Dometic FJ 1700 User manual

FJ 1700, FJ 2000, FJ 2200, FJ 3200
Air conditioning roof unit
Installation Manual. . . . . . . . . . . . . . . . . . . . . 3
Dachklimaanlage
Montageanleitung. . . . . . . . . . . . . . . . . . . . 19
Climatiseur de toit
Instructions de montage . . . . . . . . . . . . . . .36
Aire acondicionado de techo
Instrucciones de montaje . . . . . . . . . . . . . .52
Ar condicionado para tejadilho
Instruções de montagem . . . . . . . . . . . . . .69
Climatizzatore a tetto
Indicazioni di montaggio . . . . . . . . . . . . . .86
Airconditioning voor dakinbouw
Montagehandleiding . . . . . . . . . . . . . . . .103
Klimaanlæg til tagmontering
Monteringsvejledning. . . . . . . . . . . . . . . . 119
Takmonterad klimatanläggning
Monteringsanvisning. . . . . . . . . . . . . . . . .135
Takmontert klimaanlegg
Monteringsanvisning. . . . . . . . . . . . . . . . .150
Kattooilmastointilaitteisto
Asennusohje . . . . . . . . . . . . . . . . . . . . . . .165
Накрышный кондиционер
Инструкция по монтажу . . . . . . . . . . . . . . 181
Klimatyzator dachowy
Instrukcja montażu . . . . . . . . . . . . . . . . . . 198
Strešné klimatizačné zariadenie
Návod na montáž . . . . . . . . . . . . . . . . . . . 214
Střešní klimatizace
Návod k montáži . . . . . . . . . . . . . . . . . . . . 230
Tetőklím a-beren dezés
Szerelési útmutató . . . . . . . . . . . . . . . . . . 245
Krovna klimatizacijska jedinica
Upute za montažu. . . . . . . . . . . . . . . . . . . 261
Klima tavan ünitesi
Montaj Kılavuzu. . . . . . . . . . . . . . . . . . . . . 276
Strešna enota klimatske naprave
Navodilo za montažo . . . . . . . . . . . . . . . . 291
Unitate de aer condiţionat pentru
acoperiş
Instrucţiuni de montaj. . . . . . . . . . . . . . . . 306
Покривен модул на климатичната
инсталация
Инструкция за монтаж . . . . . . . . . . . . . . . 323
Kliimaseade katusele
Paigaldusjuhend . . . . . . . . . . . . . . . . . . . . 340
Μονάδα κλιματισμού οροφής
Οδηγίες τοποθέτησης. . . . . . . . . . . . . . 356
Stogo oro kondicionavimo blokas
Montavimo vadovas . . . . . . . . . . . . . . . . . 375
Gaisa kondicionēšanas jumta
iekārta
Uzstādīšanas rokasgrāmata . . . . . . . . . . . 391
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
RU
PL
SK
CS
HU
HR
TR
SL
RO
BG
ET
EL
LT
LV
AIR CONDITIONERS
FRESHJET

© 2022 Dometic Group. The visual appearance of the contents of this manual is
protected by copyright and design law. The underlying technical design and the
products contained herein may be protected by design, patent or be patent
pending. The trademarks mentioned in this manual belong to Dometic Sweden AB.
All rights are reserved.

EN
FJ 1700, FJ 2000, FJ 2200, FJ 3200 Explanation of symbols
3
Original instructions
Please read these instructions carefully and follow all instructions, guidelines, and warnings included in this product manual in order to ensure
that you install, use, and maintain the product properly at all times. These instructions MUST stay with this product.
By using the product, you hereby confirm that you have read all instructions, guidelines, and warnings carefully and thatyou understand and
agree to abide by the terms and conditions as set forth herein. You agree to use this product only for the intended purpose and application
and in accordance with the instructions, guidelines, and warnings as set forth in this product manual as well as in accordance with all appli-
cable laws and regulations. A failure to read and follow the instructions and warnings set forth herein may result in an injury to yourself and
others, damage to your product or damage to other property in the vicinity. This product manual, including the instructions, guidelines, and
warnings, and related documentation, may be subject to changes and updates. For up-to-date product information, please visit
documents.dometic.com.
Table of contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2 Safety and installation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3 Target group for this instruction manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
4 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
5 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
6 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
7 Labels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
8 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
1 Explanation of symbols
!
!
A
WARNING!
Safety instruction: Indicates a hazardous situation that, if not avoided,
could result in death or serious injury.
CAUTION!
Safety instruction: Indicates a hazardous situation that, if not avoided,
could result in minor or moderate injury.
NOTICE!
Indicates a situation that, if not avoided, can result in property damage.

