Danfoss Ikargo1 User manual

User Manual

Ikargo1 Transmitter

Remote Control

www.danfoss.com

Revision history Table of revisions

Date Changed Rev

February 2021 Updated Ikargo1 name 0102

February 2019 Rebranded to Danfoss. 0101

User Manual

Ikargo1 Transmitter

2 | ©Danfoss | February 2021 BC295377198224en-000102

Safety instructions General safety....................................................................................................................................................................................4

Safety warnings.................................................................................................................................................................................4

Technical description Dimensions and identification.....................................................................................................................................................6

Start up.................................................................................................................................................................................................7

Maintenance Maintenance tips..............................................................................................................................................................................8

Troubleshooting............................................................................................................................................................................... 8

Charger and battery BC70K and BT11K specifications.................................................................................................................................................9

BC70K Battery Charger Set-up.....................................................................................................................................................9

BC70K Charger LEDs Status ......................................................................................................................................................... 9

Battery Charging Recommendations..................................................................................................................................... 10

BC70K Battery Charger Dimensions........................................................................................................................................10

User Manual

Ikargo1 Transmitter

Contents

©Danfoss | February 2021 BC295377198224en-000102 | 3

Ikargo1 General Safety

The following safety instructions must be read carefully to install and use the product properly, and to

keep it in perfect working condition, and to reduce the risk of misuse.

•Strictly adhere to the installation instructions contained in this document.

•Make sure that professional and competent personnel carry out the installation.

•Ensure that all site and prevailing safety regulations are fully respected.

•Make sure that this document is permanently available to the operator and maintenance personnel.

•Keep the transmitter out of reach of non-authorized personnel.

•Remove the transmission key when the set is not in use.

•Check each working day the STOP button and other safety measures. When in doubt, press the STOP

button.

•Whenever several sets have been installed, make sure the transmitter is the right one. Identify the

machine controlled on the label for this purpose on the transmitter or by using the display (in case it

has one).

•Service the equipment periodically.

•When carrying out repairs, use spare parts supplied by Danfoss only.

Warning

Potential damage to the operator or the product. Do not use this product on machines in potentially

explosive atmospheres unless the model is ATEX/RATEX certified to work in such conditions.

Ikargo1 Safety Warnings

Potential damage to operator and product.

Follow the guidelines below to reduce risk of injury to the operator and the product.

•Use the device with the manufacturer's battery and battery charger (if applicable).

•Only allow qualified personnel to operate the equipment.

•Always set the STOP button in the off position when not in use.

•Always press STOP before plugging in tether cable (if applicable).

•Do not operate product when visibility is limited.

•Make sure product is compatible with the machine.

•Avoid knocking or dropping the product.

•Do not use the product if a failure is detected.

Changes or modifications not approved by Danfoss can void the user's authority to operate this product.

User Manual

Ikargo1 Transmitter

Safety instructions

4 | ©Danfoss | February 2021 BC295377198224en-000102

Quick reference precautions

ikargo

Tx Cr 1

Cr 1

User Manual

Ikargo1 Transmitter

Safety instructions

©Danfoss | February 2021 BC295377198224en-000102 | 5

IKARGO dimensions and identification

Dimensions in mm

65 54

203

1. Range limiter

2. RGB display

3. Status LED

4. Maneuver push button

5. Multi-key/START

6. STOP button

7. Movement pictogram housings

8. BT11K battery housing

9. Extractable EEPROM housing

User Manual

Ikargo1 Transmitter

Technical description

6 | ©Danfoss | February 2021 BC295377198224en-000102

IKARGO start up

In order to turn the transmitter on (OPERATION mode), follow the next steps.

1. Insert the charged BT11K battery model in the transmitter and ensure the EEPROM module is in place.

The battery must be charged according to the charger manual's instruction.

ikargo

crane ??

ikargo

Pulso LED

Display

LED pulse

ikargo

BT11K

EEPROM

module

2. Turn the multi-key from the "0" position to the "1" position.

The multi-key cannot be removed while in the "1" position.

ikargo

crane ??

ikargo

Pulso LED

Display

LED pulse

ikargo

BT11K

EEPROM

module

3. Push and pull out the stop button.

The LED will blink in blue-green colors and the battery level will appear in the display. It is

recommended to introduce the machine identifier (example: EOT crane number).

ikargo

crane ??

ikargo

Pulso LED

Display

LED pulse

ikargo

BT11K

EEPROM

module

4. Press START with the multi-key until the radio link is performed.

The LED color will turn green to indicate that the transmitter and receiver link is confirmed. After

confirmation, press the maneuver buttons to verify corresponding movements.

ikargo

crane ??

ikargo

Pulso LED

Display

LED pulse

ikargo

BT11K

EEPROM

module

User Manual

Ikargo1 Transmitter

Technical description

©Danfoss | February 2021 BC295377198224en-000102 | 7

Ikargo1 maintenance tips

This product is designed for use in an industrial environment that may shorten the product's lifespan. Use

these tips to maximize the lifespan of the product.

