Dräger Alcotest 4000 User manual

i
Dräger Alcotest® 4000
WARNING
Strictly follow the Instructions for Use.
The user must fully understand and strictly observe the instructions.
Use the product only for the purposes specified in the Intended use
section of this document.
!
enUS Instructions for use
3
es Instrucciones de uso
18

2
8
6
7
4
9
1
5
4
3
2
00100211.ai
10
11
12

Safety-related information
3
en
1 Safety-related information
Before using this product, carefully read these instructions for use and those
of the associated products.
Strictly follow the instructions for use. The user must fully understand and
strictly observe the instructions. Use the product only for the purposes
specified in the intended use section of this document.
Do not dispose of the instructions for use. Ensure that they are retained and
appropriately used by the product user.
Comply with all local and national rules and regulations associated with this
product.
Only trained and competent personnel are permitted to inspect, repair and
service the product. Dräger recommend a Dräger service contract for all
maintenance activities and that all repairs are carried out by Dräger.
Do not use a faulty or incomplete product. Do not modify the product.
Notify Dräger in the event of any component fault or failure.
Use only genuine Dräger spare parts and accessories. Otherwise, the
proper functioning of the product may be impaired.
These instructions for use can be downloaded in other languages in
electronic form on the relevant product page (www.draeger.com/ifu) or a
free printed copy can be obtained from Dräger or the distributor.
Only use battery chargers, power packs, batteries, or rechargeable batteries that
Dräger has approved for this product.
2 Conventions used in this document
2.1 Meaning of alert icons
The following alert icons are used in this document to notify the user of possible
dangers. The meanings of the alert icons are defined as follows:
WARNING
Indicates a potentially hazardous situation. If not avoided, it could result in death
or serious injury.

Description
4
en
CAUTION
Indicates a potentially hazardous situation. If not avoided, it could result in
physical injury. It may also be used to alert against unsafe practices.
NOTICE
Indicates a potentially hazardous situation. If not avoided, it could result in
damage to the product or environment.
2.2 Typographical conventions
This symbol indicates information that may make the use of this product
easier.
3 Description
3.1 Product overview (see Page 2)
1 Breath-alcohol analyzer
2LED ring
3Button
4 Grip zone on mouthpiece
5 Mouthpiece
6 Safety cap
7 Mouthpiece receptacle
8 Display
9 USB connection (Important: Not for charging the device, for service only)
10 Battery compartment cover
11 Battery
12 Loudspeaker (Important: No reset button)
3.2 Intended use
The Dräger Alcotest® 40001) breath-alcohol analyzer is used to measure the
alcohol concentration in human breath. The measurement should not be used as
grounds for medical or therapeutic treatments.
Text Text in bold refers to labeling on the instrument and screen text.
►This triangle indicates options for avoiding the hazard in warnings.
1) Alcotest® is a registered trademark of Dräger.

Use
5
en
4Use
WARNING
Small parts of the instrument may become detached and be swallowed.
► The instrument is not intended for children under 3 years.
4.1 Prerequisites for use
The instrument is factory-calibrated when delivered. If the calibration date is
longer ago than 12 months, the instrument should be calibrated, e.g., by
DrägerService.
Optional: If the calibration date has been exceeded, a warning message is
displayed after the startup screen. Confirm the warning message with a short
press on the button or wait some seconds to continue.
Observe a wait time of approx. 15 minutes after last alcohol consumption.
The wait time cannot be reduced by rinsing the mouth with water or with
non-alcoholic beverages.
Residual mouth alcohol or aromatic beverages (e.g., fruit juice), alcoholic
mouth sprays, medication and drops, as well as belching and vomiting may
cause incorrect measuring values.
4.1.1 Before sampling
The subject must breathe regularly and calmly before sampling.
The subject must be able to provide the required minimum breath volume
for the sampling.
4.1.2 Preparation for use
1. Ensure that the batteries are charged and inserted.
2. Ensure that a clean mouthpiece is attached.
4.1.3 Switching the instrument on and off
Switching the instrument on:
1. Hold down the button for about 1 second.
2. Wait until the instrument displays that it is ready to measure.

