DeWalt DCS353D2 User manual

DCS353

B
Copyright DeWALT
English (original instructions) 5

1
Fig. A
Fig. B
31
4
8
29
5
6
7
9
8
11
8
9
XXXX XX XX
10

2
26
25
19
29
16
6
5
Fig. C
Fig. E
Fig. G
Fig. D
Fig. F
Fig. H
21 13
23
19
3
15
14

3
6
17
7
6
17
7
12
4
1
2
27
28
Fig. I
Fig. K
Fig. M
Fig. L
Fig. N
Fig. J

4
16
20
29
19
30
5
20
25
20
22
Fig. O
Fig. P Fig. Q

ENGLISH
5
EC-Declaration of Conformity
Machinery Directive
o
Cordless Oscillating Multi-Tool
DCS353
DeWALT declares that these products described under Technical
Data are in compliance with:
2006/42/EC, EN62841-1:2015, EN62841-2-4:2014.
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact DeWALT at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf ofDeWALT.
Markus Rompel
Vice-President Engineering, PTE-Europe
DeWALT, Richard-Klinger-Straße 11,
65510, Idstein, Germany
30.08.2021
The vibration and/or noise emission level given in this information
sheet has been measured in accordance with a standardised test
given in EN 62841 and may be used to compare one tool with
another. It may be used for a preliminary assessment ofexposure.
WARNING: The declared vibration and/or noise
emission
level represents the main applications of the tool. However,
if the tool is used for different applications, with different
accessories or is poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase the
exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/or
noise should also take into account the times when the tool is
switched off or when it is running but not actually doing the
job. This may significantly reduce the exposure level over the
total workingperiod.
Identify additional safety measures to protect the operator
from the effects of vibration and/or noise such as: maintain
the tool and the accessories, keep the hands warm (relevant
for vibration), organisation of workpatterns.
DCS353
Voltage VDC 12
Type 1
Battery type Li‑Ion
Oscillating frequency min‑10–18000
Oscillating angle 1.6˚
Weight (without battery pack) kg 0.84
Noise values and/or vibration values (triax vector sum) according to
EN62841‑2‑4:
LPA (emission sound pressure level) dB(A) 86
LWA (sound power level) dB(A) 97
K (uncertainty for the given sound level) dB(A) 3
Vibration emission value a
h
= m/s29.9
Uncertainty K = m/s21.5
Congratulations!
You have chosen a DeWALT tool. Years of experience, thorough
product development and innovation make DeWALT one of the
most reliable partners for professional power toolusers.
Technical Data
English (original instructions)
CORDLESS OSCILLATING MULTI‑TOOL
DCS353
DECLARATION OF CONFORMITY
THE SUPPLY OF MACHINERY SAFETY
REGULATIONS 2008
Cordless Oscillating Multi-Tool
DCS353
DeWALT declares that these products described under Technical
Data are in compliancewith:
The Supply of Machinery (Safety) Regulations, 2008, S.I.
2008/1597 (as amended), EN62841-1:2015, EN62841-2-4:2014
These products conform to the following UK Regulations:
Electromagnetic Compatibility Regulations, 2016, S.I.2016/1091
(as amended).
The Restriction of the Use of Certain Hazardous Substances
in Electrical and Electronic Equipment Regulations 2012, S.I.
2012/3032 (as amended).
For more information, please contact DeWALT at the following
address or refer to the back of the manual.

6
ENGLISH
GENERAL POWER TOOL SAFETY WARNINGS
WARNING: Read all safety warnings, instructions,
illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below
may result in electric shock, fire and/or seriousinjury.
WARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.
Denotes risk of electricshock.
Denotes risk offire.
Batteries
Chargers/Charge Times (Minutes)
Cat #
DC
Weight
*Date code 201811475B or later
**Date code 201536or later
Batteries Chargers/Charge Times (Minutes)**
Cat # VDC Ah
Weight
kg DCB104 DCB107 DCB110 DCB112/
DCB1102 DCB113 DCB115/ DCB1104 DCB116 DCB132 DCB119
DCB122 12 2.0 0.22 30 90 90 60 50 30 30 30 60
DCB124/G 12 3.0 0.25 45 140 140 90 70 45 45 45 90
DCB125 12 1.3 0.20 22 60 60 40 30 22 22 22 40
DCB126/G 12 5.0 0.46 75 240 240 150 120 75 75 75 150
DCB127 12 2.0 0.22 30 90 90 60 50 30 30 30 60
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf of DeWALT.
Karl Evans
Vice President Professional Power Tools EANZ GTS
DeWALT UK,
270 Bath Road, Slough
SL1 4DX
Berkshire, England
30.08.2021
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTUREREFERENCE
The term “power tool” in the warnings refers to your mains‑operated
(corded) power tool or battery‑operated (cordless) powertool.
1) Work Area Safety
a ) Keep work area clean and well lit. Cluttered or dark
areas inviteaccidents.
b ) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which
may ignite the dust orfumes.
c ) Keep children and bystanders away while operating
a power tool. Distractions can cause you to losecontrol.
2) Electrical Safety
a ) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of
electricshock.
b ) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if
your body is earthed orgrounded.
c ) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electricshock.
d ) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electricshock.
e ) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electricshock.
f ) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electricshock.
3) Personal Safety
a ) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment

