Derby cycle Pedelec Impulse Evo User manual

Pedelec Impulse Evo
Original User Guide | EN
Version 1
29/04/2015

EN-2 Original User Guide | Pedelec Impulse Evo Version 1
Notes
I. Introduction
» I.I CD
» I.II Service book
» I.III Declarations of conformity
» I.IV Explanation of safety symbols
» I.V Customer service
II. General safety information
III. Legal regulations
» III.I General
» III.II Legal regulations in Germany
IV. Intended use
» IV.I Pedelec
» IV.II E-Mountainbike
1. The Pedelec Impulse Evo and its
components
2. Quick-start guide
» 2.1 Charging the battery
» 2.2 Inserting and locking into place
a battery
» 2.3 Switching on the Pedelec
» 2.4 Changing assist mode
» 2.5 Enabling push assist
» 2.6 Conguring settings in the menu
» 2.6.1 Go to the main menu
» 2.6.2 Navigating within a menu
» 2.6.3 Returning from the menu
» 2.7 Changing ride prole
» 2.8 Switching o the Pedelec
TABLE OF CONTENTS

Original User Guide | Pedelec Impulse Evo Version 1 EN-3
» 2.9 Unlocking and removing the
battery
3. Drive unit, display and easy-reach control
» 3.1 Safety information
» 3.2 Technical details
» 3.3 Overview and basic functions
» 3.3.1 Switching on the Pedelec
» 3.3.2 Switching o the Pedelec
» 3.3.3 Battery charge level and
remaining range
» 3.3.4 Changing assist mode
» 3.3.5 Using push assist
» 3.3.6 SET favourites
» 3.3.6.1 Display of SET favourites in the
start menu
» 3.3.6.2 Preselecting SET favourites
» 3.4 Menu
» 3.4.1 Conguring settings in the
menu
» 3.4.1.1 Go to the main menu
» 3.4.1.2 Navigating within a menu
» 3.4.1.3 Returning to the next-highest
menu level
» 3.4.1.4 Returning to the start menu
» 3.4.2 Menu structure
» 3.4.2.1 Show ride data
» 3.4.2.2 Deleting trip data
» 3.4.2.3 Deleting tour data
» 3.4.2.4 Contrast
» 3.4.2.5 Brightness
» 3.4.2.6 Language
» 3.4.2.7 Unit
» 3.4.2.8 Date
» 3.4.2.9 Time
» 3.4.2.10 Wheel circumference
» 3.4.2.11 Light reserve
» 3.4.2.12 Shift sensor
» 3.4.2.13 Climb assist
» 3.4.2.14 Ride prole
» 3.4.2.15 Name
» 3.4.2.16 SET favourites
» 3.4.2.17 Factory settings
» 3.4.2.18 Version
4. App: Impulse E-Bike navigation
» 4.1 Location from map
» 4.2 Every day
» 4.3 Leisure time
» 4.4 Impulse Evo Smart display:
Show route
» 4.5 Impulse Evo Smart display:
Charging the smartphone
» 4.5.1 Tips
» 4.5.1.1 Transportation and shipping
» 4.5.1.2 Riding with a trailer and/or
luggage
» 4.5.1.3 Storage
» 4.5.1.4 Cleaning
» 4.5.1.5 Disposal
5. Battery
» 5.1 Safety information
» 5.2 Technical details
» 5.2.1 Battery management system
(BMS)
» 5.2.1.1 Checking the charge level
» 5.2.1.2 Checking the capacity
» 5.2.1.3 Sleep mode
» 5.3 Fitting
» 5.3.1 Inserting and locking into place a
battery
» 5.3.2 Unlocking and removing the battery
» 5.4 Tips
» 5.4.1 Range
» 5.4.2 Transportation and shipping
» 5.4.3 Storage
» 5.4.4 Cleaning
» 5.4.5 Disposal
6. Chargers
» 6.1 Safety information
» 6.2 Technical details
» 6.3 Overview and functions
» 6.3.1 Charging a battery
» 6.3.1.1 Battery display during the charge
process
» 6.4 Tips
» 6.4.1 Cleaning
» 6.4.2 Storage
» 6.4.3 Disposal
7. Faults
» 7.1 Drive unit, display and easy-reach
control
» 7.2 Battery
» 7.3 Chargers
» 7.4 Other

