Displays2go LCKDPHS Series User manual

AssemblyAssembly
InstructionsInstructions
SKUs: LCKDPHS SeriesSKUs: LCKDPHS Series
HOSTESSHOSTESS
STATIONSTATION
WITH HIDDENWITH HIDDEN
WHEELSWHEELS

2
PARTS LIST
If you have any questions regarding our products, please visit us at www.displays2go.com or
contact Displays2go customer service at 844-221-3388.
Scan QR code
to visit product
page
Attention: Before you start assembling your hostess station,
please prepare a soft surface work area on the floor.
Carefully remove all hardware from packaging and place
the hardware parts on the soft work area where they will not
come in contact with the laminated wood lectern components.
To avoid damage to the laminated wood surfaces, keep
hardware parts separated until they are needed for assembly.
TOOLS REQUIRED: Phillips head screwdriver
TWO PEOPLE RECOMMENDED FOR ASSEMBLY.

3
2. Insert cam posts into side panel, then fit
assembled A, D, and C panels onto posts.
Then, insert cam locks and tighten to secure.
1. Insert cam posts into back panel, then fit top and
bottom panel onto posts. Then, insert cam locks
and tighten to secure.
NOTE: Ensure that the holes on board C are facing
outward.
Board A must be attached
to the TOP of back panel,
which is the side with more
space between the holes
and the edge of the board.
3. Repeat step 2 for second side panel.

4
Eny r wEny r w
hoe n!hoe n!
CONTACT INFORMATION:
www.displays2go.com
PHONE: [phone]
4. Line up casters with the guide holes on the
bottom of panel C. Then, tighten screws to
secure casters to the unit.
NOTE: For each caster, partially tighten all
screws to ensure correct alignment with pilot
holes, then go back and finish tightening all
four screws.w
NOTE: Locking casters should be closest to
the open back of the unit, for ease of access.
5. Press adjustable pins into holes inside the unit.
Ensure that all are lined up at the same level. Then
insert shelf panel to rest on the pins.