7
ENGLISH
Additional Safety Rules for Oscillating
Multi-Tool
WARNING: Take special care when sanding some woods
(e.g. beech, oak) and metal which may produce toxic dust.
Wear a dust mask specifically designed for protection
f ) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier tocontrol.
g ) Use the power tool, accessories and tool bits, etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardoussituation.
h ) Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the
tool in unexpectedsituations.
5) Battery Tool Use and Care
a ) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another batterypack.
b ) Use power tools only with specifically designated
battery packs. Use of any other battery packs may create
a risk of injury andfire.
c ) When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause burns
or afire.
d ) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation orburns.
e ) Do not use a battery pack or tool that is damaged
or modified. Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire, explosion or risk
ofinjury.
f ) Do not expose a battery pack or tool to fire or
excessive temperature. Exposure to fire or temperature
above 130°C may causeexplosion.
g ) Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specified in the instructions. Charging
improperly or at temperatures outside the specified range
may damage the battery and increase the risk offire.
6) Service
a ) Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool ismaintained.
b ) Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorised serviceproviders.
of inattention while operating power tools may result in
serious personalinjury.
b ) Use personal protective equipment. Always wear eye
protection. Protective equipment such as a dust mask,
non‑skid safety shoes, hard hat or hearing protection used
for appropriate conditions will reduce personalinjuries.
c ) Prevent unintentional starting. Ensure the switch
is in the off position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on
invitesaccidents.
d ) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached
to a rotating part of the power tool may result in
personalinjury.
e ) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpectedsituations.
f ) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can be
caught in movingparts.
g ) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can
reduce dust‑relatedhazards.
h ) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause severe
injury within a fraction of asecond.
4) Power Tool Use and Care
a ) Do not force the power tool. Use the correct power
tool for your application. The correct power tool
will do the job better and safer at the rate for which it
wasdesigned.
b ) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must berepaired.
c ) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the
power toolaccidentally.
d ) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrainedusers.
e ) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by
poorly maintained powertools.

8
ENGLISH
Chargers
DeWALT chargers require no adjustment and are designed to be
as easy as possible tooperate.
Electrical Safety
The electric motor has been designed for one voltage only.
Always check that the battery pack voltage corresponds to the
voltage on the rating plate. Also make sure that the voltage of
your charger corresponds to that of yourmains.
iYour DeWALT charger is double insulated in
accordance with EN60335; therefore, no earth wire
isrequired.
If the supply cord is damaged, it must be replaced only by
DeWALT or an authorised serviceorganisation.
Residual Risks
In spite of the application of the relevant safety regulations
and the implementation of safety devices, certain residual risks
cannot be avoided. These are:
• Impairment ofhearing.
• Risk of personal injury due to flyingparticles.
• Risk of burns due to accessories becoming hot
duringoperation.
• Risk of personal injury due to prolongeduse.
SAVE THESE INSTRUCTIONS
against toxic dust and fumes and ensure that persons
within or entering the work area are alsoprotected.
WARNING: Use this tool in a well‑ventilated area when
sanding ferrous metals. Do not operate the tool near
flammable liquids, gases or dust. Sparks or hot particles
from sanding or arcing motor brushes may ignite
combustiblematerials.
Sanding Paint
WARNING: Observe the applicable regulations for
sanding paint. Pay special attention to the following:
• Whenever possible, use a vacuum extractor for dustcollection.
• Take special care when sanding paint which is possibly
lead based:
‑ Do not let children or pregnant women enter the
workarea.
‑ All persons entering the work area should wear a mask
specially designed for protection against lead paint dust
andfumes.
‑ Do not eat, drink or smoke in the workarea.
• Dispose of dust particles and any other removal debrissafely.
• Hold the power tool by insulated gripping surfaces when
performing an operation where the cutting tool may
contact hidden wiring or its own cord. Contact with a "live"
wire will make exposed metal parts of the tool "live" and shock
theoperator.
• Use clamps or another practical way to secure and
support the workpiece to a stable platform. Holding the
work by hand or against your body leaves it unstable and may
lead to loss ofcontrol.
Mains Plug Replacement
(U.K.& Ireland Only)
If a new mains plug needs to be fitted:
• Safely dispose of the oldplug.
• Connect the brown lead to the live terminal in theplug.
• Connect the blue lead to the neutralterminal.
WARNING: No connection is to be made to the
earthterminal.
Follow the fitting instructions supplied with good quality plugs.
Recommended fuse: 3A.
Using an Extension Cable
An extension cord should not be used unless absolutely
necessary. Use an approved extension cable suitable for the
power input of your charger (refer to Technical Data). The
minimum conductor size is 1mm2; the maximum length is30m.
When using a cable reel, always unwind the cablecompletely.
Important Safety Instructions for All
BatteryChargers
SAVE THESE INSTRUCTIONS: This manual contains important
safety and operating instructions for compatible battery
chargers (referto TechnicalData). Before using charger, read all
instructions and cautionary markings on charger, battery pack, and
product using batterypack.
WARNING: Shock hazard. Do not allow any liquid to get
inside charger. Electric shock mayresult.
WARNING: We recommend the use of a residual current
device with a residual current rating of 30mA orless.
CAUTION: Burn hazard. To reduce the risk of injury,
charge only DeWALT rechargeable batteries. Other types of
batteries may burst, causing personal injury anddamage.
CAUTION: Children should be supervised to ensure that
they do not play with theappliance.
NOTICE: Under certain conditions, with the charger
plugged into the power supply, the exposed charging
contacts inside the charger can be shorted by foreign
material. Foreign materials of a conductive nature such as,
but not limited to, steel wool, aluminum foil or any buildup
of metallic particles should be kept away from charger
cavities. Always unplug the charger from the power supply
when there is no battery pack in the cavity. Unplug charger
before attempting toclean.
• DO NOT attempt to charge the battery pack with any
chargers other than the ones in this manual. The charger
and battery pack are specifically designed to worktogether.
• These chargers are not intended for any uses other than
charging DeWALT rechargeable batteries. Any other uses
may result in risk of fire, electric shock orelectrocution.
• Do not expose charger to rain orsnow.
• Pull by plug rather than cord when disconnecting charger.
This will reduce risk ofdamage to electric plug andcord.
• Make sure that cord is located so that it will not be
stepped on, tripped over, or otherwise subjected to
damage orstress.

