The HIGHlite display range of
SUPER-HIGH-BRIGHTNESS DIGITAL VIDEO PROJECTORS
HIGHlite 5000GV
USER MANUAL
Revision A - 01/02/2000

Directives covered by this Declaration
89/336/EEC Electromagnetic Compatibility Directive, amended by 92/31/EEC & 93/68/EEC.
73/23/EEC Low Voltage Equipment Directive, amended by 93/68/EEC.
Products covered by this Directive
Large Screen Projector type HIGHlite 5000GV.
Basis on which Conformity is being declared
The products identified above comply with the protection requirements of the above EU
directives, and the manufacturer has applied the following standards:-
EN 55022:1995 - Limits and Methods of Measurements of Radio Disturbance Characteristics
Information Technology Equipment.
EN 55024:1998 - Limits and Methods of Immunity Characteristics of Information
Technology Equipment.
EN 61000-3.2:1995 - Harmonic Current Emissions.
EN 61000-3.3:1995 - Immunity to Voltage Fluctuations and Flicker.
Conformance with the Low Voltage Directive is to EN 60950:1992 +A1 +A2 +A3 +A4
+A11 and is covered by TUV certificate No. S1 20500 13 dated January 6, 2000 and a copy
of which is available for inspection by the relevant enforcement authorities. The CE mark
was first applied in 2000.
Signed:
Authority: D.J. Quinn, Product Development Director
Date: 29th January 2000
Attention!
The attention of the specifier, purchaser, installer, or user is drawn to special measures and
limitations to use which must be observed when these products are taken into service to
maintain compliance with the above directives. Details of these special measures are
available on request, and are also contained in the product manuals.
Declaration of Conformity
LBV00063; Revision A - 01/02/2000

The technical documentation required to demonstrate that the products met the requirements
of the Low Voltage Directive has been compiled by the signatory below and is available for
inspection by the relevant enforcement authorities. The CE mark was first applied in 2000.
Supplier’s Declaration of Conformity
Declaration of Conformity with Electromagnetic Compatibility Standards as required under
the Radiocommunications Act.
We, Digital Projection Limited of Greenside Way, Middleton, Manchester, UK, M24 1XX
declare under our sole responsibility that the product:
DLP projector model - HIGHlite 5000GV
to which this declaration relates is in conformity with the following standards:
Title Number Date of Issue
Limits and methods of measurement of radio AS/NZS 3548 1995
disturbance characteristics of information Amdt 1/2 1997
technology equipment Class B.
Disturbance Characteristics of
Information Technology Equipment
Class A
Signed:
Authority: D.J. Quinn, Product Development Director
Date: 29th January 2000
LBV00063; Revision A - 01/02/2000

From time to time revisions will be issued to this manual. To maintain a correct and
up to date copy of the manual it is important that the instructions given in revision
notices are carried out.
The person carrying out the revision should complete the table below.
Revision No Revision Details Date Revised
Revision Record
LBV00063; Revision A - 01/02/2000

LBV00063; Revision A - 01/02/2000

The HIGHLite 5000GV is one of the finest, most technically advanced projectors
available today. The HIGHLite 5000GV enables you to project exceptionally bright,
precise images up to 500 inches across (measured diagonally) from your PC or
Macintosh computer, VCR, document camera, laser disc player, DVD player and
even an HD VCR or HD laser disc player.
Please read the following before proceeding
This initial release (Revision A) of the HIGHLite 5000GV User Manual has been
designed to provide basic information on the configuration and use of the projector.
A complete version of this manual will be available from Digital Projection in the
near future. Digital Projection disclaims any direct or indirect damages resulting
from the use of any information in this initial release.
An Outline of Contents is given overleaf which provides an overview of the five
sections, A to E, in this manual and lists all the major topics covered along with
their location. This outline allows the user to direct themselves to the appropriate
section of this manual where a detailed contents page will provide the exact location
of the topic required. Section identifiers are also provided on the outside edge of the
pages to allow the quick location of individual sections.
The user is strongly recommended to read Section A: Overview before unpacking
or switching on the projector, paying particular attention to the safety warnings
provided.
Disclaimer Digital Projection makes a sincere effort to ensure accuracy and quality of it's published materials;
however, no warranty, expressed or implied, is provided. Digital Projection disclaims any direct or indirect damages
resulting from the use of any information in this manual.
Introduction
Introduction
INTRODUCTION
LBV00063; Revision A - 01/02/2000

Digital Projection Limited,
Greenside Way, Middleton, Manchester M24 1XX, UK.
Registered in England No. 2207264, Registered Office: As Above
Tel: [phone]
Fax:[phone]
E-Mail:[email protected], [email protected]
Web Site:www.digitalprojection.co.uk
Digital Projection Inc.
55 Chastain Road, Suite 115, Kennesaw, GA 30144. USA
Tel: (USA) 770 420 1350
Fax: (USA) 770 420 1360
E-Mail: [email protected]
Web Site: www.digitalprojection.com
DMD and Digital Micromirror Device are trademarks of Texas Instruments Incorporated.
Introduction
INTRODUCTION
LBV00063; Revision A - 01/02/2000