•Use the hook/belt provided with the transmitter to prevent the transmitter from falling

•Do not clean the transmitter with solvents or pressurized water; use a damp cloth or soft brush for

cleaning

•If the push buttons show signs of deterioration, contact the Authorized Technical Service for repair

•Check if the battery contacts are correct, otherwise replace them.

•Ensure that the product is supplied with AAA alkaline batteries or has a rechargeable battery

•Be sure to recharge or replace battery regularly

Maintenance tips quick reference

Ikargo1 troubleshooting

The transmitter has status monitoring LED's which help identify irregularities. The most common signals

are contained in the table below:

Color and frequency Pulse frequency Description Action

Green | continuous Working Operate

Green | slow pulses Latency; no action has been taken for some time Press START to return to operation

mode

Red | slow pulses Low battery signal Replace or recharge battery

Red | fast pulses EEPROM module missing or corrupt Check EEPROM and reprogram if

necessary

Red | double pulses A maneuver is activated at transmitter start up process;

may indicate hardware damage if no order is active Release maneuver or replace

transmitter if necessary

Red | continuous General hardware failure Replace transmitter

User Manual

Ikargo1 Transmitter

Maintenance

8 | ©Danfoss | February 2021 BC295377198224en-000102

BC70K and BT11K specifications

BC70K battery charger

Specification Value

AC power supply 110 – 230 V, 50/60 Hz, ± 10%, automatic switching

DC power supply, nominal 12 – 24 V

BT11K battery

Specification Value

Voltage 3.7 V

Capacity 1130 mAh Li-Ion

Charging temperature 0°C to 45°C

Discharge temperature -20°C to 60°C

Charging mode Fast (<2.5 h) and intelligent

Weight 23 g

BC70K Battery Charger Set-up

The battery charger has two charging compartments that can simultaneously charge two BT11K

batteries. Use the information below to set up the BC70K battery charger.

1. Connect the charger to a power source using the cable provided.

The red LED will switch on if the charger is properly connected.

2. Place the batteries in the charger.

3. Optional: If charging two batteries, wait at least five seconds before inserting the second battery into

the compartment.

Warning

Possible damage to battery.

Be sure to charge batteries in environments with temperatures over 0°C.

BC70K Charger LEDs Status

The BC70K charger has a LED for each compartment (BAT 1 and BAT 2) and a common indicator

(POWER).

LED color / frequency Description

Green LED / pulsing (BAT 1, BAT 2) The battery is being charged

Green LED / continuous (BAT 1, BAT 2) The battery is completely charged

Red LED / pulsing or continuous (BAT 1, BAT 2) The battery charger fault

Red LED / continuous (POWER) The charger is properly connected to power source

User Manual

Ikargo1 Transmitter

Charger and battery

©Danfoss | February 2021 BC295377198224en-000102 | 9

Battery Charging Recommendations

The battery lifespan is estimated to 500 recharging cycles and is largely dependent on the conditions of

use. To maximize the lifespan of the batteries and battery charger, follow these recommendations:

•Do not recharge the battery until it is completely flat, as shown with red LED slow pulse on the

transmitter

•Always charge the batteries at temperatures between 0° and 45°C (the batteries will not become fully

charged at temperatures exceeding 45°C)

•Do not leave the battery charger or batteries in a direct sunlight

•Charge batteries at least once every six months

•Avoid short circuits between the battery contacts; do not carry charged batteries in toolboxes or next

to other metal objects (keys, coins, etc.)

•Always keep contacts clean

BC70K Battery Charger Dimensions

Dimensions (mm)

97.15

103.31

30.10

23.50

127.90

2.57

User Manual

Ikargo1 Transmitter

Charger and battery

10 | ©Danfoss | February 2021 BC295377198224en-000102
