DKN technology HM3310 User manual

DELUXE SMITH MACHINE
Model #: HM3310
OWNER’S MANUAL
Caution: Read all precautions and
instructions in this manual before using
this equipment. Save this manual for
future reference.
!

Contents
Assembly Instructions
Contents
Before You Begin
Assembly Steps
1
2
Safety Instructions 3-4
5-7
8-9
Parts & Hardware List
Page 1

Page 3
WARNING: Prior to use of HM3310 please ensure that you Read and Understand all the
following Precautions and Safety Notes. It is the responsibility of the owner to ensure that all
users of equipment HM3310 are adequately informed of all Precautions and Safety Notes.
Precautions
1. This equipment is designed for home use only. Using this product in any commercial setting will void
all warranties and may result in serious injury!
2. Make sure all parts are properly tightened each time the Equipment is used.
3. All parts should be checked regularly for signs of wear. Replace any worn parts immediately.
4. Keep hands and feet away from moving parts.
5. Any of the adjustment devices should not be left projecting.
6. Never allow children to use or play near this equipment. Teenagers under the age of 18 must always
have parental supervision and instruction on the use of this machine.
7. Use the equipment and start your training step by step, because injuries to health may result from
incorrect or excessive training.
8. Consult your physician before starting an exercise program. Stop exercising if you feel pain or
tightness in your chest, become short of breath, or feel faint. Contact your doctor before using the
equipment again.
Safety Notes
1. When doing exercises WITHOUT using Smith Bar, such as, Chin-Up, Barbell Squat or Barbell
Bench Press with front J-hooks and Spotters, etc.
1) Hook the Smith Bar on the top position and make sure it is secured in place.
2) Place Safety Hooks (Part 9#/18#) right below the Smith Bar for double security. Very Important!
Safety Instructions

Page 4
2. When doing exercises WITH the Smith Bar, such as, Smith Squat, Smith Bar Bench Press and
all other exercises using Smith Bar.
1) Take off all the J-hooks and Spotters, put them aside and store appropriately.
2) Adjust the Smith Bar to a suitable height, place the Safety Hooks at a proper position to keep the
Smith Bar away from your body in case of Smith Bar accidental falling or your failure to lift the weights.
(Note: All the above diagrams are for reference only, you need to adjust the Safety Hooks to a proper position due to
different user and different exercises position.)
Safety Instructions

Assembly Instructions
Page 3
STEP 1
N10
12
5
6
7
8
9
10
H10-14
3x
6x
H10-2
3x
x2
x2
x2
x16
16x
x2
1
11
2
3
4
BW10
x3
x3
S8-1
W10

Assembly Instructions
Page 4
STEP 2
24
14
13 15 16
17
18
19
20 21
23
22
W10
x18
H10-14
x6
H10-2
x4 x4
x2
x2
x4
N10
x10
BW10
x6
H10-15
x4
CH12-3
x2

Assembly Instructions
Page 5
H10-2
x4
6x
2x
4x
2x
2x
A6-1
STEP 3
25 26
27
28
29
30
2x 31
x6
P10-5
F6-1
6x
W10
2x 32

Assembly Instructions
Page 6
Parts & Hardware List
Part# Description Qty Remark
1 Right Front Upright Frame 1
2 Right Bottom Frame 1
2doRediuGtnorF3
delbmessa-erP4gniRgniniateR4
5 Right Bearing Housing 1
4revoCreppoC6
delbmessa-erP4gniraeBraeniL7
2repmuBrebbuR8
9 Right Weight Bar Safety Support 1
10 Bar Safety Support Sleeve 2 Pre-assembled
23sixAtrohS11
23sixAgnoL21
1raBthgieW31
14 Left Front Upright Frame 1
15 Left Bearing Housing 1
16 Weight Bar Olympic Sleeve 2
2rehsaWnaP71
18 Left Weight Bar Safety Support 1
19 Olympic Bar Holder 2
20
Rubber Bumper
4
20
Rubber
Bumper
4
21 Dia48 mm Inner Cap 4
1emarFmottoBtfeL22
23 Bottom Cross Frame 1
1emarFssorCpoT42
1eldnaHthgiR52
1eldnaHtfeL62
27 Dia30 mm Inner Cap 2
2kooH-J82
delbmessa-erP2redloH92
2mrAgnittopS03
delbmessa-erP2
2
daPrebbuRgiB13
23
delbmessa-erP
delbmessa-erP
delbmessa-erP
Pre-assembled
Olympic Spring Clip

Assembly Instructions
Page 7
Parts & Hardware List
Part# Description Qty Remark
delbmessa-erP601x6MtloBnellA1-6A
F6-1 Flat Head Bolt M6x10 6 Pre-assembled
201x8MteSwercS1-8S
P10-5 Positioning Bolt M10x35 6 Pre-assembled
H10-2 Hex Head Bolt M10x20 14
H10-14 Hex Head Bolt M10x80 12
H10-15 Hex Head Bolt M10x85 4
CH12-3 Cheese Head Bolt M12x25 2
21rehsaW01MgiB01WB
43rehsaW01M01W
61tuN01M01N
