Danfoss Ik3 User manual

User Manual

Remote Controls

IK3 Transmitters

www.danfoss.com

Revision history Table of revisions

Date Changed Rev

May 2021 Added trouble shooting and start-up information for TR2400 0201

February 2019 Rebranded to Danfoss Power Solutions 0101

User Manual

Remote Control IK3 Transmitters

2 | ©Danfoss | May 2021 BC290857689420en-000201

Safety instructions FCC rules..............................................................................................................................................................................................4

General safety....................................................................................................................................................................................4

Safety warnings.................................................................................................................................................................................5

Technical description Dimensions and identification.....................................................................................................................................................6

IK Transmitters Start up (400-900Mhz).....................................................................................................................................7

IK Transmitters Start up (2.4 GHz)...............................................................................................................................................7

IK3 Detailed description.................................................................................................................................................................9

Maintenance Maintenance tips............................................................................................................................................................................10

Troubleshooting 400-900 MHz................................................................................................................................................. 10

Troubleshooting 2.4 GHz............................................................................................................................................................ 10

Charger and battery Charger and battery......................................................................................................................................................................12

CB70 and BT27IK specifications................................................................................................................................................12

Setting up the CB70 battery charger...................................................................................................................................... 12

CB70 status LEDs............................................................................................................................................................................13

Battery Charging Recommendations..................................................................................................................................... 13

CB70 battery charger dimensions............................................................................................................................................14

User Manual

Remote Control IK3 Transmitters

Contents

©Danfoss | May 2021 BC290857689420en-000201 | 3

FCC rules

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant

to Part 15 of the FCC Rules.

Changes or modifications not expressly approved by the manufacturer can void the user's authority to

operate the equipment.

To comply with FCC RF exposure compliance requirements, this device and its antenna must not be

collocated with, or operating in conjunction with, any other antenna or transmitter, may not cause

harmful interference, and must accept any interference received, including interference that may cause

undesired operation.

The limits are designed to provide reasonable protection against harmful interference when the

equipment is operated in a commercial environment. This equipment generates, uses, and can radiate

radio frequency energy, and if not installed and used in accordance with the instruction manual, may

cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case the

user will be required to correct the interference at his own expense.

Warning

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de

licence. L'exploitation est autorisée aux deux conditions suivantes:

1. l'appareil ne doit pas produire de brouillage, et

2. l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est

susceptible d'en compromettre le fonctionnement.

IK3 General Safety

The following safety instructions must be read carefully to install and use the product properly, and to

keep it in perfect working condition, and to reduce the risk of misuse.

•Strictly adhere to the installation instructions contained in this document.

•Make sure that professional and competent personnel carry out the installation.

•Ensure that all site and prevailing safety regulations are fully respected.

•Make sure that this document is permanently available to the operator and maintenance personnel.

•Keep the transmitter out of reach of non-authorized personnel.

•Remove the transmission key when the set is not in use.

•Check each working day the STOP button and other safety measures. When in doubt, press the STOP

button.

•Whenever several sets have been installed, make sure the transmitter is the right one. Identify the

machine controlled on the label for this purpose on the transmitter or by using the display (in case it

has one).

•Service the equipment periodically.

•When carrying out repairs, use spare parts supplied by Danfoss only.

Warning

Potential damage to the operator or the product. Do not use this product on machines in potentially

explosive atmospheres unless the model is ATEX/RATEX certified to work in such conditions.

User Manual

Remote Control IK3 Transmitters

Safety instructions

4 | ©Danfoss | May 2021 BC290857689420en-000201

IK3 Safety Warnings

Potential damage to operator and product.

Follow the guidelines below to reduce risk of injury to the operator and the product.

•Use the device with the manufacturer's battery and battery charger (if applicable).

•Only allow qualified personnel to operate the equipment.

•Always set the STOP button in the off position when not in use.

•Always press STOP before plugging in tether cable (if applicable).