9
ENGLISH
Battery Packs
Important Safety Instructions for All BatteryPacks
When ordering replacement battery packs, be sure to include
catalogue number andvoltage.
has reached an appropriate temperature, the yellow light will
turn off and the charger will resume the chargingprocedure.
The compatible charger(s) will not charge a faulty battery pack.
The charger will indicate faulty battery by refusing tolight.
NOTE: This could also mean a problem with acharger.
If the charger indicates a problem, take the charger and battery
pack to be tested at an authorised servicecentre.
Hot/Cold Pack Delay
When the charger detects a battery pack that is too hot or too
cold, it automatically starts a Hot/Cold Pack Delay, suspending
charging until the battery pack has reached an appropriate
temperature. The charger then automatically switches to the pack
charging mode. This feature ensures maximum battery packlife.
A cold battery pack will charge at a slower rate than a warm
battery pack. The battery pack will charge at that slower rate
throughout the entire charging cycle and will not return to
maximum charge rate even if the battery packwarms.
The DCB118 charger is equipped with an internal fan designed to
cool the battery pack. The fan will turn on automatically when the
battery pack needs to be cooled. Never operate the charger if the
fan does not operate properly or if ventilation slots are blocked.
Do not permit foreign objects to enter the interior of thecharger.
Electronic Protection System
XR Li-Ion tools are designed with an Electronic Protection
System that will protect the battery pack against overloading,
overheating or deepdischarge.
The tool will automatically turn off if the Electronic Protection
System engages. If this occurs, place the lithium-ion battery
pack in the charger until it is fullycharged.
Wall Mounting
These chargers are designed to be wall mountable or to sit
upright on a table or work surface. If wall mounting, locate the
charger within reach of an electrical outlet, and away from a
corner or other obstructions which may impede air flow. Use
the back of the charger as a template for the location of the
mounting screws on the wall. Mount the charger securely using
drywall screws (purchased separately) at least 25.4mm long
with a screw head diameter of 7–9mm, screwed into wood to
an optimal depth leaving approximately 5.5mm of the screw
exposed. Align the slots on the back of the charger with the
exposed screws and fully engage them in theslots.
Charger Cleaning Instructions
WARNING:Shock hazard. Disconnect the charger
from the AC outlet before cleaning. Dirt and grease
may be removed from the exterior of the charger using a
cloth or soft non‑metallic brush. Do not use water or any
cleaning solutions. Never let any liquid get inside the tool;
never immerse any part of the tool into aliquid.
• Do not use an extension cord unless it is absolutely
necessary. Use of improper extension cord could result in risk
of fire, electric shock, orelectrocution.
• Do not place any object on top of charger or place
the charger on a soft surface that might block the
ventilation slots and result in excessive internal heat.
Place the charger in a position away from any heat source. The
charger is ventilated through slots in the top and the bottom
of thehousing.
• Do not operate charger with damaged cord or plug—
have them replacedimmediately.
• Do not operate charger if it has received a sharp blow,
been dropped, or otherwise damaged in any way. Take it
to an authorised servicecentre.
• Do not disassemble charger; take it to an authorised service
centre when service or repair is required. Incorrect reassembly
may result in a risk of electric shock, electrocution orfire.
• In case of damaged power supply cord, the supply cord must
be replaced immediately by the manufacturer, its service agent
or similar qualified person to prevent anyhazard.
• Disconnect the charger from the outlet before attempting
any cleaning. This will reduce the risk of electric shock.
Removing the battery pack will not reduce thisrisk.
• NEVER attempt to connect two chargerstogether.
• The charger is designed to operate on standard
230V household electrical power. Do not attempt to
use it on any other voltage. This does not apply to the
vehicularcharger.
Charging a Battery (Fig.B)
1. Plug the charger into an appropriate outlet before inserting
batterypack.
2. Insert the battery pack 1 into the charger, making sure the
battery pack is fully seated in the charger. The red (charging)
light will blink repeatedly, indicating that the charging
process hasstarted.
3. The completion of charge will be indicated by the red light
remaining ON continuously. The battery pack is fully charged
and may be used at this time or left in the charger. To
remove the battery pack from the charger, push the battery
release button 9 on the batterypack.
NOTE: To ensure maximum performance and life of lithium-ion
battery packs, charge the battery pack fully before firstuse.
Charger Operation
Refer to the indicators below for the charge status of the batterypack.
Charge Indicators
FCharging I
GFully Charged J
HHot/Cold Pack Delay* K
*The red light will continue to blink, but a yellow indicator light
will be illuminated during this operation. Once the battery pack

