Delta ASDA-A2 Series User manual

Revision February, 2017 i
Preface
Thank you for purchasing ASDA-A2. This user manual provides the related information of ASDA-
A2R series servo drive and ECMA series servo motors. This manual includes:
Installation and inspection of servo drive and servo motor
The configuration of servo drive
Procedures of trial run
Control function and adjustment methods of servo drive
Parameters
Communication protocol
Maintenance and inspections
Troubleshooting
This manual addresses personnel with the following qualifications:
Servo system designers
Installation or wiring personnel
Trial and tuning personnel
Maintenance and inspection personnel
Before using the product, please read through this manual carefully in order to ensure the correct
use of the product. In addition, please place this manual safely for quick reference whenever is
needed. Please follow the rules below if you have not finished reading this manual yet.
No water, corrosive gas and inflammable gas are allowed in installation environment.
Three-phase power is prohibited to connect to U, V and W connector when wiring. It is
possible to damage the servo drive.
Ground is a must.
Do not disconnect the servo drive, motor or change the wiring when connecting to the
power.
Be ensured that the emergency stop can be activated anytime before connecting to the
power and operation.
Do not touch the heat sink to avoid scald before connecting to the power and operation.
If you have any enquiry, please contact the distributors or DEALTA customer service center.

Preface ASDA-A2
ii Revision February, 2017
Safety Precautions
ASDA-A2 series is the high resolution and open type servo drive. It should be installed in a
shielded control box during operation. This servo drive uses precise feedback control and the
digital signal processor with high-speed calculation function to control the current output which
generated by IGBT so as to operate three-phase permanent magnet synchronous motors (PMSM)
and to achieve precise positioning.
ASDA-A2 is applicable on industrial application and is suggested to be installed in the panel-board
of the user manual. (Servo drives, wire rod and motors all should be installed in the environment
which complies with the minimum requirement of UL Level 1.)
Pay special attention to the following safety precautions anytime during inspection, installation,
wiring, operation and examination.
The symbol of danger, warning and stop represent:
It indicates the potential hazards. It is possible to cause severe injury or fatal harm if not
follow the instructions.
It indicates the potential hazards. It is possible to cause minor injury or lead to serious
damage of the product or even malfunction if not follow the instructions.
It indicates the absolute prohibited activity. It is possible to damage the product or
cannot be used due to malfunction if not follow the instructions.
Inspection
Please follow the instruction when using servo drive and servo motor, or it is possible
to cause fire or malfunction.
Installation
It is prohibited to expose the product with the environment which containing water,
corrosive gas, inflammable gas, etc. Or it is possible to cause electric shock or fire.
Wiring
Please connect the ground terminal to class-3 ground system (under 100 Ω); poor
grounding may result in electric shock or fire.
Do not connect the three-phase source to the motor output terminal U, V and W. Or it
is possible to cause personnel injury or fire.
Please tighten the screws of the power and motor output terminal. Or it is possible to
cause fire.
Please connect wiring according to the wire rod in order to prevent any danger.

ASDA-A2 Preface
Revision February, 2017 iii
Operation
Before the operation, please change the parameter setting value according to the
needs. If it is not adjusted to the correct setting value, it is possible to lead to
malfunction of the machine or the operation might out of control.
Before the machine starts to operate, please be ensured the emergency stop can be
activated anytime.
When power on, please make sure the motor shaft stands still and will not operate
because of mechanical inertia or other causes.
During the operation, it is prohibited to touch any rotating motor parts. Or it is
possible to cause personnel injury.
In order to prevent any accident, please separate the couplings and belts of the
machine and isolate them. Then conduct the initial trial run.
If users fail to operate the machine properly after the servo motor connects to the
equipment, it would cause the damage of the equipment and lead to the personnel
injury.
In order to prevent the danger, it is strongly recommended to check if the motor can
operate normally without load first. Then, operate the motor with load.
Do not touch the heat sink of the servo drive. Or it is possible to cause scald due to
the high temperature.
Maintenance and Inspection
It is prohibited to touch the internal parts of the servo drive and servo motor. Or it is
possible to cause electric shock.
It is prohibited to disassemble the panel of the servo drive when turning on the
power. Or it is possible to cause electric shock.
Do not touch the ground terminal within 10 minutes after turning off the power. Or the
residual voltage may cause electric shock.
Do not disassemble the motor. Or it is possible to cause electric shock or personnel
injury.
Do not change the wiring when the power is on. Or it is possible to cause electric
shock or personnel injury.
Only the qualified electrical and electronics professionals can install, wire and
maintain the servo drive and servo motor.

Preface ASDA-A2
iv Revision February, 2017
Main Circuit Wiring
Do not put the power cable and the encoder cable in the same channel and bond
them together. Please separate the power cable and the encoder cable for at least
30 centimeters (= 11.8 inches) when wiring.
Please use stranded wires and multi-core shielded-pair wires for the encoder cables
and encoder feedback cables. The maximum length of command input cable is 3
meters (= 9.84 feet) and the maximum length of feedback cable is 20 meters (=
65.62 feet).
The high voltage might remain in the servo motor even when the power is off. Do not
touch the power terminal temporally (at least 10 minutes). Please conduct the
inspection not until the indicator light, CHARGE is off.
Do not turn the power on and off too often. If continuous power on and off is needed,
please be ensured the interval is one minute at most.
Terminal Wiring of the Main Circuit
When wiring, please disassemble the terminal socket from the servo drive.
One terminal of the terminal socket for one electric wire only.
When inserting the electric wires, do not connect the conductor to the adjacent wire.
Before connecting to the power, please inspect and be ensured the wiring is correct.
NOTE
If there is any difference of each version, please refer to DELTA’s website
(http://www.delta.com.tw/industrialautomation/) for the latest information.
