DRAGONFIRE 16-1805 User manual

DragonFire
DragonFire Racing
3191 N Washington St. Suite 2
Chandler, AZ 85225
1 [phone]
http://www.DragonFireRacing.com
Trailing Arm DragonScales
Part # 16-1805 Trailing Arm Guard Black
Part # 16-1806 Trailing Arm Guard Silver
Fits Polaris RZR XP 1000 & Polaris RZR RS1
Trailing Arm Guard Skid Plate Kit 16-1807 Sold Separately
Congratulations on your purchase of the DragonFire Trailing Arm DragonScales Now you can ride in Style, while also protecting
your Trailing Arms. Be sure to check out the full line of DragonFire Accessories for your Polaris vehicle at your local authorized
dealer or online at http://www.DragonFireRacing.com
Disclaimer
Off road activities can be hazardous and could lead to injury, dismemberment, paralysis and death. No warranty
of representation is made as to the products ability to protect the user from any injury or death. The user assumes
that risk. The acceptance and /or use of this merchandise purchased from DragonFire by the customer hereby
shall release DragonFire from any and all liability pertaining to the use of such merchandise.
Step 1: Place vehicle on a at and level surface. Place gear selector in “Park” and remove keys from the ignition.
Step 2: Lift the rear end of the vehicle with a hydraulic jack until both rear tires are off the ground (Figure A). Place two jack stands under
neath the vehicle (Figure B). View the Vehicle Manual for recommended points to place the jack, and jack stands.
Step 3: Remove the Sway Bar Bolt using a 15mm Socket, and the Shock Mount Bolt using the 18mm Socket (Figure C). Retain hardware as
it will be re-used in a later step.
Note: You may have to apply slight upward pressure on the Trailing Arm to get the Shock Mount Bolt out.
• Read and understand these instructions before installing product
• This product does not provide roll over protection
• Do not use product if there are any signs of damage
Tools Required
Hydraulic Jack
Jack stands
Torque Wrench
Socket Wrench
18 mm Socket
15 mm Socket

DragonFire
Step 4: Identify the Left & Right Trailing Arm Guard. The Dragon Head should be facing the outside of the Trailing Arm (Figure D).
Step 5: Slide the Guard onto the Trailing Arm, and line up both of the holes evenly (Figure E)
Step 6: Re-install the Factory Hardware and tighten with a Socket Wrench. Using a Torque Wrench, Torque hardware to Factory Specications.
Note: You may have to apply slight upward pressure on the Trailing Arm to get the Shock Mount Bolt in.
Note: Figure F shows how the Trailing Arm Guard should look if installed correctly.
ProTip: Periodically check all hardware and re-tighten if needed.
For further assistance please contact us at
customerservice@dragonreracing.com, or by phone at
1-800-708-9803.
