DAG2500-48S/72S/96S FXS Gateway
User Manual V1.0
Shenzhen Dinstar Co., Ltd.
Address: Floor 18, Building 7A, Vanke Cloud City Phase 1, Xingke 1st Street, Xili Sub-district,
Nanshan District, Shenzhen.
Postal Code: 518052
Telephone: [phone]
Fax: [phone]
Email：[e-mail]
Website: www.dinstar.com

Preface
Welcome
Thanks for choosing the Dinstar’s Product! We hope you will make full use of
this rich-feature FXS Gateway. Contact us if you need any technical support:
[phone].
About This Manual
This manual provides information about the introduction of the analog
telephone adapter, and about how to install, configure or use it. Please read this
document carefully before install the gateway.
Note: All types of DAG2500 in this user manual will be called as device or
gateway!
Intended Audience
This manual is aimed primarily at the following people:
⚫Users
⚫Engineers who install, configure and maintain the gateway.
Revision Record
Document Name
DAG2500-48S/72S/96S FXS Gateway User Manual V1.0
Document Version
1.0
Revised by
Ellie Zhang
Date
05/16/2023
Descriptions
The new released product

Contents
I
Contents
1Product Introduction ................................................................................................................ 1
1.1 Overview........................................................................................................................................................1
1.2 Application Scenario ..................................................................................................................................2
1.3 Outlooks of Products .................................................................................................................................2
1.3.1 Outlooks of Device (take DAG2500-96S for example).............................................................2
1.3.2 Ports and Connectors .......................................................................................................................3
1.4 Features & Functions .................................................................................................................................5
1.4.1 Key Features ........................................................................................................................................5
1.4.2 Physical Interfaces .............................................................................................................................5
1.4.3 Voice Capabilities & Fax...................................................................................................................6
1.4.4 FXS .........................................................................................................................................................6
1.4.5 VoIP........................................................................................................................................................6
1.4.6 Call Features........................................................................................................................................7
1.4.7 Security .................................................................................................................................................8
1.4.8 Physical Features................................................................................................................................8
1.4.9 Maintenance........................................................................................................................................8
2Quick Installation ..................................................................................................................... 10
2.1 Installation Attentions..............................................................................................................................10
2.2 Installation Steps ....................................................................................................................................... 11
3Basic Operation......................................................................................................................... 12
3.1 Methods to Number Dialing..................................................................................................................12
3.2 Call Holding ................................................................................................................................................12

Contents
II
3.3 Call Waiting.................................................................................................................................................12
3.4 Call Transfer ................................................................................................................................................13
3.4.1 Blind Transfer ....................................................................................................................................13
3.4.2 Attended Transfer ............................................................................................................................13
3.5 Function of Flash-hook............................................................................................................................14
3.6 Description of Feature Code ..................................................................................................................14
3.7 Send or Receive Fax..................................................................................................................................16
3.7.1 Fax Mode Supported ......................................................................................................................16
3.7.2 Explanation of T.38 and Pass-through........................................................................................16
3.8 Function of RST Button............................................................................................................................17
3.9Query IP Address and Restore Default Setting .................................................................................17
4Configurations on Web Interface ...................................................................................... 18
4.1 Access WEB Interface...............................................................................................................................18
4.1.1 Preparation for Login......................................................................................................................18
4.1.2 Log in WEB.........................................................................................................................................20
4.2 Navigation Tree..........................................................................................................................................21
4.3 Status & Statistics .....................................................................................................................................21
4.3.1 System Information .........................................................................................................................22
4.3.2 DTU Status .........................................................................................................................................25
4.3.3 Port Status..........................................................................................................................................25
4.3.4 Current Call........................................................................................................................................26
4.3.5 RTP Session........................................................................................................................................27
4.3.6 CDR......................................................................................................................................................27
4.3.7 Record Statistics ...............................................................................................................................28
4.4 Quick Setup Wizard..................................................................................................................................29
4.5 Network .......................................................................................................................................................29
4.5.1 Local Network...................................................................................................................................29

