Dräger Atlan User manual

Atlan
Anesthesia workstation
Software 2.0n
Quick reference guide
The quick reference guide does not replace the
instructions for use.
Any use of the medical device requires full understanding
and strict observation of the instructions for use. Atlan

2 Quick reference guide | Atlan SW 2.0n
Trademarks
Atlan
Trademarks
Trademarks owned by Dräger
The following web page provides a list of the countries in which the trademarks are
registered: www.draeger.com/trademarks
Trademark
Atlan®
AutoFlow®
Infinity®
D-Vapor®
Drägersorb®
MEDIBUS®
ServiceConnect®
WaterLock®

Quick reference guide | Atlan SW 2.0n 3
Contents
Contents
1Overview .................................................................................................................. 4
1.1 Hardware....................................................................................................... 4
1.2 Functional scope ........................................................................................... 14
2Assembly and preparation ..................................................................................... 15
2.1 Selecting and connecting patient-specific accessories ................................. 15
3Operating concept................................................................................................... 18
3.1 Screen........................................................................................................... 18
3.2 Color concept ................................................................................................ 20
3.3 Selecting and setting..................................................................................... 21
4Getting started......................................................................................................... 22
4.1 Turning on the device.................................................................................... 22
4.2 Password dialog............................................................................................ 23
4.3 Checking the operational readiness.............................................................. 24
4.4 Emergency start-up....................................................................................... 25
5Tests ......................................................................................................................... 26
5.1 Available test types ....................................................................................... 26
6Ending operation..................................................................................................... 28
6.1 At the end of the OR day............................................................................... 28
6.2 Storing the device ......................................................................................... 28
6.3 Disconnecting the mains power supply......................................................... 28
7Alarms ...................................................................................................................... 29
7.1 Alarm signaling.............................................................................................. 29
7.2 Response to alarms ...................................................................................... 30
8Troubleshooting ...................................................................................................... 32
8.1 Leakage ........................................................................................................ 32
9Principles of operation ........................................................................................... 33
9.1 Description of the ventilation modes ............................................................. 33
9.2 CO2measurement with pediatric patients and neonates.............................. 39
10 Annex ....................................................................................................................... 42
10.1 Symbols ........................................................................................................ 42

4 Quick reference guide | Atlan SW 2.0n
Overview
1 Overview
The quick reference guide does not replace the instructions for use. Any use of the
medical device requires full understanding and strict observation of the instructions for use.
1.1 Hardware
1.1.1 Front
1.1.1.1 Large version
44222
No. Designation Description
1 Screen Enables user inputs by touchscreen and rotary
knob.
2 Plug-in connectors for vaporizers Enable the connection of up to 3 vaporizers.
3 Backup manual switch (behind
the flap)
Used to switch to backup manual mode in the
event of malfunctions of the device.
4 Gas mixing unit Produces a gas mixture from the selected gases
(e.g., O2and Air).
5 Work surface Used for storage.
6 Pull-out writing tray (option) Provides additional work surface.
7 Viewing window for piston venti-
lator
Allows visual checking of the movement of the
piston ventilator.
8 Lockable drawer Provides additional storage space.
9 Trolley with castors and cable
deflectors
Used for moving the device. The central brake
(option) locks the two front castors.
10 CO2absorber Absorbs CO2from the patient’s expiratory gas.

Quick reference guide | Atlan SW 2.0n 5
Overview
1.1.1.2 Compact version
11 Anesthetic gas receiving system Used for scavenging excess anesthetic gas and
breathing gas. Used to reduce the anesthetic
gas concentration released into the environment
by the anesthesia machine and to scavenge the
sample gases from an external anesthetic gas
monitor.
12 External O2flowmeter (option) Supplies oxygen for O2insufflation.
13 Rail Used for fastening additional components.
No. Designation Description
49305
No. Designation Description
1 Screen Enables user inputs by touchscreen and rotary
knob.
2 Plug-in connectors for vaporizers Enable the connection of up to 2 vaporizers.
3 Backup manual switch (behind
the flap)
Used to switch to backup manual mode in the
event of malfunctions of the device.
4 Folding table extension (option) Used for storage.
5 Work surface Used for storage.
6 Viewing window for piston venti-
lator
Allows visual checking of the movement of the
piston ventilator.
7 Lockable drawer Provides additional storage space.
8 Trolley with castors and cable
deflectors
Used for moving the device. The central brake
(option) locks the two front castors.
9CO
2absorber Absorbs CO2from the patient’s expiratory gas.
10 Anesthetic gas receiving system Used for scavenging excess anesthetic gas and
breathing gas. Used to reduce the anesthetic
gas concentration released into the environment
by the anesthesia machine and to scavenge the
sample gases from an external anesthetic gas
monitor.

