DMP Electronics XR6 COMMAND PROCESSOR Operating instructions

PROGRAMMING GUIDE
XR6 COMMAND PROCESSOR™ PANEL and
XR10 COMMAND PROCESSOR™ PANEL

MODEL XR6/XR10
COMMAND PROCESSOR
PROGRAMMING GUIDE
FCC NOTICE
This equipment generates and uses radio frequency energy and, if not installed and used
properly in strict accordance with the manufacturer's instructions, may cause interference
with radio and television reception. It has been type tested and found to comply with the limits
for a Class B computing device in accordance with the specification in Subpart J of Part 15
of FCC Rules, which are designed to provide reasonable protection against such interference
in a residential installation. If this equipment does cause interference to radio or television
reception, which can be determined by turning the equipment off and on, the installer is
encouraged to try to correct the interference by one or more of the following measures:
Reorient the receiving antenna
Relocate the computer with respect to the receiver
Move the computer away from the receiver
Plug the computer into a different outlet so that computer and receiver are on
different branch circuits
If necessary, the installer should consult the dealer or an experienced radio/television
technician for additional suggestions. The installer may find the following booklet, prepared
by the Federal Communications Commission, helpful:
"How to identify and Resolve Radio-TV Interference Problems."
This booklet is available from the U.S. Government Printing Office, Washington D.C.
20402
Stock No. 004-000-00345-4
Copyright © 1995 - 2002 Digital Monitoring Products, Inc.
Information furnished by DMP is believed to be accurate and reliable.
This information is subject to change without notice.

iii
Digital Monitoring Products XR6/XR10 Programming Guide
TABLE OF CONTENTS PageSection
Introduction
1.1 Before You Begin............................................................. 1
1.2 Getting Started .............................................................. 1
1.3 Programming Menu .......................................................... 2
1.4 Programmer Lockout Codes............................................... 2
1.5 Reset Timeout ................................................................ 2
1.6 Special Keys ................................................................... 2
1.7 Entering Alpha Characters ................................................ 3
1.8 Entering Non-Alpha Characters .......................................... 3
1.9 Keypad Prompts Display Current Programming...................... 3
Initialization
2.1 INITIALIZATION ............................................................... 4
2.2 CLEAR ALL CODES ............................................................ 4
2.3 SET TO FACTORY DEFAULTS ................................................ 4
2.4 HOURS TILL TEST............................................................. 4
Communication
3.1 COMMUNICATION ............................................................. 5
3.2 COMMUNICATION TYPE ..................................................... 5
3.3 ACCOUNT NUMBER ........................................................... 5
3.4 TRANSMIT DELAY ............................................................. 5
3.5 DTMF ............................................................................ 5
3.6 DEFER RECALL TEST ......................................................... 5
3.7 TEST FREQUENCY ............................................................ 5
3.8 RECEIVER 1 PROGRAMMING................................................ 5
3.9 ALARM REPORTS .............................................................. 5
3.10 SUPERVISORY/TROUBLE REPORTS ....................................... 5
3.11 OPENING/CLOSING AND USER REPORTS ................................ 6
3.12 TEST REPORT .................................................................. 6
3.13 BACKUP REPORTING ......................................................... 6
3.14 FIRST TELEPHONE NUMBER ................................................ 6
3.15 SECOND TELEPHONE NUMBER ............................................. 6
3.16 RECEIVER 2 PROGRAMMING................................................ 6
3.17 PAGER REPORTING ........................................................... 6
3.17A ALARM REPORTS .............................................................. 6
3.17B TROUBLE REPORTS........................................................... 6
3.17C OPENING/CLOSING REPORTS .............................................. 6
3.18 TEST REPORT .................................................................. 6
3.19 BACKUP REPORTING ......................................................... 7
3.20 FIRST TELEPHONE NUMBER ................................................ 7
3.21 SECOND TELEPHONE NUMBER ............................................. 7
3.22 PAGER IDENTIFICATION NUMBER ......................................... 7
Remote Options
4.1 REMOTE OPTIONS ............................................................ 8
4.2 REMOTE KEY................................................................... 8
4.3 MANUFACTURER AUTHORIZATION ........................................ 8
4.4 ARMED RINGS ................................................................. 8
4.5 DISARMED RINGS ............................................................. 8
4.6 ALARM RECEIVER AUTHORIZATION....................................... 8
4.7 SERVICE RECEIVER AUTHORIZATION ..................................... 8
4.8 REMOTE DISARM .............................................................. 8

XR6/XR10 Programming Guide Digital Monitoring Products
iv
TABLE OF CONTENTS PageSection
System Reports
5.1 SYSTEM REPORTS ............................................................. 9
5.2 OPENING/CLOSING REPORTS .............................................. 9
5.3 ABORT REPORT ............................................................... 9
5.4 ZONE RESTORAL REPORTS ................................................. 9
5.5 BYPASS REPORTS ............................................................. 9
5.6 CODE CHANGE REPORTS.................................................... 9
5.7 AMBUSH ........................................................................ 9
System Options
6.1 SYSTEM OPTIONS ............................................................ 10
6.2 ALL/PERIMETER ............................................................. 10
6.3 CLOSING CODE ...............................................................10
6.4 ENTRY DELAY 1 .............................................................. 10
6.5 EXIT DELAY ...................................................................10
6.6 CROSS ZONE TIME ........................................................... 10
6.7 POWER FAIL DELAY.......................................................... 10
6.8 RESET SWINGER BYPASS ................................................... 10
Output Options
7.1 OUTPUT OPTIONS ...........................................................11
7.2 BELL CUTOFF TIME.......................................................... 11
7.3 AUTOMATIC BELL TEST.....................................................11
7.4 BELL ACTION ................................................................. 11
7.4A FIRE ZONES ................................................................... 11
7.4B BURGLARY ZONES ........................................................... 11
7.4C SUPERVISORY ZONES ....................................................... 11
7.4D PANIC ZONES .................................................................11
7.4E EMERGENCY ZONES .........................................................11
7.4F AUXILIARY 1 ZONES .........................................................11
7.4G AUXILIARY 2 ZONES .........................................................11
7.5 OUTPUT ACTION .............................................................12
7.5A CUTOFF OUTPUTS........................................................... 12
7.5B OUTPUT CUTOFF TIME .....................................................12
7.5C COMMUNICATION FAILURE OUTPUT ....................................12
7.5D FIRE ALARM OUTPUT .......................................................12
7.5E FIRE TROUBLE OUTPUT ....................................................12
7.5F AMBUSH OUTPUT............................................................12
7.5G ENTRY OUTPUT .............................................................. 12
7.5H EXIT OUTPUT ................................................................. 12
7.5I READY OUTPUT .............................................................. 12
7.5J ARMED OUTPUT..............................................................12
7.5K BURGLARY OUTPUT .........................................................12
7.5L GROUND START OUTPUT .................................................. 12

