Depstech 86T User manual

User manual
for Depstech®industrial endoscope

Thanks for choosing Depstech®86T Industrial
endoscope!
Depstech 86T Industrial endoscope was featured as a multifunctional
industrial endoscope.
Thanks to ultra thin HD camera probe/ Flexible Simi-Rigid Cable, it
not only compatible with most of engine’s spark plug, but also brings
you the highest definition and up to 30fps real-time image.
Equipped with Anti- Slipped Side Mirror, which can help you locate
the carbon/ oil/ scratch as soon as possible and also help viewing
tube wall.
Equipped with Type-C plug, you can easily get access to connect
your Android Phone. Besides, it comes with some converter which
make it possible to get the connection with the PC/ Laptop or cell
phone with a micro-USB.
It’s better to give it a shot right now!
NOTE:
Any suggestions or customer service needs are warmly welcomed by
us. You can feel free contacting us via
Email: [email protected]
Facebook Official Page: @DEPSTECH. FANS

Description of Different Parts
APP Download Guidance
For Android user, search and download “DEPSTECH-View” from
Google Play Store.
Note:
For Android 10 user, we’d recommend you download the compatible version
“DEPSTECH-View”from www.depstech.com.
For Windows user, we would recommend you download the
advertisement-free “DEPSTECH-View” application via Microsoft
Store or www.depstech.com, or you can turn to the “Camera”appli-
cation from Microsoft Store.
For Mac OS user, Simply used the “PhotoBooth” application to
capture the real-time image.
IP67 rating HD camera
probe + 6* Dimable LEDs
Different length of simi-rigid
cable: Compatible with
different needs of length
USB-C plug: Can hookup
with USB-C to USB-A /
micro-USB converter
LED light dimmer: Roll
this gear to adjust the
brightness of the LEDs

OTG ON
Type-C to Micro USB
converter
Connection Guidance
For Android user
A: Confirm whether the phone supports the OTG function and whether the
OTG function was turned on.
Note:
1.Once the connection of the endoscope and the Android phone finished, the
app will tips you whether the Android phone support OTG function or not. If
your deviece didn’t support this function, please change another Android
phone or contact us for returning process via: [email protected]
2.You can turn on the OTG function in the “Settings”. For some brand of
Android phone, it will turn off the OTG function per several minutes. Please
regular check if you couldn’t get the connection.
B: Connect the industrial endoscope to an Android phone with the USB
connector (Pls notice the difference of Micro-USB/ Type-C, and connect the
industrial endoscope properly.)
C: Open the “Depstech-View” application in the phone, the screen will display
the real-time transmission image captured by the industrial endoscope.
Note:
If the endoscope failed to get access to capture the real-time image, it may
cause by the UVC protocol function of your Andorid phone has been disabled.
Please update the android version or change a phone and try it again. Or you
can contact us for returning process via: [email protected]

Mac OS
Windows
For Windows user
Connect the industrial endoscope with the Windows PC/ Laptop.
After the connection, open the “Depstech-View” or the “Camera”
application, the screen will display the real-time image of the
industrial endoscope.
For Mac OS user
Connect the industrial endoscope with the Mac OS PC/ Laptop. After
the connection, open the built-in “PhotoBooth” application. The
screen will display the real-time transmission screen captured by the
industrial endoscope.

