Dräger X-pid 800 Series User manual
Dräger X-pid®8x00 Sensor Unit
Instructions for use
enUS · fr
WARNING
To properly use this product, read and comply with these
instructions for use.
Contents_ HQ
,QVWUXFWLRQVIRUXVH_ Dräger X-pid®8x00 Sensor Unit
Dräger X-pid®8x00 Sensor Unit
Contents
Safety information
Conventions in this document
Meaning of the warning notes
Typographical conventions
Trademarks
Description
Product overview
Gas detector
Sensor unit
Control unit
Mobile app
Status LED
Intended use
Approvals
Operation
Operating concept
Turning the gas detector on or off
Initial start-up
Turning the sensor unit on
Turning the sensor unit off
Turning on the control unit
Turning off the control unit
Starting or opening the mobile app
Closing or exiting the mobile app
Connecting the sensor unit and control unit
Preparations for operation
During operation
Measurement in Analysis measurement mode
Identifying alarms
Standby mode
Maintenance
Maintenance intervals
Running a functional test
Carrying out a calibration
Charging the sensor unit
Configuration
Replacing the water and dust filter
Cleaning
Transport
Storage
Disposal
Technical data
,QVWUXFWLRQVIRUXVH_ Dräger X-pid®8x00 Sensor Unit
HQ_ Safety information
1 Safety information
The technical manual (order no. 9033850) can be downloaded in electronic
format from the technical documentation database (www.draeger.com/ifu) in
selected languages.
– Before using this product, carefully read the instructions for use and those of
the associated products.
– Strictly follow the Instructions for Use. The user must fully understand and
strictly observe the instructions. Use the product only for the purposes
specified in the Intended use section of this document.
– Do not dispose of the Instructions for Use. Ensure that they are retained and
appropriately used by the product user.
– Only trained and competent users are permitted to use this product.
– Comply with all local and national rules and regulations associated with this
product (e.g. IEC 60079-14).
– Only trained and competent personnel are permitted to inspect, repair and
service the product as detailed in these Instructions for Use (see Section 5).
Further maintenance work that is not detailed in these Instructions for Use
must only be carried out by Dräger or personnel qualified by Dräger. Dräger
recommends a Dräger service contract for all maintenance activities.
– Use only genuine Dräger spare parts and accessories. Otherwise, the
proper functioning of the product may be impaired.
– Do not use a faulty or incomplete product. Do not modify the product.
– Notify Dräger in the event of any product or product component fault or
failure.
– Replacing components may impair the intrinsic safety of the product.
– Electrical connections to devices which are not listed in these instructions
for use should only be made following consultation with the respective
manufacturers or an expert.
Use in explosion-hazard areas
Devices or components for use in explosion-hazard areas which have been
tested and approved according to national, European, or international explosion
protection regulations may only be used under the conditions specified in the
approval and with consideration of the relevant legal regulations. The devices or
components may not be modified in any manner. The use of faulty or
incomplete parts is forbidden. The appropriate regulations must be observed at
all times when carrying out repairs on these devices or components.
2 Conventions in this document
2.1 Meaning of the warning notes
The following warning signs are used in this document to indicate and highlight
areas of the associated text that require particular attention by the user. A
definition of the meaning of each sign is as follows:
2.2 Typographical conventions
Alert icon Signal word Consequences in case of nonob-
servance
WARNING Indicates a potentially hazardous situa-
tion. If not avoided, it could result in
death or serious injury.
CAUTION Indicates a potentially hazardous situa-
tion. If not avoided, it could result in
physical injury. It may also be used to
warn against unsafe practices.
NOTICE Indicates a potentially hazardous situa-
tion. If not avoided, it could result in
damage to the product or environment.
Text Text in bold identifies labels on the device and screen texts.
►This triangular symbol in warning notices identifies the options
for avoiding the hazard.
This symbol identifies information that makes the product easier
to use.
Description_ HQ
,QVWUXFWLRQVIRUXVH_ Dräger X-pid®8x00 Sensor Unit
2.3 Trademarks
The trademarks cited are only registered in certain countries and not
necessarily in the country where this material has been published.
3 Description
3.1 Product overview
3.1.1 Gas detector
The Dräger X-pid xx00 gas detector consists of 3 components:
– Dräger X-pid xx00 sensor unit (referred to below as the "sensor unit")
– Dräger X-pid xx00 mobile app (referred to below as the "mobile app")
– Explosion-proof smartphone (referred to below as the "control unit")
The Dräger X-pid xx00 is a portable gas detector for clearance measurements
for hazardous substances in explosion-hazard areas at the workplace.
Occupational exposure limits for benzene and other toxic and carcinogenic
volatile organic compounds (VOCs) can be monitored using the gas detector.
The metrology and sensors are located in the sensor unit, from which
measurement data is transmitted to the control unit via Bluetooth, and
evaluated and displayed in the mobile app.
The gas detector has one measurement mode:
For further information, see the following chapter: "Measurement in Analysis
measurement mode", page 11.
Trademark Trademark holder
X-pid®bentekk GmbH | A Dräger Company
Bluetooth®Bluetooth SIG, Inc.
Smart-Ex®ECOM Instruments GmbH
Measurement mode Explanation
Analysis Selective measurement of previously selected individ-
ual substances, known as target substances, in a
matter of seconds (discontinuous). For example, the
"Analysis" enables the concentrations of benzene
and butadiene to be individually displayed after 30 s
with a high level of accuracy. The measurement mode
is comparable to GC analyses in the laboratory.
