Dräger Alcotest 7000
Alcohol breath device for mass screening
The Dräger Alcotest® 7000 sets new standards in alcohol test devices. Its
benefits include a wider temperature and measuring range, low maintenance
requirements and various networking options. In addition, the device can
perform alcohol tests via both a mouthpiece and a funnel. Reliable alcohol
tests have never been so fast, simple, hygienic and efficient.
D-22900-2020
2.4" TFT color display
Clear presentation of information,
notices and warnings

Better visibility due to sewn-in
threads


Two testing methods in one
device


Choice of lithium-ion or alkaline
batteries

Secure grip and easy handling
due to rubber coating on sides

Benefits
02 | Dräger Alcotest 7000
Exceptional measurement stability
Some alcohol testing devices must be adjusted every six months. Thanks to its exceptional measurement
stability, Dräger recommends checking accuracy on the Dräger Alcotest® 7000 every 12 months. This saves
time, and above all: money.
Two measurement methods in one device
Alongside the classic test using a mouthpiece, with the Alcotest 7000 you can also carry out tests using a
funnel attachment. This enables you to complete a large number of alcohol tests in a very short span of time,
which is: time-saving, cost-effective and hygienic. The funnel-based test gives you an initial indication as to
whether alcohol is present in the subject's breath. If the answer is yes, you simply press a button to switch
over to the mouthpiece-based test mode. The following test then shows you the actual level of alcohol in the
subject's breath.
Wide temperature range
With the Alcotest 7000 you can take reliable measurements even in extreme temperatures. The alcohol tester's
patented heating system and high-quality materials ensure dependable results in temperatures ranging from
14°F to 131°F
Network-connected solutions
The built-in Bluetooth Low Energy technology offers you energy-saving, digital connectivity for the device and
its data. This has many advantages: For example, the wireless connection of the alcohol tester to the Dräger BT
Mobile Printer enables you to print out test results from a distance of up to 16 yards.
Plus, our "Dräger add" software solution offers you a range of processes, including precise location mapping
and on-site digitization of personal data and test results.
Dräger's Service Connect software enables you to download measurement data and much more. You can also
connect the Alcotest 7000 directly to a computer with a USB-C cable to read out just the test results.
High alcohol-detection limits
The increased performance capacity of the Alcotest 7000 also includes its measurement range. The maximum
blood alcohol limit that can be set with this alcohol testing device is as high as 6%. If this measurement range
limit is exceeded, the display will tell you.

Benefits
Dräger Alcotest 7000 | 03
The Alcotest Hygiene Plus
Hygiene is an increasingly important part of our everyday lives. Dräger Alcotest breath-alcohol detection devices
use non-invasive measuring technologies with a high degree of hygiene – for the user as well as the test
subject – thanks to the following features:
‒ During testing, the exhaled air is directed past rather than through the device
‒ There is a 90° angle between the user and the test subject during testing
‒ Disposable mouthpieces and funnel attachments are individually packaged
‒ Benefits of the Slide ’n’ Click mouthpieces:
– safe, hygienic distance between user and test subject
– spacer prevents direct contact between lips and device
– mouthpiece is easy to remove
– the one-way non-return valve prevents inhalation of air through the mouthpiece
‒ Benefits of the replaceable funnel attachment:
– no body contact with the test subject
– blocks backflow of the test subject's own exhaled air, which prevents intake of potential pathogens from
previous test subjects
Innovation born out of tradition
With more than 65 years of experience, Dräger is a market leader in the field of breath-alcohol testing. Law
enforcement in many countries use devices from the Alcotest product series in everyday traffic monitoring. The
Alcotest 7000 is manufactured in Germany and meets the highest quality standards.

Details
04 | Dräger Alcotest 7000
D-24153-2020
D-24151-2020 D-24144-2020
Mouthpiece receptacle can be mounted
on left or right
The 2.4" color display provides
information, notices and warnings
Fast switchover from funnel-based to
mouthpiece-based testing
D-24152-2020
D-24145-2020 D-24147-2020
Simple push-button print function USB-C port to easily charge the
version with the built-in Li-battery (while
stationary or on the move)
Rubberized handling area for a secure
grip
Accessories
D-25372-2020
Dräger Mobile Printer BT
The Dräger BT Mobile Printer facilitates wireless printing from any
compatible Dräger testing device within a 16-yard radius. You secure
the small, lightweight mobile printer to your belt with a retaining clip.
The OK key to switch the device on and off and the paper-feed button
ensure ease of use. Illuminated symbols provide you with information
about the status of the device.