v
Digital Monitoring Products XR6/XR10 Programming Guide
TABLE OF CONTENTS PageSection
Zone Information
8.1 ZONE INFORMATION ........................................................ 13
8.2 ZONE NUMBER ...............................................................13
8.3 ZONE NAME ................................................................... 13
8.4 ZONE TYPE.................................................................... 13
8.5 AREA NAME ................................................................... 13
8.6 ARM AREAS.................................................................... 14
8.7 NEXT ZONE ...................................................................14
8.8 ALARM ACTION ............................................................... 14
8.9 DISARMED OPEN .............................................................14
8.9A MESSAGE TO TRANSMIT ....................................................15
8.9B OUTPUT NUMBER ...........................................................15
8.9C OUTPUT ACTION -...........................................................15
8.10 SWINGER BYPASS ............................................................15
8.11 ENTRY DELAY ................................................................. 16
8.12 CROSS ZONE .................................................................. 16
8.13 PRIORITY ......................................................................16
8.14 ZONE NUMBER ...............................................................16
Stop
9.1 STOP ............................................................................17
Set Lockout Code
10.1 SET LOCKOUT CODE ........................................................17
Appendix
11.1 Status List .................................................................... 18
11.2 False Alarm Reduction Features ........................................18
11.3 4-2 and CID reporting operation .......................................18
11.4 Zone Type Specifications .................................................19
11.5 Zone Type Descriptions ...................................................20
11.6 Manual telephone line seizure .......................................... 20
11.7 Default panel programming ............................................. 21
11.8 4-2 Communication Reports .............................................22
11.9 How to Read this Table ...................................................22
11.10 4-2 Examples ................................................................23
11.11 4-2 Communication Format Configuration ..........................23
11.12 Numeric Pager Message Formats ....................................... 23

This page left intentionally blank.

XR6/XR10 Programming Guide Digital Monitoring Products
1
1 - INTRODUCTION
1.1 Before You Begin
About this Guide
This guide provides programming information for the DMP XR6/XR10 Command Processor Panel. After this
Introduction, the remaining sections describe the functions of each programming menu item along with their
available options. Before starting to program, we recommend you read through the contents of this guide. The
information contained here allows you to quickly learn the programming options and operational capabilities of the
XR6/XR10 panel.
In addition to this guide, you should also read and be familiar with the following XR6/XR10 documents:
• XR6/XR10 User's Guide (LT-0226)
• XR6/XR10 Programming Sheet (LT-0212)
• XR6/XR10/XR20/XR40 Installation Guide (LT-0229)
Internal Programmer
The panel contains all of its programming information in an on-board processor and does not require an external
programmer. You can perform all programming tasks through a keypad connected to the system.
Programming Information Sheets
Included with each panel is a Programming Information Sheet. This lists the various keypad prompts and available
options for programming the panel. Before starting to program, we recommend you completely fill out the sheet
with the programming options you intend to enter into the panel.
Having a completed programming sheet available while entering data helps prevent errors and can shorten the time
you spend programming. A completed programming sheet also provides you with an accurate record of the panel's
program you can keep on file for future system service or expansion. The remainder of this Introduction tells you
how to start and end a programming session.
1.2 Getting Started
Ground Yourself Before Handling the Panel! Touch any grounded metal, such as the enclosure, before
touching the panel to discharge static.
Remove All Power From the Panel! Remove all AC and Battery power from the panel before installing
or connecting any modules, cards, or wires to the panel.
Before you begin programming, make sure the panel is properly grounded and AC and battery power is applied to the
appropriate panel terminals. All wiring connections and grounding instructions are detailed in the
XR6/XR10/XR20/XR40 Installation Guide (LT-0229).
Initializing the Panel
When programming a panel for the first time, or rewriting the entire program of an existing panel, use the
Initialization function described in section 2. Initializing clears the panel's memory of any old or incorrect data.
Accessing the Programmer
To access the programmer function of the XR6/XR10:
1. Place a slotted screwdriver across the two J16 reset jumpers for two seconds.
2. Remove the screwdriver.
3. Enter the code 6653 (PROG) into the keypad.
4. Enter your Access Code (if prompted to do so).
5. The keypad displays: PROGRAMMER.
You are now ready to start programming the panel. Pressing the COMMAND key scrolls you through the programming
menu items listed in section 1.3.

