Daewoo COL1540 User manual

1
4” Portable Rechargeable Fan
Model No. COL1540
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

2
4” Portable Rechargeable Fan
Model No. COL1540
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
•Read and familiarise yourself with all operating
instructions before using this Table Mini Fan.
•Before using your Table Mini Fan, visually check that the
unit is intact and has not suffered any transit damage.
•Always use this appliance on a solid, level, non-flammable
surface.
•Ensure that there is clearance of at least 100mm (4
Inches) minimum around the Table Mini Fan for sufficient
ventilation.
•Ensure that any ventilation openings are not covered with
items, such as newspapers, table-cloths, curtains, etc.
•No naked flame sources, such as lighted candles, should
be placed on the Table Mini Fan.
•DO NOT position the Table Mini Fan close to sources of
heat such as radiators, heaters, other electronic
equipment, etc.
•The Table Mini Fan shall not be exposed to dripping or
splashing and that no objects filled with liquids, such as
vases, shall be placed on the apparatus.
•DO NOT immerse the Table Mini Fan or its charging cable
in water or any other liquids.

3
4” Portable Rechargeable Fan
Model No. COL1540
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
•DO NOT leave the Table Mini Fan unattended during use.
•DO NOT leave the Table Mini Fan unattended whilst
connected to a USB supply.
•Close supervision is required when using this Table Mini
Fan near children.
•Never leave this Table Mini Fan within reach of children.
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
•Children of less than 3 years should be kept away unless
continuously supervised.
•It is imperative to unplug the USB supply after the Table
Mini Fan has been used, before it is cleaned and whilst
being repaired.
•Unplug after each use.
•Repairs to electrical appliances should only be performed
by qualified personnel. Improper repairs may place the
user at serious risk.
•DO NOT operate this appliance after a malfunction or
after being dropped or damaged in any way.
•DO NOT allow the charging cable to hang over sharp
edges or come in contact with hot surfaces.
•DO NOT run the charging cable under carpets, rugs, etc.
•This product is intended for household use only and
should not be used for industrial purposes.
•DO NOT use any accessories or attachments with this
product other than those supplied or recommended by
supplier.
•DO NOT use this product for anything other than its
intended use.

4
4” Portable Rechargeable Fan
Model No. COL1540
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
•DO NOT push objects into any openings as damage to the
product and/or electric shock may occur.
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
This symbol provides useful additional information on the
use of this product.
This symbol identifies voltage and the current rating for direct
current.
This symbol means batteries and rechargeable batteries may
not be disposed of with household waste!
As the end user you are required by law to bring all batteries
and rechargeable batteries to a collection point run by the Local
Authority or to a retailer, so that they can be disposed of in an
environmentally friendly manner.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not be
disposed of with normal household waste. Please ensure it is
taken to a suitable facility for disposal. Check with your Local
Authority or retailer for recycling advice or visit www.recycle-
more.co.uk enter your postcode to find out your nearest
recycling site.

5
4” Portable Rechargeable Fan
Model No. COL1540
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Before the First Use of Your Table Mini Fan
Remove all packing materials and discard responsibly.
Ensure all parts are present (if applicable) see Description of Parts below.
Description of Parts - Accessories
Description of Parts
1.Fan Guard
2.Air Outlet
3.LED Indicator
4.Power / Speed Button
5.Air Inlet
6.USB charging Port
7.USB Charging Cable
8.Micro USB Plug
9.Large USB Plug
7
8
9
6
4
3
1
5
2

6
4” Portable Rechargeable Fan
Model No. COL1540
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Charging the internal Battery
Before use, please ensure that the internal rechargeable battery is fully charged as
follows:
1.Insert the Micro USB Plug (8) of the USB
Charging Cable (7) into the USB Charging Port
(6) on the rear panel of the Table Mini Fan to
charge the internal battery.
2.Insert the Large USB Plug (9) of the USB
Charging Cable (7) into a suitable USB charger
rated at 1A or higher such as a dedicated USB
mains charger or USB outlet on a computer.
3.The LED Indicator (3) will flash Red whilst
charging. Once the battery is fully charged, the
LED Indicator (3) will change to White to indicate fully charge and the USB
Charging Cable (7) can be removed.
4.The internal battery can operate for 2 - 8hours after it is fully charged. Battery
will take 2 - 3hours to fully charge from flat.
The Table Mini Fan can be used whilst connected to the USB supply.
Using Your Table Mini Fan
1.Switch on the Table Mini Fan by pressing the
Power/Speed Button (4).
2.Press the Power/Speed Button (4) for fan speed I.
3.Repeatedly press the Power/Speed Button (4) for
speeds 2 and 3.
4.The LED Indicator (3) will illuminate White when
the Table Mini Fan is switched ON (speed I).
5.Further press the Power/Speed Button (4) after Speed III to switch the unit off.
The airflow direction can be adjusted by swinging the
Fan Guard (1) up and down.
The LED Indicator (3) will flash Red whilst during use
when the battery Power is less than 20%

7
4” Portable Rechargeable Fan
Model No. COL1540
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Care and Use of your Table Mini Fan
•Always disconnect the Table Mini Fan from the USB supply before cleaning.
•Clean outside of the Table Mini Fan with a clean damp cloth. Never clean with
harsh or abrasive cleaners.
•Do not submerge the Table Mini Fan or its charging cable in water or any other
liquids.
•Keep the Table Mini Fan in dry place.
Technical Specification
*Battery is not removable
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-
cycling facilities.
Dispose of plastics in the appropriate plastics collection service.
Dispose of non-recyclable plastics in the appropriate plastics
collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste. Please ensure it is taken to a suitable facility for
disposal. Check with your Local Authority or retailer for recycling
advice or visit www.recycle-more.co.uk enter your postcode to find
out your nearest recycling site
This symbol means batteries and rechargeable batteries may not
be disposed of with household waste!
As the end user you are required by law to bring all batteries and
rechargeable batteries to a collection point run by the Local
Authority or to a retailer, so that they can be disposed of in an
environmentally friendly manner.
Model Number
COL1540
Rated Power
4W
Charge Input
DC 5V 1A
Battery Type/Capacity*
Li-ion 3.7V 1800mAh
Unpacked Weight
Approx. 235g
Dimensions (Approx.)
167mm (H) x 85mm (W) x 118mm (D) Approx.

8
4” Portable Rechargeable Fan
Model No. COL1540
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Daewoo is a registered trademark.
Produced and imported under licence by
ESG Ltd. Manchester M3 1JS UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in addition to your 1 year
guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
• The product must becorrectly installed and operated in accordance with the
requirements contained in the instruction manual.
• The product must beused solely for domestic purposes.
• It does not cover general wear and tear, damage, misuse or any consumable parts.
• The guarantee will berendered invalid if the product is re-sold or has been damaged through
inexpert repair.
• The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to
the conditions outlined above.
