Displays2go BLKDMPTB Installation guide

ASSEMBLY INSTRUCTIONS MANUAL
BLKDMPTB WHITE FOLDING DUMP TABLE
PAGE 1 OF 9

PARTS IN CARTON:
FOLD-UP LEGS
(2 EACH)
END WALL
(2 EACH - INSIDE VIEW)
END WALL
(2 EACH - OUTSIDE VIEW)
TABLE TOP
(1 EACH - BOTTOM VIEW)
JOINER STRIP
(1 EACH)
TABLE TOP EXTENDER
(1 EACH - BOTTOM VIEW)
SIDE WALL
(2 EACH - INSIDE VIEW)
PAGE 2 OF 9
ASSEMBLY INSTRUCTIONS MANUAL
BLKDMPTB WHITE FOLDING DUMP TABLE

PARTS IN CARTON:
YOU WILL NEED TO SUPPLY YOUR OWN SCREWDRIVER FOR INSTALLATION.
INTSTALLATION WILL REQUIRE THE USE OF A SCREWDRIVER (REGULAR OR
PHILLIPS-HEAD) THIS IS FOR THE INSTALLATION FOR SOME OF THE CAM
LOCKING NUTS.
STANDARD PHILLIPS-HEAD SCREWDRIVER IS NEEDED FOR THE INSTALLATION
OF THE LONG SCREWS, 2 INCH WOOD SCREWS AND THE CAM LOCKING SCREWS.
CAM LOCKING SCREW
(10 EACH)
CAM LOCKING NUT
(10 EACH)
LONG SCREW
(8 EACH)
LONG SCREW COVER
(8 EACH)
LEG SCREWS
(16 EACH)
LEG CAPS
(4 EACH)
PAGE 3 OF 9
ASSEMBLY INSTRUCTIONS MANUAL
BLKDMPTB WHITE FOLDING DUMP TABLE

STEP 1
PLACE TABLE TOP ON FLAT SURFACE WITH BOTTOM FACING UP. SLIDE
JOINER STRIP INTO SIDE OF TABLE TOP THAT HAS A RECESSED GROOVE
(SEE FIGURE 1).
FOLLOW THIS STEP AGAIN INSERTING THE
TABLE TOP EXTENDER INTO THE OTHER HALF
OF THE JOINER STRIP THAT WAS INSERTED
INTO THE TABLE TOP. IT SHOULD NOW BE
ONE COMPLETE SECTION.
TABLE TOP
JOINER STRIP
FIGURE 1
TABLE TOP
(BOTTOM VIEW)
JOINER
STRIP
TABLE TOP
EXTENDER
RECESSED GROOVE EDGE RECESSED GROOVE EDGE
PAGE 4 OF 9
ASSEMBLY INSTRUCTIONS MANUAL
BLKDMPTB WHITE FOLDING DUMP TABLE

STEP 2
PLACE (10) CAM LOCKING NUTS INTO EACH OF THE HOLES IN
THE COMPLETED TABLE TOP SECTION.
STEP 3
LOCATE (2) SIDE WALLS & (4) CAM LOCKING SCREWS. USING YOUR SCREWDRIVER,
(NOT INCLUDED WITH HARDWARE, SEE PAGE 3). SCREW IN (2) CAM LOCKING
SCREWS INTO THE SIDE WALL.
REPEAT STEP 3 FOR
OTHER SIDE WALL.
NOTE: MAKE SURE THE ARROW
ON THE CAM LOCKING NUTS ARE
FACINGTOWARDS THE CLOSEST
EDGE OF THE BOARD.
SIDE WALL
PAGE 5 OF 9
ASSEMBLY INSTRUCTIONS MANUAL
BLKDMPTB WHITE FOLDING DUMP TABLE

STEP 4
LOCATE (2) END WALLS & (6) CAM LOCKING SCREWS.
USING YOUR SCREWDRIVER, SCREW IN (3) CAM
LOCKING SCREWS INTO THE END WALL.
REPEAT STEP 4 FOR OTHER END WALL.
STEP 5
LOCATE (2) ASSEMBLED SIDE WALLS (FROM STEP 3) & SCREWDRIVER. INSERT
CAM LOCKING SCREWS FROM SIDE WALL INTO THE SIDE OF(TABLE TOP)
WITH THE ARROWS OF THE CAM LOCKING NUTS FACING OUT.
TO LOCK INTO PLACE: USE YOUR SCREWDRIVER TO TIGHTEN CAM
LOCKING NUTS, TURNING CLOCKWISE UNTIL TIGHT.
REPEAT STEP 5 FOR THE OTHER SIDE WALL.
END WALL
TABLE TOP
(BOTTOM VIEW)
SIDE WALL (BOTTOM VIEW)
PAGE 6 OF 9
ASSEMBLY INSTRUCTIONS MANUAL
BLKDMPTB WHITE FOLDING DUMP TABLE

STEP 6
LOCATE (2) END WALLS. INSERT CAM LOCKING SCREWS FROM END WALL INTO
***NOTE*** WHEN ASSEMBLING, MAKE SURE THE CAM LOCKS ARE ON
THE BOTTOM SIDE OF THE TABLE.
THE THE SIDE WALL END. TIGHTEN ALL (3) CAM NUTS. THEN INSERT (4) LONG
SCREWS INTO THE HOLES ON THE END WALL.
TO LOCK INTO PLACE: USE YOUR SCREWDRIVER TO TIGHTEN CAM
LOCKING NUTS, TURNING CLOCKWISE UNTIL TIGHT.
REPEAT STEP 6 FOR THE OTHER SET OF FOLD-UP LEGS.
FIGURE 2
PAGE 7 OF 9
ASSEMBLY INSTRUCTIONS MANUAL
BLKDMPTB WHITE FOLDING DUMP TABLE

FOLD-UP LEGS
TABLE TOP (BOTTOM VIEW)
STEP 7
LOCATE (2) FOLD-UP LEGS & (16) LEG SCREWS. WITH TABLE TOP ASSEMBLED,
PLACE (1) SET OF FOLD-UP LEGS ONTO UNDERSIDE OF TABLE TOP. ALIGN ALL
(8) HOLES ON TABLE TOP TO HOLES ON FOLD-UP LEGS. USING YOUR SCREW-
DRIVER, SCREW IN (8) LEG SCREWS (SEE FIGURE 3).
*NOTE: SLIGHTLY RAISE LEGS TO INSTALL THE SECOND SET OF LEGS.
OPEN LEGS AND MAKE CERTAIN THAT THE LEGS LOCK INTO PLACE.
REPEAT STEP 7 FOR THE OTHER SET OF FOLD-UP LEGS.
LEG SCREWS
(16 EACH)
FIGURE 3
PAGE 8 OF 9
ASSEMBLY INSTRUCTIONS MANUAL
BLKDMPTB WHITE FOLDING DUMP TABLE

STEP 8
WITH TABLE TOP STILL ON FLAT SURFACE AND LEG SECURLEY OPEN, INSERT
(4) LEG CAPS ONTO END OF LEGS.
LEG CAPS
FOLD-UP LEGS
LEG CAPS
STEP 9
LOCATE (8) LONG SCREW COVERS. USING YOUR THUMB, INSERT SCREW COVER
OVER EACH LONG SCREW (SEE FIGURE 4) LOCATED ON THE ENDS OF TABLE
TOP ON END WALLS.
AFTER THE ASSEMBLY IS COMPLETED, TURN THE TABLE OVER ONTO LEGS
(2 PEOPLE RECOMMENDED). THIS COMPLETES THE ASSEMBLY.