1 - INTRODUCTION
Digital Monitoring Products XR6/XR10 Programming Guide
2
1.3 Programming Menu
To select a section for programming, press any top row Select key when the name of that section is displayed on the
keypad. The detailed instructions for each programming step are found in the following sections. There are 9
programming menu items to choose from:
Menu Item Section Menu Item Section
Initialization 2 Output Options 7
Communication 3 Zone Information 8
Remote Options 4 Stop 9
System Reports 5 Set Lockout Code 10
System Options 6
1.4 Programmer Lockout Codes
Although the XR6/XR10 panel allows you to enter the built-in Programmer without a lockout code, we recommend
you install one to restrict programming access to only those persons your company authorizes. You can do this by
using the SET LOCKOUT CODE feature at the end of the Programmer menu.
Installing a lockout code
1. After entering the Programmer menu, the keypad displays PROGRAMMER. Press the COMMAND key to
advance through the programming sections until SET LOCKOUT CODE displays (after STOP).
2. Press any top row Select key. At the ENTER CODE: - display, enter a 1 to 5-digit programmer lockout
code. Press COMMAND.
3. The displays shows ENTER AGAIN. Enter the same lockout code again and press COMMAND. The display
shows CODE CHANGED. The new code number must now be entered before the Programmer menu can
be accessed.
Write the lockout code number down and keep it in a secure place with access limited to authorized persons.
Lost Lockout Code requires factory reset: If you lose or forget the lockout code, the panel must be sent back to
the factory to be reset. There is no field option for gaining access to the panel without a valid lockout code.
1.5 Reset Timeout
The XR6/XR10 has a feature that requires you to enter the Programmer within 30 minutes of resetting the panel.
After 30 minutes, if you attempt to program by entering the 6653 (PROG) code, the keypad displays: RESET PANEL.
You must reset the panel and enter the program code within 30 minutes.
If you are already in the Programmer and do not press any keys on the programming keypad for 30 minutes, the
panel terminates programming. All data entered up to that point is saved in the panel's memory.
Using the STOP function disarms all areas: To exit the panel's Programmer you must use the Stop function. The
STOP function is the second to the last option in programming. The Stop function disarms all areas and clears the
panel's Status List.
The programming session is then terminated and the keypads return to the Status List.
1.6 Special Keys
Pressing the COMMAND key allows you to go forward through the
programming menu and through each step of a programming section.
The COMMAND key is also used to enter information into the panel's
memory such as phone numbers or zone names. Press the COMMAND
key after you have entered the information.
Back Arrow Key
Use the Back Arrow key to back up one step while in the
programming menu or within a programming section. The Back Arrow
key also allows you to correct an error by erasing the last character
entered.
A B C D EF G H I J K L
VWX
MNO PQR STU
Y Z
COMMAND
90
1234
5678
JONES RESIDENCE
FRI 2:51 AM
POWER
ARMED
Figure 1: Keypad Function keys
Select Keys
COMMAND Key
Back Arrow Key

XR6/XR10 Programming Guide Digital Monitoring Products
3
1 - INTRODUCTION
Select Keys
The top row of keys are called the Select keys. When the Programmer displays an option for you to select, such as
YES or NO, you press the Select key under the option you want to enable.
The Select keys also allow you to change programming information currently in the panel's memory. As you step
through each program option, the keypad displays the current information. To change this information, press the
appropriate key under the display then enter the new information through the keypad.
If you are changing a phone number or account number, press the Select key followed by the appropriate digit keys.
If entering a communication type or choosing a programming option, the keypad displays the available response
options above the Select keys. When there are more than four response options available, the keypad displays the
first four. Pressing the COMMAND key brings up the next set of options on the display. Pressing the Back Arrow key
allows you to review the previous four choices.
The Select keys are also used for selecting a section from the programming menu. This is done by pressing any one of
the Select keys when the name of the programming section you want is displayed.
1.7 Entering Alpha Characters
Some options during programming require you to enter alpha
characters. To enter an alpha character, press the key that has
that letter written below it. The keypad displays the number
digit of the key. Next, press the Select key that corresponds to
the location of the letter under the key. Pressing a different
Select key changes the letter. When another digit key is pressed,
the last letter is retained and the process begins again.
1.8 Entering Non-Alpha Characters
To enter a space in an alpha entry, press the 9 digit key
followed by the third Select key. You can also enter the
following characters: – (dash), . (period), * (asterisk), and
# (pound sign) using the zero key and the four Select keys
from left to right. For example, to enter a – (dash), press
the zero key and then the left Select key. A dash now
appears in the keypad display.
Refer to the diagram to the right for a complete layout of
the digit keys, and the letters and characters each digit
key contains.
1.9 Keypad Displays Current Programming
Each programming prompt displayed at the keypad shows the currently selected option in the panel's memory. These
options are either shown as a number, a blank, or a NO or YES. To change a number or blank to a new number, press
any top row Select key. The current option is replaced with a dash. Press the number(s) on the keypad you want to
enter as the new number for that prompt.
It is not necessary to enter numbers with leading zeros. The XR6/XR10 automatically justifies the number when you
press the COMMAND key.
To change a programming prompt that requires a NO or YES response, press the top row Select key under the
response not selected.
For example, if the current prompt is YES and you want to change it to NO, press the third top row Select key from
the left. The display changes to NO. Press the COMMAND key to go to the next prompt. See Figure 4.
Figure 2: Keypad Display and Select keys
Left
Character
Special
Character
Center
Character
Right
Character
(
CBA
90
1234
5678
COMMAND
ABC (DEF )GHI !JKL ?
MNO /PQR &ST $VWX ,
YZ
(space) ' - . * #
Figure 3: Special Characters
BELL TST YES
Press the top row Select key.
BELL TST NO
The keypad display changes to the newly
selected option. Press COMMAND.
NEXT
Figure 4: Changing the current option selected.