EN-4 Original User Guide | Pedelec Impulse Evo Version 1
I. Introduction
This user guide will help you to enjoy all the benets of your Pedelec
Impulse Evo and to use it correctly.
WARNING
Prior to initial use, carefully read the "Original User Guide | Pedelec
Impulse Evo" and the "Original User Guide | General" (CD). Also
follow the instructions from component suppliers. Familiarise yourself
with the meaning and depiction of safety information in the user
guide. Ensure to contact your cycle dealer in the event clarication is
required. Failure to comply with safety symbols and instructions can
cause electric shock, re, serious injury and/or damage to the cycle.
The manufacturer's liability and warranty are deemed null and void
for damage and injury caused by a failure to adhere to safety symbols
and instructions.
Keep the user guides for informational and reference purposes in the
future. The guides must be passed on to all those using, looking after
and repairing this Pedelec.
I.I CD
The accompanying CD contains the "Original User Guide | Pedelec Impulse
Evo" in dierent languages. Also on the CD is the "Original User Guide |
General", containing general information on cycles. Download the latest
version of the user guide next time you are on the Internet. The CD can be
played on any standard PC or laptop. Proceed as follows:
METHOD A
1. Insert the CD
2. Left-click twice the shelexec.exe le
3. Select the required language
4. Select "Open User Guide from CD" or "Check Online for New Version of
User Guide"
METHOD B
1. Insert the CD
2. Right-click once "Open Folder to Show Files"
3. Left-click twice "Start"
4. Select the required language
5. Select "Open User Guide from CD" or "Check Online for New Version of
User Guide"

Original User Guide | Pedelec Impulse Evo Version 1 EN-5
I.III Declarations of conformity
Please take note of the accompanying declarations of
conformity and keep them in a safe place.
We conrm with the declarations of conformity that all safety requirements
in the directives applicable to the Pedelec and charger are satised.
The Adobe Reader application is required to read the user
guide. It is on the CD and can also be downloaded free from
www.adobe.com.
The print version of the "Original User Guide | General" can
be ordered at no charge from:
Derby Cycle GmbH/Raleigh Univega GmbH
Siemensstraße 1-3
49661 Cloppenburg, Germany
[phone]
[email protected]
I.II Service book
In the accompanying service book are the warranty regulations, a cycle
passport, and forms to use for initial sale, maintenance and owner
changes.
Keep the service book up-to-date accurately and adhere to
the maintenance intervals. This will prolong the service life
of your Impulse Evo and keep it safe.

EN-6 Original User Guide | Pedelec Impulse Evo Version 1
This symbol denotes user tips and particularly useful or
important information on the product or its additional
benet. It is not an indication of a dangerous or harmful
situation.
I.V Customer service
If you have any questions on the cycle or its components, please contact a
trained cycle dealer or the customer service team at Derby Cycle/Raleigh
Univega:
Derby Cycle GmbH/Raleigh Univega GmbH
Siemensstraße 1-3
49661 Cloppenburg, Germany
[phone]
I.IV Explanation of safety symbols
DANGER
This symbol in conjunction with the "Danger" word denotes a
potentially dangerous situation. Failure to comply with this safety
symbol may result in very serious injury or death.
WARNING
This symbol in conjunction with the "Warning" word denotes a
potentially dangerous situation. Failure to comply with this safety
symbol may result in serious injury.
CAUTION
This symbol in conjunction with the "Caution" word denotes a
potentially dangerous situation. Failure to comply with this safety
symbol may result in minor or slight injury.
PLEASE NOTE
This symbol in conjunction with "Please note" denotes a
potentially dangerous situation. Failure to comply with this safety
symbol may result in damage to the Pedelec and its components.

