Printer features
Media Battery
Quick Start Guide
This guide provides information on the daily use of the DP-330/330L printer.
For additional information, please refer to the DP-330/330L User Guide.
NOTE:
When using
2” paper,
install spacer.
Press button to see
battery charge level.
4LED 100% charge
3LED 75%
2LED 50%
1LED 25%
Loosen hand strap
(not pictured) to
access battery
door.
Rotate knob 180o
to unlock battery
door.
Drop in battery.
Close battery door
and rotate knob
180oto lock.
Press Paper door release button to
open the paper compartment door.
Pull small leader of paper out and
close paper door. “ Clicks” when
properly closed.
Disposal
Please dispose the batteries separately and free of cost at your
sales agency or the designated local collecting points.
Therefore please consider the national recycling standards!
Disassembly and removal of the batteries are described in the
User Guide.
Paper door release button
USB Data Port
Power Port
Control Panel
Paper Door
Tear paper
towards back of
printer

© 2018 DASCOM , Drivers, User Manuals, and SW Utilities available @ www.dascom.com
Control Panel indicators
Install the Config Tool
Dascom Representatives
Americas Dascom Americas Corp 34 Lakeview Court Verona, VA 24482, USA Phone: [phone]
UK DASCOM GB Ltd Hart House, Priestley Road Basingstoke, Hampshire, RG24 9PU Phone: [phone]
Germany DASCOM Europe GmbH Heuweg 3 D-89079 Ulm Phone: [phone]
France DASCOM Europe GmbH 117 Avenue Victor Hugo 92100 Boulogne-Billancourt Phone: [phone]
Singapore (AP) DASCOM AP Pte Ltd 2 Jurong East Street 21 #05-42, IMM Building, Singapore 609601 Phone: [phone]
Status
Power light
Charge light
Caution light
Buzz
Buffer has data
Green light-twinkle
Change according to
power
Buffer is empty
Green light-on
Standby
Change according to the Buffer
status
Off
/
Setting mode
(Config tools mode)
Orange light-on
Off
/
Open cover/paper out
Change according to the Buffer
status
Red light-on
Buzz/
2 seconds
Paper on the peeler
Orange light-on
/
Black mark/label position is
error
Red light-twinkle
/
Print head is overheating
Green light-breathing
light
/
Print head is ultracold
temperature
Red light is on
Green light-breathing
light
/
EEPROM is error
Red light is on
Red light-on
/
Battery power read error
Change according to the Buffer
status
Off
Green light-on
/
Power saving mode
Green light-breathing light
Off
Off
/
Download mode
At the same time, the three lights green-red alternating cycle flicker: Green-red-green-
red.
/
Loading
At the same time, the three lights flicker with orange color.
/
DP-330/330L Quick Start Guide
21.511.R
3. When the progress bar is full,
the right picture will be shown, click
“Finish” to complete the installation.
2. Click “next”, enter
installation interface.
1. Download the latest setup tool
“Config Tool” from official
website .
