Dors 1050 User manual

User Manual
Rev. 1Int 2018
Production date:
USER MANUAL
MULTIFUNCTIONAL
COUNTERFEIT DETECTOR
1050

CONTENTS
MULTIFUNCTIONAL COUNTERFEIT DETECTOR DORS 1050
READ T HIS M ANUAL T HOROUGHLY
BEFORE O PERATING T HE D EVICE!
3
Brief Information for Customers.................................................................................................... 4
Purpose........................................................................................................................................ 4
The Device Helps To..................................................................................................................... 5
Safety Precautions....................................................................................................................... 5
Delivery Set.................................................................................................................................. 7
Appearance.................................................................................................................................. 7
Preparing for Operation................................................................................................................. 8
Operation...................................................................................................................................... 8
............... 8Verification of MG Marks.............................................................................................
.. 9Verification of UV Marks...........................................................................................................
.. 9Verification of IR Marks........................................................................................................... ..
. 9Verification in White Light........................................................................................................ ...
Troubleshooting...................................................................................................................... .... 1.. 3
Specifications..................................................................................................................... ....... .. 1. . 3
Transportation, Storage and Disposal...................................................................... ............ ........ 1. . 4
Support and Warranty....................................................................................................... .......... 1... 4

10,9 cm
TFT
The multifunctional detector DORS 1050 is manufactured in China by DORS Industries (China)
Ltd., No 17, Shilong information industrial park, Shilong town, Dongguan city, Guangdong.
Service term is 7 years *.
*Under condition that the device is being used in strict accordance with this user manual and
applied technical standards.
BRIEF INFORMATION FOR CUSTOMERS
The multifunctional detector DORS 1050 (henceforth – the device) is designed for visual
authenticity of banknotes and security printing documents with protective marks that can be verified by
this device.
The device is equipped with:
■ an ultraviolet (hereafter – UV) source consisting of 1 fluorescent lamp 4W;
■ a top infrared (hereafter – IR) source emitting at the 940 nm wavelength;
■ a magnetic sensor;
■ a white light source;
■ 4,3” (10,9 cm) TFT display;
Video camera for transmitting on the monitor the image of the banknote / document placed in the
viewing zone of the device.
THE DEVICE HELPS TO:
Verify availability of zones printed
by magnetic ink.
Verify availability of IR images in a
reflected light.
Inspect the surface of banknotes
and other documents with
protective elements in a white
oblique reflected light (for example,
verify availability of the relief
printed elements).
Verify absence of a general
luminescence in ultraviolet rays.
Verify availability of luminescence of
the specific areas of a sheet in
ultraviolet rays (marks, security
threads and fibers).
Verify availability of watermarks and
security threads on paper.
Examine the image of banknote or
other document on 4.3" TFT
display.
54
PURPOSE
MULTIFUNCTIONAL COUNTERFEIT DETECTOR DORS 1050MULTIFUNCTIONAL COUNTERFEIT DETECTOR DORS 1050
IMPORTANT INFORMATION! Safety precautions:
IT IS PROHIBITED TO LOOK AT THE UV-LAMP DURING THE DEVICE OPERATION.
IT IS PROHIBITED TO TOUCH THE DEVICE AND THE POWER CORD PLUG WITH WET
HANDS. IT MAY RESULT IN AN ELECTRIC SHOCK.

