User Manual
for Depstech®DS450 Industrial Endoscope
Hello

Turn on the device by Holding the Button
Control the fill light on / off with the Button
To start video record, please Hold the Button
To take a photo or end the video record, please
Click the Button
Quick Overview of Your New Endoscope!

For more settings, enter the menu with Button
To adjust the lights of the camera, move the cursor in the menu, or
switch to previous/ next files in the album, please
Click the or Button
To confirm choices in the menu, please Click the Button
To open/ close the album (required TF card inside),
please Hold the Button
To rotate the image 180°, please Hold the Button
To switch the main / side camera, please Hold the Button
(Note: For Dual Camera Version Only)
To start video record, please Hold the Button

Reset
TF Card Slot: Support up to 32G TF card
(Note: Please format the TF card at the first use.)
Reset Slot: Click to reset your device.
Micro USB Charging Slot: Plug& charge your device
with the Micro USB cable.
USB Camera Slot: Plug the USB connector of the
camera into this port.
*The package enclosed with TF card/ Reset pin/ Micro USB
charging cable/ 3*Efficiency tools like magnet, hook and side
mirror (for single camera version only) / EVA storage bag (EVA
storage bag only for the limited version)

Q2: Can it be used for inspection when charging? Will it work
normally?
A2: Yes, it can be used. But be aware do not frequently used it in
such situation, which may do damage to battery lifespan.
Q3: I can’t get the image of the camera, or it keeps showing no
signal on the screen.
A3: Please make sure the USB camera was connected correctly to
the screen display before open it. Plus, if the USB camera fell apart
from the screen display accidentally, you can try to reconnect it and
wait for a few seconds.
If it’s still showing no signal, you can shut down the endoscoep
and opened it again.Or turn to reset function for the fastest
response.
FAQ
Q1: Can I view the files of the endoscope by connecting the
screen display to the PC/laptop?
A1: Sure you can. Please follow the steps below:
1. Open the screen display part of the “DS450”.
2. Connect the screen display with your
PC/laptop via the USB-A to micro USB data
cable.
(Note: Make sure you’re using the data cable
enclosed in the package, and make sure that
the TF card has been inserted)
3. Go into “Menu” - “USB mode” - choose
“USB Card Reader”, then you can check the
files in your PC/laptop.
Resolution 1080P
Auto-off Off
USB mode
Camera
USB Card Reader
USB mode Camera

FAQ Specifications of Different Version
Blue LED Indicator flash: Low battery status
Blue LED Indicator on: Working status
Red LED indicator flash: Charging status
Red LED Indicator on: Charging finished
178° View Angle 4.5” IPS Screen
6H
IP67 Waterproof for the Probe
1/5 in 1/4 in 1/3 in
Camera Diameter
Best Focal
Range
2.0 MP 2.0 MP
16.5 ft
0.22-16.7 ft 0.22-33.1 ft 0.22-16.7 ft 0.22-16.7 ft
16.5 ft 16.5 ft32.8 ft
5.0 MP 2 x 2.0 MP
6 x LEDLED
Max Pixel
Cable Length
Working Range
LED Indicator
Status
2.75-15.7 in
7 x LED
Main cam:
1.2-3.9 in
Side cam:
4/5~2.4 in
3/10 in
Scree Spec
Battery Life
Waterproof
Model DS450
FHD
DS450
FHD 2.0
DS450
QHD
DS450
Dual Cam
Charging Voltage/
Electric current DC 5V/ 2A
