Doro HEARPLUS 313CI User manual

HearPlus
313ci
English

Telephone line socket
Handset hook
Keypad
Handset cord socket
Handset volume
Recall
Volume boost
Call memory / OK
Delete
Mains adapter socket
Ring tone
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
Ring melody
Ring volume
Speed dial keys
Phone book
Handset tone
Speaker volume
Speakerphone
UP/DOWN
New call indicator
Ringer indicator
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
English
1
2
3
4
5
6
7
8
21
20
19
18
17
16
10
13
14
15
9
11
12

1
English
Description
Doro HearPlus 313ci
This product can be used as a desktop or wall-
mounted telephone. Handset tone control, volume
boost, enhanced ring volume and visual call
indication make the telephone well suited for
people with hearing difficulties.
The extra-large keypad and easy to read display with
large characters make the telephone easy to use
even with impaired eyesight.
The built-in phonebook can store up to 30 names
and numbers. Three one touch memory keys can
be programmed for frequently used numbers or
emergency numbers. A call memory logs the 15
most recently incoming and outgoing calls.
A speakerphone function allows you to talk hands-
free with the simple press of a button.

2
English
Installation
Connection
Connect the curly cord to the handset and to the
socket marked yon the telephone.
Connect the telephone line cord to a network
wall socket and to the Ksocket on the back of
the telephone.
Connect the mains adapter to the mains power
wall socket and to the DC 9V socket on the
telephone.
Lift the handset and listen for the dial tone.
Batteries
Four AA alkaline batteries are needed for the call
memory and speakerphone in the event of a power
cut. When BATT. LOW is displayed, replace all 4
batteries. Use only AA alkaline batteries of good
quality (not included).
Note!
Before installing or changing the batteries,
make sure that the telephone is not connected
to the telephone network.
Remove the battery cover and insert the batteries
ensuring correct battery polarity is observed.
Replace the battery cover and reconnect the
telephone line cord.
1.
2.
3.
4.
1.
2.

3
English
Basic setup
Before using the telephone the first time,
the following basic settings should be made.
After confirming a setting, the next setting is
automatically displayed. To skip to the next setting,
press .
The phone will return to standby mode after 30
seconds of inactivity or when pressing .
On first setup the display clock will show 00:00 .
Press and hold *for about 5 seconds until the
hour flashes.
Use v / Vto change the value and confirm
with .
Repeat steps 1–2 to set the minutes, day and
month.
ENGLISH is displayed.
Use v / Vto select the desired language, then
confirm with .
1.
2.
3.

4
English
-2- CONTRAST
Use v / Vto set the display contrast setting
(1–4), and confirm with .
KEYT. ON
Use v / Vto set key tone ON/OFF, and confirm
with .
-100- FLASH
Use v / Vto set the flash key time
(100/300/600 ms) and confirm withand confirm with .
The standard setting is 100 for most countries,
300 for France/Portugal, 600 for New Zealand.
LED OFF
Use v / Vto enable/disable the LED indicator for
new calls, and confirm with .
TONE
Use v / Vto select either tone or pulse dialling
mode, and confirm with .
Note!
If unsure of which mode to use, select TONE as
this works in most locations.

5
English
Wall mounting
The telephone can be wall mounted by using the
included wall mount bracket and two screws (not
included).
Warning!
Make sure that no cables, water pipes or gas pipes
are located inside the wall before drilling into it.
Drill two holes in the wall, vertically 83 mm
apart..
Insert the screws, allowing them to project
~5 mm out from the wall.
Unplug and remove the handset.
Fit the guide tabs (A) on the bracket into the
slots (B) on the back of the telephone, then slide
the bracket upwards until it snaps into place.
B
A
1.
2.
3.
4.

6
English
Position the telephone so that the screws on the
wall fit into the slots in the bracket, then slide
the telephone downwards until it is hanging on
the screws.
Remove the handset hook (C) by pushing it
upwards, and insert it in the reversed position so
that the small tab (D) protrudes. The hook will
now keep the handset in the cradle when the
phone is wall mounted.
C
D
C
Reconnect the handset and place it in the
cradle.
Note!
If the phone is to be used as a desktop phone
again, remember to reverse the position of the
handset hook.
5.
6.
7.

7
English
Operation
Making a call
Normal dialling
Lift the handset.
Dial the number. Hang up the handset to
terminate the call.
Speakerphone
Note!
The speakerphone only works when batteries are
installed or mains adapter is connected.
Press sto activate the speakerphone. The
LED next to the key will light up.
Dial the number. Press sagain to terminate
the call.
Lift the handset to switch from speaker to handset
during a call.
Pre-dialling
Enter the number. Press to delete the last
entered digit.
Lift the handset or press sto dial.
1.
2.
1.
2.
1.
2.

8
English
Quick redial
Lift the handset or press s.
Press to redial the last dialled number.
Dialling numbers in the call memory
Press to display the most recent call.
Use v / Vto scroll through the last 15
incoming and outgoing calls.
= Incoming call
= Outgoing call
Lift the handset or press s to dial the
displayed number.
Speed dial (one-touch dialling)
Press one of the speed dialling keys A/B/C. The
stored telephone number is displayed.
Lift the handset or press sto dial.
Dialling numbers in the phone book
Press b to open the phone book.
Use v / Vto browse through the phone
book, or enter the first character in the name to
quickly find an entry (see Keypad characters).
Lift the handset or press sto dial.
Answering
Lift the handset to answer an incoming call, or
press sto answer using the speakerphone.
1.
2.
1.
2.
3.
1.
2.
1.
2.
3.