7
6
WARNING! UNPLUGING THE DEVICE FROM THE POWER OUTLET, HOLD THE PLUG,
NOT POWER CORD TO AVOID ANY DAMAGE OF THE CORD.
WARNING! TO AVOID ANY POWER CORD DAMAGE AND A SHORT CIRCUIT, MOVE THE
DEVICE ONLY AFTER THE POWER CORD PLUG HAS BEEN DISCONNECTED FROM THE
POWER NETWORK.
IT IS PROHIBITED TO INSTALL THE DEVICE WITH ITS UV-LAMP BEING VISIBLE FOR
THE OPERATOR.
ATTENTION! IF THE DEVICE HAS BEEN UNDER COLD CONDITIONS FOR A LONG TIME,
IT SHALL BE KEPT UNDER ROOM TEMPERATURE FOR NOT LESS THAN TWO HOURS
BEFORE ITS SWITCHING ON.
ATTENTION! TO PROVIDE A SUCCESSFUL OPERATION OF THE DEVICE FOR A LONG
TIME WITHOUT AN INTERFERENCE OF A TECHNICIAN, OBSERVE THE FOLLOWING
RULES:
1. THE DEVICE SHALL BE INSTALLED ON AN EVEN HORIZONTALSURFACE.
2. WHEN INSTALLING THE DEVICE, AVOID ITS EXPOSURE TO DIRECT SUNLIGHT
AND SPOT LIGHT ARTIFICIAL ILLUMINATION.
WARNING! TO AVOID AN ELECTRIC SHOCK, APPLY TO A QUALIFIED SPECIALIST TO
REPLACE THE LAMP.
IT IS PROHIBITED TO DISPOSE THE USED LAMPS IN THE DOMESTIC GARBAGE
CONTAINERS. AFTER A LAMP HAS BEEN REPLACED, IT SHALL BE HANDED IN TO THE
SERVICE OF FLUORESCENT LAMPS DISPOSAL.
MULTIFUNCTIONAL COUNTERFEIT DETECTOR DORS 1050MULTIFUNCTIONAL COUNTERFEIT DETECTOR DORS 1050
Multifunctional counterfeit detector DORS 1050........................................................................ 1 pc.
AC adapter................................................................................................................................. 1 pc.
User manual............................................................................................................................... 1 pc.
Packaging.................................................................................................................................. 1 set
DELIVERY SET
12 3
4
5
6
7
Rear viewFront view
Mark of
magnetizing area
А
А
Fig.1. APPEARANCE
B
8
1 Power switch;
2 TFT display;
3 LED:
Flashing green when
detecting magnetic marks;
4 Button for switching the
lighting mode:
UV or White light;
5 Magnetic sensor;
6 UV lamp;
7 White light source;
8 Jack for AC adapter.

98 MULTIFUNCTIONAL COUNTERFEIT DETECTOR DORS 1050MULTIFUNCTIONAL COUNTERFEIT DETECTOR DORS 1050
The optimal location of the device is considered to be a position when the operator’s look is
perpendicular to the surface of the screen.
To start the device operation, connect the supplied AC adapter to the power jack of the device and plug
AC adapter to power supply 190-240V, 50-60 Hz. Then switch on the device using the power switch 1
(see Fig. 1). The screen of device shall turn on to show that the device is switched on and ready for
operation.
PREPARING FOR OPERATION
ATTENTION! BEFORE THE DEVICE OPERATION STARTS, MAKE SURE ABOUT THE
INTEGRITY OF ITS BODY AND UV LAMP (Fig.1 item 6).
IT IS PROHIBITED TO CONNECT TO THE POWER SUPPLY THE PRODUCT WITH A
DAMAGED BODY, WITH THE DAMAGED UV LAMP OR WITHOUT IT.
OPERATION
When the device is switched on, the screen of device (Fig.1, item 2) turns on and the UV or white
light mode is activated (UV lamp or white diode is depended on the position of the switch 4 (refer to
Fig.1) – UV/White; using this switch the light mode can be changed during device operation). In both
modes the IR image of the banknote placed in the viewing zone of device (Fig.1, item B) is displayed
on the monitor.
VERIFICATION OF MAGNETIC MARKS
The verification of magnetic marks is active in all operation modes. Pass a part of banknote, which
has a magnetic ink, cross the head of inductive sensor Fig. 1 item 5. Once a magnetic ink is detected,
the diode Fig. 1 item 3 flash green. To improve the quality of magnetic control, for example, for
verification of worn-out banknotes, put the banknote on the magnetic bias area (Fig. 1, item A) for
several seconds.
VERIFICATION OF UV MARKS
IT IS PROHIBITED TO LOOK AT UV LAMP WHEN DEVICE IS WORKING.
Place a banknote or a document in the viewing zone (Fig.1, item B) of device.
Turn the key (Fig. 1, item 4) into position 1
that means the UV mode is activated.
Examine UV images on the surface of a banknote / document.
The simultaneous verification in UV and IR is available.
IR image can be seen on the screen (Fig.1, item 2).
1
VERIFICATION OF IR MARKS
Place a banknote or a document in the viewing zone (Fig.1, item B) of device.
The IR verification is activated once the device is switched on.
Observe the IR images on the screen (Fig.1, item 2).
VERIFICATION IN WHITE LIGHT
Place a banknote or a document in the viewing zone (Fig.1, item B) of device.
Turn the key (Fig. 1, item 4) into position 2
that means the white light mode is activated.
This mode is very convenient for observing the relief of printed elements visible in oblique white
light.
When placing a banknote or a document in front of device, you can verify watermarks.
For the white illumination a point-type LED of high brightness is used, so it is not recommended to
look directly at the source of white light.
2

