Danfoss MBS 32R User manual

Pressure Transmitters
Types MBS 32, MBS 32R, MBS 33, MBS 33M, MBS 2000, MBS 2050, MBS 2100, MBS 2150, MBS 2200, MBS 2250
MBS 3000, MBS 3050, MBS 3100, MBS 3150, MBS 3200, MBS 3250, MBS 3300, MBS 3350
MBS 4010, MBS 4050, MBS 4510
Elektrisk tilslutning: Se produktskilt
Electrical connection: See product label
Elektrischer Anschluss: Siehe Produktschild
Raccordement électrique: Voir étiquette du produit
Conexión eléctrica: Ver la pecatina en el producto
Connessione elettrica: Vedi etichetta sulla confezione
060R9328
060R9328
Instructions
Forbundet til kapsling
Connected to enclosure
Anschluss an das Gehäuse
Connecté au boïtier
Conectado a la caja
Collegato al corpo
IC.PI.P20.G7.53
Others:
Skærmet kabel: Skærm ikke forbundet til kapsling
Screened cable: Screen not connected to enclosure
Geschirmtes Kabel: Schirm nicht mit dem Gehäuse verbunden
Blindage: Isolé du boîtier
Cable apantallado: la pantalla no se conecta a la caja
Cavo schermato: la schermatura non è collegata all’involucro
MBS 3300/MBS 3350
Skærmet kabel: Skærm forbundet til kapsling
Screened cable: Screen connected to enclosure
Geschirmtes Kabel: Schirm mit dem Gehäuse verbunden
Blindage: Raccordé à boîtier
Cable apantallado: la pantalla se conecta a la caja
Cavo schermato: la schermatura è collegata all’involucro
IEC 60947-5-2, M12 x 1
(4 pin)
EN 175301-803-A
AMP Econoseal, J-Series AMP Super Seal,
1.5 Series (3 pin)
ISO 15170 A1-3.2-Sn/Au
MBS 32, MBS 33, MBS 32R
MBS 33M, MBS 2000
MBS 2100, MBS 2200,
MBS 3000, MBS 3100,
MBS 3200, MBS 3300
MBS 2050, MBS 2150,
MBS 2250, MBS 3050,
MBS 3150, MBS 3250,
MBS 4050, MBS 3350
MBS 4010
MBS 4510

IC.PI.P20.G7.53 http://ic.danfoss.com/ ®Danfoss A/S , DE-BD, 07-2009
060R9328
060R9328
Instructions
60 Nm
Zero adjustment Span adjustment
0 – 1 →0 – 10 bar -5 →+20% FS
-5 →+5% FS
0 – 16 →0 – 40 bar -5 →+10% FS
0 – 60 →0 – 600 bar -5 →+2.5% FS
Australian approvals:
According to N1297
American and Canadian approvals:
1. Temperature indicating equipment acc. to UL 873, file no E31024 and Process control equipment acc. to CSA
std. C22.2 no 142-M1987
2. Class I, Div. 2, Group A, B, C and D acc. to UL 1604, file no E227388 and Non-incendive electrical equipment for
use in Class I, Div. 2, Group A, B, C and D acc. CSA std. no C22.2 no 213-M1987
Must be powered by a Class 2 power supply when used in Haz. Loc. Class I, Div. 2, Group A, B, C and D.
MWP 600 bar/ 8700 psi.
Type MBS 32/ 33, MBS 32R, MBS 4050, MBS 33M
MBS 2000, MBS 2050, MBS 3000/ 3050
MBS 3100/ 3150, MBS 4010/ 4510
MBS 2100/ 2150
MBS 2200/ 2250
MBS 3200/ 3250
MBS 3300/3350
Max. ambient temperature 85º C/ 185º F 125º C/ 257º F
Temperature code T4 T3B
MBS 4510
MBS 4510
MBS 3300
MBS 3350