EN
Safety and installation instructions FJ 1700, FJ 2000, FJ 2200, FJ 3200
4
I
2 Safety and installation instructions
Pleaseobservetheprescribedsafetyinstructions and stipulations fromthe
vehicle manufacturer and service workshops.
2.1 Handling the device
!WARNING! Failure to obey these warnings could result in death
or serious injury.
Electrocution hazard
• Do not operate the device if it is visibly damaged.
• Always disconnect the power supply when working on the device.
• Operate the device only if you are certain that the housing and the
cables are undamaged.
Health hazard
• This device can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or
instruction concerning use of the device in a safe way and understand
the hazards involved.
• Children shall not play with the device.
• Installation, maintenance and repairs of the roof air conditioner may
only be carried out by qualified personnel who are familiar with the
risks involved when handling refrigerant and air conditioning systems
as well as the relevant regulations. Inadequate repairs may cause seri-
ous hazards. For repair service, please contact the service centre in
your country.
Fire hazard / Flammable materials
• Keep the ventilation openings free of obstructions.
• Do not damage the refrigerant circuit.
• Do not use the roof air conditioner near flammable fluids or in closed
rooms.
• Make sure no combustible objects are stored or installed near the air
outlet. A distance of at least 50 cm must be kept.
NOTE
Supplementary information for operating the product.

EN
FJ 1700, FJ 2000, FJ 2200, FJ 3200 Safety and installation instructions
5
•Donot undo the upper cover of the roof air conditioner in the event of
a fire. Use approved extinguishing agents instead. Do not use water to
extinguish fires.
• Do not use means to accelerate the defrosting process or to clean,
other than those recommended by the manufacturer.
• The device shall be stored in a room without continuously operating
ignition sources (for example: open flames, an operating gas appli-
ance or an operating electric heater).
• Do not pierce or burn the device.
• Be aware that refrigerants may not contain an odor.
!CAUTION! Failure to obey these cautions could result in minor or
moderate injury.
Health hazard
• Only use the device as intended.
• Do not make any alterations or conversions to the device.
• Do not reach into air outlets or insert any foreign objects in the roof air
conditioner.
• If faults occur in the roof air conditioner's refrigerant circuit, the roof air
conditioner must be checked by a specialist company and properly
repaired. The refrigerant must never be released into the air.
ANOTICE! Damage hazard
• Never drive through automatic car washes when the roof air
conditioner is mounted.
• Please ask your vehicle manufacturer if a technical inspection is
required after fitting an air conditioner and whether the height entered
in your vehicle documents needs to be altered:
– FreshJet1700, 2000, 2200: increased height 225 mm
– FreshJet3200: increased height 248 mm
2.2 Installing the device
!WARNING! Failure to obey these warnings could result in death
or serious injury.
Electrocution hazard
• The electrical power supply may only be connected by a qualified
electrician (e.g. VDE 0100, Part 721 in Germany).

