KL-45
LED HEADLIGHT
INSTRUCTION MANUALGB

doerr-outdoor.de2
GB
THANK YOU very much for choosing a quality product by DÖRR.
Please read the instruction manual and the safety hints carefully
before using the device for the first time.
Keep the operating instructions together with the device for referen-
ce. If other people use this device, provide them with these instruc-
tions. If you sell the unit, this manual forms an integral part of the
device and must be supplied with it.
DÖRR is not liable for damage caused by improper use or failure to
observe the operating and safety instructions.
In the event of damage caused by improper handling or by external
influence, the guarantee or warranty claim becomes void. Any ma-
nipulation, structural modification of the product or opening of the
housing by the user or an unauthorised third party shall be considered
improper handling.
01 | SAFETY HINTS
• This device is not a toy! To prevent accidents and suffocation
keep the device, the accessories and the packing materials away
from children and pets.
• Do not look directly into the LED and do not direct the light
beam into the eyes of humans or animals.
• Do not point the light at vehicles or aircrafts.
• People with physical or cognitive disabilities should use the device
with supervision.
• People with cardiac pacemakers, defibrillators or any other elect-
rical implants should maintain a minimum distance of 30 cm, as
the device generates magnetic fields.
• Do not submerge or throw the device into water. Do not throw the
device into fire – risk of explosion!
• Protect the device from rain, moisture, direct sunlight and extreme
temperatures.
• Do not operate or touch the device with wet hands.
• Never leave the device unattended while charging the battery. After
charging, disconnect the device from USB power supply.
• If the device is not used for a longer period of time, charge the
battery to approx. 60% to avoid deep discharge of the battery.
• Turn off the device after use.
• Protect the device against impacts. Do not use the device if it has
been dropped. In this case a qualified electrician should inspect the
device before you use it again.
• Do not attempt to repair the device by yourself. Risk of electric
shock! When service or repair is required, contact qualified service
personnel.
• The built-in battery and the LEDs cannot be replaced.
• Protect the device against dirt. Never use aggressive cleansing
agents or benzine to clean the device. We recommend a soft,
slightly damp microfiber cloth to clean the outer parts of the device.
Before cleaning, turn off the device and disconnect from the
power source.
• Store the device in a dust-free, dry and cool place.
• If the device is defective or without any further use, dispose of the
device according to the Waste Electrical and Electronic Equipment
Directive WEEE. For further information, please contact your local
authorities.

doerr-outdoor.de3
02 |PRODUCT DESCRIPTION
The compact and lightweight DÖRR KL-45 headlamp is a reliable LED
light source in the forest, when fishing, for sports and outdoor acti-
vities. Depending on your needs, you can choose between spotlight
or area light in dierent brightness levels. White or red flashing light
ensures safety and optimal visibility.
• Ultra bright spotlight and area lights
• Soft, detachable headband
• Quickly and easily adjustable to head or helmet size
• Light angle adjustable
• LED battery capacity indicator
• Built-in, long-lasting lithium polymer battery 3.7V, 600mAh
• Including USB-C charging cable
03 |NOMENCLATURE
01 On/O button spotlight
02 On/O button area lights
03 Area lights
04 Spot light
05 LED battery capacity indicator
06 USB-C charging socket
06a) Rubber cover
07 USB-C charging cable
08 Eyelets for headband
04 |ILLUSTRATION OF PARTS
01
04
02
03 03
06
06a
07
05
08 08

doerr-outdoor.de4
05 |FIRST STEPS
05.1 Fasten the headband
Thread the supplied headband into the two side eyelets (08) as shown:
05.2 Charging the integrated battery
▶ NOTICE
• Please fully charge the built-in lithium polymer battery before
first use.
• If the device is not used for a longer period of time, charge the
battery to approx. 60% to avoid deep discharge of the battery.
CAUTION
Never leave the device unattended while charging the battery.
After charging, disconnect the device from USB power supply.
Open the rubber cover (06a). Below is the USB-C charging socket
(06). Connect the headlamp to a USB charging source, e.g. PC/laptop/
power bank, using the supplied USB-C charging cable (07).
During the charging process, the LED battery capacity indicator (05)
flashes blue. After approx. 2 hours the battery is fully charged and all
4 LEDs of the LED battery capacity indicator (05) light up constantly
blue. Disconnect the headlamp from the USB charging source and
properly close the rubber cover (06a) to ensure splash protection.
05.3 Adjust the light angle
Depending on the application, the light angle of the headlamp can be
adjusted in 3 stages:

doerr-outdoor.de5
06 |HEADLIGHT FUNCTIONS
Spotlight (04)
On/O button (01)
press once
Spotlight (04) lights up.
100% brightness.
On/O button (01)
press a 2nd time Spotlight (04) with 50% brightness.
On/O button (01)
press a 3rd time Switch o spotlight (04).
On/O button (01)
press and hold for
about 4 seconds
Spotlight (04) flashes white (stro-
be).
Area lights (03)
On/O button (02)
press once
Area lights (03) light up.
100% brightness.
On/O button (02)
press a 2nd time
Area lights (03) with 50% bright-
ness.
On/O button (02)
press a 3rd time Switch o area lights (03).
On/O button (02)
press and hold for
about 4 seconds
Area lights (03) flash red (strobe).
The spotlight (04) and
the area lights (03) can
be operated in com-
bination. To do this,
switch on the lights
one after the other as
described above.
▶ NOTICE
Turn off the headlamp after each use.
07 |CLEANING AND STORAGE
Never use aggressive cleansing agents or benzine to clean the head-
light. We recommend a soft, slightly damp microfiber cloth to clean
the outer parts of the headlight. Before cleaning, turn o the he-
adlamp and disconnect from the USB power source if necessary.
To wash the headband, remove the headband from the headlight and
hand wash the headband at 30° C. Do not put in the dryer.
When not in use, store the headlamp in a dust-free, dry, cool place.
The headlamp is not a toy - keep it out of the reach of children.
Keep the headlamp away from pets.
08 |TECHNICAL SPECIFICATIONS
Brightness approx. 450 lumens
Range up to max. 110 m
Internal battery Lithium Polymer 3.7V, 600mAh
Charging time approx. 2 hours
Operating time up to 12 hours (depending on light mode)
Protection class IPX7
Housing ABS
Colour black
Size adjustable ✓
Dimensions approx. 6 x 4 x 3,5 cm
Weight approx. 63 g
DÖRR GmbH reserves the right to make technical changes without notice.
09 |SCOPE OF DELIVERY
1x LED Headlight KL-45
1x Headband
1x USB-C charging cable
1x Safety hints

doerr-outdoor.de6
10 |DISPOSAL, CE MARKING
10.1 DISPOSAL OF BATTERY/ACCUMULATOR
Batteries and rechargeable batteries are marked with the symbol of a
crossed-out waste bin. This symbol indicates that empty batteries or
rechargeable batteries that can no longer be recharged must not be
disposed of in household waste. Old batteries may contain harmful
substances that can cause damage to health and the environment. As
the end user, you are legally obliged to return used batteries (under
German battery law, Section 11 Act Revising the Law of Waste-Rela-
ted Product Responsibility for Batteries and Accumulators). You can
return batteries free of charge after use at the point of sale or in your
immediate vicinity (e.g. at municipal collection points or in shops). You
can also return batteries to the seller by post.
10.2 WEEE INFORMATION
The WEEE (Waste Electrical and Electronic Equipment) Directive,
which came into force as European law on 13 February 2003, led to
comprehensive changes in the disposal of discarded electrical equip-
ment. The primary purpose of this directive is to prevent e-waste
while promoting reuse, recycling and other forms of reprocessing in
order to reduce waste. The WEEE logo (dustbin) shown on the product
and on the packaging indicates that the product must not be dispo-
sed of in normal household waste. You are responsible for deliver-
ing all discarded electrical and electronic equipment to appropriate
collection points. Sorting waste for separate collection and sensible
recycling of packaging waste helps to use natural resources more spa-
ringly. Furthermore, e-waste recycling is a contribution to preserving
our environment and thus also people‘s health. Further information
on the disposal of electrical and electronic equipment, recycling and
collection points can be obtained from local authorities, waste dispo-
sal companies, specialist retailers and the manufacturer of the device.
10.3 CONFORMITY WITH ROHS
This product complies with the European RoHS Directive on the res-
triction of the use of certain hazardous substances in electrical and
electronic equipment and variations thereof.
10.4 CE MARK
The imprinted CE mark complies with the applicable EU standards and
indicates that the device meets the requirements of all EU directives
applicable to this product.
DÖRR LED Headlight KL-45
Item-No. 980522
Made in China
DÖRR GmbH
Messerschmittstr. 1
D-89231 Neu-Ulm
