Danfoss T70 2 User manual

User Manual
Remote Control
T70 2 Transmitter
www.danfoss.com

Revision history Table of revisions
Date Changed Rev
January 2019 Rebranded to Danfoss Power Solutions 0101
User Manual
T70 2 Transmitter
2 | ©Danfoss | January 2019 BC292360528568en-000101

Safety instructions General safety....................................................................................................................................................................................4
Safety warnings.................................................................................................................................................................................4
Technical description Dimensions and identification.....................................................................................................................................................6
Start up.................................................................................................................................................................................................7
Maintenance Maintenance tips..............................................................................................................................................................................9
Troubleshooting............................................................................................................................................................................... 9
Charger and battery Technical specifications...............................................................................................................................................................10
Setting up the CB70 battery charger...................................................................................................................................... 10
CB70 status LEDs............................................................................................................................................................................11
Battery charging tips.....................................................................................................................................................................11
CB70 battery charger dimensions............................................................................................................................................12
User Manual
T70 2 Transmitter
Contents
©Danfoss | January 2019 BC292360528568en-000101 | 3

T70 2 general safety
The following safety instructions must be read carefully in order to install and use the product properly
and to keep it in perfect working condition and to reduce the risk of misuse.
Potential damage to operator and product.
Do not use this product on machines in potentially explosive atmospheres unless the model is ATEX/
RATEX certified to do so.
•Strictly adhere to the installation instructions contained in this document.
•Make sure that professional and competent personnel carry out the installation.
•Ensure that all site and prevailing safety regulations are fully respected.
•Make sure that this document is permanently available to the operator and maintenance personnel.
•Keep the transmission key when the set is not in use.
•On starting each working day, check to make sure that the STOP button and other safety measures
are working.
•When in doubt, press the STOP button.
•Whenever several sets have been installed, make sure the transmitter is the right one. Identify the
machine controlled on the label for this purpose on the transmitter or by using the display (in case it
has one).
•Service the equipment periodically.
•When carrying out repairs, only use spare parts from Danfoss.
T70 2 safety warnings
Potential damage to operator and product.
Follow the guidelines below to reduce risk of injury to the operator and the product.
•Use the device with the manufacturer's battery and battery charger (if applicable).
•Only allow qualified personnel to operate the equipment.
•Always set the STOP button in the off position when not in use.
•Always press STOP before plugging in tether cable (if applicable).
•Do not operate product when visibility is limited.
•Make sure product is compatible with the machine.
•Avoid knocking or dropping the product.
•Do not use the product if a failure is detected.
Changes or modifications not approved by Danfoss can void the user's authority to operate this product.
User Manual
T70 2 Transmitter
Safety instructions
4 | ©Danfoss | January 2019 BC292360528568en-000101

Quick reference precautions
User Manual
T70 2 Transmitter
Safety instructions
©Danfoss | January 2019 BC292360528568en-000101 | 5

T70 2 dimensions and identification
The illustration and list below describe dimensions, buttons, LEDs and labels of the T70 2 transmitter.
Dimensions in mm
64
56
71
270
6
5
7
1
2
3
4
5
6
8
9
1. Label for crane identification
Option: LCD Display
2. LED
3. Maneuver push button
4. Contact key
5. Start button
6. STOP button
7. Option: Range Limiter
8. External and extractable EP70 EEPROM module
9. Battery
User Manual
T70 2 Transmitter
Technical description
6 | ©Danfoss | January 2019 BC292360528568en-000101

T70 2 start up
Use the information below to properly turn the transmitter ON (OPERATION mode).
1. Place a charged battery in the transmitter. The charge must be done following the instructions of the
Battery Chargers' Manual.
2. Turn the contact key.
3. Push and pull out the STOP button.
LED will flash orange-green pulse. If the transmitter has LCD, it displays the identification of the
machine and battery level (only if it has been pre-programmed).
LED pulse
User Manual
T70 2 Transmitter
Technical description
©Danfoss | January 2019 BC292360528568en-000101 | 7

4. Press the start button. The green LED will now light to indicate the transmitter is transmitting. Once
the Tx is connected, press any maneuver button and its corresponding relay will be activated. Check
to make sure all other maneuvers work in a coherent way with the expected movements.
LED pulse
User Manual
T70 2 Transmitter
Technical description
8 | ©Danfoss | January 2019 BC292360528568en-000101

T70 2 maintenance tips
This product is designed for use in an industrial environment that may shorten the product's lifespan. Use
these tips to maximize the lifespan of the product.
•Use the hook/belt provided with the transmitter to prevent the transmitter from falling
•Do not clean the transmitter with solvents or pressurized water; use a damp cloth or soft brush for
cleaning
•If the push buttons show signs of deterioration, contact the Authorized Technical Service for repair
•Check if the battery contacts are correct, otherwise replace them.
•Ensure that the product is supplied with AAA alkaline batteries or has a rechargeable battery
•Be sure to recharge or replace battery regularly
Maintenance tips quick reference
T70 2 troubleshooting
The transmitter has status monitoring LED's which help identify irregularities. The most common signals
are contained in the table below:
Color and frequency Pulse frequency Description Action
Green | continuous Working Operate
Green | slow pulses Latency; no action has been taken for some time Press START to return to operation
mode
Red | slow pulses Low battery signal Replace or recharge battery
Red | fast pulses EEPROM module missing or corrupt Check EEPROM and reprogram if
necessary
Red | double pulses A maneuver is activated at transmitter start up process;
may indicate hardware damage if no order is active Release maneuver or replace transmitter if necessary
Red | continuous General hardware failure Replace transmitter
User Manual
T70 2 Transmitter
Maintenance
©Danfoss | January 2019 BC292360528568en-000101 | 9