1110 MULTIFUNCTIONAL COUNTERFEIT DETECTOR DORS 1050MULTIFUNCTIONAL COUNTERFEIT DETECTOR DORS 1050
SWITCHING DEVICE OFF
Press the power switch key (Fig. 1, item 1), here the screen shall go out. It is the user who decides
whether disconnect the power cord from the power supply or not. It is worth disconnecting in case of a
long-term (more than several days) device standing by.If it is necessary to install the device on a new
place after it was switched off, disconnect the power plug from the power socket. Having done this, one
may move the device to a new place.
CARE AND MAINTENANCE
To clean the device surface from dirt, use water-based neutral detergents (for example, the ones
for dish washing) or the cleaning compositions on the base of isopropyl alcohol. Remove carefully
excess of the detergent or the cleaning composition from the device.
WARNING! BEFORE CLEANING THE DEVICE SURFACE FROM DIRT, MAKE SURE THE
POWER PLUG HAS BEEN REMOVED FROM THE POWER SOCKET!
WARNING! TO AVOID AN ELECTRIC SHOCK, AVOID ACCESS OF THE DETERGENT OR
THE CLEANING COMPOSITION INSIDE THE DEVICE!
WARNING! WHEN CLEANING THE SURFACE, USE ONLY A SOFT TISSUE TO APPLY THE
DETERGENT OR THE CLEANING COMPOSITION! IT IS PROHIBITED TO USE A BRUSH,
ASPRAYER OR AN AEROSOL SPRAY TO APPLY THE DETERGENT OR THE CLEANING
COMPOSITION!
Fluorescent lamp is used in the device as the source of UV light. After a lamp failure, the lamp shall
be replaced. As an exception, the device with a failed lamp may be in operation during not more than 8
working hours.
Attention! Fluorescent lamps are consumables, and the manufacturer’s warranty doesn’t cover
them.
To replace the fluorescent lamps, one shall use the lamps of the same type as installed in the
device. To replace UV lamp, use the lamp DORS TL 4W/08 F4 T5/BLB.
WARNING! REPLACING OF THE LAMP MAY BE ACCOMPANIED BY TOUCHING OF THE
METAL CAPS OF THE FLUORESCENT LAMPS HAVING A SINGLE INSULATION FROM
THE CIRCUIT OF THE DEVICE POWER SUPPLY. THEREFORE, IT IS PROHIBITED TO
REPLACE THE LAMPS IN THE DEVICE WITH ITS POWER PLUG INSERTED INTO THE
POWER SOCKET. ONLY QUALIFIED PERSONNEL SHALL REPLACE THE LAMP IN THE
DEVICE.
When looking at active UV lamp, the user gets UV radiation. Therefore to determine the failed UV
lamp, please use a sheet of A4 white paper of standard density (not more than 80 g/m2). The
procedure is as follows:
1. Ensure that the UV light is on.
2. The good condition of UV lamp can be confirmed by placement of a paper sheet in the viewing
zone B. If a paper sheet becomes to emit light intensely, the UV lamp works; if a paper doesn’t
fluoresce, it is necessary to replace UV lamp (see UV LAMP REPLACING PROCEDURE).
The failed white light source is determined visually when the white light mode is on – whether the
white lamp lights or not.
1. Turn the device upside down and place it on a table covered by soft cloth.
2. Applying no excessive strength, turn the failed lamp around its axis for a quarter of a turn. Doing it,
hold the lamp with two fingers of each hand.
UV LAMP REPLACING PROCEDURE
WARNING! BEFORE REPLACING A LAMP, MAKE SURE THE POWER PLUG HAS BEEN
DISCONNECTED FROM THE POWER SOCKET!