Contents
III
4.5.2 VLAN (Virtual Local Area Network).............................................................................................31
4.5.3 DHCP Option.....................................................................................................................................34
4.5.4 QoS ......................................................................................................................................................35
4.5.5 ARP ......................................................................................................................................................35
4.6 SIP Server ....................................................................................................................................................36
4.7 IP Profile.......................................................................................................................................................39
4.8 Tel Profile.....................................................................................................................................................39
4.9 Port ...............................................................................................................................................................39
4.10 Advanced...................................................................................................................................................43
4.10.1 Line Parameter................................................................................................................................43
4.10.2 FXS Parameter.................................................................................................................................46
4.10.3 Media Parameter............................................................................................................................49
4.10.4 Service Parameter ..........................................................................................................................51
4.10.5 SIP Compatibility............................................................................................................................54
4.10.6 NAT Parameter................................................................................................................................60
4.10.7 Speed Dial........................................................................................................................................61
4.10.8 Feature Code...................................................................................................................................62
4.10.9 System Parameter ..........................................................................................................................64
4.11 Call & Routing..........................................................................................................................................67
4.11.1 Wildcard Group ..............................................................................................................................67
4.11.2 Port Group .......................................................................................................................................67
4.11.3 IP Trunk .............................................................................................................................................71
4.11.4 Routing Parameter.........................................................................................................................72
4.11.5 IP →Tel Routing .............................................................................................................................72
4.11.6 Tel →IP/Tel Routing ......................................................................................................................74
4.12 Manipulation ............................................................................................................................................75
4.12.1 IP →Tel Called ................................................................................................................................76

Contents
IV
4.12.2 Tel →IP/Tel Caller ..........................................................................................................................78
4.12.3 Tel →IP/Tel Callee..........................................................................................................................80
4.13 Management ............................................................................................................................................82
4.13.1 TR069 ................................................................................................................................................82
4.13.2 SNMP ................................................................................................................................................83
4.13.3 Syslog................................................................................................................................................87
4.13.4 Provision...........................................................................................................................................88
4.13.5 Cloud server ....................................................................................................................................89
4.13.6 User Manage...................................................................................................................................89
4.13.7 Remote Server ................................................................................................................................90
4.13.8 Record Parameter ..........................................................................................................................91
4.13.9 Radius Parameter ...........................................................................................................................92
4.13.10 Action URL .....................................................................................................................................93
4.13.11 SIP PNP ...........................................................................................................................................94
4.13.12 NMS Configuration .....................................................................................................................95
4.14 Security ......................................................................................................................................................95
4.14.1 WEB ACL...........................................................................................................................................95
4.14.2 Telnet ACL ........................................................................................................................................96
4.14.3 Passwords.........................................................................................................................................97
4.14.4 Encrypt..............................................................................................................................................98
4.15 Tools............................................................................................................................................................99
4.15.1 Firmware Upload............................................................................................................................99
4.15.2 Data Backup ..................................................................................................................................100
4.15.3 Data Restore..................................................................................................................................100
4.15.4 Outward Test .................................................................................................................................101
4.15.5 Ping Test .........................................................................................................................................102
4.15.6 Tracert Test.....................................................................................................................................102

Contents
V
4.15.7 Network Capture..........................................................................................................................103
4.15.8 Factory Reset.................................................................................................................................106
4.15.9 Device Restart ...............................................................................................................................106
5Glossary ..................................................................................................................................... 107

1 Product Introduction
1
1 Product Introduction
1.1 Overview
The DAG2500 Series FXS analog gateway is multi-functional voice gateway that
provides seamless connectivity with analog phones, fax machine or analog PBXs
to VoIP gateway. The overall frame of DAG2500 is compact and structured,
supporting RJ45/RJ21 interface standards and up to 48/72/96 FXS voice
interfaces at a size of 1U. In addition, DAG2500 provides high-performance
hardware solution with good voice/fax processing capability. It is able to provide
efficient and high-quality IP voice services for service provider, enterprises,
community residents, hotel phone system, and corporate telephone systems.
DAG2500 supports standard SIP and RTP protocols and is compatible with
multiple well-known platforms, for example, compatible with BroadSoft. It also
works as extensions with various IPPBX products based on Asterisk and
FreeSWITCH, and is also perfectly compatible with IMS/NGN softswitch
platforms and call center systems. In addition, customers can build an enterprise
branch communication network by using the DAG2500 to achieve
interoperability between branches, which can provide an efficient, stable, and
cost-effective voice communication solution for large enterprises.
The FXS analog gateway available in the following configurations:
✓DAG2500-48S, 48 ports FXS gateway
✓DAG2500-72S, 72 ports FXS gateway
✓DAG2500-96S, 96 ports FXS gateway

1 Product Introduction
2
1.2 Application Scenario
The application scenario of device is shown as follow:
Figure-Application Scenario of the device
1.3 Outlooks of Products
1.3.1 Outlooks of Device (take DAG2500-96S for example)
Front View:
Back View-Type 1:

1 Product Introduction
3
Back View-Type 2:
Notes: DAG2500-48S/72S/96S has a similar outlook except for the different
number of ports. And the AUX port on the front panel means the reserved
interface.
1.3.2 Ports and Connectors