EN
Target group for this instruction manual FJ 1700, FJ 2000, FJ 2200, FJ 3200
6
• The device shall be installed, operated and stored in a room with a
floor larger than 4 m2.
!CAUTION! Failure to obey these cautions could result in minor or
moderate injury.
Health hazard
• Attach and lay the cables so that they cannot be tripped over or
damaged.
• The roof air conditioner must be installed securely so that it cannot fall
down.
ANOTICE! Damage hazard
• The roof air conditioner is not suitable for use in agricultural or
construction vehicles.
• Use cable ducts to lay cables through walls with sharp edges.
• Do not lay loose or bent cables next to electrically conductive
materials (metal).
• Do not pull on the cables.
3 Target group for this instruction manual
The instructions in this manual are intended for qualified personnel at workshops
who are familiar with the guidelines and safety precautions to be applied.
4Scopeofdelivery
• With air diffuser box Chillout ADB
• With air diffuser box ADB
No. in fig. 1Number Description
1 1 Roof air conditioner
2 1 Air outlet unit
3 1 Fastening frame
4 1 Air filters (with air diffuser box Chillout ADB only)
5 1 Filter covers (with air diffuser box Chillout ADB only)
6 1 Seals

EN
FJ 1700, FJ 2000, FJ 2200, FJ 3200 Accessories
7
5Accessories
Available as accessories (not included in the scope of delivery):
I
6 Intended use
The Dometic FreshJet roof air conditioner is designed for use in motorcaravans,
caravans and other vehicles with habitation compartments only. It is not suitable for
houses and appartments.
The roof air conditioner is not suitable for installation in construction machines, agri-
cultural machines or similar equipment. It will not work properly if exposed to strong
vibrations.
The function of the roof air conditioner is guaranteed for an operating temperature
range (see leaflet technical data).
I
This product is only suitable for the intended purpose and application in accordance
with these instructions.
7 3 Cable connectors
8 4 Long fastening screws
9 4 Short fastening screws
10 1 Remote control
Designation Reference no. FJ1700 FJ2000 FJ2200 FJ3200
DC Kit PP12 9100300003 – – – –
DC Kit DSP-T 12 9600007286 ••••
DC Kit DSP-T 24 9600007287 ••••
NOTE
The DC extension kit (accessory) allows the Dometic FreshJet roof air
conditioner to be used while in motion.
NOTE
You can find additional information on roof air conditioners in the
operating manual, such as the technical description or the controls.
No. in fig. 1Number Description

EN
Labels FJ 1700, FJ 2000, FJ 2200, FJ 3200
8
This manual provides information that is necessary for proper installation and/or
operation of the product. Poor installation and/or improper operating or mainte-
nance will result in unsatisfactory performance and a possible failure.
The manufacturer accepts no liability for any injury or damage to the product
resulting from:
• Incorrect assembly or connection, including excess voltage
• Incorrect maintenance or use of spare parts other than original spare parts
provided by the manufacturer
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in this manual
Dometic reserves the right to change product appearance and product
specifications.
7Labels
Labels are attached to the Dometic FreshJet roof air conditioners. These labels
provide the user and fitter with information on specifications of the device.
8 Installation
!
8.1 Note on installation
Read this installation manual completely before installing the roof air conditioner.
The following tips and instructions must be observed while installing the roof air
conditioner:
!
CAUTION! Health hazard
The roof air conditioner may only be installed by qualified personnel
from a specialist company. The following information is intended for
technicians who are familiar with the guidelines and safety precautions
to be applied.
WARNING! Electrocution hazard
Disconnect all power supplies when working on the roof air conditioner.

