Dension ice-Link: Plus User manual

Install Guide
The ultimate car integration kit for the iPod.
for Volkswagen

ice Link: Plus 22Install Guide
This instruction is provided for educational purposes only, we are not responsible for
any damages! Always seek professional help when in doubt !
Overview:
1.Confirm that you have all Dension ice>Link Plus parts and they are compatible with your vehicle and radio
system
2.Make sure to have the radio security code available if the vehicle requires code upon loss of power
3.Follow the hardware installation guides. If radio removal is required, proceed following the factory service
guide of the vehicle
4.Configure the system if not factory pre-configured .See configuration guide at http://install.densionusa.com
5.Verify operation
6.Read users manual
Included parts:
iPod Docking
Cradle (1)
Docking Cradle
mini Insert (1)
Cradle Spacer (1) Docking Cradle
Mounting Base (1)
Screws for
Mounting Base (4)
Allen Wrench (1)
ice>Link Plus Adapter (1) Radio Specific Cable (1)
(image may not show actual cable)
ice>Link Plus
Users Manual (1)
ice>Link Plus
Install Guide (1)
ice>Link Plus
Quick Start Guide (1)
!
Kit Contents

ice Link: Plus
33
Install Guide
!
RFor component location see vehicle's service manual or contact vehicle dealer for information.
Connection Diagram
Disconnect vehicle's battery before installation! Failure to do so may result in damage to elctrical
components. The ice>Link Plus may not function or wil funtion improperly if the battery is not
disconnected before installation!

ice Link: Plus 44Install Guide
!
Mounting the ice Link: Plus Cradle
Broken cradle due to the use of force without first loosening the set screw is not covered by the
warranty!
Assemble the base of the iPod cradle with an optional vehicle specific adapter. An optional adapter is not
required, however it is recommended for easy and damage free installation.
Attach the cradle to the back with at least 2 screws. If holes do not align rotate the base until a match is found.
Insert the front of the cradle to the back piece, but do not force the cradle onto the base. The pin is keyed
and will only insert in one orientation. Align cradle orientation as desired. Tighten the set screw with the
included Allen wrench. Do not drive the set screw through the pin, only tighten the screw so it grabs the pin.
Once set, the cradle should not be forced to a different position. To adjust, first loosen the set screw, tilt and
rotate to realign, and then fasten the screw again.
A variety of spacers and rubber pads are included to provide the best support for the iPod. These are held in
place by a double sided tape, and may be removed by the end user if a thicker iPod is used later on.
?A slight black line may appear on the back side of the iPod Photo the first few times it is inserted
into the cradle. This line can be easily removed with a soft cloth, as it is only paint rubbing off of
the cradle.

ice Link: Plus 55Install Guide
There are two radio end connectors included in the kit. Use only the connector which fits
the CD changer connector on the back of your radio (shown by red arrow)
The black wire must be grounded. If a factory CD changer is installed in the vehicle, it MUST
be disconnected.
!
Vehicle Specific Connector

ice Link: Plus 66Install Guide
Troubleshooting
If iPod does not charge -
1. Check all connections.
2. Make sure that charge control is not turned off (see user's manual pages 11 and 12).
3. Connect the iPod to a computer to see if it will charge from there.
If you can not hear music playing -
1. Make sure CD changer, SAT mode, or AUX is selected on your radio; the correct key will depend on your radio system
and the installation type
2. Make sure that a non-empty album or playlist is selected on the iPod.
If you can not switch your radio to CD changer mode -
1. Check cables to make sure everything is tight.
2. Remove the fuse of the radio, wait for 30 seconds, and then reinsert the fuse. This will reset your radio and the interface.
You may have to enter the radio security code, so please keep it handy.
3. Consult with your installer or contact your local Dension support center.
If you can not control the iPod from the radio or if checkmark remains on iPod screen -
1. Make sure the firmware on your iPod is the most recent. For updates please visit www.apple.com/ipod
2. Reset the iPod.On the click-wheel iPods hold the center button and the Menu buttons, on the 3rd generation models
press and hold Menu and Play/Pause buttons until iPod reboots. (Resetting will not erase your music, it will only restart the
operating system of the iPod.)
If iPod does not turn on -
1. Verify that the iPod's battery is not depleted by attempting to turn it on without connecting it to the car.
2. Turn off both your car stereo, and the iPod before inserting it to the cradle. Power on your radio and select the
appropriate source.
3. Attempt to lower output level of ice>Link Plus from the ice>Link Plus setup menu. See users manual pg.12.
If the music is distorted or the sound level is too low -
1. Check and make sure all EQ and BASS boost options are turned OFF on your iPod.
2. Make sure the Gain control is adjusted properly on the ice>Link, located under ice>Link Plus setup.
Why is the menu size small on the iPod photo?
1. iPod photo has a high resolution screen, and therefore everything appears smaller.
2. At the time of development, iPod photo specifications were not available. A future firmware upgrade may enlarge menu
size.
!
Please make sure that you connect the plug and the receptacle in the right orientation and that the housing
latches to ensure tight retention.
incorrect correct

ice Link: Plus 77Install Guide
Important Disclaimer, please read !
Driving is dangerous and requires concentration. Do not allow the Apple iPod to distract you from prevailing traffic conditions. If in doubt, only
operate the unit when stationary or ask a passenger to operate it for you.
Do not submerge or expose to water or other fluids. ice>Link Plus is NOT water proof and it will be damaged by water.
You must properly insulate its casing if your installation environment may subject the unit to water, such as a convertible vehicle.
Keep away from children !
The ice>Link Plus cradle can be broken, or disassembled, and components may become loose from vibration and heat. Small components and
packaging materials may become choking hazard when handled by children.
Unauthorized reproduction, or reverse engineering is strictly prohibited ! Intellectual property included is distributed under specific of general
agreement with respective vendor(s). No warranty, explicit or implied is stated, and neither Dension USA, nor any of its distributors, dealers or
vendors shall be liable for damages. IN NO EVENT SHALL DENSION USA'S LIABILITY EXCEED THE PRICE PAID FOR THE PRODUCT
FROM DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT,
ITS ACCOMPANYING SOFTWARE, OR ITS DOCUMENTATION. Dension ice>Link is a registered trademark of Dension Audio System LTD,
and/or Dension USA, Inc. All other products are registered and copyrighted by their respective owners.
FCC Instruction to the user
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
o Reorient or relocate the receiving antenna.
o Increase the separation between the equipment and receiver.
o Consult the dealer or an experienced radio/TV technician for help.
This equipment has been verified to comply with the limits for a class B computing device, pursuant to FCC Rules. In order to maintain
compliance with FCC regulations, shielded cables must be used with this equipment. Operation with non-approved equipment or unshielded
cables is likely to result in interference to radio and TV reception. The user is cautioned that changes and modifications made to the equipment
without the approval of manufacturer could void the user's authority to operate this equipment.
Warranty and Support
The Dension ice>Link Plus carries a one year limited warranty that protects you from defects in material and workmanship of products sold by
Dension USA or its authorized agents, distributors and dealers. We do not warrant any installation. If you experience any problems or need help,
please contact Dension USA support at www.densionusa.com , or by phone at (562)- 595-5143. To order accessories, call us at [phone].
Proof of purchase is required.
Warranty does not cover normal tear and wear, damages due to negligence, improper installation or operation.
Disclaimer / FCC Information / Warranty and Support