Original User Guide | Pedelec Impulse Evo Version 1 EN-7
CAUTION
Only use the cycle for its intended purpose - otherwise there is a risk
of technical failure IV. Intended use Page EN-9.
Observe the overall weight of the Pedelec - exceeding it can result in
the breaking or failing of safety parts 4.5.1.2 Riding with a trailer
and/or luggage Page EN-41.
Before setting o on a ride, always check all quick-release clamps are
seated tightly and correctly.
Disc brakes: The brake disc and the quick clamping lever for a wheel
must be on opposite sides. If they are on the same side, there is a risk
they may collide.
PLEASE NOTE
Have assembly and adjustment work carried out by a specialist
cycle dealer. If you need to tighten something yourself, refer to
the comprehensive list of torques which must be observed - in the
"Original User Guide I General" (CD).
If you carry out technical modications to your Pedelec, bear in mind
national trac regulations and applicable standards. Remember also
that the warranty may become void as a result.
II. General safety information
WARNING
Rim brakes: When cycling for long periods downhill, try to avoid
continual, uninterrupted braking if possible. It may result in a
reduction of braking eect or damage to the tyres. It is better to brake
every now and then with "cooling times" in-between, allowing the
head wind to cool the braking system. If absolutely necessary, take
breaks to let the braking system cool down.
Regularly check wearing parts such as brakes, brake pads and tyres.
Damaged parts can cause accidents and falls. The addition power
means higher loads are applied to wearing parts on a Pedelec than on
a normal cycle. Replace brake pads when their wear limit is reached.
This is evident from the mark on a brake pad and when you can pull
the brake lever all the way back to the handle bars.
Do not touch the motor after a long downhill ride - it can become very
hot. Touching it can cause burns.
Also follow the safety instructions at the start of the next section.

EN-8 Original User Guide | Pedelec Impulse Evo Version 1
III.II Legal regulations in Germany
Other regulations may be in place in other countries. Find
out about applicable local legislation before using your
Pedelec abroad.
Some of the regulations in place in Germany at the time this user guide
was written:
» The motor may only be used as a pedalling aid, i.e. it may only "help"
when the rider is pedalling him/herself
» The average motor power may not exceed 250 W
» The motor power must continue falling as the cycle speed keeps
increasing
» The motor must cut out at a speed of 25 km/h
IMPORTANT FOR THE RIDER
» The rider need not wear a helmet. Although in the interests of his/her
own safety, a suitable helmet should always be worn.
» The rider does not require a driving license
» The rider does not require insurance
» The use of cycle paths is regulated as for normal cycles
» The use of children trailers and cycle trailers is generally permitted for
Pedelecs
III.Legal regulations
III.I General
DANGER
Never ride "hands free". You must always have at least one hand on
the handle bars. If you do not, you are liable to prosecution (and are
also endangering your health).
Never perform any alterations to the drive unit (with which the cut-o
speed is increased at speeds faster than 25 km/h). Pedelecs whose
motor rating and/or ride characteristics have been modied may no
longer satisfy the legal regulations of the country of use. You may be
making yourself liable to prosecution when riding on public roads
with a "tuned" Pedelec. This also presents a risk of technical failure.
A cycle modied this way is excluded from guarantee and warranty
cover.
WARNING
We discourage allowing children under the age of 14 years to ride
Pedelecs. They may not be able to cope with the speed.
Pedelecs must, as all cycles, satisfy the requirements laid
down in the respective national road trac acts.

Original User Guide | Pedelec Impulse Evo Version 1 EN-9
IV.II E-Mountainbike
Its design and equipment mean this cycle is not intended for use on public
roads. The equipment stipulated must be tted to the cycle before it may
be used on public roads. This cycle is intended to be used o-road (but
not for competition use). The manufacturer and dealer accept no liability
for damage resulting from any use extending beyond this denition and/
or failure to comply with the safety instructions in the user guide. This
applies in particular when the cycle is used in competitions, when it is
overloaded and when faults are not rectied properly. Also included in the
denition of intended use are conformance to the operating, maintenance
and repair conditions in the user guide and service book - stipulated by
the manufacturer. Fluctuations in consumption and battery power, and
a reduction in capacity due to the cycle's age, are commonplace and
technically unavoidable - and as such do not represent material defects.
DANGER
Before using a trailer, read Section 4.5.1.2 Riding with a trailer and/
or luggage Page EN-41.
IV. Intended use
IV.I Pedelec
Its design and equipment mean the cycle is intended for use on public
roads and paved pathways. It can also be used on easy terrain. The
manufacturer and dealer accept no liability for damage resulting from
use extending beyond this denition and/or failure to comply with the
safety instructions in the user guide. This applies in particular for using
the cycle o-road, when it is overloaded and when faults are not rectied
properly. Also included in the denition of intended use are conformance
to the operating, maintenance and repair conditions in the user guide and
service book - stipulated by the manufacturer. Fluctuations in consumption
and battery power, and a reduction in capacity due to the cycle's age, are
commonplace and technically unavoidable - and as such do not represent
material defects.

