Silicon Errata for CY8CTST120, CY8CTMG120, and CY8CTMA120
This document describes the errata for the TrueTouch™devices CY8CTST120, CY8CTMA120, and
CY8CTMG120. Details include errata trigger conditions, scope of impact, available workarounds, and silicon
revision applicability. Compare this document to the device’s data sheet for a complete functional description.
Contact your local Cypress Sales Representative if you have questions.
Part Numbers Affected
Part Number
Ordering Information
CY8CTxx120
CY8CTST120-56LFXI
CY8CTST120-56LFXIT
CY8CTST120-00AXI
CY8CTMG120-56LFXI
CY8CTMG120-56LFXIT
CY8CTMG120-00AXI
CY8CTMA120-56LFXI
CY8CTMA120-56LFXIT
CY8CTMA120-00AXI
Errata Summary
The following table defines the errata applicability to available CY8CTxx120 family devices.
Items
Part Number
Silicon Revision
Fix Status
[1]. Internal Main Oscillator
(IMO) tolerance deviation at
temperature extremes
CY8CTxx120
A
Silicon fix is planned.
[2]. The DP line of the USB
interface may pulse low when
the PSoC device wakes from
sleep, causing an unexpected
wakeup of the host computer
CY8CTxx120
A
Use workaround.
[3]. Invalid Flash reads may
occur if Vdd is pulled to -0.5V
just before power on
CY8CTxx120
A
Use workaround.
[4]. PMA Index Register fails
to auto increment with
CPU_Clock set to SysClk/1
(24 MHz)
CY8CTxx120
A
Use workaround.
[+] Feedback

CY8CTST120, CY8CTMG120, CY8CTMA120
September 25, 2008 Document No. 001-49038 Rev. ** 2
1. Internal Main Oscillator (IMO) tolerance deviation at temperature extremes.
PROBLEM DEFINITION
Asynchronous digital communication interfaces may fail framing beyond 0 to 70°C. This problem does not
affect end product usage between 0 and 70°C.
PARAMETERS AFFECTED
The IMO frequency tolerance. The worst case deviation when operated below 0°C and above +70°C and
within the upper and lower data sheet temperature range is ±5%.
TRIGGER CONDITION
The asynchronous Rx/Tx clock source IMO frequency tolerance may deviate beyond the data sheet limit
of ±4% when operated beyond the temperature range of 0 to +70°C.
SCOPE OF IMPACT
This problem may affect UART, IrDA, and FSK implementations.
WORKAROUND
Implement a quartz crystal stabilized clock source on at least one end of the asynchronous digital
communications interface.
FIX STATUS
The cause of this problem and its solution has been identified. Silicon fix is planned to correct the
deficiency in silicon.
2. The DP line of the USB interface may pulse low when the PSoC® device wakes from sleep causing an
unexpected wakeup of the host computer
PROBLEM DEFINITION
When the device is operating at 4.75V to 5.25V and the 3.3V regulator is enabled, a short low pulse may
be created on the DP signal line during device wakeup. The 15 µs to 20 µs low pulse of the DP line may
be interpreted by the host computer as a de-attach or the beginning of a wakeup.
PARAMETERS AFFECTED
The bandgap reference voltage used by the 3.3V regulator decreases during sleep due to leakage. Upon
device wakeup, the bandgap is re-enabled and after a delay for settling, the 3.3V regulator is enabled. On
some devices the 3.3V regulator that is used to generate the USB DP signal may be enabled before the
bandgap is fully stabilized. This can cause a low pulse on the regulator output and DP signal line until the
bandgap stabilizes. In applications where Vdd is 3.3V, the regulator is not used; therefore, the DP low
pulse is not generated.
WORKAROUND
To prevent the DP signal from pulsing low, keep the bandgap enabled during sleep. The most efficient
method is to set the No Buzz bit in the OSC_CR0 register. The No Buzz bit keeps the bandgap powered
and output stable during sleep. Setting the No Buzz bit results in a nominal 100 µA increase to sleep
current. Leaving the analog reference block enabled during sleep also resolves this issue because it
forces the bandgap to remain enabled. An example to disable the No Buzz bit is as follows.
Assembly
M8C_SetBank1
or reg[OSC_CR0], 0x20
M8C_SetBank0
C
OSC_CR0 |= 0x20;
[+] Feedback