10
ENGLISH
Transportation
WARNING: Fire hazard. Transporting batteries can
possibly cause fire if the battery terminals inadvertently
come into contact with conductive materials. When
transporting batteries, make sure that the battery
terminals are protected and well‑insulated from
materials that could contact them and cause a short
circuit. NOTE: Lithium‑ion batteries should not be put in
checkedbaggage.
DeWALT batteries comply with all applicable shipping
regulations as prescribed by industry and legal standards, which
include UN Recommendations on the Transport of Dangerous
Goods; International Air Transport Association (IATA) Dangerous
Goods Regulations; International Maritime Dangerous Goods
(IMDG) Regulations; and the European Agreement Concerning
The International Carriage of Dangerous Goods by Road
(ADR). Lithium-ion cells and batteries have been tested to
section 38.3of the UN Recommendations on the Transport of
Dangerous Goods Manual of Tests andCriteria.
In most instances, shipping a DeWALT battery pack will
be excepted from being classified as a fully regulated
Class9Hazardous Material. In general, only shipments containing
a lithium-ion battery with an energy rating greater than 100Watt
Hours (Wh) will require being shipped as fully regulated Class9.
All lithium-ion batteries have the Wh rating marked on the pack.
Furthermore, due to regulation complexities, DeWALT does
not recommend air shipping lithium-ion battery packs alone
regardless of Wh rating. Shipments of tools with batteries (combo
kits) can be air shipped as excepted if the Wh rating of the battery
pack is no greater than 100Wh.
Regardless of whether a shipment is considered excepted
or fully regulated, it is the shipper's responsibility to consult
the latest regulations for packaging, labeling/marking and
documentationrequirements.
The information provided in this section of the manual is
provided in good faith and believed to be accurate at the time
the document was created. However, no warranty, expressed or
implied, is given. It is the buyer’s responsibility to ensure that its
activities comply with the applicableregulations.
Storage Recommendations
1. The best storage place is one that is cool and dry away from
direct sunlight and excessive heat or cold. For optimum
battery performance and life, store battery packs at room
temperature when not inuse.
2. For long storage, it is recommended to store a fully charged
battery pack in a cool, dry place out of the charger for
optimalresults.
NOTE: Battery packs should not be stored completely depleted
of charge. The battery pack will need to be recharged beforeuse.
Labels on Charger and Battery Pack
In addition to the pictographs used in this manual, the
labels on the charger and the battery pack may show the
followingpictographs:
The battery pack is not fully charged out of the carton. Before
using the battery pack and charger, read the safety instructions
below. Then follow charging proceduresoutlined.
READ ALL INSTRUCTIONS
• Do not charge or use battery in explosive atmospheres,
such as in the presence of flammable liquids, gases or
dust. Inserting or removing the battery from the charger may
ignite the dust orfumes.
• Never force battery pack into charger. Do not modify
battery pack in any way to fit into a non‑compatible
charger as battery pack may rupture, causing serious
personalinjury.
• Charge the battery packs only in DeWALTchargers.
• DO NOT splash or immerse in water or otherliquids.
• Do not store or use the tool and battery pack in locations
where the temperature may fall below 4˚C (39.2˚F)
(such as outside sheds or metal buildings in winter), or
reach or exceed 40˚C (104˚F) (such as outside sheds or
metal buildings insummer).
• Do not incinerate the battery pack even if it is severely
damaged or is completely worn out. The battery pack can
explode in a fire. Toxic fumes and materials are created when
lithium‑ion battery packs areburned.
• If battery contents come into contact with the skin,
immediately wash area with mild soap and water. If
battery liquid gets into the eye, rinse water over the open eye
for 15minutes or until irritation ceases. If medical attention
is needed, the battery electrolyte is composed of a mixture of
liquid organic carbonates and lithiumsalts.
• Contents of opened battery cells may cause respiratory
irritation. Provide fresh air. If symptoms persist, seek
medicalattention.
WARNING: Burn hazard. Battery liquid may be flammable
if exposed to spark orflame.
WARNING: Never attempt to open the battery pack for
any reason. If battery pack case is cracked or damaged,
do not insert into charger. Do not crush, drop or damage
battery pack. Do not use a battery pack or charger that
has received a sharp blow, been dropped, run over or
damaged in any way (i.e., pierced with a nail, hit with
a hammer, stepped on). Electric shock or electrocution
may result. Damaged battery packs should be returned to
service centre forrecycling.
WARNING: Fire hazard. Do not store or carry the
battery pack so that metal objects can contact
exposed battery terminals. For example, do not place
the battery pack in aprons, pockets, tool boxes, product kit
boxes, drawers, etc., with loose nails, screws, keys,etc.
CAUTION: When not in use, place tool on its side on
a stable surface where it will not cause a tripping
or falling hazard. Some tools with large battery packs
will stand upright on the battery pack but may be easily
knockedover.

