Short Form Specifications
Exterior top is one-piece 16-gauge stainless steel, with integral 2.12”
(5.6cm) square nosing on front and 4” (10.1cm) high by 2.00” (5.1cm) thick
backsplash on rear. Interior sides are 22-gauge stainless steel.
Top to have 11.87”x 19.87” (30.2cm x 50.5cm) openings to hold pans (sup-
plied by others). Unit has (1) 16-gauge stainless steel tank with 1” (2.5cm)
drain with gate valve. Units 32”, 48” or 60” in length have (1) 5 kw electric
immersion heater; 72” and 88” lengths have (2) 5 kw electric immersion
heaters located beneath openings. Heaters are standard at 240V, single
phase (*208V available upon request). Control to be mounted in front edge
of 8” (20.3cm) wide stainless steel plate shelf.
Manual fill faucet that extends 2.5” (6.4cm) above backsplash is standard.
Lower portion of unit to have 22-gauge stainless steel open shelf.
Electrical connections are 120/240V. Unit must be hard wired.
Unit is mounted on 6.13” (15.6cm) high adjustable stainless steel legs.
NOTE: Model F14EW hot food tables are designed to be operated with water
in the tank only. Use of the equipment without water in the tank will result in
damage to the equipment and will void the warranty.
F14EW
31.50” (80 cm) Deep Electric Hot Food Tables — Single Tank
Model F14EW232
Optional Accessories & Modifications
906A Stainless steel end
505B Stainless steel back
906E Laminate end
505A Laminate back
204C Auto fill assy (mechanical float)
204D Auto fill assy (electric probe)
1030A Cutting board (.5” x 10” composite)
108 Locks
726A Dry drawers — 19”
726B Dry drawers — 27”
726C Dry drawers —32”
216 *Three phase electrical system
* Inclusion of this option will alter the electrical specifications of
the unit.
Shown with optional cutting board

The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • [phone] • Fax [phone] • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2002 The Delfield Company. All rights reserved. Printed in U.S.A.
DSF14EW 04/02
MODEL NUMBER OF AMPS SHIP
NUMBER OPENINGS 240 / 208 OPT. WEIGHT
F14EW232
2 21.0/24.0 316 lbs / 143 kg
F14EW348
3 21.0/24.0 440 lbs / 199 kg
F14EW460
4 21.0/24.0 500 lbs / 227 kg
F14EW572
5 42.0/48.0 560 lbs / 254 kg
F14EW688
6 42.0/48.0 660 lbs / 299 kg
PLAN VIEW
ELEVATION VIEW
ELEVATION VIEW
ELEV. VIEW
PLAN VIEWPLAN VIEWPLAN VIEW
ELEVATION VIEW
PLAN VIEW
ELEVATION VIEW
END VIEW ALL MODELS
Mechanical Data–Standard Unit
Electrical connections are 120/240 volt or optional 120/208 volt. (120 volt circuit is required for
the auto-fill system.) Designed for wet operation only.
ELECTRIC SUPPLY, STUB UP 4" FROM FLOOR.
ELECTRICAL CONNECTION 120/240V; 5KW FOR 32",
48" AND 60" UNITS AND 10KW FOR 72" AND 88"
UNITS.
HOT WATER SUPPLY. 1/2" FPT CONNECTION
36" ABOVE FLOOR.
WASTE, 1" FPT 20" ABOVE FLOOR.
FRONT OF UNIT
DRAIN
15.5"
39.4cm
4.0"
10.2cm
JUNCTION
BOX
HOT WATER SUPPLY
3.12"
7.9cm
8.0"
20.3cm
MECHANICAL DATA
F14EW
31.50” (80 cm) Deep Electric Hot Food Tables — Single Tank
36"
91.4cm
6.12"
15.6cm
7.62"
19.4cm
28"
71.1cm
31.5"
80cm
15.56"
39.5cm
NOTE: SHOWN DRAIN
IS INCORRECT...ACTUAL
LOCATION IS CENTER
OF TANK
40"
101.6cm
F14EW232 F14EW348 F14EW688F14EW460 F14EW572
88.00”
223.5cm
31.5”
80cm
72.00”
182.9cm
60.00”
152.4cm
