LED Diagnostics & Troubleshooting
LED Status Description Troubleshooting
Module Programming
Off Module has no power.
Make sure the D2D harness is connected or that the 12
Volt is present between the red and balck wires. If the
12 Volt is present, the module be be defective.
Solid red Waiting to begin the
programming sequence. Check if the ignition input is properly connected.
Green & Red Initialization failed.
If a second attempt fails after a complete Hard Reset,
connect the module to Directechs.com and call Tech
Support with the module ID in hand.
Flashes green Module is programming. Make sure that the bypass connections are correct (see
wiring diagram).
Flashes orange
slowly Ready for Key2GO programming. Normal operation.
Solid green then
orange for 3 secs. Bypass was skipped. Normal operation.
Solid orange for 3
seconds.
Module was successfully
programmed without bypass. Normal operation.
Solid green for 3
seconds
Module was successfully
programmed. Normal operation.
Module Programming - Error codes
Flashes red x 2 CAN C not detected. Check the CAN connections
Flashes red x 3 Bypass data not detected.
Check the bypass line connection. If more than one wire
is used, make sure they are not inverted. Start vehicle
using the key to confirm the OEM equipment is still
operational.
External module synchronization
Flashes red, red
then orange, x 10 OBDII feature not supported.
Diagnostic data bus not detected. Some features are
not supported by SmartStart. This can be caused by
missing wire connections or module hardware limitation.
Refer to the wiring installation section to check the
connections.
Active Ground While Running
Flashes green GROUND OUT ON (GWR)
command received.
Otherwise, the Ground While Running (status) signal
was lost or was never received by the module.
Commands can come from RF, D2D or W2W.
Flashes red &
orange IGNITION ON command received.
Otherwise, the ignition signal was not received by the
module. In a W2W install, it will show only if the ignition
input wire is used.
Flashes green
quickly START ON command received.
Otherwise, the start signal was not received by the
module. In a W2W install, it will show only if the ignition
input wire is used.
D2D and W2W Commands
Flashes orange x 1 LOCK command received.
Flashes orange x 2 UNLOCK command received.
If the bypass module fails to flash, it means the module
did not receive the signal.
Off
Solid
red
Flashes orange
slowly
Flashes red
x 2
Flashes red
x 3
Solid green
then orange
x 3 secs
Flashes red,
red & orange
x 10 secs
Flashes
red &
orange
Flashes
green
quickly
Flashes
orange x 1
Flashes
orange x 2
Green &
red
Flashes
green
Flashes
green
Solid green x
3 secs
Solid orange x
3 secs
Go to the next page to see the rest of the LED Diagnostics & Troubleshooting.
Optional XpressStart Kits
Directed XpressStart is the new digital solution that significantly saves installation time and provides a
more reliable connection to the vehicle.
Featuring configurable hardware and easy three step installation process, Directed XpressStart kits
remove the guess work when configuring your remote start systems, while still offering several key
options for a wide range of push-to-start vehicles.
No matter which configuration you choose, these easy to install kits provide every component your
installer needs. Please visit www.xpresskit.com for a list of XpressStart kits and their part numbers.