Section A: Overview
Packaging .................................................................. A—1
Safety Advice ............................................................. A—2
Initial Preparation ...................................................... A—5
Components ............................................................... A—7
Section B: System Installation
Installation Guidelines................................................. B—1
Installation .................................................................. B—7
Setting Up the Projector ............................................. B—11
Connecting Signal Sources ....................................... B—13
Section C: System Operation
Remote Control Overview .......................................... C—1
Menu System Overview ............................................. C—7
Menu Operation ....................................................... C—10
Source Select ............................................................ C—11
Adjustments .............................................................. C—14
Image Options .......................................................... C—21
Projector Options ...................................................... C—25
Section D: Advanced User Information
Screen Illuminance ..................................................... D—1
DMD™ Operation and Usage ..................................... D—2
Multiple Projection ...................................................... D—4
Introduction
Outline of Contents
INTRODUCTION
LBV00063; Revision A - 01/02/2000

Section D: Advanced User Information (Cont.)
Technical Specification............................................... D—7
Section E: Maintenance
Lamp Replacement .................................................... E—1
Cleaning ..................................................................... E—2
Appendix
Glossary.............................................................................. i
Introduction
INTRODUCTION
LBV00063; Revision A - 01/02/2000

Packaging ........................................................................ A—1
Projector Packaging.................................................... A—1
Lens Packaging........................................................... A—1
Safety Advice ................................................................... A—2
Fire and Shock Precautions......................................... A—2
Lamp Precautions ....................................................... A—2
Power Supply ............................................................. A—3
Installation Advice ..................................................... A—4
Initial Preparation ............................................................ A—5
Pre-Installation Check................................................. A—5
Remote Control Unit - Battery Installation .................. A—6
Components ..................................................................... A—7
Part Names ................................................................. A—7
Control Panel ............................................................. A—8
Terminal Panel ......................................................... A—10
RGB Digital Connectors & Optional SDI Board ......... A—12
Remote Control ........................................................ A—14
Overview
Section A: Overview
OVERVIEW
LBV00063; Revision A - 01/02/2000

Overview
OVERVIEW
LBV00063; Revision A - 01/02/2000

Projector Packaging
The following components should be contained within the projector packaging.
Should any of the components be absent, please contact the dealer who supplied the
projector, or Digital Projection Limited (Digital Projection Inc. if in North
America) immediately.
1 x HIGHlite 5000GV Projector
1 x Remote Control Unit with Remote Cable (wireless/wired)
1 x AC Power Cable
1 x AC Power Cable Stopper
1 x DFP Cable
2 x AAA Batteries
1 x User Manual
1 x Foam Dust Cap
All packaging should be retained to provide maximum protection during future
shipping of the projector.
Lens Packaging
Lenses are supplied as individual items and the packaging may differ depending on
the version ordered. Please refer to the instructions supplied with your lens.
A—1
Overview
Packaging
OVERVIEW
LBV00063; Revision A - 01/02/2000

The safety instructions provided in this manual are to ensure the long life of your
projector and to prevent fire and shock. Please read them carefully and heed all
warnings.
Fire and Shock Precautions
Ensure that there is sufficient ventilation and that vents are unobstructed to prevent
potentially dangerous concentrations of ozone and the build-up of heat inside your
projector. Allow at least 20cm (8”) of space between your projector and a wall.
Allow at least 50cm (20”) of space between the ventilation duct outlet and object.
Ensure that nothing can be spilled on, or dropped inside the projector. If this does
happen, switch off and unplug the mains supply immediately. Do not operate the
projector again until it has been checked by qualified service personnel.
Do not insert any metal objects such as a wire or screwdriver into your projector.
Lamp Precautions
Due to the lamp being sealed in a pressurised environment, there is a small risk of
explosion, if not operated correctly. There is minimal risk involved, if the unit is in
proper working order, but if damaged or operated beyond the recommended 1500
hours, the risk of explosion increases.
The projector has a warning system that displays the following message when you
reach 1500 hours of operation - Lamp Running Time is Over 1500 Hours!!. When
you see this message please contact your Digital Projection dealer for a
replacement lamp.
A—2
Overview
Safety Advice
OVERVIEW
LBV00063; Revision A - 01/02/2000