EN
FJ 1700, FJ 2000, FJ 2200, FJ 3200 Installation
9
!
A
Note on transport
• Always have someone help you carry the roof air conditioner.
• Always lift the roof air conditioner to move it and never drag it over the roof
(fig. 2A).
• Do not use the rear ventilation slots to lift it (fig. 2B).
Note on installation location
• Before installing the roof air conditioner, check whether any vehicle components
could be damaged by the installation of the roof air conditioner (such as lamps,
cupboards, doors).
• Before installation, find out (by consulting the manufacturer of the vehicle)
whether the construction is designed for the static weight and the loads of the air
conditioner when the vehicle is in motion. The manufacturer of the roof air
conditioner assumes no liability whatsoever.
• The vehicle manufacturer may have already provided points where the opening
for the installation of the roof air conditioner can be made without any risk of
weakening the construction or cutting power cables.
• Select a flat and sufficiently level area at the centre of the vehicle roof between
two longitudinal sections for installation.
• The roof inclination of the installation surface may not exceed 10°.
• The roof air conditioner must be installed above 2 meters.
CAUTION! Health hazard
• Improper installation of the roof air conditioner can result in
irreparable damage to the device and put the safety of the user at
risk.
• The manufacturer assumes no liability for malfunctions and for the
safety of the roof air conditioner, especially for injury and/or damage
to property, if the roof air conditioner is not fitted in accordance with
these installation instructions.
• Always wear the recommended protective clothing (e.g. protective
goggles, gloves).
NOTICE! Damage hazard
• Observe the structural engineering of the vehicle and seal of all
openings made when installing the roof air conditioner.
• Check whether the roof of the vehicle is able to support the weight
of a person before climbing onto it. Ask the vehicle manufacturer
about the permissible roof loads.

EN
Installation FJ 1700, FJ 2000, FJ 2200, FJ 3200
10
• Make sure no combustible objects are stored or installed near the air outlet. A
distance of at least 50 cm should be kept.
• Make sure that there are no objects within the vehicle which could obstruct the
attachment of the air outlet unit or the cooled air from flowing through the
swivelling air distribution nozzles.
• For safety reasons, note the location of existing wiring harnesses, wires and other
components within the installation area, in particular those which are not visible,
when installing the roof air conditioner (when drilling or screwing etc.).
• The device shall be installed, operated and stored in a room with a floor larger
than 4 m2.
Note on electrical system
• Only a qualified electrician should connect the roof air conditioner to the
electrical power.
• Check that the voltage specification on the type plate is the same as that of the
power supply.
• If the lighting should also be switched on without a 230 V voltage supply, make
sure that there is a 12 Vgpower supply line from the battery to the roof air
conditioner.
• Do not lay the 230 V mains cable and the 12/24 Vgcable together in the same
cable duct.
• Do not lay cables which are loose or bent next to electrically conductive material
(metal).
• Install an all-pole switch with a contact opening width of at least 3 mm on the
installation side.
• If the appliance is powered by the mains, ensure that the 230 V voltage supply
has a residual current circuit breaker.
• Make sure that the grounding cable of the air conditioner is connected to the
vehicle‘s grounding system.
There are two ways of installing the roof air conditioner:
• Making a new opening (chapter “Making a new opening” on page 11). In this
case the opening must be reinforced by an appropriate frame.
• Using the existing roof hatch openings (ventilation hatch) in the vehicle (chapter
“Installing in a roof hatch opening already provided” on page 11).

EN
FJ 1700, FJ 2000, FJ 2200, FJ 3200 Installation
11
8.2 Making a new opening
See fig. 3
➤Select an area at the centre on the roof between two longitudinal supports.
➤Mark the position and size of the opening using the template included in the
packaging (Aand B).
See fig. 4
➤Drill out the corners (A).
➤Carefully cut out the opening on the roof using a keyhole saw or a similar tool (B).
Make sure no electrical power cables are damaged.
See fig. 5
➤Before installation, check whether the roof hole needs reinforcing.
➤Remove the foam according to the width of your reinforcing rails (not in scope of
delivery) (A).
➤Fit the reinforcing rails (B).
8.3 Installing in a roof hatch opening already provided
I
See fig. 6
➤Remove all screws and fixtures of the existing roof hatch.
➤Take out the roof hatch.
See fig. 7
➤Remove the sealant around the opening using a scraper or similar tool.
NOTE
• Existing roof hatch openings in accordance with fig. 3are suitable
for installing the roof air conditioner.
• Dispose of all waste material, glue, silicone and seals separately.
Observe the disposal guidelines.
• The manufacturer only assumes liability for parts included in the
scope of delivery. The validity of the warranty expires if the device is
installed together with third-party parts.