2 - INITIALIZATION
Digital Monitoring Products XR6/XR10 Programming Guide
4
2.1 INITIALIZATION
This function allows you to set the panel's user codes and Programmer selections
back to factory defaults before programming the panel for the first time or a new
installation.
After you select YES to clear a section of memory, the panel asks if you are sure
you want to clear the memory. This is a safeguard against accidently erasing the
programming. No memory is cleared from the programming until you answer yes to
the SURE? YES NO prompt.
A description of each initialization options follows below:
2.2 CLEAR ALL CODES
YES clears the panel's user code memory and assigns the Master user code 99 to
user number 12.
2.3 SET TO FACTORY DEFAULTS
YES sets the panel's Programmer selections back to factory defaults and clears any
information stored in Display Events memory.
2.4 HOURS TILL TEST
Enter the number of hours from 0 to 23 the panel waits to send the Recall Test to
the receiver. Entering Zero (0) sends the first recall test report when the
programmer is exited.
Once you have finished programming the panel, reset the panel by shorting the J16
reset jumpers for two seconds. The Recall Test timer now begins and runs the
number of hours programmed in Hours Till Test. After the programmed hours have
elapsed, the Recall Test is sent to the receiver. Whatever time of day this happens
to be is the time that the Recall Test will always be sent according to the number
of days you selected in Test Frequency.
CODES? NO YES
SURE? YES NO
DEFAULTS? NO YES
SURE? YES NO
HRS TILL TEST 12
INITIALIZATION

XR6/XR10 Programming Guide Digital Monitoring Products
5
3 - COMMUNICATION
3.1 COMMUNICATION
This section allows you to configure the communication settings for the panel.
After choosing the Communication type, continue through the remaining options.
3.2 COMMUNICATION TYPE
Specifies the communication method the panel uses to contact the receiver. Press
any Select key to display the following communication options:
NONE - For local systems. Selecting this ends Communication programming.
DD - Digital Dialer communication to DMP SCS-1 or SCS-105 Receivers.
4-2 - 4-2 communication to non-DMP receivers.
CID - Contact ID communication to non-DMP receivers. This format sends the
report codes of the Ademco®Contact ID communication format.
3.3 ACCOUNT NUMBER
Enter the account number sent to the receiver.
DD - The range of account numbers for Digital Dialer is 1 to 65,535. For account
numbers of four digits or less, you do not have to enter leading zeros. The panel
automatically right justifies the account number.
4-2 - The range of account numbers using 4-2 communication is 1 to 9999.
CID - The range of account numbers using Contact ID communication is 1 to 9999.
3.4 TRANSMIT DELAY
Enter the length of time the panel waits before sending burglary alarm reports to
the receiver. The available range is 10 to 60 seconds in 10-second increments.
Alarm bells and relay outputs are not delayed during this period. Burglary Type
output must be programmed for Steady output.
If the area where the alarm occurred is disarmed during the Transmit Delay, only
an Abort Report is sent. Abort Reports must be set to YES.
Enter zero to disable Transmit Delay.
3.5 DTMF
YES enables tone dialing. NO enables rotary dialing.
3.6 DEFER RECALL TEST
Select YES to allow the programmed test report to be deferred if the panel
communicates with a receiver within the time set in Test Frequency. Select NO to
send the test report as programmed in Test Frequency, regardless of previous
panel communication.
3.7 TEST FREQUENCY
Allows you to set how often the panel's test report is sent to the receiver. Enter
from 1 to 60 days. Enter zero to disable the test report.
3.8 RECEIVER 1 PROGRAMMING
Allows you to set the reporting options for the first receiver the panel attempts to
contact when sending reports. The XR6/XR10 supports communication to two
receivers.
3.9 ALARM REPORTS
Select YES to enable Abort, Alarm, Alarm Restoral, Alarm Bell Silenced, Ambush,
Exit Error, and System Recently Armed reports to be sent to this receiver.
3.10 SUPERVISORY/TROUBLE REPORTS
Select YES to enable supervisory, trouble, trouble restoral, force armed, and zone
fault reports to be sent to this receiver.
ACCOUNT NO:123 45
XMIT DELAY: 0
DTMF NO YES
COMMUNICATION
COMM TYPE: NONE
NONE DD 4-2 CID
TEST FREQ: 0
DFR TEST NO YES
SPV/TRBL NO YES
ALARM NO YES
RECEIVER 1 PROG

3 - COMMUNICATION
Digital Monitoring Products XR6/XR10 Programming Guide
6
3.11 OPENING/CLOSING AND USER REPORTS
Select YES to enable opening/closing, door access, schedule and code changes,
bypass, and zone reset reports by user to be sent to this receiver.
3.12 TEST REPORT
Select YES to enable the Recall Test report to be sent to this receiver. Reports are
sent according to the programming in section 3.7 Test Frequency.
3.13 BACKUP REPORTING
YES enables this receiver to be a backup to the other receiver in the event the
other receiver cannot be contacted.
3.14 FIRST TELEPHONE NUMBER
This is the first number the panel dials when sending reports to this receiver. A
phone number can consist of 15 characters in length. You can program a three-
second pause in the dialing sequence by entering the letter P. You can program a
dial tone detect by entering the letter D. These characters are counted as part of
the 15 allowable characters.
3.15 SECOND TELEPHONE NUMBER
The panel dials the second number when two successive tries using the first
number have failed. If the panel cannot reach the receiver after two attempts
using the second number, it returns to the first number and makes two additional
attempts. A total of ten dialing attempts are made using the first and second
phone numbers. If a second phone number is not entered, the first phone number
is used for all dialing attempts.
Each number can be up to 15 characters in length including any P or D characters
entered for pause and dial tone detect.
3.16 RECEIVER 2 PROGRAMMING
Repeat steps 3.9 through 3.15 when communicating to a second receiver. Receiver
2 defaults are set to NO.
If you select YES for any of the Receiver 2 options, you must have at least one
phone number programmed in Receiver 2 programming.
3.17 PAGER REPORTING
YES allows the panel to send Alarm, Trouble, Opening, and Closing reports to a
numeric pager. The panel uses DTMF tones to generate the account and report
information sent over the pager terminal equipment.
Selecting NO allows you to use the Receiver 2 Programming to send panel reports
to a second central station receiver.
3.17A ALARM REPORTS
Select YES to enable Abort, Alarm, Alarm Restoral, Ambush, Exit Error, and System
Recently Armed reports to be sent to this receiver or pager.
3.17B TROUBLE REPORTS
Select YES to enable supervisory, trouble, trouble restoral, force armed, and zone
fault reports to be sent to this receiver or pager.
3.17C OPENING/CLOSING REPORTS
Select YES to enable opening/closing, door access, schedule and code changes,
bypass, and zone reset reports by user to be sent to this receiver or pager.
3.18 TEST REPORT
Select YES to enable the Recall Test report to be sent to this receiver or pager.
Reports are sent according to the programming in section 3.7 Test Frequency.
BACKUP NO YES
O/C USER NO YES
TEST RPT NO YES
–
FIRST PHONE NO.
SECOND PHONE NO.
–
RECEIVER 2 PROG
PAGER? NO YES
ALARM NO YES
SPV TRBL NO YES
O/C USER NO YES
TEST RPT NO YES

