DRAGONFIRE DFR-5TMWM-B User manual

Door Panel & Slammer Kit for XP1K
Can-Am Maverick Winch Mount Kit
Part # DFR-5TMWM-B Can-Am Maverick Black
Congratulations on your purchase of the DragonFire Winch Mount Kit for the Can-Am Maverick. Designed to work
with the DragonFire RacePace Front bumper, this mounting kit gives you the functionality of a winch with the rugged
and race ready appearance that only DragonFire can. Check out additional products at your local authorized
DragonFire dealer or on our website http://www.DragonFireRacing.com
DFR-5TMWM is designed for mounting the Warn Vantage 3000 and similar sized winches.
This product requires the use of the DragonFire RacePace Front Bumper.
•Read and understand these instructions before installing product
•Follow instructions with winch for best practices
•Do not use product if there is any sign of damage
Disclaimer
Off road activities can be hazardous and could lead to injury, dismemberment, paralysis and death. No warranty
of representation is made as to the products ability to protect the user from any injury or death. The user
assumes that risk. The acceptance and /or use of this merchandise purchased from DragonFire by the
customer hereby shall release DragonFire from any and all liability pertaining to the use of such merchandise.
Step 1: Place vehicle on a flat and level surface. Place gear
selector in park and remove keys from the ignition.
Step 2: Remove grill plate from DragonFire RacePace front
bumper, retaining the nuts for reuse. (Figure A)
Step 3: Remove the mounting hardware and take factory front
bumper off of vehicle per RacePace front bumper instructions.
Retain the factory bolts on the upper mount. If removing a
DragonFire RacePace bumper, also retain the nuts and washers
on the lower mounts.
Tools Required
3/16 Allen Wrench
8mm Allen Wrench
Ratchet & 6” extension
1/2” Socket & Wrench
9/16” Socket & Wrench
13mm Socket & Wrench
10mm Socket
17mm Wrench
DragonFire Racing
3191 N. Washington St. Suite 2
Chandler, AZ 85225
1 [phone]
WWW.DRAGONFIRERACING.COM
Dragonfire Racing

Step 4: Remove J-nut clips from upper bumper mount tabs on
vehicle. These will not be reused. (Figure B)
Step 5: Attach winch to the mounting plate, centered with back
side of the winch even with the back edge of the plate. (Figure C)
Tighten hardware to the winch manufacturer’s specifications.
Step 6: Rest the winch and winch mount plate on RacePace
bumper. The mounting ears should sit between the lower
mounting tabs on the bumper and also resting on the square tube.
Step 7: *This step may require assistance from a second
person.* Lift the front bumper and winch mount together and
place on the front of the vehicle. Place the factory upper bumper
mounting bolts in the upper mounts to hold the bumper, and
secure each with a nut and washer provided with the DragonFire
Winch Mount kit. (Figure D) Leave hardware loose.
Step 8: Align lower mounts and attach with 1-1/4” long hex bolts
and washers provided with DragonFire Winch Mount kit. Secure
with nuts and washers from RacePace Front Bumper hardware kit.
Leave hardware loose.
Step 9: Place fairlead plate on the bumper and secure with 4 new
screws, washers (2 per screw) and reuse the 4 nuts removed from
the front bumper grill plate in step 2. Align and tighten to 11 ft-lbs
(132 in-lbs).
Step 10: Install the 2 remaining screws into the bottom of fairlead
plate with washers and nuts. Torque to 11 ft-lbs (132 in-lbs).
(Figure E)
Step 11: Align front bumper and tighten upper and lower
fasteners. Upper mounts torque to 16 ft-lbs and lower mounts to
47 ft-lbs.
Step 12: Install fairlead supplied with the winch per
manufacturer’s specifications. (Figure F)
Step 13: This completes the installation process. Time to ride
and enjoy!
ProTip: Periodically check all hardware and re-tighten if
needed.
For further assistance please contact your authorized DragonFire dealer
