D-CUT HC-040 User manual

OPERATION MANUAL
Hand Cutter HC-040
www.dcutproducts.com

2
CUTTING AND C
Regular Cutting
Place the work-piece under the blade
and press down the handle to complete
the cut as shown.
Lock for storage
Lock the handle as shown for
transportation and storage.
Angle Cutting
Adjust the angle attachment to the
desired angle and lock it. Place the
work- piece under the blade and press
down the handle to complete the cut
as shown.

3
Part List
Parts Q’ty Parts Q’ty
1 Left Base 1 15 Hex Screw M8 × 25 2
2 Rubber Foot Pad 4 16 Hook 1
3 Hex Screw M5 × 20 2 17 Blade Base 1
4 Face board 1 18 Blade 1
5 Locker Nut M5 2 19 Reset Spring 1
6 Sleeve 1 20 Right Base 1
7 Stainless Steel Pad 2 21 Spacer Block1
8 Screw M4 × 8 3 22 Hex Screw M4 × 20 5
9 Locker Nut M4 5 23 Knurled Screw 1
10 Locker Nut M8 2 24 Cross Head Screw M4 × 6 1
11 Screw ST3.5 × 22 2 25 Working Table 1
12 Right Handle 1 26 Angle Attachment 1
13 Handle 1 27 Sliding block 1
14 Left Handle 1 28 pointer 1
