DoCash BIG D User manual

Universal Currency Detector
Детектор подлинности банкнот
DoCash BIG D
User Manual
Руководство по эксплуатации
РУССКИЙ
ENGLISH
LED

2

CONTENTS
Safety precautions 4
Purpose of a detector 5
Declaration of Conformity 5
Specifications 6
Design of device 7
Exterior 7
Control keys 8
Connectors on the back panel 8
Types of control provided by DoCash BIG D
9
Operational procedure 11
Main mode 11
Advanced detection modes 12
Visualization of optical marks 13
Adjusting of operational parameters 13
Warranty 14
Transportation and storage 15
Complete Set 15
This User Guide contains block with Warranty Service Coupon and
warranty terms.
Keep this User Guide at least for the duration of Detector’s warranty
terms.
3
www.docash.de

Safety Precautions
ATTENTION
Please read this manual carefully before you start to operate the detector
When operating with DoCash BIG D detector following safety precau-
tions should be observed:
 All installation works and any service and maintenance works should
be carried out only after disconnecting the device from the electric outlet
(this work can be performed only by Service Center employees).
 If the counter has been transported and stored under low temperature
conditions, it is required to maintain the counter at least two hours under
indoor temperature before switching it on.
 To avoid break-off or damage of the cable, it is required to hold on the
power supply plug while putting it on and out from the outlet. Also avoid
such actions when your hands are wet - it may cause in electric shock.
 Connect optional detectors only when DoCash BIG D is turned off.
 Don’t try to knock down or repair DoCash BIG D by yourself.
 Place DoCash BIG D only on steady surface in order to avoid fall and
damage of the equipment.
4

Thank You for choosing DoCash equipment.
DoCash®is a wide range of special cash handling equipment for retail
trade and financial organizations. DoCash is a brand for simple and reli-
able banknote and coin counters, universal and automatic currency de-
tectors, vacuum packaging machines, etc. You will find any further in-
formation at www.docash.de.
Purpose of the currency detector
DoCash BIG D detector has been designed for visualization of the
presence and location of UR, UV marks on banknotes and securities of
any type on the banknotes (Russian Rubles, Euro, US dollars etc.), doc-
umentary stamps, credit cards, stocks and shares, passports, certificates
and other capital issues and documents with security features.
Use of the Detector allows to increase identity rate of conclusions made
with regard to authenticity of examined specimen. Final conclusions
about identity rate are made by human, exploiting the detector with the
help of his own knowledge about security features of banknotes and
documents.
Declaration of Conformity
The Detector conforms to the following safety requirements:
TR TS 004/2011 «Low-voltage equipment safety»;
TR TS 020/2011 «Electromagnetic compatibility of technical means».
This Manual reflects relevant information at the time of publication and
may not include later alterations.
5
www.docash.de

Specification
6
Power supply, V/Hz 220/50
Display, inch/cm LCD 7/17, 8
Equivalent power of UV LEDs, W 18
UV emittance spectrum, nm 360-380
IR emittance spectrum, nm 800/1000
Total upper white light intensity, cd ≤36
Total bottom white light intensity, cd
Total oblique white light intensity, cd
≤144
≤144
Temperature operating range, °СFrom + 5 to + 35
Remote accessories connection Standard connectors
Overall dimensions, (WхDхL) mm 265х160х260
Net weight, kg 1,5
Power consumption, W ≤18
IR laser wavelength, nm (anti-Stokes) 980

Design of device
Exterior
1Detector’s body
37” LCD display to show image
4Control keys
5Operational area
6 Anti-stokes phosphor’s inspection area
2 Slot for А4 documents
7 Video Loupe’s magnification area
9 Magnetic marks presence sensor
8 Autostart sensor
7www.docash.de
3
4
1
5
6
2
7
8 9
LED

Control keys
Connectors on the back panel
Several connectors are located on the back panel of the device; they are
used for connection of power, remote DoCash detectors
8
1 Brightness and contrast, intensity (when in
Video Loupe mode)
Automatic switch off time, magnetic sensor on/
off.
2 Anti-stokes.
3 Backlight: Upper, Oblique.
4
Backlight: IR, IR+UV, Bottom.
5 Cameras IR х1, macro х10, macro х20.
6 Special element M.
7
On/Off Switch
1 2 3 4
1, 2 DoCash L and DoCash M connector s
3 DoCash VL connector
4 Video output

Types of control provided by
DoCash BIG D
Universal detectors DoCash BIG D ensure the following types of control:
 Visualization of infra red marks in all modes of detection (except
for Macro Camera Mode).
 Visualization of special element «M»
 Control of the compatibility of code pictures and marks of the front
and back sides
 Control of the general luminescence and individual fragments
 Control of watermarks, fibers, strips and protective threads
 Control of printing security
 Size control
 Control of anti-stokes phosphor
 Control of magnetic marks presence
Connection of remote detectors
DoCash expands opportunities of de-
tec-tor DoCash BIG D as allows to carry
out additional kinds of the control of
authenticity of studied objects.
.
9
www.docash.de
LED

DoCash L
With the help of DoCash L You can view of
the image through 10x magnifier in visible
range, with the possibility of backlighting.
DoCash L allows to study the specific fea-
tures of printing, view the elements of micro-
print and detect the attempts for changing
through expunction, gluing, etc.
DoCash М
DoCash Мis an optional accessory which
duplicates DoCash Big D built-in function. It
controls presence and location of magnetic
marks on the banknote (document).
DoCash Мallows to trace security marks,
inscriptions and images made by ferromag-
netic paint (magnetic marks) on examined
banknote (document) with light or sound sig-
nals.
DoCash VL
Video magnifier DoCash VL also duplicates Do-
Cash Big D built-in function. With this accessory
you are able to view of the 20x zoom image
through the display in visible range, IR and UV
spectrums. Please press button to switch on the
video magnifier. The sequential pressing of button
on the video magnifier lets switches the highlight
mode. DoCash VL allows to observe the specific
features of printing, view the elements of micro-
print and detect the attempts for changing through
expunction, gluing, etc.
To turn off video magnifier must be chosen re-
quired mode by keypad.
Attention! When you activate the video magni-
fier, auto-switch off of detector is not active.
For details of security features of genuine banknotes see “Security features of bank-
notes» brochures for EUR, USD, RUB. Or please see other special reference books for
other currencies.
10