EN
Installation FJ 1700, FJ 2000, FJ 2200, FJ 3200
12
See fig. 8
A
➤Seal the screw holes and recesses with a flexible non-hardening butyl sealing
compound (e.g. SikaLastomer-710).
8.4 Laying the connecting cables
!
The roof air conditioner must be connected to an electric circuit which is able to
supply the required current (see Technical data in Operating Manual).
➤Select the cross-section of the cable corresponding to the length:
–Length<7.5m:1.5mm²
– Length>7.5m:2.5mm²
See fig. 9
➤Make an opening on one side in order to feed through the electrical power
supply cable.
➤Feed the 230 Vw cable through the opening into the vehicle interior.
If the lighting should be switched on without the use of a 230 Vw voltage supply:
➤Connect the cable with the positive terminal and the negative terminal of the
vehicle battery.
➤Feed the 12 Vgcable through the opening into the vehicle interior.
8.5 Installing the roof air conditioner with Chillout ADB
A
NOTICE! Damage hazard
Observe the sealant manufacturer’s instructions.
WARNING! Electrocution hazard
Make sure there is no voltage at electrically operated components
before carrying out work on them!
NOTICE! Damage hazard
Observe the structural strength of the roof of the vehicle. The roof of the
vehicle must be able to bear the weight of the roof air conditioner. The
roof must not be indented or deformed by the weight of the unit, even
over a longer period of time.

EN
FJ 1700, FJ 2000, FJ 2200, FJ 3200 Installation
13
See fig. 0
➤Lift the roof air conditioner onto the roof of the vehicle.
➤Position the roof air conditioner over the installation opening.
Observe the direction of travel.
Attaching the roof air conditioner
See fig. a
➤Position the roof air conditioner into the mounting opening using the conical
noses.
See fig. c
➤Choose the suitable seal in accordance with the following table:
➤Position the seal with the adhesive side on the ADB.
➤Fasten the mounting frame (3) on the underside of the roof air conditioner with
the 4 screws supplied.
See fig. d
A
➤Tighten the screws using a torque spanner and a fastening torque of 2.5 Nm.
Electrical connection
The complete circuit diagram can be found in fig. g:
Roof thickness Seal thickness
25 – 30 mm 15 mm
30 – 40 mm 30 mm
40 – 60 mm 45 mm
NOTICE! Damage hazard
Tighten to the specified torque.
Item Description
1 230 Vwmains
2 Compressor
3 Fan condenser
4 Fan condenser (FreshJet3200 only)

EN
Installation FJ 1700, FJ 2000, FJ 2200, FJ 3200
14
Keys for fig. h:
See fig. b
230 Vw cable
➤Connect the roof air conditioner with the 230 Vw voltage supply.
Connect the cables (1) to a cable connector (2).
Remote light switch (not included in the scope of delivery)
You can connect the lighting to a remote light switch. This enables you to switch on
the lighting remotely.
To do this, proceed as follows:
➤Disconnect the 2-pin plug (3) from the socket on the circuit board of the air outlet
unit.
➤Connect the two cables of the remote light switch to the 2-pin plug (3).
➤Insert the 2-pin plug (3) into socket on the circuit board.
12 Vg cable
You can connect the lighting to the battery. This enables you to switch on the lighting
even if the 230 Vw voltage supply is not connected.
5 Fan evaporator
6 Battery
7 Remote socket
8 Temperature sensor
9 Heating (FreshJet1700,2000, 2200 only)
10 Heat Pump (FreshJet3200 only)
11 Soft Start (FreshJet2000, 2200,3200 only)
Item Description
1 Remote light switch
2 Circuit board in the air outlet unit
Item Description