gas, and will not cause harm if kept out of your eyes. If your eyes have been
exposed to this gas, please flush your eyes out with water immediately and seek
immediate medical attention. Do not rub your eyes as this could cause
serious injury.
WARNING: Do not look into the lens while the projector is on. Serious damage to
your eyes could result.
CAUTION: The high pressure lamp may explode if improperly handled. Refer all
servicing to qualified service personnel.
Power Supply
The projector is designed to operate on a power supply of 1.0kW 100-120VAC /
1.5kW 200-240VAC 50/60Hz. Ensure that your power supply fits this requirement
before attempting to use your projector.
Handle the power cable carefully and avoid excessive bending. A damaged cord can
cause electric shock or fire.
Running the power cord and the RGB cable close to each other can cause beat
noise. If this happens, keep the two separated so that beat noise is not generated.
If the projector is not be used for an extended period of time, disconnect the plug
from the power outlet. Do not unplug the power cable from the wall outlet under the
following circumstances, doing so may cause damage to the projector:
a) Immediately after the power cable is plugged into the wall outlet (the POWER
indicator has not changed to a steady amber glow).
b) Immediately after the lamp has been switched off. After the projector is turned
off with the POWER OFF button the cooling fan continues to operate for 3
minutes while the Two Digit INDICATOR "--" flashes.
c) While the hour glass icon or the message ‘Please wait a litttle’ is being displayed.
A—3
Overview
OVERVIEW
LBV00063; Revision A - 01/02/2000

Installation Advice
The projector should be placed on a flat, level surface and in a dry area free from
dust and moisture. Do not place the projector in direct sunlight, near heaters or heat
radiating appliances. Exposure to direct sunlight, smoke or steam could harm
internal components.
The projector should always be handled with care. Dropping or jarring the projector
could damage internal components.
If you wish to have the projector installed on the ceiling do not attempt to install the
projector yourself. The projector must be installed in accordance with any local
building codes by qualified technicians in order to ensure proper operation and
reduce the risk of bodily injury.
A—4
Overview
OVERVIEW
LBV00063; Revision A - 01/02/2000

Pre-Installation Check
Before mounting the projector in its intended location, the following pre-installation
routine must be performed:
1. Install the AC Power Lead
2. Install the projector lens.
2. Ensure all the air flow inlet and outlet ducts are clear from obstruction.
3. Switch on the projector and wait for approximately 30 seconds.
4. Insert batteries into the remote control unit (see overleaf).
5. With the screen or a wall illuminated, confirm the Menu System is operational
by pressing MENU on remote control.
6. Power down the projector and disconnect from the mains supply.
7. Continue with the system installation.
A—5
0verview
Initial Preparation
OVERVIEW
LBV00063; Revision A - 01/02/2000

Remote Control Unit - Battery Installation
The remote control unit can either be hard wired to the projector or powered by 2
AAA (HP16/RO3/LR03) alkaline batteries.
The battery compartment is located on the back of the remote control. To remove
the compartment cover press and open as shown below.
Insert the first battery into the compartment according to the (+) and (-) indications
inside the case and it to the back of the compartment. Insert the second battery by
pivoting it against the first and pushing down into place.
When the batteries are securely in place, replace the battery compartment cover.
A—6
Overview
OVERVIEW
LBV00063; Revision A - 01/02/2000

Part Names
A—7
0verview
Components
OVERVIEW
LBV00063; Revision A - 01/02/2000
Stacking Pad
Digital Input Terminal Panel
Remote Sensor
PC Card Slot
Lens (optional)
Input Terminal Panel
Ventilation (In) Foot
Release Lever
Ventilation (Out)
Carrying Handle
Ventilation (In)
Ventilation (In)
Controls
Ventilation (In)
AC Input
Power Switch

Control Panel
The control panel at the rear of the projector provides all the main controls
necessary to operate the projector.
1 - Power Button
Press to turn the projector on when the projector is in the standby condition (Main
Power switch must be on and the POWER indicator lit amber). Press and hold for 2
seconds to turn off the projector.
2 - Power LED
The power indicator is a dual colour LED. When the projector is on the indicator is
green. When the projector is in standby mode the indicator is amber.
After the projector is turned off, the indicator "--" flashes for three minutes to
show that the cooling fan is working. Do not turn off the main power during that
time. After "--" stops flashing, the POWER indicator will change to a steady
amber glow and the projector will be in the stand-by mode. The main power can
then be turned off.
3 - Status LED
When the projector is used with the ISS-6020 switcher on SW1 level or SW2 level
mode, this indicator flashes when the projector is not connected with the switcher
correctly or when the switcher is turned off.
4 - Indicator Display
During normal operation the current projector ID (address) is shown in this two
digit display. In the event of an error, a projector error code will be displayed. The
display can be turned off using the ON/OFF Switch to the left hand side.
A—8
Overview
OVERVIEW
LBV00063; Revision A - 01/02/2000
8
POWER
LENS SHIFT FOCUS ZOOM INDICATORSELECT ENTER
CANCEL STATUS
ON
OFF
MENU
-+ON/OFF
+
75 4 2 Remote Sensor910 11
613
✍
