Digital Projection HIGHlite Laser II 3D Series Operating manual

Rev C April 2017
117-895C
HIGHlite Laser II 3D Series
Super High Brightness Digital Video Projector
Important Information

Digital Projection HIGHlite Laser II 3D Series
Rev C April 2017
Page 2
Important Information
Digital Projection
Digital Projection Asia
16 New Industrial Road
#02-10 Hudson Technocentre
Singapore 536204
Tel [phone]
Fax [phone]
www.digitalprojectionasia.com
Digital Projection Inc.
55 Chastain Road, Suite 115
Kennesaw, GA 30144, USA
Tel [phone]
Fax [phone]
[email protected]
www.digitalprojection.com
Digital Projection China
中国 北京市 朝阳区 芍药居北里101号
世奥国际中心A座2006室(100029)
Rm A2006
ShaoYaoJu 101 North Lane
Shi Ao International Center
Chaoyang District
Beijing 100029, PR CHINA
Tel [phone]
Fax [phone]
[email protected]
www.dp-china.com.cn
Digital Projection Limited
Greenside Way, Middleton
Manchester M24 1XX, UK
Registered in England No. 2207264
Registered Ofce: as above
Tel [phone]
Fax [phone]
[email protected]
[email protected]
www.digitalprojection.co.uk

Digital Projection HIGHlite Laser II 3D Series
Rev C April 2017
Page 3
Important Information
Super High Brightness Digital Video Projector
Important Information
Full information about operating, connecting and setting up the projector can be found in the User
Manual, located on the CD.
Contents
Symbols used in the User Manual...............................................................................................4
Electrical and physical specications........................................................................................5
Laser precautions.............................................................................................................................5
Product labels....................................................................................................................................6
Label locations ...............................................................................................................................7
Location of laser aperture..............................................................................................................8
Interlock switches ............................................................................................................................8
Lens hood...........................................................................................................................................9
General precautions ......................................................................................................................10
Installation precautions................................................................................................................11
Operation and conguration precautions ...............................................................................12
Compliance with international standards ...............................................................................12
RF Interference.............................................................................................................................12
Noise .............................................................................................................................................12
European Waste Electrical and Electronic Equipment (WEEE) Directive ..............................12
Basic Operation Instructions ......................................................................................................13
Positioning the screen and projector.........................................................................................13
Connecting the power supply.....................................................................................................14
Switching the projector on..........................................................................................................15
Switching the projector off..........................................................................................................15
Selecting an input signal.............................................................................................................15
Selecting a test pattern................................................................................................................16
Adjusting the lens ........................................................................................................................16
Adjusting the image.....................................................................................................................16
Inserting a new lens.....................................................................................................................17
Removing the lens .......................................................................................................................18
Changing the lters .....................................................................................................................19
Control Panel Reference...............................................................................................................20
Remote Control Reference ..........................................................................................................22

Digital Projection HIGHlite Laser II 3D Series
Rev C April 2017
Page 4
Important Information
Symbols used in the User Manual
LASER WARNING: this symbol indicates that there is a potential hazard of eye
exposure to laser radiation unless the instructions are closely followed.
ELECTRICAL WARNING: this symbol indicates that there is a danger of electrical
shock unless the instructions are closely followed.
WARNING: this symbol indicates that there is a danger of physical injury to yourself
and/or damage to the equipment unless the instructions are closely followed.
NOTE: this symbol indicates that there is some important information that you should read.
Specications are subject to change without notice.

Digital Projection HIGHlite Laser II 3D Series
Rev C April 2017
Page 5
Important Information
Electrical and physical specications
Mains Voltage 200-240 VAC 9 A 50/60 Hz (single phase)
110-130 VAC 11.5 A 50/60 Hz (single phase)
Operating Temperature 0°C to 35°C
Storage Temperature -20°C to 60°C
Operating Humidity 20% to 90% non-condensing
Weight 58 kg (127.9 lb) without lens
Power Consumption 1705 W at 200 VAC, 1145 W at 110 VAC
Thermal Dissipation 5850 BTU/hr at 200 VAC, 3929 BTU/hr at 110 VAC
Laser precautions
CLASS 3R LASER PRODUCT
This Laser Product is designated as Class 3R during all procedures of operation.
LASER LIGHT - AVOID DIRECT EYE EXPOSURE.
Do not point laser or allow laser light to be directed or reected toward other people or
reective objects.
Direct or scattered light can be hazardous to eyes and skin.
There is a potential hazard of eye exposure to laser radiation if the included
instructions are not followed.
Caution – use of controls or adjustments or performance of procedures other than
those specied herein may result in hazardous radiation exposure.
Non-laser emission. There remains non-laser emission from the projection lens. This
portion of emission has been tested per IEC/EN 62471 to be Risk Group 2 (Low Risk).
Laser Parameters:
Wavelength 450 nm - 460 nm
Laser Power for classication 333.5 mW
Total internal power > 100 W
Apparent Source Size > 10 mm at lens stop
Divergence 100 miliRadian

