Dnake 280SD-C12 User manual

Model: 280SD-C12
280SD-R2
280SD-R5
Quick Start Quide
Door Station
The picture is only a schematic diagram. The actual product shall prevail.
USER MANUAL

Please follow the user manual for correct installation and
testing. If there is any doubt please call our tech-supporting
and customer center.
Our company applies ourselves to reformation and
innovation of our products. No extra notice for any change.
The illustration shown here is only for reference. If there is
any difference, please take the actual product as the
standard.
The product and batteries must be handled separately from
household waste. When the product reaches the end of
service life and needs to be discarded, please contact the
local administrative department and put it in the designated
collection points in order to avoid the damage to the
environment and human health caused by any disposal. We
encourage recycling and reusing the material resources.
REMARK

CATALOG
Technical Parameters...............................................1
Package Contents ....................................................1
Basic Function..........................................................2
Pictures.....................................................................2
Basic Operations......................................................3
Web Settings ............................................................4
System Configuration ............................................11
System Diagram.....................................................12
Installation..............................................................14
Troubleshooting .....................................................16
Safety Instructions .................................................17

TECHNICAL PARAMETERS
1
PACKAGE CONTENTS
◇Working voltage: DC12V
◇Rated power: 3W
◇Standby power: 1.5W
◇Camera resolution: 1280x720
◇Working temperature -40～+55℃:
◇Storage temperature: -40~+70℃
◇Working humidity: 10%-90% (non-condensing)
MODEL: 280SD-C12(Flush Mounting)
Quick Start Guide
Door Station Screw Screw Wrench
Quick Start Guide
Door Station
MODEL: 280SD-C12(Surface Mounting)
Screw

Package Contents
Please make sure the package contains the following items:
2
PICTURES
Card reader area
LED light
Microphone
Camera
Call button
Speaker
BASIC FUNCTION
◇Call indoor monitor by one button;
◇Support unlocking by IC access control card or password;
◇IC card information can be registered on door station. Registration
information of max. 100,000 IC cards can be stored；
◇Support unlocking by Exit button and door magnetic detection；
◇Support LED light for night vision；
◇Support PoE power supply.

BASIC OPERATIONS
1. Call indoor monitor
In standby mode, press the call button on door station to call indoor
monitor. During the call, press the call button on door station again to end
the call. If the call fails or indoor monitor is busy, door station will emit a
beep.
2. Unlocking by card
Put the registered IC card on card reader area of the door station. If IC card
has been authorized, after unlocking the door by card, the system will issue
a voice message that "the door has been opened", otherwise it will emit a
beep.
3

WEB SETTINGS
4
Connect door station to PC through the switch. Input IP address of door
station in the web browser of PC (The IP addresses of PC and door station
must be in the same network segment. Default IP address is
192.168.68.90), then input user name and password (default user name is
"admin" and the password is "123456") to enter into the following
interface:
1.Network Settings
Click the icon "Network" on the left side to enter the interface as shown
below:

DHCP: dynamic IP function.
IP address: for the same system on the same network segment, IP
address can not be repeated.
Subnet mask: the original subnet mask is 255.255.255.0, which normally
doesn't need to be changed.
Default gateway: according to the project site IP network allocation
DNS: it refers to IP address of the DNS server
Server IP: IP address of digital management software installed in the
management center computer
Access password: IP access password for management software
Normally, management center, indoor monitor and door station are in the
same LAN for communication; if they are not in the same LAN, the call can
be realized on the internet; in this case, SIP server needs to be set.
After the setup is completed, click the icon “Submit" to enable the
settings.
2.Device Settings
Building No. and Unit No. are the ones where door station is located.
The No. can be set from 1 to 9. Device No. is mainly used for distinguishing
the door station when it is watched by indoor monitor.
Password refers to the one used in your login to the webpage for outdoor
panel settings (default password is 123456).
door station Mode: Person One-button Door Station
Language selection: only support simplified Chinese and English.
5

6
3.Access Settings
System volume: adjust the system volume with 6 levels for selection.
Video size: 320x240, 640x480 or 1280x720.
Call forwarding: the call can be made one by one or simultaneously.
After the setup is completed, click the icon "Submit" to enable the
Click the icon "Access" on the left side to enter the interface as shown
below:
Unlock Timeout is used for controlling the unlocking time ranging from 1
to 9s.
Unlock Delay refers to the delayed time of opening the door ranging from
0 to 9s.
Elev refer is used for setting the floor of door station, ranging from 01~99.
(It is effective when door station is set as unit door station).
Card registration
The Admin Card is used for registering user card. There are two ways to
register the admin card:
1. The user enters card No. of the admin card in the box after "Admin Card"
and then click the button "Submit". In this case, the admin card is
registered successfully.
2. If the user isn't aware of admin card No., please enter 0 in the box first
and click the button "Submit". Then place the admin card close to the card
reader area. When the system gives an indication tone, it means that the
admin card is registered successfully.

7
Then register the user card. The user should swipe the admin card first.
The system emits a beep. Then place the card to be registered near the
card reader area within 10 seconds. When the system gives an indication
tone, it means that the user card is registered successfully. When
registering the user card, the card to be registered should be swiped 10
seconds after the admin card is swiped. Once a user card is registered, the
registration time will postpone for 10 seconds. When there is no activity
for 10 seconds, the system will exit from registration status automatically.
To register a new user card, the user should swipe the admin card again.
4.SIP Settings
Click the icon "VOIP" on the left side to enter into the following
Proxy: URL of SIP proxy server in format: sip:ip or sip:domain name.
Realm: realm of the device, usually the same as IP or domain name.
User name: refer to the name of the SIP proxy server, provided by the SIP
proxy server administrator.
Password: the password to access the SIP proxy server, provided by the
SIP proxy server administrator.
STUN IP and Port refer to the IP and port of public server for NAT traversal
of audio and video.
Once this is set up, click the button "Submit" to enable new settings.
