ASSEMBLY INSTRUCTIONS - PPLNNSTLRG
PARTS LIST
A. Leg
B. Middle Connector
C. Wood Countertop
D. Top Wood Table
E. Top Table Connector
F. Screw
G. Hex Key
H. Wood Screw
I. Screw Driver
X2
X1
X1
X1
X1
X6
X1
X14
X1
A
B
C
D
E
FG
I
H
Step 3. Lay Top Wood Table (D) on a clean, smooth
surface (the side with pre-drilled holes facing up).
Align holes on Top Table Connector (E) with holes at
bottom of Wood Table-top. Insert and tighten (8)
Wood screws (H) using provided screw driver (I).
Step 1. Assemble (2) Legs (A) with Middle Connec-
tor (B) by fastening (2) screws (F) from both sides.
Use Hex Key (G) provided within the package.
Step 2. Flip over the assembled leg frame in Step 1,
and connect it to the bottom of the Wood Counter-
top (C) with (4) screws (F) as shown in picture below.
Step 4. Flip over the assembled parts in Step 3. Align
holes in Top Table Connector (F) with pre-drilled
holes on Wood Countertop (D).
Insert (3) Wood screws (H) on each mounting plate
on Top Table Connector. Tighten all Wood Screws
with the provided phillips screw driver (I).

ASSEMBLY INSTRUCTIONS - PPLNNSTSML
PARTS LIST
A. Leg
B. Middle Connector
C. Wood Table
D. Screw
E. Hex Key
F. Wood Screw
G. Screw Driver
X2
X1
X1
X2
X1
X12
X1
A
B
D
E
C
G
F
Step 1. Assemble (2) Legs (A) with Middle Connector
(B) by fastening (2) screws (D) from both sides. Use
Hex Key (G) provided within the package.
Step 2. Lay Wood Table (C) on a clean, smooth
surface (the side with pre-drilled holes facing up).
Place the assembled leg frame in Step 1, and align
holes on the round plate with the holes on the
bottom of the Wood Table. Insert (3) wood screws
(F) through each mounting plate. Tighten all wood
screws with provided Phillips Screw driver (G).