Digital Projection HIGHlite Laser II 3D Series
Rev C April 2017
Page 6
Important Information
Product labels
AC Input / EntréeCA (輸入 / 输入) : 200-240Vac 9.2A 50/60Hz
Model/ Modèle (型號 / 型号): HIGHlite Laser WUXGA 3D
警告: 此為 A 級產品，在生活環境中，該產品可能會造成無線電干擾。
在這種情況下，可能需要用戶對干擾採取切實可行的措施。
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
CAN ICES-3 (A)/NMB-3(A)
DLP P R OJECTOR / DLP Projecteur
( 數位投影機/数字投影 机 )
Caution : Do not open the cover. No user-serviceable parts inside
Avertissement :ne pas ouvrir le couvercle. Le produit ne contient aucune pièce
interne réparable par l’utilisateur.
警告: 請勿打開外 殼 ,設備內無服務性維修之元件
警告: 請勿打開外殼,設 備 內無服務性維修之元件
製造商: Digital Projection Limited
Greenside Way Middleton
Manchester, M24 1XX UK
Made in China.
(製造地:中國/製造地:中國 )
LASER LIGHT
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
455-470nm <330mW
CLASSIFIED IEC/EN 60825-1 2007
Complies with FDA performance standards for laser products except for
deviations pursuant to Laser Notice No. 50, dated June 24, 2007
3264601800
XXXX XXXX
Certication Statement Label
2
Hazard Warning Symbol and
Aperture Label
4
Manufacturer’s ID Label and Explanatory Label
with Risk Group 2 Label at the bottom right
1
CAUTION
Possibly hazardous optical radiation emitted
from this product.
Do not stare at operating lamp.
May be harmful to the eyes.
ATTENTION
Ce produit peut émettre des rayonnements
optiques dangereux.
Ne pas fixer la lampe en fonctionnement.
Peut être nocif pour les yeux.
RISK GROUP 2
AC Input / Entrée CA ( 輸入 / 输入 ) : 200-240Vac 9A 50/60Hz
AC Input / Entrée CA
(
輸入 / 输入
)
: 110-130Vac 11.5A 50/60Hz
Model/Modèle (型號 / 型号): HIGHlite Laser II 3D
DLP PROJECTOR / DLP Projecteur
( 數位投影機 / 数字投影机 )
LASER RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
450nm - 460nm < 333.5mW
激光輻射 避免眼睛受到直射 3R类激光產品
波長 : 450nm - 460nm < 333.5 mW
RAYONNEMENT LASER
EXPOSITION DIRECTE DANGEREUSE POUR LES YEUX
APPAREIL À LASER DE CLASSE 3R
450nm - 460nm < 333.5 mW
GB 7247.1-2012 / IEC/EN 60825-1:2007
警告:此為 A 級產品，在生活環境中，該產品可能會造成無線電干擾。
在這種情況下，可能需要用戶對干擾採取切實可行的措施。
This device complies with part 15 of the FCC rules.
Operation is subject tothe following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Caution : Do not open the cover. No user-serviceable parts inside
Avertissement : ne pas ouvrir le couvercle. Le produit ne contient
aucune pièce interne réparable par l’utilisateur.
警 告 : 請勿打開外殼,設備內無服務性維修之元 件
警 告 : 請勿打開外殼,設備內無服務性維修之元件
Complies with FDA performance standards for laser products except for
deviations pursuant to Laser Notice No. 50, dated June 24, 2007
製造商:Digital Projection Limited
Greenside Way Middleton Manchester, M24 1XX UK 製造地:中國/製造地:中國 / Made in China
3264625702
Part No.:116-330
CAN ICE-3(A) / NMB-3(A)
[phone]
KTL ZU10002-16011
MSIP-REM-DVP-LaserII3D
:
:
:
/ :
:
델타 비디오 디스플레이
시스템 (우장) 리미티드
*W651Z***********
MANUFACTURED 2016.51