EN-10 Original User Guide | Pedelec Impulse Evo Version 1
1. The Pedelec Impulse Evo and its components
39
3 6 7
11
10
13
15
18
20
19
21
22
16
25 24262728
45
39
2
1
29
31
30
32
33
34
35
36
38
37
81Back light
2Luggage rack
3 Saddle
4 Seat post
5Crossbar
6Handle bars
7Bell
8Front stem
9Easy-reach control
10 Front light
11 Headset
12 Headtube
13 Shock absorber
14 Display
15 Mudguard
16 Fork
17 Battery Include and
docking station
18 Front brake
19 Hub
20 Spokes
21 Wheel rim
22 Tyre
23 Motor
24 Pedal
25 Crank
26 Inner bearing
27 Chain rings
28 Derailleur
29 Belt / chain
30 Rear stand
31 Chain stay
32 Gears
33 Sprocket assembly
34 Back brake
35 Seat stay
36 Seat tube
37 Down tube
38 Frame lock
39 Chargers
9
17
23
14
12

Original User Guide | Pedelec Impulse Evo Version 1 EN-11
One-key system: The same key can be used for cycle and
battery lock.
1. Hold the battery at angle of 80˚,
slightly tilted to the left in front of the
docking station.
2. Place the battery catches into the
dents provided.
3. Push the battery forwards and
upwards into the docking station until
the locking mechanism engages.
4. Remove the battery key from the lock.
Now the battery is locked.
2. Quick-start guide
2.1 Charging the battery
You need not charge the battery if just taking a short test
ride. You should charge it before your first longer cycle ride
however, 6.3.1 Charging a battery Page EN-56, because the
battery is only partially charged (transportation regulations
dictate that batteries are supplied partially charged - by
approx. 50%).
Perform a learn cycle. You should drain a new, fully charged
battery once until the assist function stops, and without
recharging it in-between. By doing so, the battery "learns"
its capacity, and the actual capacity matches the charge
level display. Please perform a learn cycle every six months
or 5,000 kilometres. If you do not repeat the cycle from
time to time, the difference between actual battery capacity
and charge level display will become greater and greater.
2.2 Inserting and locking into place a battery
PLEASE NOTE
Hold the battery tight so it does not fall. It might be damaged
otherwise.

EN-12 Original User Guide | Pedelec Impulse Evo Version 1
If the cycle does not start up despite you
pressing the button, press the battery
button for 1 second. Then briey press the
button on the easy-reach control. The
Pedelec switches on. If it still does not
switch on, check the battery
5.2.1 Battery management system (BMS)
Page EN-47.Battery
button
2.4 Changing assist mode
1. You must be in the start menu to change assist mode. Briey press the
/ buttons to select the assist level.
DISPLAY ASSIST POWER CONSUMPTION
POWER The assist function works very hard High
SPORT The assist function works medium
hard
Medium
ECO The assist function works with low
power
Low
OFF No assist Very low
The recommendation is to remove the key now and keep it
in a safe place so it does not break o and is not lost.
Make a note of the key number on the sales receipt/
document. This number can be used to order a replacement
key 7.2 Battery Page EN-60.
2.3 Switching on the Pedelec
1. Press for 1 second the button on the
easy-reach control. The display lighting
is switched on for about 30 seconds.
The back light is also turned on. The
front light is turned on when it has been
switched on from the top of the lamp.
After a short time, a welcome screen is
shown, followed by the start menu. If you
have an Impulse Evo System with back
pedal, "Please pedal" is shown. You can
congure other settings from the start
menu.
Press the button