1 Product Introduction
4
The description of indicators:
Indicator
Definition
Status
Description
PWR
Power Indicator
On
The gateway is powered on
Off
The gateway is powered off or
there is no power supply
RUN
Running Indicator
Slow
Flashing
The gateway is running properly
(Slow Flashing means the running
indicator flashing for 2 seconds)
Fast
Flashing
SIP account is registered
successfully (Fast Flashing means
the running indicator flashing for
0.5 seconds)
Off
The gateway is running
improperly
FXS
Telephone In-use
Indicator
On
FXS port is currently occupied by
a call
Off
FXS port is idle or faulty
MGMT
Network Link
Indicator
Green
Flashing
The gateway is properly
connected to network
Off
The gateway is not connected to
network or network connection is
improper way.
Network Speed
Indicator
On
Work at 100Mbps
Off
Work at 10Mbps
GE0/GE1
Network Link
Indicator
Green
Flashing
The gateway is properly
connected to network

1 Product Introduction
5
Off
The gateway is not connected to
network or network connection is
improper way.
Network Speed
Indicator
On
Work at 1000Mbps
Off
Work at 10Mbps
1.4 Features & Functions
1.4.1 Key Features
⚫High density gateway
⚫Support IPv4 and IPv6
⚫5 km Line Length (MAX)
⚫Support SNMP and TR069
⚫Multiple codecs: G.711A/U, G.723.1, G.729A/B and iLBC
⚫Support Asterisk and FreeSWITCH platforms, and compatible with BroadSoft
⚫Fully compatible with leading IMS/NGN, SIP based IP telephony system
1.4.2 Physical Interfaces
⚫Phone Connector
DAG2500-48S: 48 FXS, RJ 45 or RJ21, 50 PIN
DAG2500-72S: 72 FXS, RJ 45 or RJ21, 50 PIN
DAG2500-96S: 96 FXS, RJ 45 or RJ21, 50 PIN
⚫Console:
1* RS232, 115200bps
⚫Network Interfaces:
2* 10/1000 Base-T
1* 10/100 Base-T

1 Product Introduction
6
1.4.3 Voice Capabilities & Fax
⚫Recording
⚫T.38/Pass-through
⚫Modem/POS
⚫Silence Suppression
⚫Bandwidth Optimization
⚫Comfort Noise Generation (CNG)
⚫Voice Activity Detection (VAD)
⚫Packet Loss Concealment
⚫Adaptive (Dynamic) Jitter Buffer
⚫Programmable Gain Control
⚫G.711A/U law, G.723.1, G.729A/B, G.726, iLBC, AMR, AMR-GSM
⚫DTMF mode: Signal/RFC2833/INBAND
⚫Echo Cancellation (G.168), with up to 128ms
1.4.4 FXS
⚫Connector: RJ45 or RJ21
⚫Max Line Length: 5 km
⚫Reversed Polarity
⚫Pulse: 10 and 20 PPS
⚫Dial Mode: DTMF and Pulse
⚫Programmable Call Progress Tone
⚫Caller ID: DTMF/FSK CLI Presentation
1.4.5 VoIP
Protocol:
⚫SIP v2.0 (UDP/TCP), RFC3261
⚫SDP, RTP(RFC2833), RFC3262, RFC3263, RFC3264, RFC3265, RFC3515，
RFC2976, RFC3311
⚫RTP/RTCP, RFC2198, RFC1889

1 Product Introduction
7
⚫IPv4 and IPv6
⚫Outbound Proxy
⚫Master/Slave Server
⚫RFC2806 TEL URI
⚫RFC3581 NAT, rport
⚫VLAN 802.1P/802.1Q
⚫RFC4028 Session Timer
⚫DNS SRV/A Query/NATPR Query
⚫NAT: STUN, Static/Dynamic NAT
1.4.6 Call Features
⚫Digit map
⚫IMPU
⚫Action URL
⚫Voicemail
⚫Custom IVR
⚫Call Waiting, Call Holding
⚫Do-not-disturb
⚫Blind/Attended Transfer
⚫Call Forward on Busy
⚫Call Forward on No Reply
⚫Ringing Group, Hotline
⚫3-way Conference
⚫Early Media/Early Answer
⚫Abbreviated Dialing
⚫Access and Peer Mode
⚫SIP PnP Auto Provisioning
⚫PBX IVR
⚫Unconditional Call Forward
⚫SIP registration to different servers