11
ENGLISH
Description (Fig.A)
WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1 Variable speed trigger
2 LED Worklight
3 Accessory clamp lever
4 Lock on/off button
5 Accessory side mount slots
6 Cut guide block
7 Cut guide arm
8 Battery pack
9 Battery release button
Intended Use
This oscillating multi-tool is designed for professional detail
sanding, plunge cutting, flush cutting, removal of excess
materials and surface preparationapplications.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
This oscillating multi-tool is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
Date Code Position (Fig.B)
The production date code 10 consists of a 4-digit year followed
by a 2-digit week and is extended by a 2-digit factorycode.
Markings on Tool
The following pictograms are shown on the tool:
a Read instruction manual beforeuse.
g Wear earprotection.
f Wear eyeprotection.
n Visible radiation. Do not stare intolight.
Package Contents
The package contains:
1 Adaptor for all blades
1 31mm x 43mm Fastcut wood blade
1 Sanding-pad
1 31mm x 43mm Wood with nails blade
1 Rigid scraper blade**
1 Blade adaptor hex key
1 Dust extraction adaptor**
1 Cutting guide**
1 Pack of assorted sanding sheets
1 9.5mm x 43mm Wood detail blade**
1 Cutting guide hex key**
1 Charger
1 TSTAK kitbox
1 Li-Ion battery pack (C1, D1, L1, M1, P1, S1, T1, X1,Y1 models)
Battery Type
These battery packs may be used: DCB122, DCB124, DCB124G,
DCB125, DCB126, DCB126G, DCB127. Refer to Technical Data
for moreinformation.
LRead instruction manual beforeuse.
p Refer to Technical Data for chargingtime.
q Do not probe with conductiveobjects.
r Do not charge damaged batterypacks.
s Do not expose towater.
t Have defective cords replacedimmediately.
u Charge only between 4˚C and 40˚C.
v Only for indooruse.
x Discard the battery pack with due care for
theenvironment.
y Charge DeWALT battery packs only with designated
DeWALT chargers. Charging battery packs other than
the designated DeWALT batteries with a DeWALT
charger may make them burst or lead to other
dangeroussituations.
z Do not incinerate the batterypack.
2 Li-Ion battery packs (C2, D2, L2, M2, P2, S2, T2, X2,Y2 models)
3 Li-Ion battery packs (C3, D3, L3, M3, P3, S3, T3, X3,Y3 models)
1 Instruction manual
** Accessory included only with NT models and kits containing
battery andcharger.
NOTE: Battery packs, chargers and kitboxes are not included
with N models. Battery packs and chargers are not included with
NT models. Bmodels include Bluetooth® batterypacks.
NOTE: The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by DeWALT is under license. Other trademarks and
trade names are those of their respectiveowners.
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.