Original User Guide | Pedelec Impulse Evo Version 1 EN-13
1. Keep the button pressed. Push assist
is activated after 3 seconds. A warning
is sounded at the same time.
"Hint (1/1) Pushing assistance" is
shown on the display. Keep the button
pressed until you no longer need push
assist.
2.6 Conguring settings in the menu
2.6.1 Go to the main menu
1. When you are in the start menu, press the button for 3 seconds. You
access the main menu.
0.0
km/h
0.00 km
Trip
ECO
00:02
140 km
00.00.00
Trip time
0.0
km/h
0.00 km
Trip
00:02
140 km
00.00.00
Trip time
0.0
km/h
0.00 km
Trip
00:02
140 km
00.00.00
Trip time
SPORT
POWER
Start menu
Main menu
Drive data
Delete trip data
Delete tour data
Settings
Back
Main menu
2.6.2 Navigating within a menu
1. Navigate to the required place using the /buttons.
The option selected is shown with a black background.
2. Conrm your selection by briey pressing the button.
You access the next-lowest menu level.
14.5
km/h
Pushing Assistance
Hint (1/1)
16:53
140 kmPOWER
AA
Name
—
ABCDEFGH I JKL M N
OPQRSTUVWXYZ
ÄÖÜßÂÊÎÔÛÀÈÌÒÙ
ÁÉÍÓÚ
<- ok abc...
A
a b c d efghijklmnop
qrstuvwxyz ä öüß â ê
îôûàèìòùáéíóú
<- ok ABC...
Name
—
Push assist activated
2. Assistance is provided as soon as you start pedalling. Assistance is
deactivated as soon as you stop pedalling or you reach a speed of 25
km/h.
Underneath the assist level selected is a display area showing the current
assist level from the drive unit in the form of ten bars having increasing
heights. The more bars are dark, the higher the assist level being provided.
This display is only shown when an assist mode is selected.
0.0
km/h
0.00 km
Trip
ECO
00:02
140 km
00.00.00
Trip Zeit
0.0
km/h
0.00 km
Trip
00:02
140 km
00.00.00
Trip Zeit
0.0
km/h
0.00 km
Trip
00:02
140 km
00.00.00
Trip Zeit
SPORT
POWER
0.0
km/h
0.00 km
Trip
ECO
00:02
140 km
00.00.00
Trip Zeit
0.0
km/h
0.00 km
Trip
00:02
140 km
00.00.00
Trip Zeit
0.0
km/h
0.00 km
Trip
00:02
140 km
00.00.00
Trip Zeit
SPORT
POWER
The drive unit is not assisting The drive unit is providing
medium assist
The drive unit is providing
maximum assist
0.0
km/h
0.00 km
Trip
ECO
00:02
140 km
00.00.00
Trip Zeit
0.0
km/h
0.00 km
Trip
00:02
140 km
00.00.00
Trip Zeit
0.0
km/h
0.00 km
Trip
00:02
140 km
00.00.00
Trip Zeit
SPORT
POWER
2.5 Enabling push assist
WARNING
Push assist may only be used when the Pedelec is being pushed. It is
not intended to be used when a rider is sitting on the cycle. There is
a risk of injury when the wheels are not in contact with the ground.
Push assist works up to a speed of 6 km/h.
It provides assistance when the cycle is being pushed. This
is particularly helpful for steep hills you are unable to climb
with pedalling.

EN-14 Original User Guide | Pedelec Impulse Evo Version 1
4. Select "Device settings" using the /buttons
5. Conrm with
6. Select "Drive" using the /buttons. The option selected is shown
with a black background.
7. Conrm with the button. You access the menu sub-items.
8. Select "Biking prole" using the /buttons. The option selected is
shown with a black background.
9. Conrm with the button. You access the ride proles.
Ride
prole
Properties
Power on
start-up
Power
delivery
Maximum
power
Power
consumption
Relax Low Low Low Low
Regular Medium Medium Medium Medium
Dynamic High High High High
10. Select the required option using the /buttons. It has a black
background.
11. Briey press the button to return to the menu sub-items
2.6.3 Returning from the menu
There are three ways to return from a menu to the next-highest menu level
or start menu:
a) Back option
1. Navigate to the Back option using the /buttons. It has a black
background when selected.
2. Conrm with the button. You access the next-highest level.
b) Brief pressing of the button
1. If there is no Back option, and one of the options displayed is selected,
briey press the button to return to the next-highest level
b) Prolonged pressing of the button
1. Pressing the button for about 3 seconds returns you to the start
menu
2.7 Changing ride prole
1. Press for 3 seconds the button in the start menu. You access the
main menu.
2. Select main menu option "Settings" using the /buttons. The option
selected is shown with a black background.
3. Conrm by briey pressing the button. You access the menu options.