CB70 and BT06K specifications
CB70 battery charger
Specification Value
Standard AC power supply 230 Vca ± 10%, 50
Optional AC power supply 115 Vca, 60 Hz
DC power supply From 10.5 V to 35V
BT06K battery
Specification Value
Voltage 4.8 V
Capacity 600 mAh NiMH
Charging temperature From 0° to 45° C
Discharge temperature From -20° to 50° C
Autonomy 10 h (use at 50%)
Charging mode Fast (<2h) and intelligent
Weight 70.3 g
The battery is protected by an internal fuse.
Setting up the CB70 battery charger
Use the information below to properly set up the CB70 batter charger.
The battery charger has two charging compartments that can simultaneously charge two batteries.
1. Connect the charger to a power source using the cable supplied.
The red LED will switch.
User Manual
T70 2 Transmitter
Charger and battery
10 | ©Danfoss | January 2019 BC292360528568en-000101

2. Place the batteries in the compartments of the battery charger.
3. Optional: If charging multiple batteries, wait at least 5 seconds before placing the second battery in
the other compartment.
Possible damage to battery!
Be sure to charge batteries in environments with temperatures over 0° C.
CB70 status LEDs
Each battery compartment has an LED that indicates the status of the batteries' charge.
Green LED; pulsing Battery is excessively depleted
Green LED; continuous Normal charging operation mode
Green LED; off Battery charging process is complete
The battery charger must be placed and used out of the danger area.
Remote control battery charging tips
The battery lifespan is estimated to be 500 recharging cycles and is largely dependent on the conditions
of use.
To maximize the lifespan of the batteries and battery charger, follow these tips:
•Do not recharge the battery until needed, as shown with slow, red LED pulse on the transmitter
•Always charge the batteries at temperatures between 0° and 45° C
•Do not leave the battery charger or batteries in direct sunlight
•Charge batteries at least once every six months
•Avoid short circuits between the battery contacts; do not transport charged batteries in toolboxes or
next to other metal objects
•Always keep contacts clean
User Manual
T70 2 Transmitter
Charger and battery
©Danfoss | January 2019 BC292360528568en-000101 | 11

CB70 battery charger dimensions
Dimensions in mm
131.60
179.80
128.50
40
34.50
User Manual
T70 2 Transmitter
Charger and battery
12 | ©Danfoss | January 2019 BC292360528568en-000101

User Manual
T70 2 Transmitter
©Danfoss | January 2019 BC292360528568en-000101 | 13

User Manual
T70 2 Transmitter
14 | ©Danfoss | January 2019 BC292360528568en-000101

User Manual
T70 2 Transmitter
©Danfoss | January 2019 BC292360528568en-000101 | 15

Danfoss Power Solutions is a global manufacturer and supplier of high-quality hydraulic and
electric components. We specialize in providing state-of-the-art technology and solutions
that excel in the harsh operating conditions of the mobile off-highway market as well as the
marine sector. Building on our extensive applications expertise, we work closely with you to
ensure exceptional performance for a broad range of applications. We help you and other
customers around the world speed up system development, reduce costs and bring vehicles
and vessels to market faster.
Danfoss Power Solutions – your strongest partner in mobile hydraulics and mobile
electrification.
Go to www.danfoss.com for further product information.
We offer you expert worldwide support for ensuring the best possible solutions for
outstanding performance. And with an extensive network of Global Service Partners, we also
provide you with comprehensive global service for all of our components.
Local address:
Danfoss
Power Solutions GmbH & Co. OHG
Krokamp 35
D-24539 Neumünster, Germany
Phone: [phone]
Danfoss
Power Solutions ApS
Nordborgvej 81
DK-6430 Nordborg, Denmark
Phone: [phone]
Danfoss
Power Solutions (US) Company
2800 East 13th Street
Ames, IA 50010, USA
Phone: [phone]
Danfoss
Power Solutions Trading
(Shanghai) Co., Ltd.
Building #22, No. 1000 Jin Hai Rd
Jin Qiao, Pudong New District
Shanghai, China 201206
Phone: [phone]
Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products
already on order provided that such alterations can be made without subsequent changes being necessary in specifications already agreed.
All trademarks in this material are property of the respective companies. Danfoss and the Danfoss logotype are trademarks of Danfoss A/S. All rights reserved.
©Danfoss | January 2019 BC292360528568en-000101
Products we offer:
•DCV directional control
valves
•Electric converters
•Electric machines
•Electric motors
•Hydrostatic motors
•Hydrostatic pumps
•Orbital motors
•PLUS+1®controllers
•PLUS+1®displays
•PLUS+1®joysticks and
pedals
•PLUS+1®operator
interfaces
•PLUS+1®sensors
•PLUS+1®software
•PLUS+1®software services,
support and training
•Position controls and
sensors
•PVG proportional valves
•Steering components and
systems
•Telematics