12
ENGLISH
Cut Guide (Fig.I)
This feature allows you to more accurately track a marked
cutline.
1. Insert the guide arm7 as shown in FigureI into the slots on
the left and right sides of the guide block6.
Depth Guide (Fig.J)
This feature allows you to precisely cut material at a
specifieddepth.
1. Insert the guide arm7 as shown in FigureJ into the front
slot on the guide block6.
2. Adjust the length of the guide by pulling out or pushing
inward to achieve the desired cut depth as shown in
FigureJ.
3. Secure the guide in place by turning the depth/cut
adjustment knob17 clockwise. To release the guide turn
the depth/cut adjustment knobcounterclockwise.
Attaching the Cut Guide (Fig.H)
The depth/cut guide allows you to precisely cut material at a
specified depth and more accurately track a marked cutline.
1. Attach the cut guide block6 by inserting the accessory
tabs16 on the guide into the accessory side mount slots5
on the main body of thetool.
NOTE: The depth/cut guide can be attached to either side
of thetool.
2. Secure the block to the main body with the supplied
screw29 and washer. Tighten with the supplied hex
wrench19.
Attaching Accessories Using the Universal
Adapter (Fig.G)
CAUTION: To avoid injury, do not use any accessory
for an application where the adaptor may fail to hold
theaccessory.
CAUTION: Read and follow all manufacturers' safety
warnings for any accessories used with thistool.
CAUTION: To avoid injury, ensure adaptor and accessory
are securelytightened.
Non-DeWALT accessories can be attached using the
universaladaptor.
1. Place the washer23 on thetool.
2. Place accessory13 on towasher.
3. Tighten and secure adaptor nut21 using hex wrench19.
Installing/Removing Accessories (Fig.C–E)
The tool features an exclusive Tool-Free System for faster
accessory changes and adjustments without the need for
wrenches or hex keys like other oscillating toolsystems.
Inserting and Removing the Battery Pack
from the Tool (Fig.B)
NOTE: Make sure your battery pack 1 is fullycharged.
To Install the Battery Pack into the Tool Handle
1. Align the battery pack with the rails inside the tool’s
handle(Fig. B).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap intoplace.
To Remove the Battery Pack from the Tool
1. Press the battery release button 9 and firmly pull the
battery pack out of the toolhandle.
2. Insert battery pack into the charger as described in the
charger section of thismanual.
Fuel Gauge Battery Packs (Fig.B)
Some DeWALT battery packs include a fuel gauge, which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge button.
A combination of the three green LED lights will illuminate,
designating the level of charge left. When the level of charge
in the battery is below the usable limit, the fuel gauge will not
illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.
WARNING: Risk of lacerations or burns. Do not touch
the sharp edges of accessories at any time. Do not
touch workpiece or blade immediately after operating the
tool. They can become very hot. Handle carefully. Always
allow accessories and workpiece to cool beforehandling.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
WARNING: Use only DeWALT batteries andchargers.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
without supervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
1. Grasp the tool and squeeze the Tool-Free accessory
clamp's3lever.
2. Clean any residual debris from the tool shaft15 and
the Tool-Free accessory clampholder.
3. Slide the accessory between the shaft and the
accessory holder making sure the accessory engages
all of the pins14 on the holder and is flush with
theshaft.
4. Release the Tool-Free accessory clamplever.
5. Some accessories, such as scrapers and blades can be
mounted at an angle ifrequired.

13
ENGLISH
Belt Hook (Fig.N)
Optional Accessory
WARNING:To reduce the risk of serious personal
injury, ONLY use the tool’s belt hook to hang the tool
from a work belt. DO NOT use the belt hook for tethering
or securing the tool to a person or object during use. DO
NOT suspend tool overhead or suspend objects from the
belthook.
WARNING:To reduce the risk of serious personal
injury, ensure the screw holding the belt hook issecure.
IMPORTANT: When attaching or replacing the belt hook, only
use the screw28 that is provided with the belt hook. Be sure to
securely tighten thescrew.
To accommodate left- or right- handed users the belt hook27
can be attached to the tool using one of the slots below the
main handle on left or right side and using the provided
screw28 installed on the underside of the mainhandle.
If the belt hook is not desired at all, it can be removed from
thetool.
Installing/Removing Sanding Sheets (Fig.F)
A diamond shaped platen25 uses a hook and loop adhesion
system to attach the sanding sheets26. The platen allows you
to use it on large flat surfaces and tight spots orcorners.
1. Attach the sanding platen accesory as described under
Installing/RemovingAccessories.
2. Align the edges on the sanding sheet with the edge of the
sanding platen and press the sanding sheet onto theplaten.
3. Firmly press the base with the sanding sheet attached
against a flat surface and briefly switch the tool on. This
provides for good adhesion between the platen and the
sanding sheet and also helps to prevent prematurewear.
NOTE: When the tip of the sanding sheet becomes worn,
detach the sheet from the platen, rotate andreapply.
Attaching the Dust Extraction Adaptor
(Fig.O)
The Dust Extraction Adaptor allows you to connect the tool to
an external dust extractor, either using the AirLock™ system
(DWV9000-XJ), or a standard 35mm dust extractorfitment.
1. Attach the dust extraction adaptor20 by inserting the
tabs16 in to the accessory side mount slots5.
NOTE: The dust extraction adaptor can be attached to either
side of thetool.
2. Insert screw29 and washer30 into the dust extraction
adaptor20 and tighten with the supplied hex wrench19.
Lock on/off Button (Fig.L)
The tool can be locked off by fully depressing the lock on/off
button4 to the left as shown in Figure L.
Pushing the lock on/off button4 to the left with the
trigger1 depressed will lock the trigger in the depressed
position. This allows for more comfort and control in extended
useapplications.
Pressing the trigger switch again will release the lock out and
the tool will turn off upon release of thetrigger.
NOTE: The tool will automatically shut off after operating
for five minutes with the lock-on button engaged. To restart
Instructions for Use (Fig.A, K)
1. Install the batterypack.
2. To turn the tool ON, hold it as shown in FigureK and press
the variable speed trigger1.
NOTE: The further the trigger switch is depressed the faster
the tool will operate. If in doubt about the proper speed
for your operation, test the performance at low speed and
gradually increase until a comfortable speed isfound.
3. To turn the tool OFF, release the variable speed trigger1.
Proper Hand Position (Fig.K)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown.
WARNING: To reduce the risk of serious personal injury,
ALWAYS hold securely in anticipation of a suddenreaction.
Proper hand position requires one hand on the main handle12.
WARNING: Ensure switch is fully OFF before installing
thebattery.
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and
applicableregulations.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
2. Adjust the length of the guide by pulling out or pushing
inward to achieve the desired length as shown in FigureI.
3. Secure the guide in place by turning the depth/cut
adjustment knob17 clockwise. To release the guide turn
the depth/cut adjustment knobcounterclockwise.
NOTE: The guide arm can also be placed in the guard assembly
vertically in order to set the height off a cut. Refer to FigureJ.
To Install the Belt Hook
1. Insert the hook into one of the slots, on left or right side,
below the mainhandle.
2. Install the screw on the underside of the mainhandle. Be
sure to securely tighten thescrew.
To Remove or Move the Belt Hook
1. Remove the screw located on the underside of the
mainhandle.
2. Pull the belt hook away from the mainhandle.
3. Insert the hook into one of the slots, on left or right side,
below the main handle, or install the screw on the underside
of the mainhandle. Be sure to securely tighten thescrew.