Original User Guide | Pedelec Impulse Evo Version 1 EN-15
2. Grip the battery and rotate it out of the
docking station.
PLEASE NOTE
Hold the battery tight so it does not fall. It might be damaged
otherwise.
The recommendation is to remove the key now and keep it
in a safe place so it does not break o and is not lost.
2.8 Switching o the Pedelec
From the easy-reach control:
1. Press for 1 second the button on the easy-reach control. The
goodbye screen is displayed and the Impulse Evo System is switched
o.
From the battery:
1. Press the battery button twice
2.9 Unlocking and removing the battery
1. Hold the battery, put the key into the
battery lock and turn it clockwise. Hold
the key. The battery is unlocked.
Battery
button

EN-16 Original User Guide | Pedelec Impulse Evo Version 1
PLEASE NOTE
Do not tug at the display cables or display-cable plugs. If you do
so, you may break the plug-retaining lugs. If you want to detach
the display – e.g. because it is no longer functioning – contact your
dealer.
3. Drive unit, display and easy-reach control
3.1 Safety information
WARNING
Do not open the drive unit. This presents a risk of electric shock. The
warranty also becomes null and void. Only have repairs to the drive
unit carried out by trained cycle dealers.
Always remove the battery before working on the Pedelec. The cycle
could switch on without warning, seriously injuring you.
Do not allow yourself to be distracted by the display. Only congure
menu settings when the Pedelec is stationary. If you do not fully con-
centrate on trac, you risk being involved in an accident or falling o.
PLEASE NOTE
All components mounted on the drive unit, and all other drive
components, may only be replaced with identical components or those
approved specially for your Pedelec by the manufacturer. Overloading
and damage may result otherwise.
Do not open the display. It can be damaged beyond repair.

Original User Guide | Pedelec Impulse Evo Version 1 EN-17
Impulse Evo Smart display
Type LCD with USB charge socket, Bluetooth and easy-reach
control
Permissible ambient
temperature for
operation
-10 to +50˚C
Dimensions L |W |H |D 9.4 cm | 7.6 cm | 2 cm | 12 cm
Protection class IP 54
Weight 127 g
Languages DE | EN | NL | FR | ES | IT | FI | DA
Easy-reach control
Type Easy-reach control with 4 buttons
Permissible ambient
temperature for
operation
-10 to +50˚C
Protection class IP 54
Weight 27 g
3.2 Technical details
Drive unit
Type Brushless electric motor with gear unit
Back pedal Free-wheel
Nominal power 250 W 250 W
max. torque 80 Nm 80 Nm
Nominal voltage 36 V 36 V
Cut-out speed 25 km/h 25 km/h
Permissible ambient
temperature for
operation
-10 to +50˚C -10 to +50˚C
Protection class IP 54 IP 54
Weight 4 kg 4 kg
Impulse Evo display
Type LCD with easy-reach control
Permissible ambient
temperature for
operation
-10 to +50˚C
Dimensions L |W |H |D 9.4 cm | 7.6 cm | 2 cm | 12 cm
Protection class IP 54
Weight 127 g
Languages DE | EN | NL | FR | ES | IT | FI | DA

EN-18 Original User Guide | Pedelec Impulse Evo Version 1
1
2
3
4
Easy-reach control
NO. SYMBOL FUNCTION
1 ON/OFF
3.3.1 Switching on the Pedelec Page EN-19
3.3.2 Switching off the Pedelec Page EN-19
2a) Increase value / scroll up
b) Push assist 3.3.5 Using push assist Page EN-21
c) Enable display light for 30 seconds
3a) Reduce value / scroll down
b) Enable display light for 30 seconds
4a) Congure/conrm
b)In the main menu, switch between the SET favourites
3.3.6.1 Display of SET favourites in the start menu Page EN-21.
c) Enable display light for 30 seconds
3.3 Overview and basic functions
0.0
km/h
0.00 km
Trip
ECO
00:02
140 km
00.00.00
Trip time
0.0
km/h
0.00 km
Trip
00:02
140 km
00.00.00
Trip time
0.0
km/h
0.00 km
Trip
00:02
140 km
00.00.00
Trip time
SPORT
POWER
1 2 3
5
7
6
4
USB power jack
(only on Impulse Evo Smart display)
Impulse Evo Smart display / Impulse Evo display
NO. FUNCTION
1Battery charge level + remaining range
2Time 3.4.2.9 Time Page EN-29
3Assist mode 3.3.4 Changing assist mode Page EN-20
4Assist display 3.3.4 Changing assist mode Page EN-20
5SET favourites 3.3.6 SET favourites Page EN-21
6Speed
7Light