XR6/XR10 Programming Guide Digital Monitoring Products
7
3 - COMMUNICATION
3.19 BACKUP REPORTING
YES enables this receiver to be a backup to the other receiver in the event the
other receiver cannot be reached.
3.20 FIRST TELEPHONE NUMBER
This is the first number the panel dials when sending reports to this receiver. A
phone number can consist of 15 characters in length. You can program a 3-second
pause in the dialing sequence by entering the letter P. You can program a dial tone
detect by entering the letter D. These characters are counted as part of the 15
allowable characters.
3.21 SECOND TELEPHONE NUMBER
The panel dials the second number when two successive tries using the first
number have failed. If the panel cannot reach the receiver after two attempts
using the second number, it returns to the first number and makes two additional
attempts. A total of ten dialing attempts are made using the first and second
phone numbers. If a second phone number is not entered, the first phone number
is used for all dialing attempts.
Each number can be up to 15 characters in length including any P or D characters
entered for pause and dial tone detect.
3.22 PAGER IDENTIFICATION NUMBER
Enter a pager identification number if your pager uses one. If it does, the panel
waits for nine seconds after having dialed the First Phone Number before sending
the Pager ID. After the Page ID has been sent, the panel waits another three
seconds before sending the actual pager message containing the panel reports.
BACKUP NO YES
FIRST PHONE NO.
–
SECOND PHONE NO.
–
PAGER I D NUMBER

4 - REMOTE OPTIONS
Digital Monitoring Products XR6/XR10 Programming Guide
8
4.1 REMOTE OPTIONS
This section allows you to enter the information needed for Remote Command/
Remote Programming operation.
4.2 REMOTE KEY
Enter a code of up to 8 digits for use in verifying the authority of an alarm or
service receiver to perform a remote command/programming session. The
receiver must give the correct key to the panel before allowing access. All panels
are shipped from the factory with the Remote Key blank.
To enter a new Remote Key, press a top row Select key and enter any combination
of up to eight digits. Press COMMAND.
4.3 MANUFACTURER AUTHORIZATION
YES allows DMP support technicians to call the panel when required during
troubleshooting. This authorization automatically expires within one hour. DMP
remote service is read only: DMP technicians can view the system programming
and make suggestions only.
4.4 ARMED RINGS
Enter the number of rings (1 to 15) the panel counts within a two-minute period
before answering the phone line when all areas of the system are armed. If zero is
entered, the panel does not answer the phone when all areas of the system are
armed.
Answering machine bypass procedure: Entering a number greater than zero into either Armed Rings or Disarmed
Rings allows a central station operator to connect remotely with the panel. How it works: The operator calls the
panel, rings the phone once, then hangs up. The panel stores this attempt to communicate. The operator then calls
back within 30 seconds causing the panel to seize the phone line and allow remote programming. This feature does
not interfere with the normal operation of the Armed Rings/Disarmed Rings function.
4.5 DISARMED RINGS
Enter the number of rings, from 1 to 15, the panel counts before answering the
phone line while any areas of the system are disarmed. If zero is entered, the
panel does not answer the phone when any area of the system is disarmed.
4.6 ALARM RECEIVER AUTHORIZATION
Enter YES to enable remote commands and programming to be accepted from the
alarm SCS-1 Receiver. The Remote Key option can also be required. When YES is
selected, the panel requests the alarm receiver key during its first alarm
communication with the SCS-1 Receiver. The panel retains this alarm receiver key
in memory and allows remote commands to be accepted from the alarm SCS-1
Receiver. If an alarm occurs during a remote connect, the alarm report is
immediately sent to this receiver only.
NO prevents remote commands and programming from the alarm SCS-1 Receiver.
4.7 SERVICE RECEIVER AUTHORIZATION
YES enables remote commands and programming to be accepted from a service
receiver other than the alarm SCS-1 Receiver. The Remote Key option can also be
required.
When YES, the panel requests the service receiver key the first time it is
contacted by the service receiver. The panel retains this key in memory.
If an alarm occurs during a remote connect, the panel disconnects from the
service receiver and sends the report to the alarm SCS-1 Receiver. It is important
that the alarm receiver key and the service receiver key programmed at the
central station are NOT the same.
NO prevents remote commands and programming from a service receiver.
4.8 REMOTE DISARM
Enter YES to enable the panel to be disarmed remotely. Selecting NO disables
remote disarming.
SVC RCVR NO YES
MFG AUTH NO YES
DISARM RINGS: 0
ARMED RINGS: 0
ALR RCVR NO YES
RMT KEY:
DISARM NO YES
REMOTE OPTIONS

