Overview
PERFORMANCE SPECIFICATIONS
Brightness (±10%)
SX+, 1080p & WUXGA: 16,000 ANSI Lumens
Contrast Ratio (±10%)
2000:1 Full White/Black
Display Type
3 x .95” DMD
DMD Specification
SX+: 1400 x 1050 pixels native, +/- 12 deg tilt angle
1080p: 1920 x 1080 pixels native, +/-12 deg tilt angle
WUXGA: 1920 x 1080 pixels native, +/-12 deg tilt angle
Fast transit Pixels for smooth greyscale and improved contrast.
Fill Factor
87%
Sealed Optics at DMD™ Interface
Protects DMD’s™ from optical contamination
Source Compatibility
Advanced Front End Processor:
• 3GSDIincluding1080p60fps,24p(4:4:4and4:2:2)and1080i.
• HDMIincludingDeepColorprocessing.
• Graphicsstandardsupto1920x1200resolutionat60fpsviaDVI
orVGA.
• Componentvideo(SDandHD)viaYPrPb,RGB,orRGBS.
• S-Video(PAL,NTSC&SECAM)
• CompositeVideo(PAL,NTSC&SECAM).
Highbandwidth,pixelmappedpath:
• DualDVIacceptsgraphicsstandardsupto1920x1200@120fps.
• HDMI1.4including3DStandards
• DualPipe(2xDVIorHDMI)
HighBandwidthInput
•3Dcapable
•PixelMapped-withlowlatency
•FastFrame™MotionBlurReduction
•120Hzwithnoframedoubling
3D Sync
Sync In - External lock
Sync Out - Shutter glass control
NetworkConnection
IRhandsetwithwiredoptionvia3.5mmjack(withloopthrough).
LANViaRJ45withfullfeaturesetviaprotocol.
DuplicationofOSDservedfromprojectorcontrollerviaRJ45.
RS232Via9Pinconnector.
Lamp Type
Fourx400WHighIntensityDischarge
Lamp Life (typical)1
FullPower:1500hrs(upto3000hrsinlampsequentialmode)
EcoMode:2000hrs(upto4000hrsinlampsequentialmode)
Intelligent Lens Mount
MotorisedandprogrammableFocus,Zoom,andVertical
andHorizontaloffsetswithtenpositionalmemorybanks.
Lens Shift (maximum)
Fixed 1.2:1 and Zoom Lenses:
•Vert:+0.5,-0.4frame;Hor:±0.2frame
0.73 Fixed lens:
•Vert:±0.11frame;Hor:±0.07frame
Lens Options
0.73 :1 fixed 2.02-2.77 :1zoom
1.2 :1fixed 2.77-4.51 :1zoom
1.26-1.61 :1zoom 4.51-7.53 :1zoom
1.5-2.02 :1zoom 7.5-11.2 :1zoom
•1.2:1Lensesincludemanualaperture
•High-contrastlensesavailablefor0.73:1
andallzoomlenses
Specifications subject to change without notice DP V1.0 06/2011 ©2011 Digital Projection, Inc.
™DLP, Digital Light Processing and DMD are trademarks of Texas Instruments, Inc.
TITAN Quad Series
TITAN SX+ Quad 3D •TITAN 1080p Quad 3D •TITAN WUXGA Quad 3D
Mechanical Mounting
•Frontorreartable;Frontorrearceiling
(ceiling mount optional)
•Rugged,stagingtolerantchassiswith
integrated handles
•Optional RapidRig™ framewithintegrated
pitch,rollandyawadjustments
Weight (chassis only)
39 kg, 86 lbs
VideoProcessing:AdvancedFrontEndprocessor:
• Advancedgeometrycorrection:
 oAccuratewarpmapgenerationbyadjustmentof
an interpolated grid array of up to 16 x 16 nodes. Up
toeightmapscanbegenerated,downloadedand
storedontheprojectorforselectionviatheOSDor
control application.
o On board implementation of Pincushion & Barrel,
Cornerstone,Vertical&HorizontalKeystone,and
Image Rotation.
• HighQualityEdgeBlending&MultiProjectorTiling
 oHighbitdepthprocessinginblendregionto
ensure smooth image.
 oAdjustableS-CurveParameteranddegamma
functions.
o Black Level Uplift to ensure uniformity across
blend in dark images.
o Correction of black level uplift to compensate for
non-active pixels at the edge of the DMD.
 oTheusercanchoosetoassigntheprojectora
positionwithinanimagematrix.Thevideoprocessing
can automatically extract the appropriate segment of
the input image and enable blending for the appropri-
ate edges.