1 Product Introduction
8
⚫Flexible Call Routing Policy
⚫Caller/Called Number Manipulation
1.4.7 Security
⚫QoS, TLS, SRTP
⚫Web ACL/SSH ACL
⚫RADIUS Authentication
⚫Certification Management
⚫Service Network Port: Isolated/BOND/Bridge Mode
⚫Signaling/Voice Encryption
1.4.8 Physical Features
⚫Power Supply: 100-240VAC, 50/60Hz
⚫Dual power supplies (only 48S and 72S support)
⚫Power Consumption: 95W
⚫Operating Temperature: 0℃ ~ 45℃
⚫Storage Temperature: -20℃ ~80℃
⚫Humidity: 10%-90% Non-Condensing
⚫Dimensions(W/D/H): 440*328*44mm (1U)
⚫Unit Weight:
DAG2500-48S: 4.1kg
DAG2500-72S: 4.25kg
DAG2500-96S: 4.4kg
⚫Compliance: CE and FCC
1.4.9 Maintenance
⚫CDR
⚫Ping/Tracert Test
⚫Network Capture
⚫Outward Test (GR909)

1 Product Introduction
9
⚫SNMP, TR069, Provision
⚫NTP/Daylight Saving Time
⚫IVR local Maintenance
⚫RADUIS Authentication Management
⚫Cloud-based Management (NMS)
⚫Syslog: Debug, Info, Error, Warning, Notice
⚫Configuration Backup/Restore
⚫Firmware Upgrade via HTTP/HTTPS/TFTP/FTP/HTTP

2 Quick Installation
10
2 Quick Installation
2.1 Installation Attentions
To avoid unexpected accident or device damage, please read the following
instructions before installing the device:
⚫The device is equipped with both RJ45 and RJ21 ports;
⚫Anti-jamming: to reduce the interference with telephone calls, it’s highly
recommended that telephone lines connected to the gateway should be
placed away from power cables;
⚫Power supply: the power adapter of the device accepts 100-240V AC power
supply. Please ensure safe and stable power supply (The DAG2500-48/72S
supports a dual 220v power supply or dual 48v power supply).
⚫Network bandwidth: please ensure there is enough network bandwidth so as
to guarantee stabilized running of the gateway;
⚫Ventilation: to avoid overheating, please do not pile up the gateway with
other devices and make sure the gateway has good ventilation around;
⚫Temperature and humidity: to avoid any accident that might cause
malfunction, it’s advised to install the gateway in an equipment room where
temperature and humidity are appropriate;
⚫Mechanical load: please make sure the gateway is placed steadily to avoid
damage. It is highly advised to horizontally place the gateway on a flat surface
or a cabinet.

2 Quick Installation
11
2.2 Installation Steps
⚫Connection Diagram for DAG2500-48S/72S/96S
⚫Connect gateway with network via a switch
⚫Connect FXS ports with analog phones, connect gateway with power input
and grounding lug

3 Basic Operation
12
3 Basic Operation
3.1 Methods to Number Dialing
There are two methods to dial telephone number or extension number:
⚫Dial the called number and wait for 4 seconds for dialing timeout, or dial the
called number directly (the system will judge whether the dialing is
completed according to Digitmap and Regular Expression dial plans).
⚫Dial the called number and press #.
3.2 Call Holding
If a calling party places a call to a called party which is otherwise engaged, and
the called party has the call holding feature enabled, the called party is able to
switch to the new incoming call while keeping the current call holding on by
dialing *# or pressing the flash button/flash hook.
When the called party dials *# once again or presses the flash button/ flash hook
once again, he or she will switch back to the first call.
3.3 Call Waiting
If a calling party places a call to a called party which is otherwise engaged, and
the called party has the call waiting feature enabled, the calling party will hear
a IVR voice ‘Please hold on, the subscriber you dialed is busy’ and the called
party will hear three beeps if waiting tone is enabled.
By pressing the flash button or the flash hook, the called party is able to switch
between the new incoming call and the current call.

3 Basic Operation
13
3.4 Call Transfer
3.4.1 Blind Transfer
Blind transfer is a call transfer in which the transferring party connects the call
to a third party without notifying the third party.
Example: A gives a call to B and B wants to blindly transfer the call to C.
Operation instructions are as follows:
1. A dials the extension number of B;
2. The extension of B rings, and B picks up the phone. Then A and B go into
conversation;
3. B presses the flash button (or flash hook), and dial *87* after hearing a dialing
tone to trigger blind transfer. Then B dials the extension number of C (end up
with #).
4. The extension of C rings, B hangs up the phone and C picks up the phone.
Then C and A goes into conversation.
Note:
⚫On the ‘Advanced →Feature Code’page, blind transfer should be enabled.
⚫If B hears continuous busy tones after he dials the extension number of C, it
means the call has timed out.
3.4.2 Attended Transfer
Attended transfer is a call transfer in which the transferring party connects the
call to a third party after he confirms that the third party agrees to answer the
call.
Example: A gives a call to B and B wants to attended transfer the call to C.
Operation instructions are as follows:
1. A dials the extension number of B;
2. The extension of B rings, and B picks up the phone. Then A and B go into
conversation;