Use
6
en
Switching the instrument off:
1. Hold down the button for about 3 seconds.
A switch off count down will be shown as well. If the display is off, stop
pressing the button. Otherwise the device will be switched on again.
The instrument will switch off automatically approx. 2 minutes after the last
use.
Switching off the instrument does not reduce the waiting period until it is
ready to take a measurement!
4.2 Initial start-up
4.2.1 Default wizard
A setup wizard starts when the instrument is switched on for the first time. This
step is not required for pre-configured instruments.
The following settings are made using the setup wizard:
Language
Date format
Date
Time format
Time
Measuring unit
All settings can be changed later on via the menu.
Language
A cursor pre-selects one language in the list. Press briefly on the button to
change the position of the cursor in order to select your needed language. If the
cursor selects the right language please hold the button for approx. 2 seconds to
confirm.
Date
A cursor pre-selects the day of the date. Press briefly on the button to change
the day until the actual day is shown. Please hold the button for approx.
2 seconds to confirm the day. Please continue with the month and the year in the
same way: short press to change and long press to confirm.

Use
7
en
Time format
A cursor pre-selects a time format. Press briefly on the button to change the
position of the cursor in order to select your needed time format. If the cursor
selects the needed time format please hold the button for approx. 2 seconds to
confirm.
Time
A cursor pre-selects the hours of the time. Press briefly on the button to change
the hour until the actual hour is shown. Please hold the button for approx.
2 seconds to confirm the hour. Please continue with the minutes in the same
way: short press to change and long press to confirm.
Measurement unit
A cursor pre-selects a measurement unit in the list. Press briefly on the button to
change the position of the cursor in order to select your needed measurement
unit. If the cursor selects the needed measurement unit, please hold the button
for approx. 2 seconds to confirm.
After the setup wizard is finished, the display shows Welcome and continues with
READY for tests.
The Alcotest® 4000 is now adjusted to your settings and is ready for breath tests.
Of course these and further settings can be adjusted in the device menu (see
Section 4.6 on Page 9).
NOTICE
Loss of default settings
If the battery replacement process takes longer than 5 minutes, the date and
time must be reset. A measurement is only possible with the time set.
4.3 Carrying out a breath sample
A new mouthpiece must be inserted for each person who provides a breath
test.
For hygiene reasons, hold the mouthpiece only on the grip zones.
Do not allow any high alcohol concentrations on the sensor, e.g., by rinsing
the mouth with a high proof alcohol shortly before the measurement, as this
will shorten the service life of the sensor.

Use
8
en
Procedure
1. Remove the safety cap from the top of the device.
2. Insert a new mouthpiece (order no. 83 25 250) into the mouthpiece
receptacle (see Page 2).
For hygiene reasons, hold the mouthpiece only on the grip zones.
3. If the device is switched off. keep the button pressed for approx. 1 second
until the startup screen is displayed.
4. READY is displayed after approx. 4 seconds. The instrument is ready to
measure.
5. Take a deep breath and blow evenly and without interruptions into the
mouthpiece.
Do not cover the outlet opening on the mouthpiece with your hand.
You have to blow a volume of 1.2 liter and at least 1.6 seconds for a valid
test. If blowing normally this will take 2-3 seconds. A continuous tone
sounds simultaneously and stops when the test parameters are fulfilled and
the device has taken the sample.
The test result is displayed after a few seconds (depending on the
instrument temperature and the measured concentration).
In case of a negative alcohol test, 0.00 will be displayed. In case of a positive
test, the measured alcohol level will be displayed.
Carry out another measurement
To prepare a new measurement, press the button briefly.
After the sensor’s recovery time (see "Technical data" on Page 15), READY
is displayed and the device is ready to use again.
4.4 Removing the mouthpiece
1. Pull the mouthpiece upwards out of the mouthpiece receptacle by holding it
on the grip zones on the left and on the right side.
2. Dispose of the mouthpiece in accordance with local regulations.
4.5 Menu control
To enter the device menu, the device has to be switched on and it has to show
READY.
Displaying the menu:
1. Briefly press the button. A menu symbol and the text Enter menu are
displayed.
If the button is not pressed for 3 seconds, the instrument will return to
READY.

Use
9
en
2. Briefly press the button again (within 3 seconds). The menu is entered. If the
button is not pressed a second time, the instrument will return to READY.
The menu is exited automatically after 30 seconds with the button not being
pressed.
In the main menu all menu options are listed one below the other. To select a
menu option, mark the respective menu option with the cursor by briefly pressing
the button several times to toggle through the menu until the cursor is at the
intended position. Afterwards hold the button for 2 seconds to enter the
submenu.
Navigating in the menu:
Tap the button.
When the last entry is reached, the next button press will go back up to the
top.
Confirming the selected feature or input:
Keep the button pressed.
Exiting the menu:
In the sub-menu, select the Back menu item.
In the main menu, select the Measuring menu item.
Changing values:
1. Tap the button until you reach the required setting.
Hold the button down to confirm the setting.
4.6 Menu items
The following table provides an overview of the menu options and how to use
them:
Menu option Description Interaction instruction
Measuring Option to leave the menu
and to go back to the READY
screen to perform a test.
Hold the button for
2 seconds to leave the
menu.

Use
10
en
Bluetooth®
(optional) Menu option to switch Bluetooth® on or off.
Confirm Bluetooth® ON or
OFF with the button.
The instrument is set up for connection to an app via
Bluetooth®.
An active Bluetooth® connection is displayed by a
corresponding symbol in the display.
Bluetooth® must not be selected in aircraft.
Results Overview of the last 10 tests
performed on the device
(incl. result, date, time, test
ID). There is one test
displayed per screen.
Briefly press the button to
navigate through the test
result list.
Hold the button for
2 seconds to leave the
submenu.
Infoscreen Serial no and part no of the
device
Hold the button for
2 seconds to leave the
submenu.
Next service Overview, in how many days
the device...
should get serviced,
should be adjusted
and should get an
accuracy check.
Hold the button for
2 seconds to leave the
submenu.
Menu option Description Interaction instruction

Use
11
en
Date & time Date, time as well as date
format (yyyy/mm/dd, yyyy-
mm-dd, mm/dd/yyyy,
dd.mm.yyyy) and time format
(12h, 24h) can be adjusted.
The submenu can be left via
the Back option.
Select an option by
moving the cursor to the
option by briefly pressing
the button. Afterwards,
enter this option by
holding the button for
2 seconds.
Change a setting or a set
number by briefly
pressing the button (e.g.
shifting the time).
Confirm a selection by
holding the button for
2 seconds.
Select the Back option
and hold the button for
2 seconds to leave the
submenu.
Contrast The display contrast can be
adjusted within 5 levels.
Change the setting by
briefly pressing the
button.
Hold the button for
2 seconds to confirm the
setting and leave the
submenu.
Speaker Any acoustical signals of the
device can be turned off or to
a volume of 50 % or 100 %.
Change the setting by
briefly pressing the
button.
Hold the button for
2 seconds to confirm the
setting and leave the
submenu.
Menu option Description Interaction instruction

Troubleshooting
12
en
5 Troubleshooting
A status message is displayed in the event of certain instrument conditions. The
number that appears below the message is used for service functions. If the
status message remains after switching the instrument on and off several times,
contact DrägerService or your dealer.
Language The language of the display
can be adjusted.
Change the set language
by briefly pressing the
button.
Hold the button for
2 seconds to confirm the
setting and leave the
submenu.
Measurement
unit The measurement unit for the alcohol test results can
be adjusted within the
following options: %, ‰, g/L,
mg/100 mL, mg%, mg/mL,
mg/L, μg/100 mL, μg%, μg/L,
g/210 L
Change the measurement
unit by briefly pressing the
button.
Hold the button for
2 seconds to confirm the
setting and leave the
submenu.
Software
version Software version and part number are displayed.
Hold the button for
2 seconds to leave the
submenu.
Fault/message Cause Remedy
The instrument cannot
be switched on. Battery drained. Replace battery.
Volume too low /
sample invalid. Test subject is blowing intermittently or not hard
enough.
Blow into the mouthpiece
harder and continuously.
Instrument outside
temperature range Instrument is too hot or too cold. Allow the instrument to cool down or warm up.
Menu option Description Interaction instruction

Maintenance
13
en
6 Maintenance
6.1 Replacing the battery
1. Switch off the instrument.
2. Slide the battery cover off.
3. Replace the battery (battery type: 3 V CR123A; order no.: 83 21 390). Pay
attention to the correct polarity.
4. Fit the battery cover.
5. Check that the time is correctly set.
If the battery replacement process takes longer than 5 minutes, the time
must be reset. A measurement is only possible with the time set.
↑↑↑
(over range) Measuring range exceeded. Alcohol
residues that are still in the
mouth may cause
incorrect measuring
values.
A wait time of at least
15 minutes after alcohol
was last orally consumed
must have elapsed. (see
Page 7).
To repeat test, press the
button.
Volume too small Breath sample volume too
small. Repeat breath sample.
Volume too great Measuring range
exceeded. Repeat breath sample.
Sample interruption Irregular exhalation,
abrupt end, or inhalation Repeat breath sample.
Fault number Instrument fault Switch the instrument off
and on again. If the fault
remains, contact
DrägerService or dealer.
… DAYS
Until next service! In … days next service is needed. Contact DrägerService or dealer for device service.
... DAYS
Service expired! Since … days service is needed. Contact DrägerService or dealer for device service.
Fault/message Cause Remedy