6 Quick reference guide | Atlan SW 2.0n
Overview
1.1.2 Screen
11 Gas mixing unit Produces a gas mixture from the selected gases
(e.g., O2and Air).
12 Rail Used for fastening additional components.
No. Designation Description
36441
No. Designation Description
1 Touchscreen Calls up functions or dialogs when touched.
2Alarm silence key Suppresses the alarm tones of all active alarms
for 2 minutes.
3 Rotary knob Used for selecting, adjusting, and confirming
settings. Lights up in color in certain situations.
4 Working light Illuminates the work surface.
5key Turns the working light on or off. Dims the illumi-
nance in 3 steps (dark, medium, and bright).
6key Turns the device on or off.

Quick reference guide | Atlan SW 2.0n 7
Overview
1.1.3 Breathing system and other components
1.1.3.1 Overview
The following illustration shows the device and the breathing system.
42406
No. Designation Description
1 Airway pressure gauge Mechanically measures the airway pressure
and displays it on an analog indicator.
2 Inspiratory port Used to connect the inspiratory hose to the
device.
3 Breathing bag arm (option) with
circuit plug
Used to connect the breathing bag. The circuit
plug is used to seal the Y-piece during an auto-
matic test.
Without this option, a bag elbow is provided
instead of the breathing bag arm.
4 APL valve In the Man/Spon mode: Limits the maximum
airway pressure to the set value (during manual
ventilation: Man) or enables spontaneous
breathing when set to Spont.
5 Breathing system cover Protects the breathing system underneath and
provides climate control for the breathing sys-
tem.
6 Expiratory port Used to connect the expiratory hose to the
device.
7 Holder Used to hold a suction hose with suction cathe-
ter.
8 Handles Used for positioning the device and for stowing
used breathing hoses.
9CO
2absorber Absorbs CO2from the patient’s expiratory gas.
10 Anesthetic gas receiving system Used for scavenging excess anesthetic gas and
breathing gas, to reduce the anesthetic gas con-
centration released into the environment by the
anesthesia machine, and to scavenge the sam-
ple gases from an external anesthetic gas moni-
tor.

8 Quick reference guide | Atlan SW 2.0n
Overview
1.1.4 Rear
1.1.4.1 Version with screw connections for standing gas cylinders
11 Water trap with connection for
sample line
Collects condensed water which forms in the
sample line. Protects the patient monitor and the
patient-gas measurement module against water,
bacteria and viruses.
12 Patient-gas measurement mod-
ule
Measures and monitors various gas concentra-
tions in the breathing gas (O2, CO2, N2O, and
anesthetic gases).
13 Guide clip Used to securely lay the O2insufflation hose.
No. Designation Description
49321
No. Designation Description
1 Storage compartment Can be used as storage space.
2 Holder for hoses and cables Used for storing and winding up central supply
hoses and cables.
3 Gas supply block Provides connectors for gases from the central
gas supply system and for gas cylinders.
4 Gas cylinder holder (option) Secures the gas cylinders.
5 Strain relief for compressed gas
hoses
Protects the compressed gas hoses from loos-
ening inadvertently.
6 Gas cylinder park holder (option) Can hold an additional gas cylinder.
7 Auxiliary power sockets (option) Allow other devices to be connected.
8 Vent Discharges warmed air from the device into the
environment.
9 Ventilation slot Feeds ambient air to the device for ventilation.
10 Connectors Provides connectors for power cable, potential
equalization, and interfaces. Used for data
exchange between external devices, additional
components, and networks.

