP66), the SB202 can withstand harsh environments including
temperatures ranging from -58° to 180°F (-50° to 82°C). The box is also resistant
to hose directed fluid and corrosion. A key latch is installed on the door allowing
the box to be sealed from the elements when not in use.
Note: The SB202 Stainless Steel Switch Box is internally grounded.

4
P D
Measurement
Location Card
Two-pin MIL
Output Connector
Switch
Quick
Connect
Option
Screw
Terminal
Option
Optional Online
Expansion Jack
Input Terminal Strip Options
BNC
Output
Connector
Figure 1. Dimensions
Figure 2. Diagram
Front View Side View

5
M I
SB202 Series Switch Boxes are supplied with mounting brackets attached.
Note: if you have purchased a switch box without cable entries provided, you
should add your own entry prior to mounting the switch box. CTC does not
recommend putting holes in the top of the enclosure due to access and moisture
concerns.
CTC
Vibration
Switch Box
(Rear View)
Mounting
Brackets
0.31 in./7.95 mm
Figure 3. Mounting Bracket Placement

6
C E
If you are running conduit to your enclosure, ensure the conduit cable entry
enters from the bottom of the enclosure when mounted.
Note: To ensure moisture will not flow into the enclosure, a hole should be drilled
at the lowest point in the conduit to provide drainage for any moisture.
Correct
Figure 4. Conduit Entry for Switch Box
Incorrect
Drill Drain
Hole Here

7
G
Ensure the shield ground wire on the SB202 Series Switch Boxes is grounded to
earth ground.
A. Mounting to Earth Ground
When mounting SB202 Series Switch boxes to earth ground (such as an I-Beam),
no additional steps are necessary, as the enclosure is grounded internally.
Figure 5. Switch Box (SB202) Earth Ground

8
B. Mounting to non-grounded structure
When mounting the switch box to a non-grounded structure, ensure the shield
ground wire or customer supplied ground wire is tied to a source of earth ground.
Figure 6. Ground Wire Placement
S I
Installation of sensors/signal input cable
1. Feed blunt end through the cable entry at the bottom of the switch box.
Note: it is recommended that cables are marked on both ends.
For cord grip cable entry, take off the cord grip cover with bushing and run cable
into enclosure, hand tighten cord grip cover to base to prevent damage of cord
grip.

9
1. Strip outer jacket of cable back 1¼ in. and remove all of the shielding.
2. Separate the internal wires from the shield and twist the shield.
3. Strip red and black insulation back ¼ in.
Figure 8. Bottom View
Figure 7. Front View
Figure 9. Stripped Wire
(-)
Shield / Drain wire
(+)
4. Locate the appropriate plug, identified by channel number, remove the plug and
install the wires using a small flathead screwdriver. Push Plug back into location.
Orientation is as follows:
a. Red insulated conductor wire is connected to (+).
b. Black insulated conductor wire is connected to (-).
c. Shield drain wire is connected to ground (GND).
d. Depress selected position button to open terminal for respective wire (may
require a mini at head screwdriver).

10
5. Insert plug into the appropriate PC board connector and double check to ensure
that the cable is going to the correct channel.
6. Mark the Measurement Location Card located on the inside front cover with a
description of each measurement location.
Figure 10. Field Wiring for 2-Conductor Sensor Inputs
CH1CH2CH3CH4CH5CH6 CH7CH8CH9CH10CH11CH12
+
-
GND
+
-
GND
+
-
GND
+
-
GND
+
-
GND
+
-
GND
+
-
GND
+
-
GND
+
-
GND
+
-
GND
+
-
GND
+
-
GND
1+
1-
2+
2-
3+
3-
4+
4-
5+
5-
6+
6-
7+
7-
8+
8-
9+
9-
10+
10-
11+
11-
12+
12-
Optional
Remote
Output
Optional
Remote
Output
SENSOR #1
SENSOR #2
SENSOR #3
SENSOR #4
SENSOR #5SENSOR #6
SENSOR #7
SENSOR #8
SENSOR #9
SENSOR #10
SENSOR #11
SENSOR #12
Sensor Inputs
Red = Positive
Black = Common
Grey = Shield (Ground)
Inputs Inputs

11
P I T
The TM1018 Accelerometer Verification Meter can be used to verify cable
conductivity, sensor location and proper wiring connections. The Verification
Meter will indicate if the sensor, cable and/or junction box is in working condition.
It will also confirm bias voltage of the accelerometer, which will inform you of the
operation of the internal accelerometer amplifier.
Testing Method:
1. Utilizing two personnel, Person A will be located at the switch box, while Person
B will be located at the measurement location.
2. Once positioned, Person A will connect the TM1018 to the data collector output
to the switch box and turn the Channel Selector to the channel that corresponds
to the referenced measurement. Person A should observe a “NORMAL” LED
reading.
3. Person B disconnects the cable from the accelerometer, and the TM1018 should
respond with an “OPEN” LED. Reconnect the cable to the accelerometer, and
the TM1018 should respond with a “NORMAL” LED.
4. Repeat for each measurement location to verify that accelerometer location is
properly identified at the switch box.
Figure 11. TM1018 Accelerometer Verication Meter

12
The following LED Readout indicates the circuit integrity:
1. Green LED: Normal. Indicates proper connection and an output bias will be given,
indicating the health of the sensor (4 – 16 V indicates a healthy accelerometer).
2. Yellow LED: Open Circuit. Indicates one of the following:
a. Cable connector is not connected to accelerometer.
b. Cable is open circuit (broken or not connected @ one end).
c. Accelerometer is not functioning correctly
3. Red LED: Short Circuit. Indicates one of the following:
a. Water or contamination in the connector.
b. Reverse Wiring ((+) and (-) leads are reversed).
c. Wires in switch box or cable connector (+) & (-) are touching.

13
W  R
Warranty
All CTC products are backed by our unconditional lifetime warranty. If any CTC
product should ever fail, we will repair or replace it at no charge.
Refund
All stock products qualify for a full refund if returned in new condition within 90
days of shipment. Build to order products qualify for a 50% refund if returned in
new condition within 90 days of shipment. Custom products are quoted and built
specifically to the requirements of the customer, which may include completely
custom product designs or private labeled versions of standard products for
OEM customers. Custom products ordered are non-cancellable, non-returnable
and non-refundable.