XR6/XR10 Programming Guide Digital Monitoring Products
9
5 - SYSTEM REPORTS
5.1 SYSTEM REPORTS
This section of the Programmer allows you to select the reports the panel sends to
the receiver.
5.2 OPENING/CLOSING REPORTS
YES allows the panel to send opening/closing reports by user to the receiver.
5.3 ABORT REPORT
YES allows the panel to send an alarm abort report to the receiver any time an
alarm report has also been sent and the Bell Cutoff time has not expired. See Bell
Cutoff section 7.2. The area must be disarmed and no alarmed zones can still be
armed. A Bell Silenced Report is also sent if the alarm bell is silenced with a valid
user code juring an alarm. When the system is disarming during an alarm, only
Abort and Opening Reports are sent.
5.4 ZONE RESTORAL REPORTS
This option allows you to specify whether the panel sends zone restoral reports
and also when they will be sent.
NO - Restoral reports are not sent by the panel.
YES - The panel always sends zone restoral reports at the time the zone restores
from an alarm or trouble condition.
DISARM - The panel sends zone restoral reports when a zone that has restored
from an alarm or trouble is disarmed. 24-hour zones send restorals immediately.
5.5 BYPASS REPORTS
YES allows the panel to send all zone bypass, reset, and force arm reports to the
receiver. The bypass report includes the zone number, zone name, and the user
number of the individual bypassing the zone.
5.6 CODE CHANGE REPORTS
YES allows the panel to send all code additions, changes, and deletions to the
receiver. The code change report includes the user number added or deleted and
the user number of the individual making the change.
5.7 AMBUSH
YES allows an ambush report to be sent anytime user code number one is entered
at a keypad. Selecting NO disables the ambush report and allows user code
number one to operate the same as all other codes.
SYSTEM REPORTS
RESTORAL: YES
NO YES DISARM
AMBUSH NO YES
BYPASS NO YES
OPN/CLOS NO YES
ABORT NO YES
CODE CHG NO YES

6 - SYSTEM OPTIONS
Digital Monitoring Products XR6/XR10 Programming Guide
10
6.1 SYSTEM OPTIONS
This section allows you to select system-wide functions of the XR6/XR10 system.
6.2 ALL/PERIMETER
YES configures the panel as a Perimeter (Area 1) and Interior (Area 2) system.
NO configures the panel for Home/Sleep/Away operation. In addition to the
Perimeter (Area 1) and Interior (Area 2) a third area, Bedrooms (Area 3) is
created. Zones must be assigned to Bedrooms for the area to be active.
6.3 CLOSING CODE
When YES is selected, a code number is required for system arming. If NO is
selected, a code number is not required for system arming.
6.4 ENTRY DELAY 1
Enter the Entry Delay time for all Exit type zones programmed to use Entry Delay
1. When an armed Exit type zone is faulted, the keypad prewarn tone begins
sounding and ENTER CODE: - displays on all keypads. If you are using Entry delay
2, enter the desired time.
The area must be disarmed before the Entry Delay time expires or an alarm will
occur on the entry zone. All Burglary type zones in all areas are delayed along
with the Exit zone during the Entry Delay. Entry delay times can be from 1 to 250
seconds in one second increments.
6.5 EXIT DELAY
Enter the Exit Delay time for all Exit type zones. When the system is armed, this
Exit Delay time starts and all activity on Exit and Burglary zones is ignored until
the Exit Delay expires. This delay countdown is displayed on the keypad for the
user.
If an Exit type zone is in a bad condition at the end of the Exit Delay:
• the alarm bell sounds for two seconds
• an Exit Error report is sent to the alarm receiver
• the bad Exit type zone is force armed
If any other zone is in a bad condition at the end of the Exit Delay, an alarm on
that zone is indicated. The Exit Delay time can be from 1 to 250 seconds in one
second increments.
Enter zero to disable the Exit Delay feature.
6.6 CROSS ZONE TIME
Enter the time allowed between zone faults. When a zone programmed for cross
zoning faults, the panel begins counting down the Cross Zone Time you enter here.
If the same zone or another zone faults within this time, an alarm report is sent to
the receiver.
If the Cross Zone Time expires without the second zone fault, only a zone fault
report from the first zone is sent to the receiver. The Cross Zone Time can be from
4 to 250 seconds in one-second increments.
Enter zero to disable the Cross Zone Time feature.
6.7 POWER FAIL DELAY
This option allows you to delay the reporting of an AC power failure. When the AC
power is off for the length of the programmed delay time, an AC power failure
report is sent to the receiver. The delay time can be from 1 to 9 hours. Entering a
zero sends the AC power failure report within 15 seconds.
6.8 RESET SWINGER BYPASS
When YES is selected, a swinger bypassed zone is reset if it remains in a normal
condition for one hour after being bypassed. A report of the automatic reset is
sent to the receiver if Bypass Reports has been selected as YES. See section 5.5.
ALL/PRM NO YES
ENTRY DLY 1: 30
ENTRY DLY 2: 60
EXIT DELAY: 45
PWR FAIL HRS: 1
CRS ZONE TM: 0
RST SBYP NO YES
SYSTEM OPTIONS
CLS CODE NO YES