•Remove the Tether connection on the transmitter First (if applicable).

•Do not operate product when visibility is limited.

•Make sure product is compatible with the machine.

•Avoid knocking or dropping the product.

•Do not use the product if a failure is detected.

Changes or modifications not approved by Danfoss can void the user's authority to operate this product.

Quick reference precautions

User Manual

Remote Control IK3 Transmitters

Safety instructions

©Danfoss | May 2021 BC290857689420en-000201 | 5

IK3 dimensions and identification

The illustration below details dimensions and features of the IK3 transmitter.

Dimensions in mm

254 181.16

216.56

1. Label for crane identification

2. LED

3. Maneuver elements

4. Contact key

5. Start push button

6. STOP button

7. Optional: Range limiter

8. External and extractable EEPROM module

9. Battery

10. 3.5 in TFT display

11. Lateral push buttons

User Manual

Remote Control IK3 Transmitters

Technical description

6 | ©Danfoss | May 2021 BC290857689420en-000201

IK Transmitters Start up (400-900Mhz)

Use the information below to properly turn the transmitter ON (OPERATION mode).

1. Place a charged battery in the transmitter. The charge must be done following the instructions of the

Battery Chargers' Manual.

2. Turn the contact key.

crane xx1

LED pulse display op� on

LED pulse

3. Push and pull out the STOP button.

LED will flash orange-green pulse. If the transmitter has LCD, it displays the identification of the

machine and battery level (only if it has been pre-programmed).

crane xx1

LED pulse Display option

4. Press the start button. The green LED will now light to indicate the transmitter is transmitting. Once

the Tx is connected, press any maneuver button and its corresponding relay will be activated. Check

to make sure all other maneuvers work in a coherent way with the expected movements.

crane xx1

LED pulse display op� on

LED pulse

IK Transmitters Start up (2.4 GHz)

In order to turn the transmitter ON (OPERATION mode), please follow these steps:

User Manual

Remote Control IK3 Transmitters

Technical description

©Danfoss | May 2021 BC290857689420en-000201 | 7

Start up the device

1. Place a charged battery in the transmitter.

The battery must be charged following the instructions of the Battery Charger Manual.

2. Turn the contact key or Multikey to the position "I." It is not necessary to switch the contact key off

after use, however, it may be removed in order to deny access to the transmitter.

3. Push and pull out the STOP button.

LED status (blue)

LED will flash, blinking blue until it reaches the Stand-by mode (fixed blue). If the transmitter includes

a Display, it will display the identification of the machine, as well as the battery level, if it has been

pre-programmed.

4. Press the START button, and wait for the status LED to turn to fixed green.

LED status (green)

The status LED will start blinking green, meaning the transmitter is trying to connect with the

receiver. Once the Tx is linked, LED will turn to fixed green.

5. Press any of the transmitter's maneuver buttons and its corresponding relay will be activated.

6. Check to make sure all the maneuvers work in a coherent way with the expected movements by

checking the supplied production sheet, included with the system.

User Manual

Remote Control IK3 Transmitters

Technical description

8 | ©Danfoss | May 2021 BC290857689420en-000201

IK3 Detailed description

Description Value

Stop function (400 - 900 MHz) Cat. 3-PLd

Stop Function (2.4 GHz) Cat3 - PLe

Ingress Protection rating IP65/NEMA4

Anti-condensation system Goretex Film

Frequency band - ERP 433.050 to 434.040 MHz; ERP<1 mW

434.040 to 434.790 MHz; ERP<10mW

869.700 to 870.000 MHz; ERP<5 mW

902.000 to 928.000 MHz; ERP<1mW

2405MHz to 2475MHz; ERP 20dBm/100mW

Range (normal conditions) 100m

Main mechanisms (maximum number) Joystick (3) or Paddle (6)

Auxiliary mechanisms Pushbutton, toggle and rotary switches

Removable EEPROM External

Battery model BT27IK

Battery life 10 hours

Response Time 100ms

Operating temperature range -20 °C to 70 °C (-4 °F to 158 °F)