Quick reference guide | Atlan SW 2.0n 9
Overview
1.1.4.2 Version with pin-index connector for suspended gas cylinders
49323
No. Designation Description
1 Storage compartment Can be used as storage space.
2 Holder for hoses and cables Used for storing and winding up central supply
hoses and cables.
3 Gas supply block Provides connectors for gases from the central
gas supply system and for gas cylinders.
4 Hanger yoke system (option) Enables the connection of gas cylinders with a
pin-index connector.
5 Strain relief for compressed gas
hoses
Protects the compressed gas hoses from loos-
ening inadvertently.
6 Vent Discharges warmed air from the device into the
environment.
7 Gas cylinder park holder (option) Can hold an additional gas cylinder.
8 Gas cylinder holder (option) Secures the gas cylinders.
9 Auxiliary power sockets (option) Allow other devices to be connected.
10 Ventilation slot Feeds ambient air to the device for ventilation.
11 Connectors Provides connectors for power cable, potential
equalization, and interfaces. Used for data
exchange between external devices, additional
components, and networks.

10 Quick reference guide | Atlan SW 2.0n
Overview
1.1.5 Connectors
36474
No. Designation Description
1 Serial port (COM 1 and COM 2) This serial port (RS232) supports the MEDI-
BUS.X protocol for data exchange between the
anesthesia machine and external devices.
2 Main switch Turns the device off and minimizes the current
consumption when the power plug is pulled out.
To be used when the device is to be discon-
nected from the power supply for longer than
2 weeks and during service activities.
3 Connector for optional work-
place light
Used for connecting an external workplace light.
4 Power inlet (connector for power
cable)
Used to connect the device to the mains power
supply.
5 Potential equalization pin Used for connecting a potential equalization
cable. This will minimize differences in electrical
potential.
6 Network port Enables data transfer within an IT network.
7 USB port Used to transfer data to a USB mass storage
device.

Quick reference guide | Atlan SW 2.0n 11
Overview
1.1.6 Gas inlets
36475
No. Designation Description
1 Connectors for pressure measur-
ing lines for gas cylinders (option)
Used for connecting the pressure measuring
lines of the pressure reducers on the gas cylin-
ders.
2 Connectors for central gas sup-
ply system
Enable the device to be supplied with gases
from the central supply.
3 Connectors for gas cylinders
(option)
Enable the device to be supplied with gases
from the gas cylinders.
4 Advanced Cylinder Support label
(option)
On devices that are equipped with Advanced
Cylinder Support, the gas cylinder valves can
also remain open during operation with the cen-
tral supply.

12 Quick reference guide | Atlan SW 2.0n
Overview
1.1.7 Gas mixing unit
1.1.7.1 Gas mixing unit (electronically controlled)
The explanation of the symbols can be found on page 42.
44239
No. Designation
1 Status display
2 Symbols for mains power supply and power supply from internal battery
3 Symbols for gas supply (O2, Air, N2O or O2, Air) from central supply and gas cylin-
ders
4O
2flowmeter (for O2insufflation Aux. O2and emergency O2delivery Add. O2)
5 Current time or time for Auto On
6O
2switch (for switching between O2insufflation Aux. O2and emergency O2deliv-
ery Add. O2)
7OutletforO
2insufflation, e.g., for nasal cannula
8 Symbol for programmed Auto On
9 Display of airway pressure in the internal breathing system, see page 7
10 O2+key (O2flush)

Quick reference guide | Atlan SW 2.0n 13
Overview
1.1.7.2 Gas mixing unit (mechanically controlled)
The explanation of the symbols can be found on page 42.
44240
No. Designation
1 Status display
2 Symbols for mains power supply and power supply from internal battery
3 Symbol for programmed Auto On
4 Symbols for gas supply (O2, Air, N2O or O2, Air) from central supply and gas cylin-
ders
5 Current time or time for Auto On
6O
2flowmeter (for O2insufflation Aux. O2) (option)
7OutletforO
2insufflation, e.g., for nasal cannula (option)
8 Flow control valves (O2, Air, N2O or O2, Air)
9 Total flow tube
10 Display of the set fresh-gas flows
11 Display of airway pressure in the internal breathing system, see page 7
12 O2+key (O2flush)