XR6/XR10 Programming Guide Digital Monitoring Products
11
7 - OUTPUT OPTIONS
7.1 OUTPUT OPTIONS
This function allows you to program the panel's Bell Output functions and certain
Output options. Switched Ground (open collector) outputs are available from the
XR6/XR10 when using a 4-wire output harness (Model 300 Harness). Refer to the
XR6/XR10/XR20/XR40 Installation Guide (LT-0229) for complete information.
A description of each output option follows:
7.2 BELL CUTOFF TIME
Enter the maximum time the Bell Output remains on. If the Bell Output is
manually silenced or the system is disarmed, the cutoff time is reset. The Bell
Cutoff Time can be from 1 to 15 minutes in one minute increments.
Enter zero to provide a continuous bell output.
7.3 AUTOMATIC BELL TEST
When YES is selected, the Bell Output is turned on for two seconds when all areas
in the system are armed. In addition, the Closing Wait feature is activated if
Opening/Closing Reports is YES. See section 5.2 Opening/Closing Reports. The
Bell Test only occurs when the areas are armed from a keypad. Arming performed
from an arming zone or remotely from Remote Link™ or Remote AccessTM does not
activate the Bell Test.
Closing Wait operation
Closing Wait provides a delay time before a monitored system arms until the panel receives an acknowledgment of
the closing report from the central station receiver. During the delay, the keypad displays DIALING . . .. Once the
closing is acknowledged, the keypad buzzer and the Bell Output sound for two seconds and the keypad displays the
system armed message.
If the closing report is not acknowledged, the keypad buzzer sounds and Bell Output does NOT sound, the keypad
displays LOCAL ALARM ONLY, and the system arms locally.
7.4 BELL ACTION
This option defines the type of Bell Output for zone alarms. (Trouble conditions do
not activate the Bell Output.) There are seven zone types you can program for Bell
Output.
For a steady Bell Output, enter S. For a pulsed output, enter P. For a Temporal
Code 3 output enter T. For no Bell Output, enter N. Program the bell action for
each zone type below:
7.4A FIRE ZONES
Defines Bell Action for Fire Type Zones.
7.4B BURGLARY ZONES
Defines Bell Action for Burglary Type zones. If you select N, Exit Error alarms are
not indicated locally but Exit Error reports are still sent to the receiver. See
Appendix section 11.2 False Alarm Reduction Features.
7.4C SUPERVISORY ZONES
Defines Bell Action for Supervisory Type Zones
7.4D PANIC ZONES
Defines Bell Action for Panic Type Zones
7.4E EMERGENCY ZONES
Defines Bell Action for Emergency Type Zones
7.4F AUXILIARY 1 ZONES
Defines Bell Action for Auxiliary 1 Type Zones
7.4G AUXILIARY 2 ZONES
Defines Bell Action for Auxiliary 2 Type Zones
OUTPUT OPTIONS
BELL CUTOFF: 15
BELL TEST NO YES
FIRE TYPE: P
BURGLARY TYPE: S
SUPRVSRY TYPE: N
PANIC TYPE: N
EMERGNCY TYPE: N
AUXLRY I TYPE: N
AUXLRY 2 TYPE: N
BELL ACTION . . . . .

7 - OUTPUT OPTIONS
Digital Monitoring Products XR6/XR10 Programming Guide
12
7.5 OUTPUT ACTION
This option allows you to define the operation of the panel's four annunciator
outputs.
7.5A CUTOFF OUTPUTS
Any or all of the available outputs can be programmed here to turn off after the
time specified in OUTPUT CUTOFF TIME. See section 7.5B. To disable this option,
press any Select key to clear the display of output numbers and then press
COMMAND.
7.5B OUTPUT CUTOFF TIME
If a Cutoff Output is assigned in section 7.5A, you can enter a Cutoff Time of up
to 15 minutes for the output to remain on. If the output is turned off manually,
the cutoff time is reset. The Cutoff Time can be from 1 to 15 minutes. Enter zero
to provide continuous output.
The Cutoff Timer is shared by all outputs. If a second output trips, the timer is not
reset. Both outputs turn off when the original time expires.
7.5C COMMUNICATION FAILURE OUTPUT
This output is turned on when a DD, 4-2, or CID system fails to communicate with
the receiver after three successive dial attempts. Enter zero to disable.
7.5D FIRE ALARM OUTPUT
This output is turned on any time a fire type zone is placed in alarm. The output is
turned off using the Sensor Reset option while no additional fire type zones are in
alarm. Enter zero to disable this output.
7.5E FIRE TROUBLE OUTPUT
This output is turned on any time a fire type zone is placed in trouble or when a
supervisory type zone is placed in alarm or trouble. The output is turned off when
all fire and supervisory troubles are restored to normal. The output is turned off
when a Sensor Reset is performed after a supervisory alarm. Enter zero to disable
this output.
7.5F AMBUSH OUTPUT
This output is turned on any time an Ambush code is entered at a keypad. The
output is turned off using the Sensor Reset option. Enter zero to disable.
7.5G ENTRY OUTPUT
This output is turned on at the start of the entry delay time. The output is turned
off when the area is disarmed or the entry delay time expires. Enter zero to
disable this output.
7.5H EXIT OUTPUT
This output is turned on any time an exit delay time starts and is turned off when
the system arms or when the arming has been stopped. Enter zero to disable.
7.5I READY OUTPUT
This output is turned on whenever all disarmed zones are in a normal state. The
output is turned off when any disarmed zone is in a bad state. Enter zero to
disable this output.
7.5J ARMED OUTPUT
This output is turned on any time an area of the system is armed. The output is
turned off when the system is completely disarmed.
7.5K BURGLARY OUTPUT
This output turns on any time a burglary zone is in alarm. The output is turned off
when the area in which the alarm occurred is disarmed and no other burglary
zones are in alarm.
7.5L GROUND START OUTPUT
This output turns on for 750ms any time the panel seizes the telephone line. Enter
zero to disable this output.
BURGLARY OUT: 0
ARMED OUT: 0
READY OUT: 0
EXIT OUT: 0
ENTRY OUT: 0
AMBUSH OUT: 0
FIRE TRB OUT: 0
FIRE ALR OUT: 0
COM FAIL OUT: 0
CUTOFF TIME: 0
CO OUTS: - - - -
OUTPUT ACTION . . .
GROUND START: 0