EN
FJ 1700, FJ 2000, FJ 2200, FJ 3200 Installation
15
To do this, proceed as follows:
➤Connect the positive cable and the negative cable to the battery.
Connecting the circuit board
See fig. e
➤Insert the 12-pin plug (1) in the socket (3) on the circuit board of the air outlet unit.
➤Connect the 2-pin connector plug (2) to the wire from CI-Bus master panel
(optional).
8.6 Installing the air outlet unit Chillout ADB
See fig. f
➤Attach the air outlet unit to the (1) fastening frame using the short fastening
screws.
See fig. e
➤Install the air filter in the specified sequence.
See fig. f
➤Fit the filter covers.
➤Enter the new vehicle height and weight in the vehicle documents.
8.7 Installing the roof air conditioner with ADB
A
See fig. 0
➤Lift the roof air conditioner onto the roof of the vehicle.
➤Position the roof air conditioner over the installation opening.
Observe the direction of travel.
NOTICE! Damage hazard
Observe the structural strength of the roof of the vehicle. The roof of the
vehicle must be able to bear the weight of the roof air conditioner. The
roof must not be indented or deformed by the weight of the unit, even
over a longer period of time.

EN
Installation FJ 1700, FJ 2000, FJ 2200, FJ 3200
16
Attaching the roof air conditioner
See fig. a
➤Position the roof air conditioner into the mounting opening using the conical
noses.
Electrical connection
The complete circuit diagram can be found in fig. g:
Keys to fig. h:
See fig. b
230 Vwcable
➤Connect the roof air conditioner with the 230 Vwvoltage supply.
Connect the cables (1) to a cable connector (2).
Item Description
1 230 Vwmains
2 Compressor
3 Fan condenser
4 Fan condenser (FreshJet3200 only)
5 Fan evaporator
6 Battery
7 Remote socket
8 Temperature sensor
9 Heating (FreshJet1700, 2000, 2200 only)
10 Heat Pump (FreshJet3200 only)
11 Soft Start (FreshJet2000, 2200,3200 only)
Item Description
1 Remote light switch
2 Circuit board of the air outlet unit

EN
FJ 1700, FJ 2000, FJ 2200, FJ 3200 Installation
17
Remote light switch (not included in the scope of delivery)
You can connect the lighting to a remote light switch. This enables you to switch on
the lighting remotely.
To do this, proceed as follows:
➤Disconnect the 2-pin plug (6) from the socket on the circuit board of the air outlet
unit.
➤Connect the two cables of the remote light switch to the 2-pin plug (5).
➤Insert the 2-pin plug (5) into socket on the circuit board (6).
12 Vg cable
You can connect the lighting to the battery. This enables you to switch on the lighting
even if the 230 Vw voltage supply is not connected.
To do this, proceed as follows:
➤Connect the positive cable and the negative cable with the battery.
Connecting the circuit board
➤Insert the 12-pin plug (3) in the socket (7) on the circuit board of the air outlet unit.
➤Connect the 2-pin connector plug (2) to the wire from CI-Bus master panel
(optional).
See fig. c
➤Choose the suitable seal in accordance with the following table:
➤Position the seal with the adhesive side on the ADB.
➤Fasten the fastening frame (3) on the underside of the roof air conditioner with
the 4 screws supplied.
Roof thickness Seal type
25 – 30 mm 15 mm
30 – 40 mm 30 mm
40 – 60 mm 45 mm

EN
Installation FJ 1700, FJ 2000, FJ 2200, FJ 3200
18
See fig. d
A
➤Tighten the screws using a torque spanner and a fastening torque of 2.5 Nm.
8.8 Installing the air outlet unit
See fig. e
➤Install the air filter in the specified sequence.
See fig. f
➤Attach the air outlet unit magnetically to the fastening frame.
NOTICE! Damage hazard
Tighten to the specified torque.