Digital Projection HIGHlite Laser II 3D Series
Rev C April 2017
Page 7
Important Information
Label locations
1Location of Manufacturer’s ID
Label, Certication Statement
Label and Explanatory Label
on the body of the projector
2Manufacturer’s ID Label
(manufacturer’s name,
address and projector model)
3Certication Statement Label
4Serial number location
5Explanatory Label
6Protective Housing Label
(under the top cover and only
visible to service personnel)
7Location of Hazard Warning
Symbol and Aperture Label
on the body of the projector
1
CAUTION
Possiblyhazardous optical radiation emitted
fromthis product.
Donot stare at operating lamp.
Maybe harmful to the eyes.
ATTENTION
Ceproduit peut émettre des rayonnements
optiquesdangereux.
Nepas fixer la lampe en fonctionnement.
Peutêtre nocif pour les yeux.
RISKGROUP 2
AC Input / Entrée CA ( 輸入 / 输入 ) : 200-240Vac 9A 50/60Hz
AC Input / Entrée CA ( 輸入 / 输入 ) : 110-130Vac 11.5A 50/60Hz
Model/Modèle (型號 / 型号): HIGHlite Laser II 3D
DLP PROJ ECTOR / DLP P rojecteur
( 數位投影機/ 数字投影机 )
LASER RADIATION
AVOIDDIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
450nm - 460nm < 333.5mW
激光輻射 避免眼睛受到直射 3R类激光產品
波長 : 450nm - 460nm < 333.5 mW
RAYONNEMENTLASER
EXPOSITION DIRECTE DANGEREUSE POUR LESYEUX
APPAREILÀ LASER DE CLASSE 3R
450nm - 460nm < 333.5 mW
GB 7247.1-2012 / IEC/EN 60825-1:2007
警告:此為 A 級產品，在生活環境中，該產品可能會造成無線電干擾。
在這種情況下，可能需要用戶對干擾採取切實可行的措施。
This device complies with part 15 of the F CCrules.
Operation is subject tothe following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Caution : Do not open the cover. No user-serviceable parts inside
Avertissement : ne pas ouvrir le couvercle. Le produit ne contient
aucune pièce interne réparable par l’utilisateur.
警 告 : 請勿打開外殼,設備內無服務性維修之元 件
警 告 : 請勿打開外殼,設備內無服務性維修之元件
Complies with FDA performance standards for laser products except for
deviations pursuant to Laser Notice No. 50, dated June 24, 2007
製造商:DigitalProjection Limited
GreensideWay Middleton Manchester, M24 1XX UK 製造地:中國/製造地:中國 /Made in China
3264625702
Part No.:116-330
CAN ICE-3(A) / NMB-3(A)
[phone]
KTLZU10002-16011
MSIP-REM-DVP-LaserII3D
:
:
:
/ :
:
델타비디오디스플레이
시스템(우장)리미티드
*W651Z***********
MANUFACTURED 2016.51
7
6
AVOIDEYE CONTACT TO THE LIGHT
CAUTION
Possibly hazardous optical radiation emitted
from this product.
Do not stare at operating lamp.
May be harmful to the eyes.
ATTENTION
Ce produit peut émettre des rayonnements
optiques dangereux.
Ne pas fixer la lampe en fonctionnement.
Peut être nocif pour les yeux.
RISK GROUP 2
AC Input / Entrée CA (輸入 / 输入) : 200-240Vac 9A 50/60Hz
AC Input / Entrée CA
(
輸入 / 输入
)
:
110-130Vac 11.5A 50/60Hz
Model/Modèle (型號 / 型号): HIGHlite Laser II 3D
DLP PROJECTOR / DLP Projecteur
( 數位投影機 / 数字投影机 )
LASER RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
450nm - 460nm < 333.5mW
激光輻射 避免眼睛受到直射 3R类激光產品
波長 : 450nm - 460nm < 333.5 mW
RAYONNEMENT LASER
EXPOSITION DIRECTE DANGEREUSE POUR LES YEUX
APPAREIL À LASER DE CLASSE 3R
450nm - 460nm < 333.5 mW
GB 7247.1-2012 / IEC/EN 60825-1:2007
警告:此為 A 級產品，在生活環境中，該產品可能會造成無線電干擾。
在這種情況下，可能需要用戶對干擾採取切實可行的措施。
This device complies with part 15 of the FCC rules.
Operation is subject tothe following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Caution : Do not open the cover. No user-serviceable parts inside
Avertissement : ne pas ouvrir le couvercle. Le produit ne contient
aucune pièce interne réparable par l’utilisateur.
警 告 : 請勿打開外殼,設備內無服務性維修之元 件
警 告 : 請勿打開外殼,設備內無服務性維修之元件
Complies with FDA performance standards for laser products except for
deviations pursuant to Laser Notice No. 50, dated June 24, 2007
製造商:Digital Projection Limited
Greenside Way Middleton Manchester, M24 1XX UK 製造地:中國/製造地:中國 / Made in China
3264625702
Part No.:116-330
CAN ICE-3(A) / NMB-3(A)
[phone]
KTL ZU10002-16011
MSIP-REM-DVP-LaserII3D
:
:
:
/ :
:
델타 비디오 디스플레이
시스템 (우장) 리미티드
*W651Z***********
MANUFACTURED 2016.51
3
2
5
4

