Dorma EMR Series User manual

8900 EMF
(NO DETECTOR)
Each (HO) hold open unit contains a door closer and track assembly with hold open electromagnet.
The unit can be connected directly to a fire control panel.
1
.
Read entire instruction sheet prior to installation and refer to NFPA 72E. Standards may be obtained from
THE NATIONAL FIRE PROTECTION ASSOCIATION, Batterymarch Park, Quincy, MA., 02269.
2
. Reference unit carton for mounting style and voltage.
3
. Prepare door and frame for fasteners using the appropriate template. Mark, drill and tap holes as indicated.
If surface wiring is used, omit 7/8" hole for wire access.
45
Install closer to door.
8900PT
8900T AND 8900DE
HINGES
(LEFT HAND DOOR) (RIGHT HAND DOOR)
C
L
HINGES
C
L
(4)
QTY
(4)
WOOD FRAMES
METAL FRAMES
QTY
C
HINGES
L
HINGES
L
C
(LEFT HAND DOOR) (RIGHT HAND DOOR)
T & DE (RH)
T & DE (LH)
NOTE: NO TOP PLUG
ON PT MOUNTS
surface wiring installations.
the installation type. Any access hole can be used for
Remove (1) wire access plug according to
SURFACE WIRING
NOTE:
Three access wire
holes on optional
surface wired units only.
INSPK NO. 08279520 Rev 08/13
www.dorma-usa.com 1-800-523-8483
INS NO.
Rev.
08281000
08/13
PAGE
1 of 5

Install track to frame.
Install with wire access plugs toward latch edge of door using (2) 1/4-20 x 2" metal or (2) No. 14 x 2-3/4" wood screws.
Route wires from frame through appropriate wire access hole in track, being careful not to pinch wires during installation.
QTY
(2)
QTY
(2)
(1)
QTY
ALARM CONTROL UNIT OR
SMOKE DETECTOR
U.L. LISTED
END CAP
COVER
8900PT ONLY
8
7
6
8900PT
8900T AND 8900DE
QTY
C HINGE
QTY
(1) (1)
END CAP
END CAP
END CAP
Insert cover into track, align end cap in end of track.
Install remaining screw as shown using 1/4-20 x 2" metal or No. 14 x 2-3/4" wood screw.
QTY
(1)
Install PT track to soffit with wire access plugs toward hinge. Install with (1) 1/4-20 x 1-1/4" combo screw and (1) 1/4-20 x 2"
metal or (1) No.14 x 2-3/4" wood screw as shown. Route wires from frame through appropriate wire access hole in track,
being careful not to pinch wires during installation. ( DO NOT INSTALL END CAP ON HINGE SIDE IN THIS STEP)
(1)
QTY
Slide wiring connection cover to allow access to wire connections.
Determine power supply and unit voltage type: 24VAC, 24VDC. CAUTION!!! DO NOT CONNECT 120VAC TO A 24 VOLT UNIT TYPE!!!
Connect power supply wires to terminal block as shown (Terminal Block can be removed for easier wiring). Be sure to use
ground screw for power supply ground wire when supplying 120VAC. Slide wiring connection cover over wire connections.
Improper voltage to unit will result in damage to unit and void warranty.
state and local electrical codes.
All wiring must comply with national,
NOTE:
CAUTION:
WIRE CONNECTION COVER
SOLENOID WIRES
THIS CONNECTION IS NOT POLARITY DEPENDENT.
TERMINAL BLOCK
NOTE:
INCOMING POWER
CONNECTION
SMOKE DETECTOR
ALARM CONTROL UNIT OR
U.L. LISTED
TERMINAL BLOCK 18awg MAX.
INS NO.
PAGE
Rev.
08281000
2 of 5
08/13

10
Attach main arm to door closer.
With door in closed position,
With door in closed position, rotate spindle 45° with wrench. Place arm on
8900PT
rotate spindle 45° with wrench. Place arm
(RIGHT HAND DOOR)
8900T
spindle parallel to door and secure arm with pinion screw and washer.
(LEFT HAND DOOR)
(LEFT HAND DOOR)
(RIGHT HAND DOOR)
9
QTY
(1)
6mm HEX KEY
45°
PINION
ROTATE
6mm HEX KEY
45°
ROTATE
PINION
on spindle parallel to door and secure arm
with pinion screw and washer.
6mm HEX KEY 6mm HEX KEY
Attach arm to slide shoe. Use 3/16 inch hex head wrench.
With door in closed position, rotate spindle 45° with wrench. Place arm on
8900DE
spindle parallel to door and secure arm with pinion screw and washer.
(RIGHT HAND DOOR)
(LEFT HAND DOOR)
6mm HEX KEY 6mm HEX KEY
INS NO.
PAGE
Rev.
08281000
3 of 5
08/13

