D-Link DFM-562E - 56 Kbps Fax User manual

If you purchased this Modem to make your Internet connection with PC, you must
have an established Internet account from an Internet Service Provider (ISP).
Check Your Package Contents
These are the items included with your D-Link 562E purchase:
If any of the above items are missing, please contact your reseller.
©2003 D-Link Corporation, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective
holders. Software and specifications subject to change without notice. D-Link DFM-562E External Modem
• D-Link DFM-562E External Modem
• CD-ROM (containing Manual and Q.I.G.)
• 9V AC, 0.8A Power Adapter
• Phone Cable
• RS-232 (9Pin) Cable
Using a powe
r
supply with a
different voltage rating
will damage and void
the warranty for this
product.
D-Link DFM-562E
External Modem
Before Your Begin

Hardware Installation
Please unplug the telephone Line and plug the telephone line into the socket on the
back of the modem marked LINE.
S
p
eaker Jack
MIC Jack
Power
Jack
Power
Switch
Tele
p
hone Line Socket
RS-232C Connect

Install Drivers
2.1 Windows 98/ME
Click Install Drivers
After system will
auto Install Modem.
Please click Close to
end the window
Click CLOSE
When the system was
complete, windows will
detect the modem
automatic, please click
Cancel. Then insert the
driver CD supplied

2.1 Windows 98/ME (continue)
Click Modems
Check Modem Model No. For
D-Link DFM-562E External
Modem.
If correct the installation is
complete then click OK to exit.
Click OK

2.2 Windows 2000
Click Install Drivers
Click
Y
es
Click Yes ignore the
message.

After system will
auto Install Modem.
Please click Close to
end the window
Click CLOSE
Click Yes ignore the
message.
Click
Y
es

2.2 Windows 2000(continue)
Please select Start /
Settings /
Control Panel and
double-click
on the Phone and
Modem Options icon.
Click Phone
and Modem
Options
Check Modem Model No.
For D-Link DFM-562E
External Modem.
If installation is complete
then click OK to exit.
Click OK

2.3 Windows XP
Click Install Drivers
Click Continue
Anyway
When the system was
complete, windows will
detect the modem
automatic, please click
Cancel. Then insert the
driver CD supplied

Click Continue
Anyway
Select the Install the
software automatically
[Recommended] then
click Next to search for the
driver.
Click Continue Anyway
to skip the warning
message.
Click Next

Install complete
Click Finish
Please click Close to
end the window
Click CLOSE