XR6/XR10 Programming Guide Digital Monitoring Products
13
8 - ZONE INFORMATION
8.1 ZONE INFORMATION
This allows you to define the operation of each protection zone used in the
system.
A description of each programming option follows.
8.2 ZONE NUMBER
Enter the number of the zone you intend to program. Press COMMAND to enter a
zone name. For instructions on entering alphanumeric characters, see section 1.7.
8.3 ZONE NAME
Press the Select key and enter up to 10 characters for the zone name. A name must
be given to each zone in the system. This name can be displayed at the keypads
when the zone is bad or viewed in Display Events. The zone name is also sent to
the receiver as part of a zone event report.
A zone that is not part of the system must be marked *UNUSED*. To mark a zone
unused, delete the old name by pressing a top row Select key, then press the
COMMAND key. The programmer automatically programs the name as * UNUSED *.
If you selected DEFAULTS? NO YES to clear the panel's memory during
Initialization, the zones will already be marked * UNUSED *. See section 2.3 Set to
Factory Defaults.
8.4 ZONE TYPE
The Zone Type defines the panel's response to the zone being opened or shorted.
See the chart in section 11.4 Zone Type Specifications.
When you assign a Zone Type to a zone, responses are made automatically for the
zone. There are 11 Zone Types to choose from including Blank. The functional
details of each response are described in section 11.4 Zone Type Specifications.
To enter a new Zone Type, press a top row Select key. The display lists the four
Zone Types shown below.
Blank, Night, Day, or Exit. Press COMMAND to display additional zone types.
Fire, Panic, Emergency, or Supervisory. Press COMMAND to display additional zone
types.
Auxiliary 1, Auxiliary 2, Fire Verify, or Arming. Press the Back Arrow key to display
the previous zone types.
When the Zone Type you want to select is displayed, press the Select key beneath
its name. The chart in section 11.4 Zone Type Specifications gives an outline of
the Alarm Action for each Zone Type.
If you select Blank, Night, Day, Exit, Auxiliary 1, or Auxiliary 2 as the Zone Type,
the zone must be assigned to an area.
If you select Fire, Panic, Emergency, or Supervisory as the Zone Type, these are 24-
hour zones that are always armed and no area assignment is needed.
Press COMMAND to continue.
Refer to the Appendix section in this guide for zone type descriptions.
8.5 AREA NAME
Press a Select key to assign this zone to one of the following areas: INTERIOR,
BEDROOMS, or PERIMETER.
INT (Interior) - Assigns the zone to area 2, Interior.
BDRM (Bedroom)- Assigns the zone to area 3, Bedrooms. This option is only
displayed in Home/Away systems.
PERIM (Perimeter) - Assigns the zone to area 1, Perimeter.
NAME: * UNUSED *
ZONE TYPE: BLANK
ZONE INFORMATION
INT BDRM PERIM
AREA : PERIMETER
ZONE NO: –
A1 A2 FV AR
F I PN EM SV
– – NT DY EX

8 - ZONE INFORMATION
Digital Monitoring Products XR6/XR10 Programming Guide
14
8.6 ARM AREAS
This option specifies the areas to be armed by the Arming Type Zone. When
disarmed, all areas in the system are disarmed.
PERIMETER/ALL - Specify whether the arming zone arms just the Perimeter
(PERIM) or the Perimeter and Interior areas (ALL) for All/Perimeter systems.
HOME/SLEEP/AWAY - Specify whether the arming zone arms the Perimeter
(HOME), the Perimeter and Interior (SLEEP), or all three areas (AWAY).
Arming zone operation
If a bad (faulted) Priority zone is in the area being armed by an Arming zone, the arming is stopped. If there are no
Priority zones, or they are all in a normal condition, the following applies:
If a non-Priority zone is in a bad condition when an area is armed with a keyswitch on an Arming zone, the arming is
delayed for five seconds. If, during the five-second delay, the keyswitch is turned to disarm, the arming is stopped. If
the keyswitch is held in the arming position for the full five seconds, the bad zone is force armed and the area
armed.
Momentary keyswitch operation
When the Arming zone changes from normal to short, any armed areas are disarmed. If all areas are disarmed when
the Arming zone is shorted, the panel arms all areas. When the Arming zone changes from normal to open while any
areas are armed, an alarm is indicated and the areas must be disarmed from a keypad. If all areas are disarmed, only
a trouble is indicated.
8.7 NEXT ZONE
When YES is selected, the programming for the zone terminates and the display
returns to ZONE NO: - allowing you to enter a new zone number. To make changes
to the Alarm Action for a zone, answer the NEXT ZONE? prompt with NO. The
Alarm Action is then defined in sections 8.8 through 8.13.
8.8 ALARM ACTION
The Alarm Action section allows you to change or confirm the default alarm
characteristics of a zone type that was selected in section 8.4 Zone Type.
If you selected the non-24-hour zone type—Blank, Night, Day, Exit, Auxiliary 1, or
Auxiliary 2— the Alarm Action programing begins with Disarmed Open.
If you selected the 24-hour zone type—Fire, Panic, Emergency, or Supervisory—the
Alarm Action programming begins with Armed Open.
The Fire Verify zone type functions the same as Fire Type, with the following
exceptions: When a Fire Verify zone is placed into shorted condition, the panel
performs a Sensor Reset and does not send a report. If any Fire Verify or Fire zone
initiates an alarm within 120 seconds after the reset, an alarm is indicated. If an
alarm is initiated after 120 seconds, the cycle is repeated. If no other Fire Verify
or Fire zone is alarmed within 120 seconds, a zone fault report is sent to the
receiver.
8.9 DISARMED OPEN
Defines the action taken by the panel when the zone is opened while the area is
disarmed. There are three actions to define:
Message to Transmit Output Number Output Action
See sections 8.9A to 8.9C. You must also make these selections for the Disarmed
Short, Armed Open, and Armed Short zone conditions.
Press the COMMAND key to continue.
NEXT ZN? NO YES
ALARM ACTION . . . .
DISARMED OPEN
PERIM ALL
HOME SLEEP AWAY
ARM AREAS:
