Directed Ds4+ User manual

SUBARU1

INSTALLATION GUIDE

This product is intended for installation by a professional installer only! Attempts to install this

product by a person other than a trained professional may result in severe damage to a vehicle’s

electrical system and components.

2017-03-07

DS4+

Contents

Warning! Safety first ....................................................................................................................... 3

Introduction .................................................................................................................................... 4

Pre-installation and application warnings ..................................................................................... 4

Vehicle application guide........................................................................................................... 5

Wiring connections ......................................................................................................................... 6

Main harness (H1), 12-pin black connector .................................................................................. 6

Relay harness (H2), 10-pin white connector.................................................................................. 6

Data harness (H3), 8-pin white connector..................................................................................... 6

Analog input/output harness (H4), 22-pin white connector............................................................. 7

RF Port harness (H5), 2-pin white connector.................................................................................. 7

D2D harness (H6), 4-pin white (1) and black (2) connectors ........................................................... 7

Temperature sensor harness (H7), 2-pin black connector ................................................................ 7

Installation (wiring diagrams, fuse selection & vehicle wiring reference charts)........................................ 8

Type 1 ..................................................................................................................................... 8

Type 2 ................................................................................................................................... 12

Type 3 ................................................................................................................................... 15

Key2GO...................................................................................................................................... 18

Connecting the module .................................................................................................................. 18

Important! .............................................................................................................................. 18

Adjusting the 8504D Shock Sensor ........................................................................................... 19

When used in conjunction with SmartStart.................................................................................. 19

D2D 1.0/2.0 port configuration ............................................................................................... 19

Module programming.............................................................................................................. 20

LED diagnostics and troubleshooting.......................................................................................... 21

Soft reset................................................................................................................................ 23

Hard reset .............................................................................................................................. 23

Learning the Tach (not needed with Virtual Tach) ............................................................................... 24

Initializing Virtual Tach (not needed with hardwired or data tach applications) ..................................... 24

Limited lifetime consumer warranty .................................................................................................. 25

Quick Reference Guide.................................................................................................................. 26

3DS4+ SUBARU1

Warning! Safety ﬁrst

The following safety warnings must be observed at all times:

• Due to the complexity of this system, installation of this product must only be performed by an authorized Directed dealer.

• When properly installed, this system can start the vehicle via a command signal from the remote control. Therefore, never

operate the system in an area that does not have adequate ventilation.

The following precautions are the sole responsibility of the user; however, authorized Directed dealers should:

• Never use a test light or logic probe when installing this unit. Always use a multimeter.

• Never operate the system in an enclosed or partially enclosed area without ventilation (such as a garage).

• When parking in an enclosed or partially enclosed area or when having the vehicle serviced, the remote start system must

be disabled using the installed toggle switch. It is the user’s sole responsibility to properly handle and keep out of reach from

children all remote controls to assure that the system does not unintentionally remote start the vehicle.

• USER MUST INSTALL A CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJACENT TO THE VEHICLE.

ALL DOORS LEADING FROM ADJACENT LIVING AREAS TO THE ENCLOSED OR PARTIALLY ENCLOSED VEHICLE

STORAGE AREA MUST REMAIN CLOSED AT ALL TIMES.

Use of this product in a manner contrary to its intended mode of operation may result in property damage, personal injury, or

death. Except when performing the Safety Check outlined in this installation guide, (1) Never remotely start the vehicle with

the vehicle in gear, and (2) Never remotely start the vehicle with the keys in the ignition. The user is responsible for having the

neutral safety feature of the vehicle periodically checked, wherein the vehicle must not remotely start while the car is in gear.

This testing should be performed by an authorized Directed dealer in accordance with the Safety Check outlined in this product

installation guide. If the vehicle starts in gear, cease remote start operation immediately and consult with the user to ﬁx the problem

immediately.

OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN GEAR IS CONTRARY TO ITS INTENDED MODE OF

OPERATION. OPERATING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT IN PROPERTY DAMAGE

OR PERSONAL INJURY. IMMEDIATELY CEASE THE USE OF THE UNIT AND REPAIR OR DISCONNECT THE INSTALLED REMOTE

START MODULE. DIRECTED WILL NOT BE HELD RESPONSIBLE OR PAY FOR INSTALLATION OR REINSTALLATION COSTS.

Remote starters for manual transmission pose signiﬁcant risks if not properly installed and operated. When testing to ensure the

installation is working properly, only remote start the vehicle in neutral gear, on a ﬂat surface and with a functional, fully engaged

parking brake. Do not allow anyone to stand in front of or behind the vehicle.

This product should not be installed in any convertible vehicles, soft or hard top with a manual transmission. Installation in such

vehicles may pose certain risk.

4DS4+ SUBARU1

Introduction

The SUBARU1 ﬁrmware for DS4+ is a complete solution for remote start, security (if applicable), bypass

interface, and convenience needs compatible with speciﬁc Subaru vehicles.

Warning! This module can only be programmed via the web tool, which can be found on

www.directechs.com or using the Directechs Mobile application for smartphones. Features and functions will

become accessible when you connect the module using the XKLoader.

Pre-installation and application warnings

Firmware notes: This section highlights important information for this speciﬁc ﬁrmware and will assist in

pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.

T-Harness

compatible

Keys required for

programming 1Keys required for

operation 0

Key2GO is mandatory to control the immobilizer override in this ﬁrmware.

Unless speciﬁed otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic

connector.

It is important to check that the fuses are positioned correctly in the module. Refer to the "Fuse selection" section following

each installation type for more information.

Refer to the "Vehicle wiring reference chart" following each installation type.

Depending on the origin of the vehicle, it could have one of two Brake Status types with the default setting as Type 1. If

under a remote start condition the brake does not shut the vehicle down, program the Brake Status as Type 2. This can be

done when ﬂashing the module found under Data Feature Conﬁguration when ﬂashing the ﬁrmware.

General notes: This section highlights important information for this speciﬁc ﬁrmware.

[1] The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin.

[2] The siren is only required when enabling the security features during module ﬂashing.

[3] The Green wire is only required for starter kill and antigrind connections.

[4] The Keysense Input connection is only needed if keysense is not recognized through data at the time of programming. See

LED Diagnostics & Troubleshooting section for more details.

Additional parts required (maximum required):

Diode 6A

0 x 1A Diodes 86 85

87a

2 x Relay

Resistor 100Ω

0 x Resistor

Fuse 7.5A

0 x Fuse

5DS4+ SUBARU1

Vehicle application guide

The following table lists the vehicles and features which are compatible with this product. The number assigned to each year

allows you to determine which installation type should be used for your vehicle.

Vehicles

2014

2013

2012

2011

2010

2009

2008

2007

2006

2005

PK-Immobilizer Bypass-Data No Key Req'd

DL-Arm Factory Security

DL-Disarm Factory Security

DL-Door Lock Control

DL-Door Unlock

DL-Trunk / Hatch Release

FOB-Control of aftermarket alarm with OEM

remote

Key2GO

RS-3x LOCK START (Start control using OEM

Remote)

RS-3x LOCK STOP (Stop control using OEM

Remote)

RS-SmartStart

RS-Tach / RPM Output

SS-Entry Monitoring ALL Door Pins

SS-Entry Monitoring Trunk/Hatch Pin

ST-Brake Status (foot brake)

ST-E-Brake Status

ST-Ignition Status

Subaru

B9 Tribeca 2 •••••••••••••••••

B9 Tribeca 1 ••••••••••••••• •

Forester 33333 •••••••••••••••••

Impreza 3333 •••••••••••••••••

Legacy 222 •••••••••••••••••

Legacy 11••••••••••••••• •

Outback 222 •••••••••••••••••

Outback 11••••••••••••••• •

Tribeca 22222222 •••••••••••••••••

Tribeca 1 ••••••••••••••• •

WRX 333 •••••••••••••••••

Legend:

DL: OE Door Lock & Alarm Controls

FOB: Sync CAN Interface w/ FOB Remote

PK: Transponder & Immobilizer Override

RS: Remote Start & Engine Controls

SS: Integrated Security & Monitoring

ST: Function/Feature Status

6DS4+ SUBARU1

Wiring connections

The wiring connections listed below are speciﬁc to this ﬁrmware.

Main harness (H1), 12-pin black connector

Conn./Pin Color Description

H1/1 Blue/White Relay 1 N.C. – Keyless Data Interrupt (conn.side) 1

H1/2 Blue/Red Relay 1 N.O. – No Connection 1

H1/3 Blue Relay 1 COM – Keyless Data Interrupt (vehicle side) 1

H1/4 White/Brown Relay 3 N.C. – No Connection 1

H1/5 White Relay 3 COM – (+) Starter Output 1

H1/6 Red (+) 12 Volt (Battery)

H1/7 Lt. Green/Red Relay 2 N.O. – No Connection 1

H1/8 Lt. Green Relay 2 COM – Immobilizer Data Interrupt (connector side) 1

H1/9 Lt. Green/White Relay 2 N.C. – Immobilizer Data Interrupt (vehicle side) 1

H1/10 Black (-) Ground

H1/11 White Relay 3 COM – (+) Starter Output 1

H1/12 Red (+) 12 Volt (battery)

Relay harness (H2), 10-pin white connector

Conn./Pin Color Description

H2/1 N/A No Connection

H2/2 Red/Black (+) 12 Volt Input (accessory/starter)

H2/3 Pink/Black Relay N.C. – Flex 1

H2/4 Pink/White Relay COM – (+) Accessory 2 /Ignition 2/ Flex Relay Output 1

H2/5 Red (+) 12 Volt Input (ignition)

H2/6 Green Relay COM – (+) Starter (key side) 1

H2/7 Violet Relay N.C. – (+) Starter 2 Output (vehicle side) 1

H2/8 Orange Relay COM – (+) Accessory Output 1

H2/9 Red/White (+) 12 Volt Input (ﬂex)

H2/10 Pink Relay COM – (+) Ignition Input/Output

Data harness (H3), 8-pin white connector

Conn./Pin Color Description

H3/1 Tan HS CAN Low

H3/2 Tan/Black HS CAN High

H3/3 Orange/Brown FT CAN Low

H3/4 Orange/Green FT CAN High

H3/5 Lt. Green No Connection

H3/6 Violet/Brown (MUX) Analog Input/Output

H3/7 Orange/Black Immo. Data (vehicle side)

H3/8 Yellow/Black Keyless Data (connector side)

1. If these outputs are not used by the ﬁrmware, they can be conﬁgured by the installer when the module is ﬂashed.

7DS4+ SUBARU1

Analog input/output harness (H4), 22-pin white connector

Conn./Pin Color Description

H4/1 Lt. Green/Black (-) Security Light Output 1

H4/2 Blue/White (-) Ground When Running (status) Output 1

H4/3 Dk. Green/Black (-) Lock Output 1

H4/4 Red/White (-) Trunk Output 1

H4/5 Brown/Black (-) Horn Output 1

H4/6 Brown/White (-) AUX 1 Output 1

H4/7 White (+) Keysense Output 1

H4/8 Violet/Black (+) AUX 4 Output 1

H4/9 Dk. Blue/Black (-) Unlock Output 1

H4/10 Lt. Blue/Black (-) Parking Light Output 1

H4/11 Brown/Red (+) Siren Output 1

H4/12 Pink (+) Ignition Input

H4/13 Violet (+) Door Input 2

H4/14 Brown (+) Brake Input 2

H4/15 White/Blue (-) Activation Input 2

H4/16 Blue/Red (-) Valet Switch 2

H4/17 Black/White (-) E-Brake Input 2

H4/18 Orange/Black (+) Keysense Input 2

H4/19 Blue (-) Trunk Input 2

H4/20 Green (-) Door Input 2

H4/21 Gray (-) Hood Pin Input 2

H4/22 Violet/White (AC) Tach Input

RF Port harness (H5), 2-pin white connector

Conn./Pin Color Description

H5/1 N/A RF Loop

H5/2 N/A RF Loop

D2D harness (H6), 4-pin white (1) and black (2) connectors

Conn./Pin Color Description

H6/1 Blue (Data) TX

H6/2 Black (-) Ground

H6/3 Green (Data) RX

H6/4 Red (+) 12 Volt

Temperature sensor harness (H7), 2-pin black connector

Conn./Pin Color Description

H7/1 Black Temperature Sensor

H7/2 Black Temperature Sensor

1. If these outputs are not used by the ﬁrmware, they can be conﬁgured by the installer when the module is ﬂashed. Note that they are low current and a relay

may be necessary.

2. These connections are only required if the corresponding statuses are not supported by the ﬁrmware. See "Vehicle application guide" on page 5 for a

list of compatible features. If these outputs are not used by the ﬁrmware, they can be conﬁgured by the installer when the module is ﬂashed. Note that they

are low current and a relay may be necessary.

8DS4+ SUBARU1

Installation (wiring diagrams, fuse selection & vehicle wiring reference charts)

Type 1

Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 9 for important information on this installation.

2224252627 2128

9111213141617 815 10

1345

B281

(White conn. at BCM,

right of steering column)

(+) Keysense: Red or

Black/White, pin 7

Immobilizer Data 1: White/Blue, pin 18

Immobilizer Data 2:

Black/Pink, pin 28

B280

(White conn. at BCM,

right of steering column)

CUT

222324252627 21

91112131416 810

1456

CUT

86 85

87a

(-) Security Light:

Brown/Red, pin 33

Keyless Data:

Yellow/Green, pin 9

FT CAN High:

Pink, pin 27

FT CAN Low:

Violet, pin 26

i84

(Gray conn. at BCM,

right of steering column)

(+) 12V

CUT

2223

2425

2627

111213141617

15 10

145

29303132

3435

B69

(White conn. at

parking light on

steering column)

(+) Parking Lights:

Orange, pin 4

2 1

86 85

87a

(+) 12V

2 13

B72

(White conn.

at Ignition Switch)

Refer to the Vehicle Wiring Reference Chart

on pages 9-10 for wire colors and location.

Keyless Data Interr. (conn.side): Blue/White: 1

Keyless Data Interr. (veh. side): Blue: 3

Immo. Data Interr. (conn. side): Lt. Green: 8

Immo. Data Interr. (vehicle side): Lt. Green/White: 9

(-) Ground: Black: 10

(+) Keysense Output: White: 7

(-) Parking Light Output: Lt.Blue/Black: 10

(-) Security Light Output: Lt.Green/Black: 1

FT CAN High: Orange/Green: 4

FT CAN Low: Orange/Brown: 3

HS CAN High: Tan/Black: 2

HS CAN Low: Tan : 1

Keyless Data (conn. side): Yellow/Black: 8

Immo. Data (veh. side): Orange/Black: 7

Siren

Hood Pin

(+) 12V: Red: 6 & 12

(+) Ignition Input/Ouput: Pink: 10

(+) 12V Input: Red: 5

(+) Accessory Output: Orange: 8

(+) 12V Input: Red/White: 9

(+) 12V Input: Red/Black: 2

(+) Ignition 2: Pink/White: 4

(+) Starter Output (veh. side): Violet: 7

(-) Hood Input: Gray: 21

(+) Siren Output: Brown/Red: 11

Starter Input (key side): Green: 6

22 810 12

4 2442

DS4+

DS4

It is important to check that the

fuses are positioned correctly. See

Fuse selection on the next page for

more information.

