D-CUT GC-230 User manual

OPERATION MANUAL
Manual Trim Cutter GC-230
www.dcutproducts.com
CUTTING AND C

2
Handle Assembly
Insert the handle to the handle base
and use the provided screw / washer
/ spring washer as shown.
Straight Cut
Insert the floor plank between the
cutting blade and the base, flush
with the guide bar on the working
table and hold the plank then pull
handle down to complete a cut.
Warning: Maintain control of the
handle. Do not allow handle to slam
back after making a cut.
Changing the Blade
Use provided Allan wrench to
remove the four screws, and then
move the blade out of the blade
holder.
Note: the flat side of the blade
should face the working table.
Warning: Do not put your fingers
against the sharp edge of the blade
at any time.

3
Changing the Nylon Bar
Use the provided Allan wrench to
remove the four screws, and then
remove the old nylon bar.
Warning: Do not put your fingers
against the sharp edge of the blade
at any time.
Transport
Push down the handle and then
move the lock-pin to lock the blade
hold in a close position as shown for
the safety.

4
Explosive View

5
Parts Q’ty Parts Q’ty
1 Screw M5 × 16 9 19 Right ABS Handle 1
2 Spring Washer φ5 3 20 Nut M4 2
3 Washer 3 21 Screw M4 × 31 2
4 Nylon Bar Holder Base 1 22 Left ABS Handle 1
5 Nylon Bar Holder 1 23 Screw M5 × 8 15
6 Nylon Bar 1 24 Working Table A 2
7 Right Bracket 1 25 Working Table B 1
8 Nut M8 2 26 End Cover 2
9 Spring Base 4 27 Cutter Base 1
10 Spring 2 28 Knurling Screw M5 1
11 Screw M6 × 16 2 29 Left Bracket 1
12 Screw M5 × 12 2 30 Rubber Feet 2
13 Nylon Cam Ring 2 31 Nut M5 2
14 Aluminum Cam Wheel 1 32 Rotating Shaft 1
15 Screw M6 × 30 1 33 Aluminum Sliding Block 2
16 Spring Washer φ6 1 34 Blade Holder 1
17 Washer φ6 1 35 Blade 1
18 Handle 1 36 Screw 6 × 10 4
Explosive View