Maintenance
14
en
CAUTION
Damage to the instrument.
Do not try to charge any kinds of batteries via the USB port. The instrument
comes without a recharging function.
Recharge any rechargeable batteries outside the instrument.
6.2 Cleaning
The instrument should be cleaned with an ethanol-based cleaning agent.
Cleaning the instrument:
1. Wipe the instrument down with a disposable cloth with the cleaning agent.
Do not apply the cleaning agent directly to the instrument.
Ensure that no liquid enters the gas inlet.
2. After cleaning the instrument, store it unpacked at room temperature (20-
25 °C) for at least 24 hours.
3. Afterward, carry out an alcohol-free breath alcohol test to ensure that no
ethanol residue remains in the instrument and the result "0.00" is displayed.
6.3 Calibration
Dräger recommends to check device accuracy every 12 months. Instrument
calibration and maintenance should only be carried out by authorized persons,
e.g. DrägerService.
The last 30 days before next service is needed, a day count down will be shown
as information in the display after switching on the device. Please confirm this
information with the button. It shall remind you that the device needs to be
serviced in the next days. After the service date, the device counts up how many
days it is over the requested service. This information can be confirmed by
pressing the button as well.

Disposal
15
en
7 Disposal
8 Technical data
This product must not be disposed of as household waste. This is
indicated by the adjacent symbol. You can return this product to
Dräger free of charge. For more information please contact the
national marketing organizations or Dräger.
It is not permitted for batteries to be disposed of as household waste.
This is indicated by the adjacent symbol. Collect and dispose of
batteries and rechargeable batteries at battery collection centers in
accordance with applicable regulations.
Measuring principle
Electrochemical sensor
Measuring range
Breath alcohol concentration 0.000 to 0.500 g/210L
Blood alcohol concentration 0.000 to 0.500 % BAC
Small values will be shown as
0.000 0.000 to 0.0063 g/210L
Ethanol mass per blood volume or mass at 20 °C / 68 °F and 1013 hPa.
For the above data, a conversion factor of 2100:1 is used to calculate the blood
alcohol concentration using the breath alcohol concentration data.
Units of measurement
mg/L, µg/100 mL, µg%, µg/L, g/210 L, g/l ‰, %, mg/100 mL, mg%, mg/mL
(country-specific configuration)
Ambient conditions
During operation –5 to +50 °C (+23 to +122 °C)
10 to 100 % r. h. (non-condensing)
600 to 1300 hPa
During storage –20 to +60 °C (–4 to +140 °F)
15 to 75 % r. h. (10 to 100 % r. h. <48 h)

Technical data
16
en
Taking samples
Respiratory volume >1.2 L (default)
Breath flow >10 L/min (default)
Duration of breath >1.6 s (default)
Measurement accuracy
Standard deviation of the repeatability with ethyl alcohol standard
<0.100 % BAC
≥0.100 % BAC
<0.50 mg/L
≥0.50 mg/L
0.0017 % BAC or
1.7 % of the measured value
whichever value is higher
0.008 mg/L
1.7 % of the measured value
Wait time for measurement readiness following a previous
measurement with:
0.25 mg/L 20 s
0.50 mg/L 40 s
1.00 mg/L 80 s
>1.50 mg/L 120 s
0.050 % 20 s
0.100 % 40 s
0.200 % 80 s
>0.300 % 120 s
Test for accuracy
Recommendation: every 12 months
Dimensions
50 mm x 133 mm x 29 mm (W x H x D)
1.97 in x 5.27 in x 1.14 in (W x H x D)
Weight
approx. 4.6 oz (130 g)
Power supply
1 x 3 V CR123A
The batteries are designed for up to 1500 measurements (depending on use and
the ambient conditions).