Accessories
Dräger Alcotest 7000 | 05
D-25676-2020
Alcotest 7000 charging station
The Alcotest 7000 charging station makes it easy to charge the lithium-
ion version as well as connect to a PC. The device's USB-C cable
charges it. The charging station can be fixed in place as required.
D-30594-2017
Hygienic flow funnel
Package unit: 10 pieces, hygienically and individually packaged
ST-178-2004
Mouthpieces (Slide ‘N’ Click)
Available in packs of 100, 250, and 1,000 mouthpieces with or without
one-way non-return valve.
D-30157-2020
Software solution "Dräger add"
Plus, our "Dräger add" software solution offers you a range of
processes, including precise location mapping and on-site digitization of
personal data and test results.

Accessories
06 | Dräger Alcotest 7000
D-25038-2020
Protection options
To protect the device, Dräger offers device protection bags and various
fabric storage bags and transport cases.
Services
D-2331-2016
Product Service
Our product service provides support with different service packages –
in our workshops or directly on your premises. Care, maintenance and
servicing are crucial for safety and reliability – but careful maintenance
and care are a must, even when it comes to commercial considerations.
Preventive checks, ongoing care and use of original replacement parts
improve the longevity of your investment.
D-2335-2016
Training
The Dräger Academy has shared its solid, practical knowledge for over
40 years. We hold more than 2,400 training courses each year, on a
range of over 600 topics, with more than 110 authorized trainers. We
equip your staff with practical knowledge and ensure that what they
learn can be applied effectively, both day-to-day and, more importantly,
whenever critical situations occur. We will be pleased to develop a
customised training program for you.

Services
Dräger Alcotest 7000 | 07
D-2330-2016
Rental Service
From bridging a temporary shortage of equipment to procuring
special equipment for applications involving specific requirements:
If you only need to cover a temporary higher demand, then Dräger
Rental Service with over 65,000 pieces of rental equipment is an
economical alternative to purchasing. Fast, straightforward and with a
wide range of additional services available upon request.
D-2329-2016
Shutdown Safety Service
You need a comprehensive safety technology solution which equips
you optimally for your project. You have to comply with many different
legal requirements – even under intense time pressure. A potential
conflict could arise between maximum efficiency and the highest
possible degree of safety. We help you to establish a balance: Our
Shutdown Safety Service is a solution which takes into account all of the
requirements for a shutdown, and your individual needs in particular.
D-2332-2016
On-site Safety Service
Rental shop, personnel services or comprehensive safety management:
Our on-site safety services provide you with support for all projects
involving special safety challenges – and of course also during your
day-to-day operations.

Related Products
08 | Dräger Alcotest 7000
D-31888-2020
Dräger Alcotest® 5000
The Dräger Alcotest® 5000 is a highly reliable breath-alcohol tester
that detects the presence of alcohol. This high-speed breathalyzer lets
you perform up to 12 tests per minute. Its special non-contact funnel
reduces the back-flow of expired air to a minimum, preventing the risk of
infection to subsequent test subjects.
D-32068-2020
Dräger Alcotest® 6000
The Dräger Alcotest® 6000 allows the professional user to perform
a breath alcohol test with speed and precision. The measuring
technology of this small and user-friendly portable measuring device
has already been proven worldwide and has been sold over 1,000,000
times.
D-20003-2015
Dräger DrugCheck 3000
Use the Dräger DrugCheck 3000 to find out within minutes if a person
has recently consumed certain drugs. The compact and quick oral fluid-
based drug test yields reliable results hygienically and easily. The device
does not require electricity and can be used anywhere. FOR LAW
ENFORCEMENT USE ONLY.
D-54720-2012
Dräger DrugTest 5000
The Dräger DrugTest 5000 system is a fast, accurate means of
testing oral fluid samples for drugs of abuse, such as amphetamines,
methamphetamine, opiates, cocaine and metabolites, benzodiazepines,
cannabinoids, and methadone. The analyzer offers easy data
management with the Dräger Diagnostics Software. FOR LAW
ENFORCEMENT USE ONLY.