Storage Temperature Range (24h) -25ºC to 75ºC (-13ºF to 167ºF)

Storage Temperature Range (long periods) -25ºC to 55ºC (-13ºF to 131ºF)

Relative Humidity max. 95% without condensation

Weight (with battery) 1780 grams

Dimensions LxWxH mm 245,04x216,56x181,16

Harness Belt/shoulder strap

Available Options

Display 3.5-inch color TFT

LED Panel Yes ( up to 12 LEDs)

Cable connector Yes (M12 Connector)

Range limiter Yes

Associated receivers R06, R13, R70, R70 PLUS, MPCAN, MP20

User Manual

Remote Control IK3 Transmitters

Technical description

©Danfoss | May 2021 BC290857689420en-000201 | 9

IK3 maintenance tips

This product is designed for use in an industrial environment that may shorten the product's lifespan. Use

these tips to maximize the lifespan of the product.

•Use the hook/belt provided with the transmitter to prevent the transmitter from falling

•Do not clean the transmitter with solvents or pressurized water; use a damp cloth or soft brush for

cleaning

•If the push buttons show signs of deterioration, contact the Authorized Technical Service for repair

•Check if the battery contacts are correct, otherwise replace them.

•Ensure that the product is supplied with AAA alkaline batteries or has a rechargeable battery

•Be sure to recharge or replace battery regularly

Maintenance tips quick reference

Troubleshooting (400-900 MHz)

The transmitter has status monitoring LED's which help identify irregularities. The most common signals

are contained in the table below:

Color and frequency Pulse frequency Description Action

Green | continuous Working Operate

Green | slow pulses Latency; no action has been taken for some time Press START to return to operation

mode

Red | slow pulses Low battery signal Replace or recharge battery

Red | fast pulses EEPROM module missing or corrupt Check EEPROM and reprogram if

necessary

Red | double pulses A maneuver is activated at transmitter start up process;

may indicate hardware damage if no order is active Release maneuver or replace

transmitter if necessary

Red | continuous General hardware failure Replace transmitter

Troubleshooting 2.4 GHz

The transmitter has status monitoring LED's which help identify irregularities. The most common signals

are in the table below:

LED color | Frequency Pulse Frequency Description Action

Blue / fast pulses Starting the system,establishing

communication with radio and EEPROM. Wait

Blue | continuous Stand-by. Set up system, waiting user’s action. Press START to enter Operation mode.

User Manual

Remote Control IK3 Transmitters

Maintenance

10 | ©Danfoss | May 2021 BC290857689420en-000201

LED color | Frequency Pulse Frequency Description Action

Green / fast pulses Trying to link with the receiver and waiting its

answer. Wait

Green | continuous The transmitter works properly. Operation

mode is OK. No action needed.

Green | slow pulses STANDBY mode. If transmitter is 4 minutes

ON and no action has been taken. Press START to return to Operation mode.

Red | slow pulses EEPROM Error. EEPROM module is missing or

corrupted. Check EEPROM module or reprogram if

necessary.

Red | double pulses Radio Error. Radio communication error. Replace transmitter

Red | continuous Hardware failure or damage. Replace transmitter

Orange | slow pulses Battery signal is critical. Replace batteries with charged ones.

Orange | double pulses A maneuver is activated. Release maneuver or replace transmitter if

necessary.

User Manual

Remote Control IK3 Transmitters

Maintenance

©Danfoss | May 2021 BC290857689420en-000201 | 11

Charger and battery

Disposal note:

This symbol on the product indicates that it may not be disposed of as household waste.

It must be handed over to the applicable take-back scheme for the recycling of electrical equipment.

•Dispose of the product through channels provided for this purpose.

•Comply with all local and currently applicable laws and regulations.

