DEMA Super Sink Series Assembly instructions

I-1279 REV. B-44805 3/5/2019 PAGE 1 OF 9
Sink Chemical Dispensing System
Installation and Setup Guide
SuperSink accurately blends proportioned chemical with water for cleaning, sanitizing or other related
needs in a commercial kitchen. The dispensing system uses a pilot drive water valve designed for
easy maintenance. SuperSink is engineered with 1055 approved back flow protect using DEMA’s Air
Gap or Action Gap proportioning system.
Warnings
All installations must conform to local plumbing codes and use approved backflow prevention devices.
A pressure indicating tee is to be installed with existing faucets according to local plumbing codes in the
state of Wisconsin and any other state that requires the use of a pressure indicating tee.
ALWAYS WEAR PROTECTIVE CLOTHING AND EYEWEAR WHEN WORKING WITH CHEMICAL
PRODUCTS.
Super Sink Dual
Super Sink Single

I-1279 REV. B-44805 3/5/2019 PAGE 2 OF 9
Installation (Super Sink Single)
WARNING: INSTALLATION OF DEMA PRODUCTS MUST MEET ALL APPLICABLE PLUMBING
CODES AND REGULATIONS ESTABLISHED BY NATIONAL, CITY, COUNTY, PARISH, PROVINCIAL
OR OTHER AGENCIES. IT IS POSSIBLE THAT PLUMBING CODES AND REGULATIONS REQUIRE
THAT A CERTIFIED INSTALLATION CONTRACTOR OR ENGINEER PERFORM THE PLUMBING
INSTALLATION.
1. Locate where to install the SuperSink Dispenser.
Keep the following in mind
a. Mount near or over the sink
b. Mount so that discharge hoses will be
above the water line
c. Best access to water hookup.
2. Remove the SuperSink cover by pressing the
black plastic tabs on each side and swing top
away from the mounting bracket.
3. Determine if the water supply connection should
be on the right of left hand side of the dispenser.
a. The entire valve and proportioner
assembly can be removed from the
mounting bracket (see illustration on this
page).
b. The water supply connection can be
moved to either side by removing the
plastic, orange retainer clips, the plug and
the water connection fitting. Then replace
the retainer clips.
Plug
Water
Connection
Fitting
Retainer Clips
(Orange)
Press in black tabs on
each side and swing
top of stainless steel
cover away from the
mounting bracket.
Valve Retainers –
Squeeze inward to
release and remove
valve/proportioner
assembly

I-1279 REV. B-44805 3/5/2019 PAGE 3 OF 9
Installation Continued…
4. Locate the key shaped mounting holes in the back plate. Mount the SuperSink using the mounting
screws and anchors that are included in the installation kit.
5. Install the desired metering tip by threading tip into the proportioner chemical pick-up elbow.
6. Cut the chemical supply tube to the length allows the foot valve to rest on the bottom of the chemical
container. Slide the ceramic weight onto the chemical supply tube until it is against the foot valve. This
will keep the foot valve at the bottom of the chemical container.
a. Note: Chemical containers cannot be greater than 6 feet (1.8M) below the SuperSink dispenser.
7. Cut the outlet tubing to the desired length. When using the system to fill sinks, it is recommended to cut
the out let tubing so that it is above the intended fill line (water line).
8. Install the SuperSink cover by positioning the tab at the bottom of the cover near the dispenser
discharge and push the cover back over the valve assembly until the tabs latch on both sides of the
unit.
9. Connect the water line to the inlet of the SuperSink.
a. Note: The water pressure must be between 20psi and 95psi. Optimum chemical induction occurs
between 30psi –60psi.
b. The water inlet options for the SuperSink are:
i. Garden Hose (female)
ii. 3/8” Elbow Brass Compression Fitting (suitable for 3/8” OD soft copper water line)
iii. 3/8” Straight Brass Compression Fitting (suitable for 3/8” OD soft copper water line)
iv. 3/8” John Guest Push-on Water Fitting (suitable for 3/8” OD soft copper or LDPE tubing)
v. 3/8” Elbow John Guest Push-on Water Fitting (suitable for 3/8” OD soft copper or LDPE
tubing)
vi. 3/8” Brass Barb Water Fitting (suitable for 3/8” LDPE tubing)
b. Faucet adapter kits are often used to provide
water source to the dispenser. DEMA
recommend P/N 68.4 NSF which includes
faucet adapters for T&S, Chicago and Fisher
faucets.
Key Shaped
Mounting Holes
Outlet Fitting –
Slide the Outlet
Tubing Over
The Outlet
Fitting
Proportioner
Elbow –
Metering Tip
Installs At This
Fitting By
Threading The
Metering Tip
Into The End Of
Fitting

I-1279 REV. B-44805 3/5/2019 PAGE 4 OF 9
Installation (Super Sink Dual)
Pull down on bottom
clip. Then swing Dual
Super Sink cover up
to remove from unit.
#8 HI- LOW SCREWS
FOR VALVE(S) REMOVAL
FROM BACK PLATE
(DUAL SUPER SINK ONLY)

I-1279 REV. B-44805 3/5/2019 PAGE 5 OF 9
Water
Connection
Fitting
Retainer
Clips
Valve Plug
Adapter
Outlet Fitting –
Slide the Outlet
Tubing Over
The Outlet
Fitting.
Key Shaped
Mounting Holes
Proportioner
Elbow –
Metering Tip
Installs At This
Fitting By
Threading The
Metering Tip
Into The End Of
Fitting.