• SingleStageScaling
 oResizingandWarpfunctionsarecarriedoutin
asinglestageprocessmaximizingtheclarityofthe
resultingimage.WhenoperatingBlendinconjunction
withWarptheprocessingwillautomaticallysuperim-
posethewarped-blendmap,ontothegeometrically
corrected image.
 oTheusercanswitchbetweendifferentsources
and input aspect ratios, yet retain the accuracy of the
geometrically corrected output.
• PIP/POP/PAP
 oUser’schoicebetweeninputsforthemainand
sub images (Picture in Picture or PIP). The processing
additionallyofferstheoptiontodisplaytwosources,
side-byside,scaledtotheverticalsizeofthepanel
Picture and Picture or PAP), or alternatively maintain-
ing their original aspect ratios (Picture Opposite Picture
or POP).
• ColorMax
 oEachprojectorisaccuratelycalibratedatthe
factorywithitsnativeprimarycolorsandwhitepoint
being stored in the on-board memory. User’s choice
toemploytheexternalcontrolapplicationtodownload
hisownmeasuredcolorspace,asspecifictotheoper-
ating environment, and also his preferred Target color
space for primary and secondary colors. Not only is
this the most flexible color management technology
available, but it also enables accurate matching of pro-
jectorsintiledorblendedapplications.
• DualFlashProcessingcanbeusedtomultiplythe
displayed frame rate for 3D sources.
• FastFramemotionblurreduction.
• DualPipeprocessingallowsthedeliveryoftwo
sources in parallel, typically one for the Left Eye and
the other for the Right.
• De-interlacing,VideoenhancementandFrame
Delay
Theprojectorautomaticallydetectsinterlacedvideo
and implements 3:2 or 2:2 extraction as appropriate,
withpixelbased,motionadaptiveinterpolationand
auto cadence correction.
INPUT CAPABILITIES
Type
Composite
S-Video
Component
Interlaced/StddefY,Cr/Pr,Cb/Pb,S
Graphics
ProgressiveRGB/ProgressiveInterlacedHidef
Y,Cr/Pr,Cb/PB
RGBHV(Progressive)
Digital RGB
Serial Digital
SD/HD-SDI(SMPTE259M/292M)
DVI-Highbandwidth
Dual - main
Dual - sub
*Themain&subdualDVIinputscanbeusedin
parallel to support dual-pipe 3D connectivity
Connector
BNC
4-pin mini DIN
BNCx4
BNCx5
D sub (15-pin)
DVI
BNC
DVI
DVI
Quantity
1
1
1
1
1
1
1
1
1
DPIpresentsarevolutioninadvanced3-chipDLPdisplayswiththe
newTITANQuadproductline.Incrediblycompactandefficientfor
its lumen performance, the TITAN Quad series incorporates DP’s
active 3D connectivity, advanced image Warp and Blend, Intelligent
Lens Mount, ColorMax calibration technology, and a host of vital
professional features to suit almost any commercial installation or
staging application imaginable.
As efficient as they are capable, the introduction of the 16,000
lumenTITANQuadlineupmarkstheworld’sfirstprojectorsofthis
brightness, in a chassis with such a small form factor.  The new
TITANQuad projectorsare availablein SX+,1080p andWUXGA
native resolution, and include powerful DP innovations such as
FastFrame, Dual-Flash Processing and CoolTek Engineering. The
TITAN Quad represents the new flagship of DPI’s TITAN product
line,which nowencompassesover 30,3D capableprecisiondis-
plays.
Utilizing DPI’s new, advanced electronics, all TITAN Quad mod-
els provide the user with advanced Warp and Blend capabilities,
includingthe abilityto makeextensive geometricwarp correction
forscreenswithcomplexgeometry.Superblycapableedgeblend-
ingand multi-projectortilingis providedbyway ofhigh bitdepth
processing that ensures a seamless, contiguous image can be cre-
atedfrommultipleprojectors.Additionally,enduserscanchoose
to utilize the TITAN Quad’s onboard tiling function by assigning
each projector a position within an image matrix. The video pro-
cessing then automatically extracts the appropriate segment of the
input image and enables blending for the appropriate edges.
Also included are DPI’s exclusive 3D advances that further extend
the remarkable flexibility engineered within each TITAN Quad
display.  Applications with 120 Hz native sources utilize the High
Bandwidth input, eliminating the need for frame doubling. For 60
Hz3Dapplications,DPI’sbuilt-inDualFlashProcessing™enables
distributionof3Dcontentvia60Hzformatsbyframe-doublingthe
signalwithintheprojector,producingthelowflickerimagecharac-
teristicsofa native 120Hz sourcewithout theinfrastructure costs
associated with distributing and switching ultra-high bandwidth
signals.
