F14GW
Short form specifications
Exterior top is one-piece 16-gauge stainless steel, with integral 2.12”
(5.4 cm) square nosing on front and 4.00” (10.1 cm) high by 2.00” (5.1
cm) thick backsplash on rear. Interior sides are 22-gauge stainless steel.
Top has (2) to (6) 11.87” x 19.87” (30.2cm x 50.5 cm) openings to hold
pans (supplied by others). Unit has a single 16-gauge stainless steel
tank with 1.00” (2.5 cm) drain with gate valve. Units 32”, 48” and 60”
have (1) 20,000 BTU natural gas burner with safety pilots evenly spaced
under the tank and (1) control. 72 and 88” units have (2) 20,000 BTU
natural gas burners with safety pilots evenly spaced under the tank and
(2) controls. Control is mounted in front edge of 8” wide stainless steel
plate shelf.
Natural gas connection is 1/2”; a gas regulator is supplied. Hot water con-
nection is 1/2”, located 36” (91.4 cm) above the floor.
Manual fill faucet that extends (2.5” (6.4cm) above backsplash is stan-
dard.
Lower portion of unit to have a 22-gauge stainless steel open shelf.
Unit is mounted on 6.13” (15.6 cm) high adjustable stainless steel legs.
NOTE: Model F14GW hot food tables are designed to be operated with
water in the tank only. Use of the equipment without water in the tank
will result in damage to the equipment and will void the warranty.
Optional Accessories & Modifications
906A Stainless steel end
505B Stainless steel back
906E Laminate end
505A Laminate back
204C Auto fill assy (mechanical float)
204D Auto fill assy (electric probe)
1030A Cutting board (.5” x 10” composite)
220 LP gas
Model F14GW688
Shown with optional cutting board
31.50” (80 cm) Deep Single-Tank Natural Gas Hot Food Tables

The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • [phone] • Fax [phone] • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2002 The Delfield Company. All rights reserved. Printed in U.S.A.
DS14GW 03/02
31.50” (80 cm) Deep Single-Tank Natural Gas Hot Food Tables
F14GW
PLAN
32.00"
81.3cm
88.00"
223.5 cm
31.50"
80.0 cm
72.00"
182.9cm
60.00"
152.4cm
48.00"
121.9cm
PLAN VIEWPLAN VIEW PLAN VIEW PLAN VIEW
40.0"
101.6 cm
ELEVATION ELEVATION VIEW ELEVATION VIEW ELEVATION VIEW ELEVATION VIEW
GATE VALVE IS 20" A.F.F.
1.00"
2.5cm
G
D
FRONT OF UNIT
D
GC
7.5"
19cm
HW=HOT WATER SUPPLY,
1/2" FPT—36" A.F.F.
GC=GAS CONNECTION, 1/2"
FPT, 20–20000 BTU,
D=1" FPT DRAIN—25" A.F.F.
4.0"
10.2cm
3.12"
7.9cm
36"
91.4cm
6.12"
15.6cm
7.62"
19.4cm
28"
71.1cm
31.5"
80cm
15.56"
39.5cm
40"
101.6cm
26.37"
66.97cm
RIGHT END VIEW
ALL MODELS
FI4GW232 F14GW460F14GW348 F14GW572 F14GW688
MECHANICAL ACCESS PLAN VIEW ALL
MODELS
Mechanical Data–Standard Unit
MODEL NUMBER OF NUMBER OF SHIP
NUMBER OPENINGS* GAS BURNERS D G WEIGHT BTU
F14GW232
2 1 5.56”/14.1cm 12”/30.5cm 256 lbs/ 116 kg 20000
F14GW348
3 1 6.56”/16.7cm 16”/40.6cm 326 lbs/ 148 kg 20000
F14GW460
4 1 5.62”/14.3cm 22”/55.7cm 396 lbs/ 180 kg 20000
F14GW572
5 2 4.69”/11.9cm 12”/30.5cm 456 lbs/ 207 kg 40000
F14GW688
6 2 5.75”/14,6cm 20”/50.8cm 536 lbs/ 243 kg 40000
*Each opening measures 11.87” x 19.87” (30.2cm x 50.5cm)
FI4GW232 F14GW460F14GW348 F14GW572 F14GW688