14
ENGLISH
Compatible accessories
Oscillating sanding pad
Oscillating wood w/ nails blade
Wide titanium oscillating wood w/ nails blade
Oscillating hardwood blade
Oscillating fastcut wood blade
Wide oscillating fastcut wood blade
Oscillating wood detail blade
Oscillating titanium metal blade
Oscillating semicircle blade
Oscillating titanium semicircle blade
Oscillating flush cut blade
Titanium oscillating flush cut blade
Oscillating multi-material blade
Oscillating rigid scraper blade
Oscillating flexible scraper blade
Oscillating carbide grout removal blade
Oscillating fastcut carbide grout removal blade
Oscillating carbide rasp
Optional Accessories
WARNING: Since accessories, other than those offered
by DeWALT, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only DeWALT‑recommended
accessories should be used with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
Cleaning
WARNING: Electrical shock and mechanical hazard.
Disconnect the electrical appliance from the power source
beforecleaning.
WARNING: To ensure safe and efficient operation,
always keep the electrical appliance and the ventilation
slotsclean.
WARNING: Never use solvents or other harsh chemicals
for cleaning the non‑metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
Ventilation slots can be cleaned using a dry, soft non-metallic
brush and/or a suitable vacuum cleaner. Do not use water or
any cleaning solutions. Wear approved eye protection and an
approved dustmask.
Lubrication
Your power tool requires no additionallubrication.
MAINTENANCE
Your power tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regularcleaning.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
Helpful Hints
• Always ensure the workpiece is firmly held or clamped to
prevent movement. Any movement of the material may
affect the quality of the cutting or sandingfinish.
• Do not start sanding without having the sandpaper
attached to sandingplaten.
• Use coarse grit paper to sand rough surfaces, medium grit
for smooth surfaces and fine grit for the finishing surfaces. If
necessary, first make a test run on scrapmaterial.
• Excessive force will reduce the working efficiency and cause
motor overload. Replacing the accessory regularly will
maintain optimum workingefficiency.
• Do not allow the sandpaper to wear away, it will damage
the sanding pad.
• If the tool overheats, especially when used at low speed,
set the speed to maximum and run it with no load for 2–3
minutes to cool the motor. Avoid prolonged usage at very
low speeds. Always keep the bladesharp.
Using the Dust Extraction Adaptor with
Plunge Cutting Accessory (Fig.Q)
1. Attach the dust extraction adaptor. Refer to Attaching the
Dust ExtractionAdaptor.
2. Push dust extraction arm22 into the lower aperture of the
dust extraction adaptor20.
3. Attach plunge cutting blade as described under Installing/
RemovingAccessories.
4. Adjust the dust extraction arm22 for bestresults.
Using the Dust Extraction Adaptor with the
Sanding Platen (Fig.P)
1. Attach the dust extraction adaptor20. Refer to Attaching
the Dust ExtractionAdaptor.
2. Attach the sanding platen25 as described under
Installing/RemovingAccessories.
3. Attach sanding sheet as described under Installing/
Removing SandingSheets.
LED Worklight (Fig.M)
The LED worklight2 will activate when the trigger is depressed.
It will automatically shut off following a short period of time
once the trigger isreleased.
the tool, the user will have to release the trigger and repress
lock-onbutton.
installing attachments or accessories. An accidental
start‑up can causeinjury.
The charger and battery pack are notserviceable.