Digital Projection HIGHlite Laser II 3D Series
Rev C April 2017
Page 8
Important Information
Location of laser aperture
The laser aperture 1is located as indicated below.
Interlock switches
Five interlock switches installed at the main frame, inside the cover, will power-off the system
individually when activated.
1 Will be activated when the lter cover is removed.
2 Will be activated when the top cover is removed.
3 Will be activated when the projection lens is removed.
4 (x2) Will be activated when the lens hood is removed.
1
1 2
34

Digital Projection HIGHlite Laser II 3D Series
Rev C April 2017
Page 9
Important Information
Lens hood
The lens hood is compatible with the following lenses:
Throw ratios Part number
0.77 : 1 xed lens 110-808
1.16 : 1 xed lens 110-809
1.45 - 1.74 : 1 zoom lens 110-803
1.74 - 2.17 : 1 zoom lens 112-878
2.17 - 2.90 : 1 zoom lens 113-852
2.90 - 4.34 : 1 zoom lens 110-806

Digital Projection HIGHlite Laser II 3D Series
Rev C April 2017
Page 10
Important Information
General precautions
The unit is never to be operated if the unit is defective or the cover or seal is damaged.
No maintenance allowed by end user.
Do not open the cabinet. There are no user serviceable parts inside.
No service is allowed except by authorized personnel.
Use only the power cable provided.
Ensure that the power outlet includes a Ground connection, as this equipment MUST be
earthed.
Take care to prevent small objects such as paper or wire from falling into the projector.
If this does happen, switch off immediately, and have the objects removed by
authorised service personnel.
Do not expose the projector to rain or moisture, and do not place any liquids on top of
the projector.
Unplug before cleaning, and use a damp, not wet, cloth.
Do not touch the power plug with wet hands.
Do not touch the power plug during a thunder storm.
Handle the power cable carefully and avoid sharp bends. Do not use a damaged power
cable.
Do not touch the ventilation outlets, as they will become hot in use.
Do not cover or obstruct the ventilation outlets or inlets.
Do not cover the lens whilst the projector is switched on. This could cause a re
Always allow the projector to cool for 5 minutes before disconnecting the power or
moving the projector.
Never use strong detergents or solvents such as alcohol or thinners to clean the
projector and lens.

Digital Projection HIGHlite Laser II 3D Series
Rev C April 2017
Page 11
Important Information
Installation precautions
Connect the LAN cable only to a computer LAN connection. Other similar connectors
may have a dangerously high voltage source.
The projector must be installed only by suitably qualied personnel, in accordance with
local building codes.
The projector should be installed as close to the power outlet as possible.
The power connection should be easily accessible, so that it can be disconnected in an
emergency.
Ensure that there is at least 30cm (12in) of space between the ventilation outlets and
any wall, and 10cm (4in) on all other sides.
Do not install the projector close to anything that might be affected by its operational
heat, for instance, polystyrene ceiling tiles, curtains etc.
Place the projector in a dry area away from sources of dust, moisture, steam, smoke,
sunlight or heat.
The projector is heavy. Use safe handling techniques when lifting the projector.
Do not drop or knock the projector.
Before installation, make sure that the surface, ceiling or rigging that is to support the
projector is capable of supporting the combined weight of the projector and lens.
When stacking projectors, the stack MUST be vertical, to ensure that the stresses are
distributed to all four chassis corners.
Do not stack more than 3 projectors.
Do not place heavy objects on top of the projector chassis. Only the chassis corners
and the optional rigging frame are capable of withstanding the weight of another
projector.
Backup safety chains or wires should always be used with ceiling mount installations.
The projector can be operated any position. However, it is not recommended to position
the projector in portrait mode with inputs facing upward, as shown in the diagram:
1 Positions to avoid: inputs side up
2Recommended positions
360° 2
Pitch
330° 2
30° 1
Roll

