Displays2go DP031NVB User manual

Model: DP031NVB
Description: LED Counter
USER MANUAL
2ASCB- DP031NVB
Scan QR code to visit
the product page:

Contents
1.Preface............................................................................................................................. 1
1.1 Instructions............................................................................................1
1.2 Safety Warnings .............................................................................................................. 1
2. Product introduction..........................................................................................................3
2.1 Overview.........................................................................................................................3
2.2 Dimension......................................................................................................................3
3.Assembly and Connection ...................................................................................................5
4.System Connection Instructions...........................................................................................6
4.1 System connection diagram of single unit .......................................................................... 6
4.2 System Connection Diagram of Multi units......................................................................... 6
4.3 Startup Instructions ...................................................................................................... 7
5.Content Management & Publish ........................................................................................ 8
5.1 Publ i sh via PC ...... .... . .... . .... . .... .... . .... . .... . .... .... . .... . .... . .... .... . .... . .... . .... .... . .... 8
5.2 Publish via Phone APP .................................................................................................... 14
5.3 Publish via USB ............................................................................................................ 18
6.Technical Specifications.................................................................................................... 20

1
1.1 Instructions
1.Preface
1) This manual is applied to LED digital Counter. For better application, this manual systematically
introduces the product make up, interface, specification, also the installation, wiring and content
publish operation.
2) Software instruction is based on built-in Nova T30 player and not applicable for other players.
3) Version 1.0.0.
1.2 Safety Warnings
Please read below instructions before installation, power-on, operation
and testing; Make sure to follow the safety instructions. For any questions,
please contact us for assistance.
Due to flame, electric shock, fall down, this product may cause injury to
person, even death;
This product is not suitable for swimming pools, sauna, bathroom and
other humid environments;
This product is non-waterproof, or cannot be used in complete outdoor
environments;
Please do not block the ventilation holes during operation;
Please take moisture-proof measures when packing and stock;
Please do not drop, strike, scratch, warp or shake LED display or external
equipment;
Please make sure the product is operated under professional staff due to
inside strong current;
please make sure the ground is flat and even before placing the product;
Ground this product correctly to ensure safety and prevent electric
shock;
Please power off the product in thunderstorm weather. Unplug the
product if it will not be used for a long time;
We strongly recommend using a surge protector, or a power strip with
internal circuit breaker to prevent damages to the product.

2
Please unplug display power under situations of unused, disassemble,
installation, maintenance;
Please make sure the AC power meets local building & electrical
standards and equipped with overload and earth faulty protection;
Please make sure and check electricity, cable and all connected
equipments meet current requirements before using this product;
Make sure power cable is in good condition. Please replace with a new
one if the product or the cable is over-heating;
Please make sure the product is operated by licensed personnel due to
in sid e st r ong cur rent ; for any qu est io n s, ple as e con su lt w i th
professional personnel;
Please wear eye-protection and do not watch the screen directly for a
long time when screen is at 100% brightness;
Do not use any optical devices with magnifying function to look at the
screen or it could cause damage to your vision;
Make sure the screen, processor and power have good ventilation, at
least 0.1m distance from other objects;
Do not stick any objects on screen;
Do not modify the product, or add new parts to it;
Do not expose the product directly to sunlight;
Do not use the product if the surrounding temperature is higher than
40°F;
Please wear a helmet to prevent body injury;
Please make sure any fixed and connected structures meet safety
standards;
Please hold the screen firmly when joint units to prevent drop or tip-
over;
Warning: Manufacturer is not responsible for any incorrect, improper,
irresponsible or unsafe operations.

2.1 Overview
2. Product introduction
2.2 Dimension
This product embodies features including easy operation, multiple communication modes,
high brightness,and high-quality display, which can be widely installed in hotels, restaurants,
shopping malls, banks, government agencies, hospitals and other locations.
3
Corian Surface
LED Module
Base
Wheels

ON/OFF Switch
USB port
RJ45 port
Speaker
Speaker
AC Power
Cord Socket
Heat Dissipaon Holes
4

Accessory Picture Qty
5
User manual 1
Parts List
3. Assembly and Connection
Power Cord 1
1
LED Digital Counter
1
Pull-strap 1
Keys

6
4.1 System connection diagram of single unit
4. System Connection Instructions
Fig 4.1
Fig 4.1 is the system connection diagram with built-in player.
Playlist can be loaded in by USB, cable, APP in PC and cell phone, then loop playback.
4.2 System Connection Diagram of Multi units
Fig 4.2
Fig 4.2 is the system connection diagram with built-in player in one LAN.
Playlist can be loaded via one PC or phone.

7
4.3 Startup Instructions
We strongly recommend using a surge protector, or a power strip with internal
circuit breaker to prevent damages to the product.
1). Connect power cable . See fig 4.3.
2). Press “I” on power switch.
3). Load in the playlist.
Notes: please refer to the Section 7 on how to load in a playlist.
Fig 4.3
Red Switch
Press I, power on
Press 0, power off

8
5.1 Publish via PC
5.Content Management & Publish
1) Software installation
a.Download the software on it's official website VIPlex Express:
https://www.novastar.tech/downloads/?_sasdk=dMTg0MDkwYzA4MmExMzktMDRiOGRhOTB
kMjIzNDFjLTU3NjE1M2UtNDIzMzYwMC0xODQwOTBjMDgyYmYxYg%EF%BC%8CNote:%20(x64)
%20&%20(x32)%20PC
downloading choose Fig5.1 software version
b. Find shortcut of the software on desk as fig 5.2.
Fig 5.1
Fig 5.2