CY8CTST120, CY8CTMG120, CY8CTMA120
September 25, 2008 Document No. 001-49038 Rev. ** 3
3. Invalid Flash reads may occur if Vdd is pulled to -0.5V just before power on.
PROBLEM DEFINITION
When Vdd of the device is pulled below ground just before power on, the first read from each 8K Flash
page may be corrupted. This issue does not affect Flash page 0 because it is the selected page upon
reset.
PARAMETERS AFFECTED
When Vdd is pulled below ground before power on, an internal Flash reference may deviate from its
nominal voltage. The reference deviation tends to result in the first Flash read from that page returning
0xFF. During the first read from each page, the reference is reset. This results in all future reads returning
the correct value. A short delay of 5 µs before the first real read provides time for the reference voltage to
stabilize.
WORKAROUND
To prevent an invalid Flash read, a dummy read from each Flash page must occur before use of the
pages. A delay of 5 µs must occur after the dummy read and before a real read. The dummy reads
occurs as soon as possible and must be located in Flash page 0 before a read from any other Flash
page. An example to read a byte of memory from each Flash page follows. Place it in boot.tpl and
boot.asm immediately after the ‘start:’ label.
// dummy read from each 8K Flash page
// page 1
mov A, 0x20 // MSB
mov X, 0x00 // LSB
romx
// wait at least 5 µs
mov X, 14
loop1:
dec X
jnz loop1
4. PMA Index Register fails to auto increment with CPU_Clock set to SysClk/1 (24 MHz).
PROBLEM DEFINITION
When the device is operating at 4.75 to 5.25V and the CPU_Clock is set to SysClk/1 (24 MHz), the USB
PMA Index Register may fail to increment automatically when used in an OUT endpoint configuration at
full speed. When the application program attempts to use the bReadOutEP() function, the first byte in the
PMA buffer is always returned.
PARAMETERS AFFECTED
An internal flip-flop hold problem associated with Index Register increment function. All reads of the
associated RAM originate from the first byte. The hold problem has no impact on other circuits or
functions within the device.
WORKAROUND
To make certain that the index register properly increments, set the CPU_Clock to SysClk/2 (12 MHz)
during the read of the PMA buffer. An example for the clock adjustment method is listed below.
PSoC Designer™4.3 User Module Workaround: PSoC Designer Release 4.3 and subsequent
releases includes a revised full speed USB User Module, which includes the revised firmware as shown in
the following example.
;;
;; 24Mhz read PMA workaround
;;
M8C_SetBank1
mov A, reg[OSC_CR0]
push A
[+] Feedback

CY8CTST120, CY8CTMG120, CY8CTMA120
September 25, 2008 Document No. 001-49038 Rev. ** 4
and A, 0xf8 ;clear the clock bits (briefly chg the cpu_clk to 3Mhz)
or A, 0x02 ;will set clk to 12Mhz
mov reg[OSC_CR0],A ;clk is now set at 12Mhz
M8C_SetBank0
.loop:
mov A, reg[PMA0_DR] ; Get the data from the PMA space
mov [X], A ; save it in data array
inc X ; increment the pointer
dec [USB_APITemp+1] ; decrement the counter
jnz .loop ; wait for count to zero out
;;
;; 24Mhz read PMA workaround (back to previous clock speed)
;;
pop A ;recover previous reg[OSC_CR0] value
M8C_SetBank1
mov reg[OSC_CR0],A ;clk is now set at previous value
M8C_SetBank0
;; end 24Mhz read PMA workaround
References
[1] Document # 001-46932 CY8CTST120 TrueTouch™Single-Touch Touchscreen Controller (Final)
[2] Document # 001-46929 CY8CTMG120 TrueTouch™Multi-Touch Gesture Touchscreen Controller (Final)
[3] Document # 001-46901 CY8CTMA120 TrueTouch™Multi-Touch All-Point Touchscreen Controller (Final)
[+] Feedback