DE
FJ 1700, FJ 2000, FJ 2200, FJ 3200 Erläuterung der Symbole
19
Original-Betriebsanleitung
Lesen und befolgen Sie bitte alle Anweisungen, Richtlinien und Warnhinweise in diesem Produkthandbuch sorgfältig, um sicherzustellen,
dass Sie das Produkt ordnungsgemäß installieren und stets ordnungsgemäß betreiben und warten. Diese Anleitung MUSS bei dem Produkt
verbleiben.
Durch die Verwendung des Produktes bestätigen Sie hiermit, dass Sie alle Anweisungen, Richtlinien und Warnhinweise sorgfältig gelesen
haben und dass Sie die hierin dargelegten Bestimmungen verstanden haben und ihnen zustimmen. Sie erklären sich damit einverstanden,
dieses Produkt nur für den angegebenen Verwendungszweck und gemäß den Anweisungen, Richtlinien und Warnhinweisen dieses Pro-
dukthandbuchs sowie gemäß allen geltenden Gesetzen und Vorschriften zu verwenden. Eine Nichtbeachtung der hierin enthaltenen Anwei-
sungen und Warnhinweise kann zu einer Verletzung Ihrer selbst und anderer Personen, zu Schäden an Ihrem Produkt oder zu Schäden an
anderem Eigentum in der Umgebung führen. Dieses Produkthandbuch, einschließlich der Anweisungen, Richtlinien und Warnhinweise,
sowie die zugehörige Dokumentation können Änderungen und Aktualisierungen unterliegen. Aktuelle Produktinformationen finden Sie
unter documents.dometic.com.
Inhaltsverzeichnis
1 Erläuterung der Symbole . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
2 Sicherheits- und Einbauhinweise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3 Zielgruppe dieser Anleitung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4 Lieferumfang . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5 Zubehör. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6 Bestimmungsgemäßer Gebrauch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
7 Kennzeichnungsschilder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
8 Montage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
1 Erläuterung der Symbole
!
!
WARNUNG!
Sicherheitshinweis: Kennzeichnet eine Gefahrensituation, die zum
Tod oder schwerer Verletzung führen könnte, wenn die jeweiligen
Anweisungen nicht befolgt werden.
VORSICHT!
Sicherheitshinweis: Kennzeichnet eine Gefahrensituation, die zu
geringer oder mittelschwerer Verletzung führen könnte, wenn die
jeweiligen Anweisungen nicht befolgt werden.

DE
Sicherheits- und Einbauhinweise FJ 1700, FJ 2000, FJ 2200, FJ 3200
20
A
I
2 Sicherheits- und Einbauhinweise
Beachten Sie die vom Fahrzeughersteller und vom Kfz-Handwerk vorge-
schriebenen Sicherheitshinweise und Auflagen!
2.1 Umgang mit dem Gerät
!WARNUNG! Nichtbeachtung dieser Sicherheitshinweise kann
zum Tod oder zu schweren Verletzungen führen.
Lebensgefahr durch Stromschlag
• Wenn das Kühlgerät sichtbare Beschädigungen aufweist, dürfen Sie
es nicht in Betrieb nehmen.
• Unterbrechen Sie bei Arbeiten am Gerät immer die Stromversorgung.
• Betreiben Sie das Gerät nur, wenn das Gehäuse und die Leitungen
unbeschädigt sind.
Gesundheitsgefahr
• Dieses Gerät kann von Kindern ab 8 Jahren und darüber sowie von
Personen mit verringerten physischen, sensorischen oder mentalen
Fähigkeiten oder Mangel an Erfahrung und Wissen benutzt werden,
wenn sie beaufsichtigt oder bezüglich des sicheren Gebrauchs des
Gerätes unterwiesen wurden und die daraus resultierenden Gefahren
verstehen.
• Kinder dürfen nicht mit dem Kühlgerät spielen.
• Die Installation, Wartung und Reparaturen der Dachklimaanlage
dürfen nur von Fachkräften durchgeführt werden, die mit den
Gefahren beim Umgang mit Kältemittel und Klimaanlagen sowie den
einschlägigen Vorschriften vertraut sind. Durch unsachgemäße
Reparaturen können erhebliche Gefahren entstehen. Wenden Sie
sich im Reparaturfall an den Service-Stützpunkt in Ihrem Land.
Brandgefahr
• Halten Sie die Lüftungsöffnungen frei von Hindernissen.
ACHTUNG!
Kennzeichnet eine Situation, die zu Sachschäden führen kann, wenn die
jeweiligen Anweisungen nicht befolgt werden.
HINWEIS
Ergänzende Informationen zur Bedienung des Produktes.
