MERIDIAN SERIES® HEATED REACH INS
Project __________________________
Item____________________________
Quantity _________________________
CSI Section 11400
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.deleld.com
Phone: [phone]
Fax: [phone]
Email: info@deleld.com
Approval _________________
Date____________________
SPECIFICATIONS
Exterior: Cabinet front, and shroud shall be
22-gauge stainless steel. Exterior sides shall
be aluminum. Facing of shroud shall be easily
removable without the use of tools.
Cabinet interior shall be anodized aluminum. Bottom
& top of liner shall be die-stamped to provide
radius corners and a recessed bottom. Base shall be
fully insulated with high-density foamed in place
polyurethane.
Interior shall have three wire shelves per door section.
Shelf support pilasters shall be heavy-duty with
shelves adjustable at 1.0” (2.5 cm) increments. Units
are mounted on 6” (15.24 cm) metal legs.
Doors: Solid doors shall have a 22-gauge stainless
steel exterior & anodized aluminum interior liner.
Doors shall be fully insulated with high density
foamed in place polyurethane. Each door shall have
two self-closing, cam-lift style hinges. Doors shall be
easily removable without use of tools. Door gaskets
shall be magnetic snap-in style to allow simple
replacement. Door handles shall be recessed.
• Please specify right or left hand hinging at time of
order.
Glass doors shall be constructed with extruded
aluminum frames and shall utilize insulated double-
pane construction. Glass doors shall be provided with
self-closing, cam-lift style hinges, and shall be easily
removable without the use of tools.
Dual Voltage Models Only: Electrical connections
shall be 115/208-240 volt, 60 hertz, single phase,
and must be hard-wired to the junction box located on
top of the unit.
Heating Assembly: Cabinets to be designed to
maintain temperature up to 200ºF. Helical shaped,
tubular nned strip heating elements. High speed blower
to provide uniform airow in cabinet. Removable/
replaceable heating system. No exposed elements inside
cabinet. Fan and heating elements service accessible
without tools. Temperature to be controlled by an
adjustable electronic thermostat equipped with an analog
display. On/off switch in front.
MODELS:
 MHR1-S Single section  MHR2-S Two section  MHR1-SH Single section
Full height solid door Full height solid doors Half height solid door
 MHR1-G Single section  MHR2-G Two section  MHR2-SH Two section
Full height glass door Full height glass doors Half height solid doors
 MHR1-GH Single section  MHR1-GH Two section
Half-height glass door Half height glass doors
CSI Section 11400
MERIDIAN SERIES®
Heated Reach Ins
MHR2-GHSH
STANDARD FEATURES
• Shroud removes without tools, for easy condenser
maintenance
• Built in door locks
• Durable stainless steel doors and shroud, for lasting good
looks
• New high-density foam insulation cuts energy costs
• Big, easy grip handles are easy to nd, don’t intrude into
kitchen trafc
• Attractive aluminum side panels are easy to clean and
corrosion resistant
• Heavy-duty hinges with stay open feature
• Refrigeration system is located outside the food zone, more
space for product storage
• Mini watt door heaters eliminate condensation with
minimal energy cost
• Easy to read dial thermometer
• Tri seal door gaskets lower energy costs with a unique
insulating design
• Chrome shelves
• Aluminum interior stands up to food acids without
corroding
• Lots of interior storage space for the money
• Rugged metal legs, adjustable to compensate for
uneven oors
OPTIONS AND ACCESSORIES
 Stainless steel exterior sides
 Stainless steel interior
 Stainless steel kick plate
 Door and end laminate
 Stainless steel exterior back
 Digital thermometer
 TXV
 Chrome Shelves
 Tray Slides
 220/50/1 electrical
 Electronic control
 Stainless steel legs
 Casters

Meridian Series® Heated Reach-Ins
Model #__________
CSI Section 11400
Printed in the USA.
08/03
DSMRH
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.deleld.com
Phone: [phone]
Fax: [phone]
Email: info@deleld.com
PLAN VIEW ALL MODELS PLAN VIEW ALL MODELS
ELEVATION VIEW MHR2-GELEVATION VIEW MHR1-G
DOOR CLEARANCE DETAIL
ALL MODELS
29”
73.7cm 56”
142.2cm
81”
205.7cm
27.25”
69.1cm
END
SECTION VIEW
ALL MODELS
PERSPECTIVE VIEW
ALL MODELS
34”
86.4cm 34”
86.4cm
58”
147.3cm
25”
63.5cm 52”
132.1cm
6.00
15.2cm
34.0”
86.4cm
12.14”
30.8cm
56.76”
144.2cm
26.48”
67.3cm
3.80”
9.7cm
MECHANICAL DATA
SHELVES NO UNIT BTU/HR CAB BTU/HR SHIP NEMA
MODEL VOLTAGE AMPS STORAGE SQ. FT. SHELVES H.P. LOAD SYSTEM CAP WEIGHT PLUG
STAINLESS DOORS
MHR1-S 120/208-240 9.0 24.96 12.81 3 NA NA NA 420 NA
MHR2-S 120/208-240 16.0 51.92 27.54 6 NA NA NA 562 NA
MHR1-SH 120/208-240 9.0 24.96 12.81 3 NA NA NA 420 NA
MHR2-SH 120/208-240 16.0 51.92 27.54 6 NA NA NA 562 NA
GLASS DOORS
MHR1-G 120/208-240 9.0 24.96 12.81 3 NA NA NA 430 NA
MHR2-G 120/208-240 16.0 51.92 27.54 6 NA NA NA 582 NA
MHR1-GH 120/208-240 9.0 24.96 12.81 3 NA NA NA 430 NA
MHR2-GH 120/208-240 16.0 51.92 27.54 6 NA NA NA 582 NA
J-BOX LOCATED
75" AFF FOR ST'D BOXES
83" AFF FOR RI/RT'S
8" (1) door units
11" (2&3) door units
6" (1) door units
23" (2) door units
39" (3) door units
Front of unit
MECHANICAL DETAIL