Original User Guide | Pedelec Impulse Evo Version 1 EN-19
3.3.2 Switching o the Pedelec
From the easy-reach control:
1. Press for 1 second the button on the easy-access control. The
goodbye screen is displayed and the Impulse Evo System is switched
o.
From the battery:
1. Press the battery button twice
You can switch o the Pedelec anywhere within the menus.
The start menu does not need to be displayed for this.
The most recent setting changes remain saved.
If the drive unit is not required to deliver power for 20
minutes or so (because the Pedelec is stationary for
example), the Impulse Evo switches o by itself.
3.3.1 Switching on the Pedelec
The system can only be activated when a suciently
charged battery is used.
1. Press for 1 second the button on the easy-reach control. The display
lighting is switched on for about 30 seconds. The back light is also
turned on. The front light is turned on when it has been switched
on from the top of the lamp. After a short time, a welcome screen is
shown, followed by the start menu. If you have an Impulse Evo System
with back pedal, "Please pedal" is shown. You can congure other
settings from here.
If the cycle does not start up despite you
pressing the button, press the battery
button for 1 second. Then briey press the
button on the easy-reach control. If it
still does not switch on, check the battery
5.2.1 Battery management system (BMS)
Page EN-47.
The back light has a sidelight function. It
cannot be turned o.
Battery
button

EN-20 Original User Guide | Pedelec Impulse Evo Version 1
3.3.3 Battery charge level and remaining range
The battery charge level and range are shown in the top left of the display.
A battery-shaped icon shows the remaining range, telling you how long
the Impulse Evo system can continue to assist you. The lower the battery
charge level, the shorter the black part in the battery. The range also
shows a lower value.
High battery charge level
and long remaining
range
Low battery charge level
and short remaining range
14.5
km/h
Schiebehilfe
Hinweis (1/1)
16:53
180 km
POWER
14.5
km/h
Schiebehilfe
Hinweis (1/1)
16:53
30km km
POWER
The value displayed can change quickly when the
circumstances change, such as when riding up an incline
after a long, at stretch.
3.3.4 Changing assist mode
1. You must be in the start menu to change assist mode. Briey press the
/buttons to select the assist level.
DISPLAY ASSIST POWER CONSUMPTION
POWER The assist function works very hard High
SPORT The assist function works medium
hard
Medium
ECO The assist function works with low
power
Low
OFF No assist Very low
Underneath the assist level selected is a display area showing the current
assist level from the drive unit in the form of ten bars having increasing
heights.
The more bars are dark, the higher the assist level being provided. This
display is only shown when an assist mode is selected.
0.0
km/h
0.00 km
Trip
ECO
00:02
140 km
00.00.00
Trip Zeit
0.0
km/h
0.00 km
Trip
00:02
140 km
00.00.00
Trip Zeit
0.0
km/h
0.00 km
Trip
00:02
140 km
00.00.00
Trip Zeit
SPORT
POWER
0.0
km/h
0.00 km
Trip
ECO
00:02
140 km
00.00.00
Trip Zeit
0.0
km/h
0.00 km
Trip
00:02
140 km
00.00.00
Trip Zeit
0.0
km/h
0.00 km
Trip
00:02
140 km
00.00.00
Trip Zeit
SPORT
POWER
The drive unit is not assisting The drive unit is providing
medium assist
The drive unit is providing
maximum assist
0.0
km/h
0.00 km
Trip
ECO
00:02
140 km
00.00.00
Trip Zeit
0.0
km/h
0.00 km
Trip
00:02
140 km
00.00.00
Trip Zeit
0.0
km/h
0.00 km
Trip
00:02
140 km
00.00.00
Trip Zeit
SPORT
POWER