I-1279 REV. B-44805 3/5/2019 PAGE 6 OF 9
Replacement Parts:
Super Sink Replacement Parts
Item No.
DEMA Part
No.
QTY
DESCRIPTION
1
40.886.1
1
ACTIVATION KNOB
2
40.883.1
1
COVER SINGLE, SUPER SINK
3
40.887.1
1
KNOB BACK PLATE
4
40.909.2
1
KNOB RETURN SPRING
5
40.854.1
2
ADAPTER RETAINING CLIP
6
40.926.1
1
FUSION VALVE PLUG ADAPTER
7
40.847.2
1 - 2
FUSION VALVE ASSEMBLY, LESS ADAPTER
8
89.20.3
1
FLOW DISC ASSEMBLY (4GPM)
9
81.18.1
1
#6 HI-LO SCREW 3/8" LG.
10
16.30
1
ACTION GAP
11
61.22.3
1
PROPORTIONER FOR ACTION GAP (4 GPM)
12
61.22.3BAG
1
PROPORTIONER FOR AIR GAP (4 GPM)
13
40.890.1
1
BACK PLATE (SINGLE)
14
40.925.1
1
GARDEN HOSE WATER INLET FITTING (STANDARD THREAD)
14
40.925.2
1
GARDEN HOSE WATER INLET FITTING (BRITISH THREAD)
15
40.927.1
1
3/8” ELBOW BRASS COMPRESSION WATER INLET FITTING
16
40.927.2
1
3/8” STRAIGHT BRASS COMPRESSION WATER INLET FITTING
17
40.927.3
1
3/8” JOHN GUEST PUSH-ON WATER INLET FITTING
18
40.927.4
1
3/8” ELBOW JOHN GUEST PUSH-ON WATER INLET FITTING
19
40.927.5
1
3/8” BRASS BARB WATER INLET FITTING
20
40.884.1
1
COVER DUAL, SUPER SINK
21
44.116.5
2
SCREW, #8 HI-LOW (DUAL SUPER SINK ONLY)

I-1279 REV. B-44805 3/5/2019 PAGE 7 OF 9
ITEMS #25 - #31 NOT SHOWN ON EXPLODED VIEWS
SuperSink Dual units can be made
to have dual inlets, using the
various inlet fittings as an option.
22
40.892.1
1
FUSION VALVE COUPLING, OPEN (DUAL SUPER SINK ONLY)
22
40.892.2
1
FUSION VALVE COUPLING, CLOSED (DUAL SUPER SINK
ONLY)
23
40.891.1
1
BACK PLATE, SUPER SINK DUAL
24
40.970.1
1
BUBBLE LEVEL (DUAL SUPER SINK ONLY)
25
100.15K
1
TIP KIT
26
66.54
1
SCREW & ANCHOR KIT
27
L806
1
CHEMICAL LABEL
28
L1860
1
BRANDING LABEL (SINGLE SINK DISPENSER)
28
L1861
1
BRANDING LABEL (DUAL SINK DISPENSER)
29
63.75.1
1
TUBING, 9/16” I.D. OUTLET
30
100.16E.1
1
TUBING, INLET (CHEMICAL)
31
61.107.2
1
CERAMIC WEIGHT
[Type a quote from the document or the
summary of an interesting point. You
can position the text box anywhere in the
document. Use the Drawing Tools tab to
change the formatting of the pull quote
text box.]

I-1279 REV. B-44805 3/5/2019 PAGE 8 OF 9
Replacement Parts Valve Body
Valve Replacement Parts
ITEM NO.
DEMA PART NO.
QTY
DESCRIPTION
1
40.854.1
2
RETAINING CLIP PILOT ACTIVATED VALVE
2
41.058.1
1
DIAPHRAGM CAP
3
619.21
1
O-RING SEAL EPDM (15/16” X 1/16”)
4
98.26.1
1
1-1/16" DIAPHRAGM
5
40.824.1
1
VALVE BODY
6
40.849.1
1
BUTTON, PILOT ACTIVATED VALVE
7
640.106
2
O-RING SEAL (3/16"ID X 3/8"OD X 3/32"NOM.)
8
98.39.2
1
RETURN SPRING
9
63.78
1
O-RING-SEAL EPT (7/16"I.D. X 9/16"O.D. X 1/16 NOM.)
10
40.851.1
1
BOTTOM CAP

I-1279 REV. B-44805 3/5/2019 PAGE 9 OF 9
Specifications
Operation Pressure Rating: 20psi –95psi
Water Temperature Rating: 45ºF (7ºC) –125ºF (50ºC) Max
Back Flow Protection –ASSE 1055 (Action Gap & Air Gap)
Warranty
Merchandise Returns
No Merchandise Will Be Returned For Credit Without DEMA’S Written Permission.
Returned Merchandise Authorization Number Is Required In Advance Of Return.
Product Warranty
DEMA products are warranted against defective material and workmanship under
normal use and service for one year from the date of manufacture. This limited
warranty does not apply to any products that have a normal life shorter than one year or
failure and damage caused by chemicals, corrosion, physical abuse, or misapplication.
Rubber and synthetic rubber parts such as “o”-rings, diaphragms, PVC tubing, and
gaskets are considered expendable and are not covered under warranty. This warranty
is extended only to the original buyer of DEMA products. If products are altered or
repaired without prior approval DEMA, this warranty is void.
Defective units or parts should be returned to the factory with transportation prepaid. If
inspection shows them to be defective, they will be repaired or replaced without charge,
F.O.B. factory. DEMA assumes no liability for damages. Return merchandise
authorization number must be granted in advance of return units for repair or
replacement (See “Merchandise Returns” above).