1312 MULTIFUNCTIONAL COUNTERFEIT DETECTOR DORS 1050MULTIFUNCTIONAL COUNTERFEIT DETECTOR DORS 1050
3. Remove the failed lamp 6 together with its protection covers 11 out of the holders 10 (see Fig. 2).
4. Remove (shift off) the lamp protection covers 11.
5. Take a new lamp from the package and inspect it: the glass bulb shall be devoid of scratches and
chipping, the lamp shall not be damaged, and the glass bulb surface shall not be contaminated.
6
9
6 – UV lamp
9 – Protective cover catch
10 – UV-lamp holder
11 – UV-lamp protective
cover
Fig. 2 Removing of the UV-lamp
Protective cover
10
11 11 Bottomside view
6. Insert the lamp into the holders up to the stop. Holding the lamp by two fingers of each hand, turn it
around its axis by a quarter of a turn.
Make sure the lamp is fixed in the holders.
7. Put on a protective cover 11 on each lamp holder (no tool is required).
8. Install the device in a working position and make a trial turning on UV light, make sure that the
failure is recovered.
9. Pack the failed lamp and hand it over to a specialized disposal service.
ATTENTION! DO NOT INSTALL IN THE DEVICE A LAMP HAVING MECHANICAL
DAMAGES AND BULB CONTAMINATION!
The device fails to switch on (display doesn’t light):
■ Check the device connection to the power supply. If the device isn’t connected to AC
adapter or to power sypply, connect it. If the device still fails to switch on, call your supplier.
The device switches on, but the white light has failed:
■ Call your supplier.
The device switches on, but the UV light has failed:
■ Replace the UV lamp of the recommended type.
TROUBLESHOOTING
SPECIFICATIONS
Supply voltage................................................................................................. 190 -240 V ~ 50/60 Hz
Current consumption....................................................................................... 0,08-0,06 А
Power consumption, not more than.................................................................. 14 W
Weight (not more than)..................................................................................... 0,48 kg
Overall dimensions (Width х Depth х Height): .................................................. 200x87x119 mm
Power of UV source......................................................................................... 1 х4 W
Peak wavelength of UV-radiation..................................................................... 365 nm
Operating range of IR source............................................................................ 800 -1000 nm
Operating temperature..................................................................................... +5 to +40°С

14 MULTIFUNCTIONAL COUNTERFEIT DETECTOR DORS 1050
TRANSPORTATION, STORAGE AND DISPOSAL
The device shall be transported in its standard package by sea (in containers), by railway (in
closed wagons), by air (in a pressurized baggage or a cargo compartment), and by truck (in an
enclosed body or in a container under a water-resistant tent along the public paved roads). The
transportation conditions are temperature – 20°C to + 50°C, relative humidity up to 95 % without water
condensation at +25°C, atmospheric pressure 84 to 107 kPa (630 to 800 mm Hg).
The device shall be stored in its package in a heated warehouse at temperature 0°C to +40°C, at
relative air humidity not exceeding 80%.
The device meets the requirements of the European Union's RoHS Directive which decreases the
environmental pollution by hazardous substances.
ATTENTION! BEFORE DISPOSAL OF THE DEVICE, REMOVE THE FLUORESCENT LAMP
FR O M T H E D E V I CE F O L L O W I N G I T E M S 1 – 4 O F T H E S E C T I O N S « U V- L A M P
REPLACEMENT PROCEDURE». THE REMOVED LAMP SHALL BE HANDED OVER TO A
SPECIALIZED DISPOSAL SERVICE.
The device without UV lamp may be disposed as a domestic waste.
SUPPORT AND WARRANTY
The manufacturer guarantees 12 months of the device operation since the moment of its purchase. The
manufacturer by means of its local dealer is obliged to repair the failed device if the user has observed all the
requirements of this User Manual.
Failure of the fluorescent lamps is not a guarantee event. Neither is a guarantee event the device damage
resulting from an improper use of the device, its falling and applying an excessive physical strength.