FAQ& Help
Q1: How to connect the USB endoscope to “DEPSTECH-View”?
A1:
Q2: No response after plug the usb endoscope into your android phone?
A2:
1. USB endoscopes are only available for Android phone users. Please make
sure you have turned on the OTG function of your phone. Go to the phone
"Settings"-"About this machine"-"Software Information"-repeatedly click on
"Kernel Version" or "Compilation Number" to open "Developer Mode". After
opening "Developer Mode", please click "Settings"-"Developer Mode"-turn
on "OTG Function";
2. Select the corresponding adapter(micro USB / type-C) to connect the
mobile phone;
3. Open “DEPSTECH-View” to obtain real-time images of the endoscope. If
only the loading icon rotates when the APP acquires the device image, this
may be a hardware failure, please contact the seller of the device.
4. If you still can’t get the image in the above steps, it may be that the USB
port of the phone is loose. Please try to connect to another Android phone
and try again according to the above steps;
5. If your phone version is Android 10.0, please click the jump link in the App
pop-up window to download the ““DEPSTECH-View” apk” installation
package adapted to Android 10.0.
1. If you got the “No OTG function ”tips after plug the usb endoscope into your
android phone but no image, your cellphone may not availiable for
“OTG”function, please try to plug the endoscope into another phone.
2. Please remember to open the “OTG”function in the “Settting”,and for some
model of cellphone it may turn off the “OTG”function automatically for
serval minutes, please regularly check if the “OTG”function has been turn
off or not.
3. The aging of the charging interface and the failure of the USB converter will
cause the device to be unavailable. Please change a android phone or a
USB converter and try to get connection again.
4. If you still couldn’t get the connection after following the steps, please
contact the supplier for help.

Type-C industrial
endoscope
Type-C
1280*720px 1600*1200px 1600*1200px 2592*1944px
0.21in 0.25in 0.25in 0.33in
60° 70°
11.5ft / 16.4ft
DC 5V/2A
IP67
80° 80°
2.75-15.74in 1.96-3.93in 2.75-15.74in 2.75-15.74in
Type-C Type-C
Micro USB +
USB-A
1*Magnet,
1*Hook,
1*Side-View
mirrow,
1*Type-C to USB A
converter,
1*Type-C to micro
USBconverter
1*Magnet,
1*Hook,
1*Side-View mirrow,
1*Type-C to USB A
converter,
1*Type-C to micro
USBconverter
1*Magne
1*Hook,
1*Side-View
1*Holder
1*Micro USB
converter
1*Magnet,
1*Hook,
1*Side-View
mirrow
1*Type-C to USB A
converter
1*Type-C to micro
USBconverter
Type-C industrial
endoscope
Type-C industrial
endoscope
Endoscope with 2
in 1 USB plug
Specifications
USB type
Maximum resolution
Diameter
Cable Length
Fixed focus range
FOV
Product name
Waterproof grade
Accessories
Working Voltage/
Electric current
86T 100w 86X 200w 86T 200w 86T 500w

Safety Warrenty
※ Operation and storage conditions: Please keep the device away from fire
source/ liquid/ acidic. These may increase the risk of electrical shocks and
damages of the device. The storage temperature should between 32-158 ℉. And
the working temperature should between 32-113℉.
※ The Child can only operate this device with the guidance of adults, please do not
let them operate this device alone.
※ FCC statement: This device complies with Part 15 of the FCC
rules. Operation is subject to the following two conditions:
1)This device may not cause harmful interface;
2)This device must accept any interference received, including
interference that may cause undesired operation.
※ EU Conformity Statement
This product and - if applicable - the supplied accessories too are
marked with "CE" and comply therefore with the applicable
harmonized European standards listed under the EMC Directive
2004/108/EC, the RoHS Directive 2011/65/EU and Amendment
(EU)2015/863.
2012/19/EU (WEEE directive): Products marked with this symbol
cannot be disposed of as unsorted municipal waste in the
European Union. For proper recycling, return this product to your
local supplier upon the purchase of equivalent new equipment, or
dispose of it at designated collection points. For more information
see: www.recyclethis.info
※ WEEE Notice: The directive on Waste Electrical and Electronic
Equipment (WEEE), which entered into force as European law on
14/02/2014, resulted in a major change in the treatment of electrical
equipment at end-of- life.
The purpose of this Directive is, as a first priority, the prevention of
WEEE, and in addition, to promote the reuse, recycling and other
forms of recovery of such wastes so as to reduce disposal.