DECREASE
INCREASE
BACKCHECK OR DELAYED ACTION
NOTE: DELAYED ACTION IS AN OPTIONAL FEATURE.
TAB
SNAP VALVE ADJUSTMENT
WRENCH INSIDE COVER
12
11
13
Hold open position is preset at approximately 90°.
HOLD OPEN DEVICE
HOLD OPEN SET SCREWS - 3/32 HEX
Loosen set screws using 3/32 inch hex wrench slide hold open device for desired position.
Retighten set screws securely.
14
GREATER HOLD
OPEN ANGLE OPEN ANGLE
LESS HOLD
Place cover over closer and fasten securely with
Place tab in cover slot opposite main arm.
HAND IS A MIRROR IMAGE (T & DE)
NOTE: LEFT HAND INSTALLATION SHOWN. RIGHT
screws provided.
(2)
QTY
BACKCHECK RANGE
DELAYED ACTION
SWEEP (SPEED)
(SPEED)
LATCH
(TIME)
DELAYED
ACTION
RANGE
(INTENSITY)
BACKCHECK
INCREASE
DECREASE
POSITIONING VALVE
SWEEP & LATCH
RANGE
RANGE
LATCH
SWEEP
CAUTION: DO NOT REMOVE VALVES.
Adjust sweep, latch and backcheck valves.
NOTE: POWER MUST BE SUPPLIED TO RESET POSITION.
NOTE: DO NOT ADJUST SPRING LOWER THAN SIZE 3
SPRING
ADJUST SPRING TENSION ACCORDING TO THE FOLLOWING CHART.
ADJUSTER
FULL TURNS
OF SPRING
Adjust according to chart.
8916 supplied with size 3 spring setting.
8956 supplied with size 6 setting.
Adjust spring tension, if required, using a 1/4" wrench.
CLOSER
8956
TYPE
8916
DOOR
WEIGHT
250
200
200
150
125
6+
6
6
SIZE
4
5
ULC LABELED UNITS ONLY
DOOR WIDTH
8916
8956
TYPE
CLOSER
3'-0"
MAX.
3'-6"
3'-6"
4'-0"
INTERIOR
2'-6"
CRITICAL
+
-
NOTE:
FULL TURNS
+6
0
OF SPRING
+16
+8
ADJUSTING NUT
0
SPRING
5 +8
0
+6
+16
6+
6
6
0
SIZE
4
ADJUSTER
SPRING TENSION
NOTE: DO NOT ADJUST SPRING LOWER THAN SIZE 3
HOLD OPEN FORCE ADJUSTMENT - 5/32 HEX
CLOCKWISE = STRONGER
INS NO.
PAGE
Rev.
08281000
4 of 5
08/13

17
15
Final installation and test.
OPERATION
FIRE ALARM- When the alarm sounds, the alarm
to the solenoid which releases the hold
ELECTRICAL SPECIFICATION
Voltage input- 24VDC +10% -15%
24VAC +10% -15%
Maximum input current- 24VDC 166mA
24VAC 166mA
NORMAL- The closer unit's solenoid will be energized
across a normally closed alarm contact
from 24VDC, 24VAC or 120VAC power
supply based on unit voltage.
contact will open and interrupt current
IMPORTANT: THE UNIT MUST BE TESTED AFTER THE
INSTALLATION, BY THE END USER, TO ASSURE
THAT THE DOOR CLOSER UNITS FUNCTION PROPERLY
WHEN THE ALARM SYSTEM IS ACTIVATED. THE ENTIRE
SYSTEM MUST ALSO BE TESTED PERIODICALLY AFTER
THE INITIAL INSTALLATION TEST, IN CONJUNCTION WITH
THE TESTING OF THE FIRE ALARM SYSTEM. THE END
USER IS ALSO RESPONSIBLE FOR THE ADJUSTMENTS
AND MAINTENANCE TO RETAIN THE SYSTEM IN
WORKING ORDER.
1. After installation is completed, recheck all
connections. Apply power to units.
2. Open door so slide block engages with hold
open assembly.
3. Advise fire officials prior to testing.
5. If the closer is used in conjunction with a
detectored unit, trip the test switch of the
main closer detector as explained in the test
procedure for that unit. After a short time
delay, the hold open electromagnet of both units
will release and the doors will close.
Resetting the test switch will allow
the units to return to standby.
4. Activate system into alarm so the electromagnet
releases and the doors closes.
open allowing the door to close and latch.
16
18
An auxiliary door stop (by others) must be installed to limit the
maximum degree of door swing. Failure to do so may result in
damage to the unit.
Slide wiring connection cover to allow access. Attach bracket and assemble bypass switch.
OPTIONAL:
BYPASS SWITCH
All wiring must comply with national,
Improper voltage to unit, will result in damage to unit and void warranty.
Determine power supply and unit voltage type: 24VAC/ 24VDC. CAUTION!!! DO NOT CONNECT 120VAC TO A 24 VOLT UNIT TYPE!!!
Connect power supply wires, one (1) to terminal block one (1) to bypass switch. connect other bypass switch wire to
terminal block . (Terminal Block can be removed for easier wiring). Slide wiring connection cover over wire connections.
WIRE CONNECTION COVER
NOTE:
state and local electrical codes.
CAUTION:
U.L. LISTED
INCOMING POWER
SMOKE DETECTOR
ALARM CONTROL UNIT OR
THIS CONNECTION IS NOT POLARITY DEPENDENT.
WIRE CONNECTION COVER
TERMINAL BLOCK 18awg MAX.
NOTE:
BYPASS SWITCH
TERMINAL
BLOCK
CONNECTION
INS NO.
PAGE
Rev.
08281000
5 of 5
08/13