14 Quick reference guide | Atlan SW 2.0n
Overview
1.2 Functional scope
1.2.1 Safety functions
1.2.1.1 Overview
The following table gives an overview of the integrated safety functions which come into
effect if problems occur during operation:
Fault Safety function
Leakage Pressure regulation and PEEP compensation
– In mechanical ventilation modes, the set PEEP is actively
adjusted even in the case of small leaks.
– In pressure-controlled modes, the pressure is controlled
during the entire respiratory cycle.
Mains power supply
failure
Uninterruptible power supply provided by internal battery
– Device runtime in battery operation see Instruction for Use
– Automatic deactivation of the breathing system warmer to
increase battery runtime
Mains power supply
failure and battery dis-
charged
– Manual ventilation and spontaneous breathing are available
– Emergency O2delivery (electronically controlled gas mixer)
– Fresh-gas delivery (mechanically controlled gas mixer)
– Delivery of anesthetic agents via connected vaporizers
Failure of the central
gas supply system
– Use of the connected gas cylinders
Complete failure of
the gas supply
– Mechanical ventilation with ambient air possible (the hose
with the breathing bag will have to be removed for this)
– No anesthetic agent delivery from the connected vaporizers
possible; switch to intravenous anesthetic agent required
Flow measurement
failure
– Mechanical ventilation can be continued.
– Restrictions with regard to displayed measured values, mea-
surement accuracies, and when triggering mandatory
breaths are possible.
Failure of fresh-gas
delivery (electroni-
cally controlled mixer
only)
– Emergency O2delivery
see Instruction for Use
– Anesthetic agent delivery from connected vaporizers possi-
ble
– All ventilation modes are available.
Alternatively:
– Backup manual mode
Ventilator failure – Manual ventilation or spontaneous breathing possible
– Fresh-gas delivery available
– Anesthetic agent delivery from connected vaporizers possi-
ble
Alternatively:
– Backup manual mode
Screen fault (screen
does not respond to
operation or has
failed)
If backup manual mode is activated:
– Manual ventilation or spontaneous breathing possible
– Emergency O2delivery (electronically controlled gas mixer)
or fresh-gas delivery (mechanically controlled gas mixer)
available
– Anesthetic agent delivery from connected vaporizers possi-
ble

Quick reference guide | Atlan SW 2.0n 15
Assembly and preparation
2 Assembly and preparation
The quick reference guide does not replace the instructions for use. Any use of the
medical device requires full understanding and strict observation of the instructions for use.
2.1 Selecting and connecting patient-specific accessories
2.1.1 Fitting the breathing circuit and the filters
The device can be used with Infinity ID breathing hoses or conventional breathing hoses. If
no leakage test has yet been performed after switching on the device, hose compliance and
hose resistance will automatically be adopted when Infinity ID breathing hoses are
connected.
1. Select suitable accessories for the respective patient category.
Complete device fail-
ure
If backup manual mode is activated:
– Manual ventilation or spontaneous breathing possible
– Emergency O2delivery (electronically controlled gas mixer)
or fresh-gas delivery (mechanically controlled gas mixer)
available
– Anesthetic agent delivery from connected vaporizers possi-
ble
Fault Safety function
Adults Pediatric
patients
Neonates
Tidal volume >700 mL 301 to 700 mL 50 to 300 mL <50 mL
Breathing bag 3L 2L 1L 0.5L
Breathing cir-
cuit
Adults Pediatric Neonates
(or pediatric)
Filter Filter or HMEF Use an HME or a
filter with low
resistance and
compliance.
Observe the fol-
lowing informa-
tion: "Permissible
hose configura-
tions", page 16.