(+) Brake Input: Brown: 14

(+) Keysense Input: Orange/Black: 18

(+) Brake: Brown/Red

or Brown/White, pin 23

HS CAN High:

Red, pin 20

HS CAN Low:

Blue, pin 30

9DS4+ SUBARU1

Fuse selection

To ensure correct functionality of your system, please conﬁgure the fuses on your system as follows:

DS4+ DS4

22 810

4 2442

Slide to open

MAIN (5A) (+)

(-) RLY3 PK LIGHT (15A) (+)

(-) ACC & START (30A) (+)

(-) FLEX RLY (20A) (+)

IGN (20A) (+)

MAIN (5A) (+)

(-) RLY3 PK LIGHT (15A) (+)

(-) ACC & START (30A) (+)

(-) FLEX RLY (20A) (+)

IGN (20A) (+)

MAIN (5A) (+)

(-) RLY3 PK LIGHT (15A) (+)

(-) ACC & START (30A) (+)

(-) FLEX RLY (20A) (+)

IGN (20A) (+)

MAIN (5A) (+)

(-) RLY3 PK LIGHT (15A) (+)

(-) ACC & START (30A) (+)

(-) FLEX RLY (20A) (+)

IGN (20A) (+)

MAIN (5A) (+)

(-) RLY3 PK LIGHT (15A) (+)

(-) ACC & START (30A) (+)

(-) FLEX RLY (20A) (+)

IGN (20A) (+)

MAIN (5A) (+)

(-) RLY3 PK LIGHT (15A) (+)

(-) ACC & START (30A) (+)

(-) FLEX RLY (20A) (+)

IGN (20A) (+)

MAIN (5A) (+)

(-) RLY3/PK LIGHT(15A) (+)

MAIN (5A) (+)

(-) RLY3/PK LIGHT(15A) (+)

22 8

4 2442

Slide to open

Vehicle wiring reference chart

This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to

www.directechs.com for additional information.

Wire Information Connector Information

Function Color Pin Polarity Location Color Pins Ref.

Subaru B9 Tribeca 2006

HS CAN High Red 20 Data Body Integrated Unit, B280, right of steering column. White 30 A

HS CAN Low Blue 30 Data Body Integrated Unit, B280, right of steering column. White 30 A

Immobilizer Data 1 White/Blue 18 Data Body Integrated Unit, B280, right of steering column. White 30 A

Immobilizer Data 2 Black/Pink 28 Data Body Integrated Unit, B280, right of steering column. White 30 A

FT CAN High Pink 27 Data Body Integrated Unit, i84, right of steering column. Gray 35 B

FT CAN Low Violet 26 Data Body Integrated Unit, i84, right of steering column. Gray 35 B

Keyless Data Yellow/Green 9 Data Body Integrated Unit, i84, right of steering column. Gray 35 B

Security Light Brown/Red 33 (-) Body Integrated Unit, i84, right of steering column. Gray 35 B

Keysense Red or Black/White 7 (+) Body Integrated Unit, B281, right of steering column. White 28 C

Brake Brown/Red 23 (+) Body Integrated Unit, B281, right of steering column. White 28 C

12V White 3 (+) Ignition Switch, B72, at steering column. White 6 D

Accessory Yellow 4 (+) Ignition Switch, B72, at steering column. White 6 D

Ignition Green 6 (+) Ignition Switch, B72, at steering column. White 6 D

Ignition 2 Blue 1 (+) Ignition Switch, B72, at steering column. White 6 D

Starter White/Black 2 (+) Ignition Switch, B72, at steering column. White 6 D

Parking lights Orange 4 (+) Parking Light Switch, B69, at steering column. White 4 E

10 DS4+ SUBARU1

Wire Information Connector Information

Function Color Pin Polarity Location Color Pins Ref.

Subaru Outback 2005-2006