15
ENGLISH
Protecting the Environment
wSeparate collection. Products and batteries marked
with this symbol must not be disposed of with normal
householdwaste.
Products and batteries contain materials that can be
recovered or recycled, reducing the demand for raw materials.
Please recycle electrical products and batteries according to local
provisions. Further information is available at www.2helpU.com.
Rechargeable Battery Pack
This long-life battery pack must be recharged when it fails to produce
sufficient power on jobs that were easily done before. At the end of
its technical life, discard it with due care for ourenvironment:
• Run the battery pack down completely, then remove it from
thetool.
• Li-Ion cells are recyclable. Take them to your dealer or a
local recycling station. The collected battery packs will be
recycled or disposed ofproperly.

NA377607 08/23
Belgique et
Luxembourg België en Luxemburg
DeWALT ‑ Belgium BVBA
EgideWalschaertsstraat 16
2800Mechelen
Tel: NL 3215473763
Tel: FR 3215473764
Fax: 3215473799
www.dewalt.be
enduser[email protected]
Danmark DeWALT (Stanley Black&Decker AS)
Roskildevej 22
2620Albertslund
Tel: 70201510
Fax: 70224910
www.dewalt.dk
[email protected]
Deutschland DeWALT
Richard‑Klinger‑Str. 11
65510Idstein
Tel: 06126‑21‑0
Fax: 06126‑21‑2770
www.dewalt.de
[email protected]
Ελλά DeWALT (Ελλάς) Α.Ε.
EΔΡΑ‑ΓΡΑΦΕΙΑ : Στράβωνος 7
& Λ. Βουλιαγμένης, Γλυφάδα 16674, Αθήνα
SERVICE : ΗμεροςΤόπος 2(Χάνι Αδάμ) – 19300Ασπρόπυργος
Τηλ: 00302108981616
Φαξ: 00302108983570
www.dewalt.gr
[email protected]
España DeWALT Ibérica, S.C.A.
Parc de Negocios“Mas Blau”
Edificio Muntadas, c/Bergadá, 1, Of. A6
08820El Prat de Llobregat (Barcelona)
Tel: 934797400
Fax: 934797419
www.dewalt.es
[email protected]
France DeWALT (Stanley Black & Decker France SAS)
62Chemin de la Bruyère
69570Dardilly, France
Tel: 0472203920
Fax: 0472203900
www.dewalt.fr
[email protected]
Schweiz
Suisse
Svizzera
DeWALT
In der Luberzen 42
8902Urdorf
Tel: 044‑ 7556070
Fax: 044‑ 7307067
www.dewalt.ch
[email protected]
Ireland DeWALT
Building 4500, Kinsale Road
Cork Airport Business Park
Cork, Ireland
Tel: 00353‑2781800
Fax: 012781811
www.dewalt.ie
[email protected]
Italia DeWALT
via Energypark 6
20871Vimercate (MB), IT
Tel: 800‑014353
39039‑9590200
Fax: 39039‑9590311
www.dewalt.it
Nederlands DeWALT
Netherlands BVPostbus 83,
6120AB BORN
Tel: 31164283063
Fax: 31164283200
www.dewalt.nl
Norge DeWALT
Postboks 4613
0405Oslo, Norge
Tel: 45251300
Fax: 45250800
www.dewalt.no
[email protected]
Österreich DeWALT
WerkzeugVertriebsges m.b.H
Oberlaaerstrasse 248, A‑1230Wien
Tel: 01‑ 66116‑ 0
Fax: 01‑ 66116‑ 614
www.dewalt.at
[email protected]
Portugal DeWALT
Ed. D Dinis, Quina da Fonte
Rua dos Malhoes 2 2A 2ºEsq.
Oeiras e S. Juliao da Barra, paço de Arcos e Caxias
2770071Paço de Arcos
Tel: [phone]
Fax: [phone]
www.dewalt.pt
[email protected]
Suomi DeWALT
PL47
00521Helsinki, Suomi
Puh: 0104004333
Faksi: 0800411340
www.dewalt.fi
[email protected]
Sverige DeWALT
BOX 94
43122Mölndal
Sverige
Tel: 031686160
Fax: 031686008
www.dewalt.se
[email protected]
Türkiye Stanley Black & DeckerTurkey Alet ÜretimTic. Ltd.Şti.
İçerenköy Mahallesi Umut Sokak No: 10‑12 / 82‑83‑84 Kat: 19
Ataşehir‑İstanbul,Türkiye
Tel: +90 2166652900
Faks: +90 2166652901
www.dewalt.com.tr
[email protected]
United Kingdom DeWALT, 270Bath Road;
Slough, Berks SL1 4DX
Tel: 01753‑567055
Fax: 01753‑572112
www.dewalt.co.uk
[email protected]
Australia / New Zealand DeWALT
810Whitehorse Road Box Hill
VIC 3128Australia
Tel: Aust 1800654155
Tel: NZ 0800339258
www.dewalt.com.au
www.dewalt.co.nz
Middle East Africa DeWALT
P.O. Box ‑ 17164,
Jebel Ali Free Zone (South), Dubai, UAE
Tel: 97148127400
Fax: 97142822765
www.dewalt.ae
[email protected]