16 Quick reference guide | Atlan SW 2.0n
Assembly and preparation
2. Assemble the breathing circuit and connect it to the Y-piece and nozzles on the
breathing system. Observe the following information: "Permissible hose configurations",
page 16.
When attaching or removing the breathing hoses, always hold them by the connection
sleeve and not by the hose itself.
2.1.1.1 Permissible hose configurations
The permissible hose configurations are marked with an "X" in the following table:
35636
Configuration Adult Ped. Neo.
A breathing system filter or an HME filter
between Y-piece and patient; sample line
connected to the filter
XX
One breathing system filter on each of the
inspiratory port and expiratory port; sample
line connected to the Y-piece
XX
– One breathing system filter each on the
inspiratory port and expiratory port; sam-
ple line connected to a connector as
close as possible to the patient
– Extract the sample gas at a connector in
which the gas has laminar flow without
turbulence.
– If no filter can be used at the expiratory
port (e.g., if there is intrinsic PEEP due to
Air trapping), reprocess the breathing
system after every patient.
Perform the reprocessing in accordance
with the reprocessing instructions sup-
plied with the product.
XXX

Quick reference guide | Atlan SW 2.0n 17
Assembly and preparation
When taking a gas sample at a connector
located as close as possible to the patient
– One breathing system filter on the inspi-
ratory port and one on the expiratory port
– Use only heat and moisture exchangers
(HMEs) between the Y-piece and the
patient that are listed in the list of acces-
sories.
– Do not use fine-pored filters or HME fil-
ters between the Y-piece and the patient.
– Set the alarm limits for MV low and Paw
to suitable values. Observe the following
information: "Optimization of the sample
gas quality", page 40.
XX
When using fine-pored filters between the Y-
piece and the patient
– Do not connect the sample line between
the tube and the filter. Instead, connect it
to the filter or the Y-piece.
XX
Configuration Adult Ped. Neo.

18 Quick reference guide | Atlan SW 2.0n
Operating concept
3 Operating concept
The quick reference guide does not replace the instructions for use. Any use of the
medical device requires full understanding and strict observation of the instructions for use.
3.1 Screen
3.1.1 Main screen
The main screen displays the most important information regarding anesthesia and
ventilation.
34746
No. Designation
1 Header bar The header bar shows the following information:
– Patient category
– Patient data
– System information (date, time, device name)
– Alarms, messages, and notifications
– Information regarding temporarily deactivated alarms
2 Main menu bar The main menu bar contains buttons to open dialogs and acti-
vate functions.
These buttons are assigned to various groups.
3 Monitoring area The following information is displayed in the monitoring area:
– Gas measurement
– Waveforms
– Parameter fields
– Loops (Pressure-Volume and Flow-Volume)
– Mini-trends
– Virtual flow tubes
1:35
2
3
4
1

Quick reference guide | Atlan SW 2.0n 19
Operating concept
3.1.2 Dialogs
Dialogs consist of one or more pages which are displayed by touching the corresponding
horizontal or vertical tab.
4 Therapy bar The therapy settings can be adjusted in the therapy bar.
Electronically controlled gas mixer:
– Ventilation modes
– Ventilation parameters
– Fresh-gas delivery
Mechanically controlled gas mixer:
– Ventilation modes
– Ventilation parameters
No. Designation
34766
No. Designation
1 Title of the dialog
2 Button for closing the dialog
3 Vertical tab to open subordinate structures
4 Horizontal tab to open a page
3
12
4

20 Quick reference guide | Atlan SW 2.0n
Operating concept
3.1.3 Therapy bar
The following illustration shows the expanded therapy bar for the electronically controlled
gas mixer:
3.2 Color concept
3.2.1 Colors of the control elements
Colors denote the availability of functions and settings.
3.2.1.1 Therapy controls and buttons
34752
No. Designation
1 Name of active ventilation mode
2 Tabs
3 Notification field
4 Buttons to expand and collapse the therapy bar
5 Field with additional information:
– More values
– Spontaneous breathing activity of the patient
6 Therapy controls for ventilation parameters and buttons for synchronizing the
breaths
7 With electronically controlled gas mixer:
Therapy controls and buttons for fresh-gas delivery
2341
5
4
67
Color Example Meaning
Dark green Available element:
function activated
Yellow Selected element:
not yet confirmed with rotary
knob
Light green Available element:
function not activated