Digital Projection HIGHlite Laser II 3D Series
Rev C April 2017
Page 12
Important Information
Operation and conguration precautions
Do not make changes to the networking conguration unless you understand what you
are doing, or have taken advice from your Network Manager. If you make a mistake,
it is possible that you will lose contact with the projector. Always double-check your
settings before pressing the APPLY button. Always keep a written note of the original
settings, and any changes you have made.
Software update should NOT be carried out except by, or with the supervision of, Digital
Projection Service personnel.
Compliance with international standards
RF Interference
FCC
The Federal Communications Commission does not allow any modications or changes to the unit
EXCEPT those specied by Digital Projection in this manual. Failure to comply with this government
regulation could void your right to operate this equipment.
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant with Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area may cause harmful interference, in which case the
user will be responsible for correcting any interference.
Noise
GSGV Acoustic Noise Information Ordinance
The sound pressure level is 52 dB (A) according to ISO 3744 or ISO 7779.
European Waste Electrical and Electronic Equipment (WEEE) Directive
Digital Projection Ltd is fully committed to minimising Waste Electrical and Electronic
Equipment. Our products are designed with reuse, recycling and recovery of all components
in mind. To this end, at end of life, your projector may be returned to Digital Projection Ltd or
its agent so that the environmental impact can be minimised.

Digital Projection HIGHlite Laser II 3D Series
Rev C April 2017
Page 13
Important Information
Basic Operation Instructions
Positioning the screen and projector
1. Install the screen, ensuring that it is in the best position for viewing by your audience.
2. Mount the projector, ensuring that it is at a suitable distance from the screen for the image to ll
the screen. Set the adjustable feet so that the projector is level, and perpendicular to the screen.
The drawing below shows the positions of the feet for table mounting, and the xing holes for ceiling
mounting.
1Four adjustable feet
2Six M6 holes for ceiling mount
The screws should not penetrate more than 15 mm into the body of the projector.
1
2
1
1
1
2
2
2
2
2

Digital Projection HIGHlite Laser II 3D Series
Rev C April 2017
Page 14
Important Information
Connecting the power supply
Adjust the VOLTAGE SELECT switch 1 to the required voltage, then rmly push the mains
connector into the socket 2.
Voltage selection
The VOLTAGE SELECT switch must be set to match the power supply you are using:
Voltage of power supply used Position of VOLTAGE SELECT switch
AC110V outlet
AC200V (single phase) outlet
Use only the power cable provided.
Ensure that the power outlet includes a ground connection as this equipment MUST be
earthed.
Handle the power cable carefully and avoid sharp bends. Do not use a damaged power
cable.
AC MAINS
交流電源輸入
AC POWER
SWITCH
交流電源開關
200-240Vac
VOLTAGE SELECT
交流電壓選擇
110-130Vac
1
2

Digital Projection HIGHlite Laser II 3D Series
Rev C April 2017
Page 15
Important Information
Switching the projector on
1. Make sure the voltage selector is set to match the power supply you are using.
2. Connect the power cable between the mains supply and the projector. (See Connecting the
power supply above.) Switch on at the switch next to the power connector.
3. The STANDBY indicator lights red to signal that the projector is in STANDBY mode. Press one of
the following buttons:
• On the remote control, the ON button
• On the projector control panel, the POWER button.
After approximately 15 seconds, the ON indicator begins ashing blue. When the ashing stops,
the ON indicator lights solid blue and the Digital Projection logo appears on the screen. The
projector is switched on.
Switching the projector off
1. Press OFF on the remote control or POWER on the control panel, then press again to conrm
your choice.
The ON indicator on the control panel will start ashing, the system will go out and the cooling
fans will run for a short time until the STANDBY indicator goes steady green to indicate that the
projector has entered STANDBY mode.
2. If you need to switch the projector off completely, switch off at the AC power switch above the
power connector and then disconnect the power cable from the projector.
Selecting an input signal
1. Connect one or more image sources to the projector.
2. Select the input you want to display:
• Press one of the input buttons on the remote control.
• Alternatively, open the On-screen display (OSD) by pressing MENU. Highlight Input from the
main menu, press ENTER/OK and then select an input signal using the UP and DOWN arrow
buttons. Press ENTER/OK to conrm your choice.