AsisthecasewithallDigitalProjectiondisplays,ourcarefulengi-
neering guarantees TITAN projectors provide remarkable resolu-
tion, color saturation and light output for years to come. Equally
important, DPI’s legacy in providing superior customer and techni-
calservicesassuresourexperiencedsupportstaffisalwaysavail-
able to address your needs.
TheTITANQuad...now,FourisMore.
1080p-3D
sx+ 3D WUXGA-3D
PRELIMINARY

Native Color Temperature
HDTV Formats Supported
Scan Rates Supported
Remote Control
Automation Control
Operating/Storage Temperature
Operating Humidity
Thermal Dissipation
Fan Noise
Power Requirements
Power Consumption
PARAMETERS
Projectors Part #
TITAN sx+ Quad 3D 111-869
TITAN 1080p Quad 3D 111-872
TITAN WUXGA Quad 3D 111-875
Accessories Part #
TITAN Quad 3D Lamp & Housing* (4 required) 111-896A
RapidRigTM Frame 107-956
TITAN Quad 3D Series Adjustable Ceiling Mount 111-897A
Infrared Remote (Replacement) 105-023
* Includes high-performance replacement air filter(s)
1Based on 4-6 hour/day operational profile. Venue and application conditions may
impact actual lamp life.
See Digital Projection’s Product Warranty Statement for details on lamp warranty.
Installations requiring horizontal or vertical tilt orientations greater than 15 degrees
may reduce the actual operational hours of one of the two lamps.
ADVANCED TECHNICAL SPECIFICATIONS
SX+ Lenses HB Part # HC Part #
0.73:1 105-607 107-195
1.2:1 105-608 105-608
1.2:1 (short) 105-609 105-609
1.26 - 1.61:1 109-236 109-359
1.5 - 2.02:1 105-610 107-196
2.02 - 2.77:1 105-611 107-197
2.77 - 4.51:1 105-612 107-198
4.51 - 7.53:1 105-613 107-199
7.5 - 11.2:1 109-235 109-358
shown with optional rigging frame
DIGITAL PROJECTION, INC. • 55 CHASTAIN ROAD, SUITE 115 KENNESAW, GA. 30144 • T: 770.420.1350 • F: 770.420.1360 • www.digitalprojection.com
DIGITAL PROJECTION, LTD. • GREENSIDE WAY, MIDDLETON MANCHESTER, UK. M24 1XX • T: +44.161.947.3300 • F: +44.161.684.7674 • www.digitalprojection.co.uk
DIGITAL PROJECTION, CHINA • TOWER C, RM C1202, CAI FU JIA YUAN, NO. 19 XIA0 YING STREET, CHAOYANG DISTRICT BEIJING, PR CHINA 100101 • T: +86.10.58239771• F: [phone]
DIGITAL PROJECTION, ASIA • 16 NEW INDUSTRIAL ROAD, #02-10 HUDSON TECHNOCENTRE SINGAPORE 536204 • T: +65.6284.1138 • F: +65.6284.1238
Projector Dimensions
TITAN Quad Series
Projectordimensions(in)
L124.4W121.3H110.2
TM
CORE TECHNOLOGY
Projectordimensions(mm)
L1620W1540H1258
1080p-3D
sx+ 3D WUXGA-3D
PRELIMINARY
NativeColorTemperature:UserSelectablefrom3200K,to10000K
Signalformats480i,576i480p,576p,720p,1080i(50,59.94and60Hz)and1080p(23.98,24,25,29.97and30Hz).
The3GSDIInputsupportsSD-SDI,HD-SDIand3G-SDIYCbCr4:2:2serialdigitalcomponentvideo.SMPTE292M,SMPTE
259M-C and SMPTE 424M compliant. Accepts 484i, 576i, 720p, 1080i and 1080p Single link formats at 270Mb, 1.485Gb or
2.97Gbrates.StreamA&StreamB-switchable.
HDMI&DVIInputs-HDMI1.3withorwithoutHDCP,36bitvideocompatible.
DVI-DinputwithorwithoutHDCP.
AddressableIPremotecontrol,wirelessandwiredwithloopthrough.OnBoardkeypad.
LANconnectionviaRJ45/RS2329pinDType.
Operating 0-40C. Storage -10 to +50C
20 to 80% non-condensing
7161 BTU/hr
TBA
200-265VAC50/60HzSinglePhase.
2100 Watts
1080p &
WUXGA Lenses HB Part # HC Part #
0.67:1 105-607 107-195
1.12:1 105-608 105-608
1.16 - 1.49:1 109-236 109-359
1.39 - 1.87:1 105-610 107-196
1.87 - 2.56:1 105-611 107-197
2.56 - 4.16:1 105-612 107-198
4.16 - 6.96:1 105-613 107-199
6.92 - 10.36:1 109-235 109-358