Technical Data
Dräger Alcotest 7000 | 09
Dräger Alcotest 7000
Detection basis Electrochemical DrägerSensor®, 1/4" technology, alcohol-specific
Measurement range Breath alcohol concentration: 0 to 0.63 % BrAC
(Ethanol mass per minimum volume at 93 °F and 1,013 hPa)
Visual signal when measuring limits are exceeded
Sample collection Default: Automatic sample collection when minimum volume or
predefined blowing time is reached;
Passive sampling or manual triggering of sampling possible
Start-up time Approx. 3 seconds after switching on (depending on
configuration)
Display of test results After approx. 3 seconds at 0.0 % BrAC
After approx. 10 seconds at 0.1 %BrAC
Ambient operating conditions +14 °F to +131 °F; 10 to 100 % relative humidity
(non condensing); 600 to 1,300 hPa
Ambient conditions during storage -4 °F to +140 °F; 15 to 75 % relative humidity
(10 to 100% relative humidity <48 h); 600 to 1,300 hPa
Display QVGA TFT color display 320 x 240 2.4"
LEDs tricolor LEDs to help display results and warning messages
Acoustic signals Various signal tones to support display and warning messages
Memory Store the last 10,000 tests (software can be modified on request
to offer even more storage space)
Energy supply Lithium battery version (rechargeable via USB-C) or alkaline
version (3 x 1.5 V alkaline or 3x NiMH or 3x lithium primary cell
(Mignon, LR06, AA)).
Charge status shown in display; one charge/battery change is
sufficient for up to 5,000 breath tests (lithium version) or up to
1,500 breath tests (alkaline version).
Mouthpiece receptacle The Slide ’n’ Click mouthpiece or Alcotest funnel mounts on either
side
Mouthpiece Hygienic, individually packaged with tamper-proof, non-closing air
outlet
Mouthpiece ejector and spacer between mouth and device
housing
Funnel Hygienic, individually packaged with air outlets for minimizing
back-flow of expired air
Operating design Measuring functions can be performed with one button;
Navigation in menu with two menu buttons
Test for accuracy Recommended interval of 12 months
Wet gas or dry gas calibration;
Casing Impact-resistant ASA/PC
Dimensions (W x H x D), Weight (including batteries) 2.4 in x 6.8 in x 1.4 in
A7000 Li: 9.7 oz
A7000 AA: 10.1 oz
Vibration and impact resistance EN 60068-2-27, EN 60068-2-6; EN 60068-2-64
CE mark Electromagnetic compatibility
Standards EN 15964, NHTSA, Australian Standard, FDA conformity,
depending on configuration
Internal clock Warning or switch-off after expiration of calibration period
(depending on configuration)
IP protection class IP 54
Interface USB-C
Bluetooth®Bluetooth® Low Energy 5.0

Technical Data
10 | Dräger Alcotest 7000
Not all products, features, or services are for sale in all countries.
Mentioned Trademarks are only registered in certain countries and not necessarily in the country
in which this material is released. Go to www.draeger.com/trademarks to find the current status.
CORPORATE HEADQUARTERS
Drägerwerk AG & Co. KGaA
Moislinger Allee 53–55
23558 Lübeck, Germany
www.draeger.com
USA
Draeger, Inc.
7256 S. Sam Houston Parkway W.,
Suite 100
Houston, TX 77085
1 800 4DRAGER
(1 800 437 2437)
.
Locate your Regional
Sales Representative at:
www.draeger.com/contact
91 09 781 | 22.03-3 | HQ | PP | Subject to modifications | © 2022 Drägerwerk AG & Co. KGaA
GPS Optional
Ordering Information
Dräger Alcotest 7000 – Configuration tool 37 00 398
Dräger Alcotest 7000 – Standard configuration
Testing device with built-in lithium battery and Bluetooth 3
mouthpieces, wrist strap, USB-C cable, calibration certificate, no
GPS, no NFC.
37 00 400
Dräger Alcotest 7000 charging cradle 37 00 420
Dräger Bluetooth mobile printer 37 00 421
Mouthpieces – package of 250 68 10 825
Mouthpieces – package of 1,000 68 10 830
Mouthpiece with one-way/non-return valve – package of 100 68 11 055
Mouthpiece with one-way/non-return valve – package of 250 68 11 060
Mouthpiece with one-way/non-return valve – package of 1,000 68 11 065
Hygienic flow funnel, package of 10; individually, hygienically
packed
83 27 718
NiMH battery (AA, 1.2 V rechargeable) – 3 batteries required,
batteries must be charged outside the unit
44 01 006
Lithium primary battery (AA, 1.5 V) – 3 batteries required 37 00 481
