D-CUT MH-510 User manual

OPERATION MANUAL
D-Cut Multi-Flooring Cutter MH-510
www.dcutproducts.com

2
SAFETY RULES FOR THE MULTI-FLOORING CUTTER
1. READ AND UNDERSTAND THIS INSTRUCTION MANUAL BEFORE
OPERATING THE D-CUT MULTI-FLOORING CUTTERS.
2. If you are not thoroughly familiar with the operation of D-Cut Multi-flooring
Cutter, obtain advice from a qualified instructor or call 800-982-3434 USA
3. Stay alert. Do not operate while under the influence of drugs, alcohol, or
medication.
4. Always wear safety approved eye protection with side shields(ANSI Z87.1)
5. Keep work area free of debris.
6. Keep children and unauthorized persons away from the D-Cut Multi-flooring
Cutter and work area.
7. Make sure tool is secure. Operate only on a firm substrate or solid stand.
8. Use the right tool. Do not force the D-Cut Multi-flooring Cutter or use it for a
job for which it was not designed; use only on approved materials.
9. Keep the blade sharp. A dull blade will not perform properly.
10. Always keep hands away from blade while operating or carrying the cutter.
11. Do not alter or misuse this tool. The D-Cut Multi-flooring Cutter is precision
built; modifications not specified in this manual may result in a dangerous
and unsafe environment.
12. Maintain the D-Cut Multi-flooring Cutter with care. Keep Blade sharp and
clean. Follow instructions for changing accessories.
13. Use only recommended accessories. The use of improper accessories may be
hazardous and cause injuries.
14. Never leave the D-Cut Multi-flooring Cutter unattended. Secure the handle
with the lock chain when not in use.

3
SET UP
CUTTING AND C
Installation of the Cutter (2)
Pull up the lock pin on the
aluminum handle as shown and
insert the handle into the
handle base as shown.
Warning: Do not put your
fingers against the sharp edge
of the blade at any time.
Installation of the Cutter (1)
Install the table to the cutter
base with provided screws and
bolts as shown.
Warning: Do not put your
fingers against the sharp edge
of the blade at any time.
Cutting Preparation
Adjust the angle attachment to
desired angle as needed.
The angle attachment can be also
used on left side of the table as
shown.
Warning: Do not put your fingers
against the sharp edge of the
blade at any time.

4
CUTTING
Straight Cutting
Insert material between the
cutting blade and the base,
flush with the angle attachment
as shown and hold the material
with foot then push handle
down to complete a cut.
Warning: Maintain control of
the handle. Do not allow
handle to slam back after
making a cut.
45° Cutting
Adjust the angle attachment to
45°. Insert material between
the cutting blade and the base,
against the angle attachment as
shown, then push the handle
down to complete a cut.
Warning: Maintain control of
the handle. Do not allow
handle to slam back after
making a cut.
Warning: Do not put your
fingers against the sharp edge
of the blade at any time.

5
Carry
Hook the chain to the ring on
the handle and carry the
cutter as shown.
Changing the Blade
Use the provided Allan wrench
to remove the six screws, then
hold the blade by each end and
carefully remove the blade out of
the blade holder.
Note: The flat side of the blade
faces the table.
Warning: Do not put your
fingers against the sharp edge of
the blade at any time.
MAINTENANCE

6
PART LIST

7
Parts Q’ty Parts Q’ty
1 Cross Head Screw M5 × 10 2 30 Hex Nut M5 4
2 Hex Head Screw M5 × 16 8 31 Nut Straight Locating Slot 1
3 Hex Head Screw M6 × 14 6 32 Nut Curve Locating Slot 1
4 Nylon Bar Holder 1 33 Chain 1
5 Blade Cutting Base 1 34 Hex Head Screw M5 × 12 19
6 Nylon Bar 2 35 Hook B 1
7 Rubber Feet-2 2 36 Working Table 1
8 Plain Washer Φ5 2 37 Hex head screw M5 × 8 10
9 Blade 1 38 Hex head screw M5 × 20 6
10 Hex Head Screw M8 × 66 4 39 Carrying Handle 1
11 Side Frame B 1 40 Thin Nut M5 3
12 Spring 2 41 End Table Frame 1
13 Blade Holder 1 42 Hex Head Screw M8 × 8 4
14 Rotating Shaft A 1 43 Rubber Feet-1 2
15 Aluminum Eccentric Cam 1 44 Blind Rivet Φ5 4
16 Hex Head Screw M5 × 10 1 45 Working Table Frame 2
17 Handle Base 1 46 Cross Bar 3
18 Handle-1 1 47 Nut Base 4
19 Pull Pin 2 48 Nylon Lock Nut M5 16
20 Handle-2 1 49 Rotating Shaft B 1
21 Thin Nut M4 2 50 Customized Bolt M8 2
22 Right ABS Handle 1 51 Spring Washer Φ8 2
23 Cross Head Screw M4 × 31 2 52 Side Frame A 1
24 Left ABS Handle 1 53 Cross Head Screw M6 × 16 2
25 Hook A 1 54 Guide Rod 2
26 Knurled Pin M5 3 55 Allan Wrench M8 1
27 Cutting Guide 1 56 Allan Wrench M6 1
28 Hex Head Screw M12 × 30 1 57 Allan Wrench M5 1
29 Nylon Board 3
PART LIST