Technical data
17
en
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Protection class
IP 52
Interface
USB connection for service only
CE markings
Electromagnetic compatibility
Configuration possible, see name plate

Información relacionada con la seguridad
18
es
1 Información relacionada con la seguridad
Antes de utilizar el producto, leer atentamente estas instrucciones de uso,
así como las de los productos correspondientes.
Observar exactamente las instrucciones de uso. El usuario debe
comprender íntegramente las instrucciones y cumplirlas estrictamente. El
producto debe utilizarse exclusivamente conforme a los fines de uso
previstos.
No eliminar las instrucciones de uso. Se debe garantizar que los usuarios
guarden y usen las instrucciones correctamente.
Observar las directrices locales y nacionales aplicables a este producto.
Solo personal especializado y formado debe comprobar, reparar y
mantener el producto. Dräger recomienda cerrar un contrato de
mantenimiento con Dräger y que todos los trabajos de mantenimiento sean
realizados por Dräger.
No utilizar productos defectuosos o incompletos. No realizar modificación
alguna en el producto.
Informar a Dräger si se produjeran fallos o averías en el producto o en
componentes del mismo.
Utilizar únicamente piezas y accesorios originales de Dräger para realizar
los trabajos de mantenimiento. De lo contrario, el funcionamiento correcto
del producto podría verse mermado.
Estas instrucciones de uso se pueden descargar en diferentes idiomas en
formato electrónico a través de la página de producto correspondiente
(www.draeger.com/ifu) o recibir en ejemplar impreso a través de Dräger o
un distribuidor autorizado.
Utilizar única y exclusivamente cargadores, unidades de suministro, pilas o
baterías autorizados por Dräger para este producto.
2 Convenciones en este documento
2.1 Significado de los símbolos de advertencia
En este documento se utilizan los siguientes símbolos de advertencia, para
advertir al usuario acerca de los posibles peligros. El significado de los símbolos
de advertencia se define a continuación:

Descripción
19
es
ADVERTENCIA
Advertencia de una situación potencialmente peligrosa. En caso de no evitarse,
pueden sufrirse lesiones graves e incluso mortales.
PRECAUCIÓN
Advertencia de una situación potencialmente peligrosa. En caso de no evitarse
pueden producirse lesiones. Puede utilizarse también para advertir acerca de
un uso incorrecto.
AVISO
Advertencia de una situación potencialmente peligrosa. En caso de no evitarse,
pueden producirse daños en el producto o en el medio ambiente.
2.2 Convenciones tipográficas
Este símbolo identifica información que facilita el uso del producto.
3 Descripción
3.1 Vista general del producto (véase página 2)
1 Analizador de alcohol en el aliento
2Aro de LED
3 Botón
4 Zona de agarre de la boquilla
5 Boquilla
6 Tapa de seguridad
7 Alojamiento de boquilla
8 Pantalla
9 Conexión USB (Importante: no para cargar el equipo, únicamente para el
servicio)
10 Cubierta del compartimento de la pila
Texto Los textos escritos en negrita señalizan rótulos en el dispositivo
y textos de pantalla.
►En las advertencias, este triángulo indica qué posibles
acciones se pueden llevar a cabo para evitar el peligro.

Uso
20
es
11 Pila
12 Altavoz (Importante: sin botón de reinicio)
3.2 Uso previsto
El Dräger Alcotest® 40001) sirve para medir la concentración de alcohol en el
aire espirado. La medición no debe servir de base para tratamientos médicos o
terapéuticos.
4Uso
ADVERTENCIA
Las piezas pequeñas del aparato podrían desprenderse y suponer riesgo de
asfixia.
► El aparato no está indicado para niños menores de 3 años.
4.1 Requisitos
El instrumento es suministrado en estado calibrado. Si han transcurrido más de
12 meses desde la última calibración, el dispositivo deberá calibrarse, por
ejemplo, por parte de DrägerService.
Opcional: Se se ha superado la fecha den calibración, en la pantalla de inicio se
muestra un mensaje de advertencia. Confirmar el mensaje de advertencia
pulsando brevemente el botón o esperar unos segundos para continuar.
Esperar aprox. 15 minutos después de haber tomado la última bebida
alcohólica.
El plazo de espera no puede reducirse enjuagándose la boca con agua o
bebidas no alcohólicas.
Las cantidades residuales de alcohol o las bebidas aromatizadas (p. ej.,
zumo de fruta), los aerosoles alcohólicos para la boca, los medicamentos o
gotas, así como consecuencias de eructos o vómitos pueden falsear los
resultados de la medición.
4.1.1 Antes de la toma de muestras
La persona objeto de la prueba debe respirar con normalidad y tranquilidad
antes de la toma de muestras.
La persona objeto de la prueba tiene que estar en condiciones de
proporcionar el volumen de aire espirado mínimo requerido.
1) Alcotest® es una marca registrada propiedad de Dräger.