Digital Projection HIGHlite Laser II 3D Series
Rev C April 2017
Page 16
Important Information
Selecting a test pattern
To display a test pattern:
• Press TEST on the remote control. If necessary, press again to change the test pattern. Test
patterns are displayed in the following order:
White, Black, Red, Green, Blue, CheckerBoard, CrossHatch, V Burst, H Burst, ColorBar, Off
After the nal test pattern, the projector exits test pattern mode and returns to the main image. To
view test patterns again, you need to press TEST again.
• Alternatively, open the OSD by pressing MENU. Highlight Test Patterns from the main menu,
then select a test pattern using the LEFT and RIGHT arrow buttons.
Adjusting the lens
The lens can be adjusted using the Lens menu, or using the lens buttons on the remote control.
Lens menu
The Lens menu provides access to the Lens Control setting and the Lens Center command.
Lens Control allows Zoom, Focus and Shift adjustment using the arrow buttons. The setting
operates in Zoom/Focus Adjustment and Shift Adjustment mode.
Press ENTER/SELECT to switch between the two modes.
Remote control
Use the remote control to adjust zoom, focus and shift directly, without opening a menu:
• OK enters lens control, then switches between Zoom/Focus Adjustment and Shift Adjustment.
• EXIT exits lens control and opens the Lens menu.
• MENU exits lens control and returns to the main image.
• The arrow buttons adjust zoom, focus and shift as indicated on the screen.
Adjusting the image
Orientation
• This can be set from the Setup menu.
Highlight Orientation and choose from Front Tabletop, Front Ceiling, Rear Tabletop and Rear
Ceiling.
Keystone
• This can be set from the Geometry menu.
• Settings such as Gamma, Brightness,Contrast, Saturation, Hue and Sharpness can be set
from the Image menu.

Digital Projection HIGHlite Laser II 3D Series
Rev C April 2017
Page 17
Important Information
Inserting a new lens
Before changing the lens, always make sure the projector is switched off and fully
disconnected from its power supply.
When changing the lens, avoid using excessive force as this may damage the
equipment.
Take care to preserve the original lens packaging and protective caps for future use.
The projector will not power on without the lens and lens hood tted.
1. Insert the lens into the lens aperture, making sure that the plug on the zoom drive mechanism
lines up with socket on the right of the lens aperture.
2. Rotate the lens clockwise until it clicks into place.
3. Secure the lens hood to the front of the projector
with the screws.

Digital Projection HIGHlite Laser II 3D Series
Rev C April 2017
Page 18
Important Information
Removing the lens
Before changing the lens, always make sure the projector is switched off and fully
disconnected from its power supply.
When changing the lens, avoid using excessive force as this may damage the
equipment.
Take care to preserve the original lens packaging and protective caps for future use.
The projector will not power on without the lens and lens hood tted.
1. Loosen the four screws securing the lens
hood to the body of the projector.
Remove the lens hood.
2. Push down the lens holder tab.
3. Rotate the lens anti-clockwise. 4. Pull the lens forward to remove it from the
lens aperture.

Digital Projection HIGHlite Laser II 3D Series
Rev C April 2017
Page 19
Important Information
Changing the lters
Before changing the lters, always make sure the projector is switched off and fully
disconnected from its power supply.
When changing the lters, avoid using excessive force as this may damage the
equipment.
1. Remove the two screws 1 holding the lter cover.
2. Remove the filter cover 2.
3. Remove the old filter 3.
4. Place the new lter in the slot. Make sure the air flow arrow 4points toward the projector, as
shown in the illustration.
5. Replace the lter cover and tighten the screws.
21 3 4

Digital Projection HIGHlite Laser II 3D Series
Rev C April 2017
Page 20
Important Information
Control Panel Reference
ERROR STANDBY
INPUT
CLOSE
FOCUS
ZOOM
SHUTTER
OPEN
OUT IN
OUT IN
SHIFT
MENU EXIT
2
4
5
6
3
7
8
9
11
12
1
10
