Cumberland Hi-Lo Flood Feeder User manual

Date: 01-01-15 PNEG-1291
Instructions
1004 East Illinois Street • Assumption, IL 62510 • 1-217-226-4421
PNEG-1291
Page 1 of 2
Printed in the U.S.A.
Copyright © 2015 by The GSI Group, LLC
www.gsiag.com CN-315800
Hi-Lo Flood Feeder
Install the Hi-Lo flood assembly by aligning the locking tabs on the assembly with the slots on the drop
tube. Insert into the drop tube and lock the tabs into place. (See Figure 1 below and Figure 7 on Page 2.)
Figure 1
Snap feed level onto feed level stand. (See Figure 2.)
Figure 2
Slide grill over drop tube. The grill should slide freely over the drop tube. Then snap feed level assembly
onto drop tube assembly. (See Figure 3.)
Figure 3
Drop tube
Hi-lo food
assembly
Feed level
stand
Feed level
Drop tube
Feed level
assembly
Grill

Page 2 of 2 PNEG-1291
Hi-Lo Flood Feeder
Snap the pan onto the bottom of the grill. (See Figure 4.)
Figure 4
The completed assembly should appear shown
in Figure 5.
Figure 5 Completed Assembly
If you have any problems, please call the
Engineering Department:
Cumberland
1004 East Illniois St.
Assumption, IL 62510
Tele: 1- 217-226-4421
Fax: [phone]
Figure 6
Figure 7
Grill
Pan
Ref # Description
ADrop Tube Extension
BLifter
Ref # Description
ALocking Tabs
B Drop Tube Extension
CLifter Tab
DLifters