CB70 and BT27IK specifications

CB70 battery charger

Specification Value

Standard AC power supply 230 Vca ± 10%, 50

Optional AC power supply 115 Vca, 60 Hz

DC power supply From 10.5 V to 35 V

BT27IK battery

Specification Value

Voltage 4.8 V

Capacity 2700 mAh NiMH

Charging temperature From 0° C to 45° C

Discharge temperature From -20° C to 50° C

Autonomy From 8 to 15 h (configuration dependant)

Charging mode 7h and intelligent

Weight 156.3 g

Setting up the CB70 battery charger

Use the information below to properly set up the CB70 batter charger.

The battery charger has two charging compartments that can simultaneously charge two batteries.

1. Connect the charger to a power source using the cable supplied.

The red LED will switch.

User Manual

Remote Control IK3 Transmitters

Charger and battery

12 | ©Danfoss | May 2021 BC290857689420en-000201

2. Place the batteries in the compartments of the battery charger.

3. Optional: If charging multiple batteries, wait at least 5 seconds before placing the second battery in

the other compartment.

Possible damage to battery!

Be sure to charge batteries in environments with temperatures over 0° C.

CB70 status LEDs

Each battery compartment has an LED that indicates the status of the batteries' charge.

Green LED; pulsing Battery is excessively depleted

Green LED; continuous Normal charging operation mode

Green LED; off Battery charging process is complete

The battery charger must be placed and used out of the danger area.

Battery Charging Recommendations

The battery lifespan is estimated to 500 recharging cycles and is largely dependent on the conditions of

use. To maximize the lifespan of the batteries and battery charger, follow these recommendations:

•Do not recharge the battery until it is completely flat, as shown with red LED slow pulse on the

transmitter

•Always charge the batteries at temperatures between 0° and 45°C (the batteries will not become fully

charged at temperatures exceeding 45°C)

•Do not leave the battery charger or batteries in a direct sunlight

•Charge batteries at least once every six months

•Avoid short circuits between the battery contacts; do not carry charged batteries in toolboxes or next

to other metal objects (keys, coins, etc.)

•Always keep contacts clean

•Caution! Risk of Explosion if Battery is Replaced by an incorrrect type. Non Danfoss Battery use may

void warranty

User Manual

Remote Control IK3 Transmitters

Charger and battery

©Danfoss | May 2021 BC290857689420en-000201 | 13

CB70 battery charger dimensions

Dimensions in mm

131.60

179.80

128.50

34.50

User Manual

Remote Control IK3 Transmitters

Charger and battery

Danfoss Power Solutions is a global manufacturer and supplier of high-quality hydraulic and

electric components. We specialize in providing state-of-the-art technology and solutions

that excel in the harsh operating conditions of the mobile off-highway market as well as the

marine sector. Building on our extensive applications expertise, we work closely with you to

ensure exceptional performance for a broad range of applications. We help you and other

customers around the world speed up system development, reduce costs and bring vehicles

and vessels to market faster.

Danfoss Power Solutions – your strongest partner in mobile hydraulics and mobile

electrification.

Go to www.danfoss.com for further product information.

We offer you expert worldwide support for ensuring the best possible solutions for

outstanding performance. And with an extensive network of Global Service Partners, we also

provide you with comprehensive global service for all of our components.

Local address:

Danfoss

Power Solutions GmbH & Co. OHG

Krokamp 35

D-24539 Neumünster, Germany

Phone: +49 4321 871 0

Danfoss

Power Solutions ApS

Nordborgvej 81

DK-6430 Nordborg, Denmark

Phone: +45 7488 2222

Danfoss

Power Solutions (US) Company

2800 East 13th Street

Ames, IA 50010, USA

Phone: +1 515 239 6000

Danfoss

Power Solutions Trading

(Shanghai) Co., Ltd.

Building #22, No. 1000 Jin Hai Rd

Jin Qiao, Pudong New District

Shanghai, China 201206

Phone: +86 21 2080 6201

Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products
